Toyota Hilux (2017 year). Manual - part 84

343

4

4-5. Using the driving support systems

D

riv

in

g

Stop & Start system (Smart Stop)

∗

■

Stopping the engine

X

Vehicles with automatic
transmission

While driving in D or S, depress
the brake pedal, and stop the
vehicle.

The Stop & Start indicator will
come on.

X

Vehicles with manual trans-
mission

Stop the vehicle With the clutch pedal fully depressed, shift the shift
lever to N, and release the clutch pedal.

The Stop & Start indicator will come on.

■

Restarting the engine

X

Vehicles with automatic transmission

Release the brake pedal.

The Stop & Start indicator will go off.

X

Vehicles with manual transmission

Check that the shift lever is in N and depress the clutch pedal.

The Stop & Start indicator will go off.

∗

: If equipped

The Stop & Start system stops and restarts the engine according
to the brake pedal operation (automatic transmission) or clutch
pedal operation (manual transmission) for stopping and starting
the vehicle.

Stop & Start system operation

344

4-5. Using the driving support systems

Press the Stop & Start cancel
switch to disable the Stop & Start
system.

The Stop & Start cancel indicator
will come on.
Press the switch again to re-enable
the Stop & Start system.

■

Automatic reactivation of the Stop & Start system
Even if the Stop & Start system is disabled by the Stop & Start can-
cel switch, it will be automatically re-enabled once the engine
switch is turned to the “LOCK” position (vehicles without smart
entry & start system) or off (vehicles with smart entry & start sys-
tem), and then the engine is started.

■

If the Stop & Start cancel switch is pressed while the vehicle is
stopped
● When the engine is stopped by the Stop & Start system, pressing

the Stop & Start cancel switch will restart the engine.
From the next time the vehicle is stopped (after Stop & Start sys-
tem has been turned off), the engine will not be stopped.

● With the Stop & Start system disabled, pressing the Stop & Start

cancel switch will re-enable the system but not stop the engine.
From the next time the vehicle is stopped (after Stop & Start sys-
tem has been turned on), the engine will be stopped.

Disabling the Stop & Start system

345

4-5. Using the driving support systems

4

D

riv

in

g

After the engine is stopped by the Stop & Start system when the vehi-
cle is on an incline, brake force is temporarily maintained to prevent
rolling backwards until the engine is restarted and drive force is gener-
ated. When drive force is generated, the maintained brake force is
automatically canceled.
● This system operates on flat surfaces as well as steep grades.
● Sound may be generated by the brakes, but this is not a malfunc-

tion.

● The brake pedal response may change and vibration may occur,

but these are not malfunctions.

■

Operating conditions

●

The Stop & Start system is operational when all of the following conditions
are met:
• Vehicles with automatic transmission: The brake pedal is being

depressed firmly

• Vehicles with manual transmission: The clutch pedal is not being

depressed.

• The engine is adequately warmed up.
• The outside temperature is -5

°C (23 °F) or higher

• Vehicles with automatic transmission: The shift lever is in D or S, or P

after driving in D or S.

• Vehicles with manual transmission: The shift lever is in N.

• Vehicles with automatic air conditioning system:

 is off.

• The hood is closed. (

→P. 347)

• The driver’s seat belt is fastened.
• The driver’s door is closed.
• The accelerator pedal is not being depressed.

●

In the following circumstances, the engine may not be stopped by the Stop
& Start system. This is not a malfunction of the Stop & Start system.
• The air conditioning system is being used when the ambient temperature

is high or low.

• The battery is not sufficiently charged, or is undergoing a periodic

recharge.

• The brake booster vacuum is low.
• The vehicle is stopped on a steep hill.

Hill-start assist control

346

4-5. Using the driving support systems

• When the steering wheel is being operated
• Due to traffic or other circumstances the vehicle is stopped repeatedly,

resulting in the amount of time the engine is stopped by the Stop & Start
system to become excessively high.

• At high altitude.
• Engine coolant temperature or transmission fluid temperature is too low

or too high.

• The battery fluid temperature is excessively high or low.
• After the battery terminals have been disconnected and reconnected.
• For a while after a battery replacement.
• When the front-wheel drive control switch is in the L4 position or the rear

differential is locked.

●

In the following circumstances, the engine will automatically restart when
the engine is stopped by the Stop & Start system.
• The air conditioning system is turned on.

• Vehicles with automatic air conditioning system:

 is turned on.

• When the steering wheel is being operated.
• Vehicles with automatic transmission: The shift lever is in any position

other than D, S or P.

• Vehicles with manual transmission: The shift lever is in any position other

than N

• The driver’s seat belt is unfastened.
• The driver’s door is opened.
• The accelerator pedal is depressed.
• The Stop & Start cancel switch is pressed.
• The vehicle starts to roll on an incline.
In order to have the engine stopped by the Stop & Start system again, drive
the vehicle once.
Vehicles with automatic transmission: The engine may be stopped by Stop
& Start system automatically without driving the vehicle if the idling stop
time is set to “Long”. (

→P. 348)

●

In the following circumstances, the engine may automatically restart when
the engine is stopped by the Stop & Start system.
• The brake pedal is pumped or strongly depressed.
• The air conditioning system is being used.
• The battery is not sufficiently charged.
In order to have the engine stopped by the Stop & Start system again, drive
the vehicle once.
Vehicles with automatic transmission: The engine may be stopped by Stop
& Start system automatically without driving the vehicle if the idling stop
time is set to “Long”. (

→P. 348)
