Toyota Hilux (2017 year). Manual - part 35

147

3

Operation of

each component

3-1. Key information

Keys...................................148

3-2. Opening, closing and

locking the doors

Side doors..........................160
Access panels (smart-cab

models only) ....................166

Tailgate ..............................167
Smart entry & start

system .............................170

3-3. Adjusting the seats

Front seats.........................186
Rear seats .........................188
Head restraints ..................191

3-4. Adjusting the steering

wheel and mirrors

Steering wheel ...................194
Inside rear view mirror .......196
Outside rear view

mirrors .............................197

3-5. Opening and closing

the windows

Power windows..................200
Quarter windows

(smart-cab models)..........204

Back window

(sliding type) ....................205

148

3-1. Key information

Keys

The following keys are provided with the vehicle.

X

Type A

Master keys
Valet key
Key number plate

X

Type B

Master keys
Valet key
Key number plate

X

Type C

Master keys

Operating the wireless remote con-
trol function (

→P. 150)

Valet key
Key number plate

The keys

1
2
3

1
2
3

1

2
3

149

3-1. Key information

3

O

pe

rati

on
of e
ac

h c
om
pon
ent

X

Type D

Master keys

Operating the wireless remote con-
trol function (

→P. 150)

Valet key
Key number plate

X

Type E (vehicles with smart entry & start system)

Electronic keys

• Operating the smart entry & start

system (

→P. 170)

• Operating the wireless remote

control function (

→P. 150)

Mechanical keys
Key number plate

X

Type F (vehicles with smart entry & start system)

Electronic keys

• Operating the smart entry & start

system (

→P. 170)

• Operating the wireless remote

control function (

→P. 150)

Mechanical keys
Key number plate
Mechanical keys (supplemen-
tary keys)

1

2
3

1

2
3

1

2
3
4

150

3-1. Key information

X

Vehicles without smart entry & start system

Locks all the doors (

→P. 160)

Check that the door is securely
locked.

Unlocks all the doors (

→P. 160)

Sounds the alarm

*

 (

→P. 151)

*

: If equipped

X

Vehicles with smart entry & start system

Locks all the doors (

→P. 160)

Check that the door is securely
locked.

Unlocks all the doors (

→P. 160)

Releasing

To release the key, press the but-
ton.

Folding

To stow the key back in its case,
push the key back to the stowed
position while pressing the button.

Wireless remote control (if equipped)

1

2
3

1

2

Using the master key (type C and D)

1

2
