9C-5 Instrumentation / Driver Info. / Horn: Terminal arrangement of coupler viewed from combination meter side Component Location Audio System Component Location S6JB0B9303001 3. Combination switch 8. ODO-TRIP 13. Interface circuit 18. Headlight auto leveling control module (if equipped) 4. Tachometer 9. Junction connector 14. CAN driver 5. Speedometer 10. SDM 15. Stepper motor and LED output driver Terminal Circuit Terminal Circuit G28-1 To audio unit (Illumination control output G28-12 To headlight auto leveling control module (if equipped) G28-2 To information display (Illumination control G28-13 Power source G28-3 — G28-14 Backup power source G28-4 — G28-15 GND G28-5 — G28-16 To SDM (Air bag warning light signal) G28-6 — G28-17 — G28-7 — G28-18 — G28-8 CAN communication line (Active Low Signal) G28-19 To turn signal light switch (turn L) G28-9 — G28-20 To turn signal light switch (turn R) G28-10 CAN communication line (Active High Signal) G28-21 — G28-11 To rear fog light switch (if equipped) G28-22 — 17 16 11 1 22 10 21 9 20 8 19 7 18 6 15 5 14 4 13 3 12 2 I5JB0A930002-01 2 1 4 3 3 6 5 2 (a) 7 I5JB0A930003-01 1. Radio or navigation assembly 4. Antenna feeder 7. GPS antenna (if equipped) 2. Front speaker 5. Antenna : 10 N ⋅m (1.0 kgf-m, 7.5 lb-ft) 3. Rear speaker 6. Antenna base |
