EN(H4DOTC)(diag)-13
Electrical Component Location
ENGINE (DIAGNOSTICS)
3. SOLENOID VALVE, ACTUATOR, EMISSION CONTROL SYSTEM PARTS AND IGNITION
SYSTEM PARTS
(1)
Wastegate control solenoid valve
(4)
Ignition coil
(7)
Secondary air combination valve RH
(2)
Purge control solenoid valve 2
(5)
Intake oil flow control solenoid valve
(8)
Secondary air combination valve LH
(3)
Purge control solenoid valve 1
(6)
Secondary air pump
(9)
Tumble generator valve ASSY
EN-05068
(4)
(8)
(4)
(5)
(1) (2)
(3)
(9)
(5)
(7) (9)
(6)
