DIESEL ENGINE MECHANICAL  1B3-163

SSANGYONG  Y200

SPECIAL TOOLS TABLE (Cont’d)

117 589 03 23 00

Go/No Go Gauge

(for Exhaust)

YAD1BLE0

346 589 00 63 00

Super Cooling Box

YAD1BL90

363 589 02 21 00

Dial Gauge Holder

YAD1BKQ0

366 589 00 21 05

Extension

YAD1BKP0

601 589 00 25 00

Pressure Testing Device

YAD1BKH0

601 589 00 66 00

Counter Sink

YAD1BKD0

601 589 01 59 00

Assembling Board

YAD1BKY0

601 589 02 43 00

Drift

YAD1BL50

SSANGYONG  Y200

1B3-164  DIESEL ENGINE MECHANICAL

SPECIAL TOOLS TABLE (Cont’d)

601 589 02 59 00

Supporting Bridge

YAD1BKZ0

601 589 03 14 00

Sleeve

601 589 03 43 00

Oil Seal Assembler

YAD1B790

YAD1BKN0

601 589 05 15 00

Drift (for Intake)

YAD1BLA0

601 589 06 15 00

Drift (for Exhaust)

YAD1BLB0

601 589 07 21 00

Measuring Device

YAD1BKK0

602 589 00 40 00

Engine Lock

YAD1B720

603 589 00 09 00

Serration Wrench

YAD1BKB0

DIESEL ENGINE MECHANICAL  1B3-165

SSANGYONG  Y200

SPECIAL TOOLS TABLE (Cont’d)

657 589 03 63 00

Sliding Hammer

667 589 00 23 00

Height Gauge

YAD1BKE0

YAD1BKC0

667 589 00 31 00

Press Lever

YAD1BL00

603 589 00 40 00

Counter Holder

YAD1B4K0

603 589 01 40 00

Holding Wheel

YAD1BL20

667 589 01 21 00

Fixing Device

YAD1BKL0

667 589 02 63 00

Supporting Bar

YAD1BL30

SECTION 1F1

M162 ENGINE CONTROLS

CAUTION: Disconnect the negative battery cabl e beforer emoving or i nstalling any electrical unit or when
a tool or equipment could easily come in contact with exposed electrical terminals. Disconnecting this
cable will help prevent personal injury and damage to the vehicle. The ignition must also be in LOCK
unless other-wise noted.

TABLE OF CONTENTS

Engine and ECM Problem Check Report ........... 1F1-3

Diagnostic Information and Procedure ............. 1F1-4

Failure Code Diagnosis ...................................... 1F1-4

Clearing Failure Codes ....................................... 1F1-4

Failure Codes Table ........................................... 1F1-4

Ignition System ................................................... 1F1-8

Ignition Coil ...................................................... 1F1-10

Crankshaft Position (CKP) Sensor ..................... 1F1-12

Camshaft Position (CMP) Sensor ....................... 1F1-16

Camshaft Actuator ............................................ 1F1-20

Knock Sensor (KS) ........................................... 1F1-22

Spark Plug ....................................................... 1F1-24

System Voltage ................................................ 1F1-28

Ignition Switch .................................................. 1F1-29

Fuel System ...................................................... 1F1-30

Fuel Pump ........................................................ 1F1-32

Fuel Injector ...................................................... 1F1-36

Purge Control Valve .......................................... 1F1-40

Fuel Rail ........................................................... 1F1-42

Fuel Pressure Regulator .................................... 1F1-44

Induction System .............................................. 1F1-46

Throttle Valve Actuator ...................................... 1F1-46

Hot Film Air Mass (HFM) Sensor ........................ 1F1-50

Engine Coolant Temperature (ECT) Sensor ........ 1F1-54

Accelerator Pedal Module ................................. 1F1-58

Clutch Switch ................................................... 1F1-61

Cooling Fan ...................................................... 1F1-62

A/C Compressor Relay ..................................... 1F1-63

Cruise Control Switch ........................................ 1F1-64

Traction Control System (TCS) ........................... 1F1-65

Resonance Flap ................................................ 1F1-66

Stop Lamp Switch ............................................. 1F1-67

Engine RPM ..................................................... 1F1-68

Exhaust System ................................................ 1F1-69

Catalytic Converter ........................................... 1F1-69

Oxygen Sensor ................................................. 1F1-70

Engine Control Module .................................... 1F1-76

Serial Data Communication ............................... 1F1-77

Internal Failure .................................................. 1F1-79

Electronic Throttle Controller Safety Malfunction . 1F1-80

Immobilizer ...................................................... 1F1-82

Maintenance and Repair ................................. 1F1-83

On-Vehicle Service ........................................... 1F1-83

Discharging the Pressure in Fuel System .......... 1F1-83

Fuel Pump ........................................................ 1F1-83

Fuel Filter .......................................................... 1F1-84

Fuel Tank .......................................................... 1F1-85

Fuel Pressure Regulator .................................... 1F1-86

Fuel Rail and Injector ........................................ 1F1-87

Engine Coolant Temperature Sensor .................. 1F1-88

Throttle Body (Integrated with the Actuator) ....... 1F1-89

Hot Film Air Mass (HFM) Sensor ........................ 1F1-90

Knock Sensor ................................................... 1F1-90

Pedal Position Sensor ....................................... 1F1-91

Oxygen Sensor ................................................. 1F1-91

Purge Control Valve .......................................... 1F1-92

Canister ............................................................ 1F1-92

Camshaft Position Sensor ................................. 1F1-92

Crankshaft Position Sensor ............................... 1F1-93

Engine Control Module ...................................... 1F1-93
