ELECTRICAL WIRING DIAGRAMS 5-129
SSANGYONG REXTON XDi (LHD)
A. CONNECTOR INFORMATION
B. CONNECTOR IDENTIFICATION SYMBOL & PIN NUMBER POSITION
Connector Number
(Pin Number, Color)
Engine Room Fuse Box (B) - Engine
Engine Room Fuse Box (D) - Engine
Engine Room Fuse Box (E) - Engine
Engine Room Fuse Box (F) - Engine
Engine Room Fuse Box (K) - Engine
Main - Floor (LH)
Main - Floor (LH)
Engine - Main (RH)
Floor - Tail Gate
W/H Main
W/H Floor
C102 (20Pin, White)
C104 (20Pin, White)
C105 (22Pin, White)
C106 (18Pin, White)
C108 (4Pin, Colorless)
C205 (11Pin, White)
C207 (15Pin, Blue)
C210 (13Pin, Green)
C391 (10Pin, White)
G201
G401
Connecting Wiring
Harness
Engine Room Fuse Box
Engine Room Fuse Box
Engine Room Fuse Box
Engine Room Fuse Box
Engine Room Fuse Box
Inside Driver Side Cowl PNL
Inside Driver Side Cowl PNL
Inside Driver Side Cowl PNL
Inside the Left Side Cover the Tail Gate
Inside Driver Side Cowl PNL
Center the Tail Gate
Remark
Connector Position
