ELECTRICAL WIRING DIAGRAMS 5-125
SSANGYONG REXTON XDi (LHD)
A. CONNECTOR INFORMATION
B. CONNECTOR IDENTIFICATION SYMBOL & PIN NUMBER POSITION
Connector Number
(Pin Number, Color)
Engine Room Fuse Box (J) - Engine
Engine Room Fuse Box (K) - Engine
Main - Floor (LH)
Main - Floor (LH)
Floor - Driver Door
Floor - Driver Door
Driver Door - Door Extention
Floor - Co-Driver Door
Floor - RR Left Door
Floor - RR Right Door
W/H Main
W/H Floor
W/H Floor
W/H Floor
C107 (14Pin, White)
C108 (4Pin, Colorless)
C205 (11Pin, White)
C209 (22Pin, Yellow)
C351 (20Pin, White)
C352 (13Pin, White)
C353 (13Pin, White)
C361 (13Pin, White)
C371 (21Pin, White)
C381 (21Pin, White)
S206 (14Pin, Black)
G301
G302
G303
Connecting Wiring
Harness
Engine Room Fuse Box
Engine Room Fuse Box
Inside Driver Side Cowl PNL
Inside Driver Side Cowl PNL
Inside Driver Side Cowl PNL
Inside Driver Side Cowl PNL
Inside Driver Side Cowl PNL
Inside Co-Driver Side Cowl PNL
Under Left “B” Filler
Under Right “B” Filler
Behind the Left the FATC
Under Driver Seat
Under Driver Seat
Under the Left “B” Filler
Behinel Conn Holder
Behinel Conn Holder
Behinel Conn Holder
ECU GND
Remark
Connector Position
