SsangYong Rexton. Manual - part 265
ELECTRICAL WIRING DIAGRAMS 5-93
SSANGYONG REXTON XDi (LHD)
A. CONNECTOR INFORMATION
B. CONNECTOR IDENTIFICATION SYMBOL & PIN NUMBER POSITION
Connector Number
(Pin Number, Color)
Engine Room Fuse Box (E) - Engine
Engine Room Fuse Box (F) - Engine
Engine Room Fuse Box (M) - Engine
Main - Floor (LH)
Main - Floor (LH)
Main - Floor (LH)
Floor - Driver Seat
Floor - Driver Seat
Driver Seat - Seat Back
Floor - Driver Door
Floor - Driver Door
Floor - Co-Driver Door
Floor - Co-Driver Door
W/H Main
W/H Floor
W/H Floor
W/H Floor
C105 (22Pin, White)
C106 (18Pin, White)
C109 (16Pin, White)
C204 (12Pin, Black)
C206 (20Pin, Black)
C208 (20Pin, Black)
C301 (20Pin, White)
C302 (21Pin, White)
C303 (6Pin, White)
C351 (20Pin, White)
C352 (13Pin, White)
C361 (13Pin, White)
C362 (12Pin, White)
S208 (14Pin, Black)
S302 (14Pin, Black)
G301
G302
Connecting Wiring
Harness
Engine Room Fuse Box
Engine Room Fuse Box
Engine Room Fuse Box
Inside Driver Side Cowl PNL
Inside Driver Side Cowl PNL
Inside Driver Side Cowl PNL
Under the Driver Seat
Under the Driver Seat
Under the Driver Seat
Inside Driver Side Cowl PNL
Inside Driver Side Cowl PNL
Inside Co-Driver Side Cowl PNL
Inside Co-Driver Side Cowl PNL
Behind the Right the FATC
Under Driver Seat
Under Driver Seat
Under Driver Seat
A/T
Power Seat
Power Seat
Power Seat
Behinel Conn Holder
Behinel Conn Holder
Behinel Conn Holder
Behinel Conn Holder
ECU GND
Remark
Connector Position
