ELECTRICAL WIRING DIAGRAMS 5-89
SSANGYONG REXTON XDi (LHD)
A. CONNECTOR INFORMATION
B. CONNECTOR IDENTIFICATION SYMBOL & PIN NUMBER POSITION
Connector Number
(Pin Number, Color)
Engine Room Fuse Box (B) - Engine
Engine Room Fuse Box (D) - Engine
Engine Room Fuse Box (E) - Engine
Engine Room Fuse Box (F) - Engine
Engine Room Fuse Box (M) - Engine
Main - Roof
Main - Floor (LH)
Main - Floor (LH)
W/H Main
W/H Main
W/H Main
W/H Main
W/H Engine
W/H Main
C102 (20Pin, White)
C104 (20Pin, White)
C105 (22Pin, White)
C106 (18Pin, White)
C109 (16Pin, White)
C201 (8Pin, White)
C203 (13Pin, Green)
C210 (13Pin, Green)
S201 (14Pin, Black)
S202 (14Pin, Black)
S203 (14Pin, Black)
S204 (14Pin, Black)
G101
G201
Connecting Wiring
Harness
Engine Room Fuse Box
Engine Room Fuse Box
Engine Room Fuse Box
Engine Room Fuse Box
Engine Room Fuse Box
Under the I/P Fuse Box
Under the I/P Fuse Box
Inside Driver Side Cowl PNL
Upper the I/P Relay Box
Upper the I/P Relay Box
Upper the I/P Relay Box
Behind the Left the FATC
Center the Engine Room Fuse Box
Inside Driver Side Cowl PNL
GND
GND
Remark
Connector Position
