CHANGED BY
EFFECTIVE DATE
AFFECTED VIN
59
TOD
STAVIC - 2004.09
4D
P1835
P1836
P1841
P1842
P1843
P1844
Too low speed sensor reference voltage
Too high speed sensor reference voltage
Open to ground in shift motor circuit
Short to ground in shift motor output circuit
Shift system timeout
Too low position encoder voltage (Stuck in
Low)
- Reference voltage: below 4 V
- Check the relevant harnesses.
- Check the relevant connectors for contact.
- Replace sensors if necessary.
- Reference voltage: over 8 V
- Check the relevant harnesses.
- Check the relevant connectors for contact.
- Replace sensors if necessary.
- When TCCU detects the motor failure for 1 second
(Action: IG switch ON)
- Check the relevant harnesses for contact.
- Replace shift motor if necessary.
- When TCCU detects the motor failure for 1 second
(Action: IG switch ON)
- Check the relevant harnesses for contact.
- Replace shift motor if necessary.
- 2H-4H: after 1.5 seconds
- 4H-4L: after 3 seconds
- Check the relevant harnesses for contact.
- Replace shift motor if necessary.
- When no signals from the position encoder
- Check the relevant harnesses for contact.
- Replace shift motor if necessary.
Code
Description
Action
