SsangYong Stavic / SsangYong Rodius (2005 year). Manual - part 112

DI04-41

CHANGED BY

EFFECTIVE DATE

AFFECTED VIN

EXHAUST SYSTEM

DI ENG SM - 2004.9

5. Remove the #3 hanger.

6. Remove the exhaust pipe.

7. Install in the reverse order of removal.

DI05-1

CHANGED BY

EFFECTIVE DATE

AFFECTED VIN

LUBRICATION SYSTEM

DI ENG SM - 2004.9

LUBRICATION SYSTEM

 00

SECTION DI05

Table of Contents

LUBRICATION SYSTEM ............................................. DI05-2

Lubrication system layout ....................................... DI05-3

Lubrication diagram ................................................ DI05-4

Specifications .......................................................... DI05-5

Engine oil change ................................................... DI05-9

Oil pump ................................................................ DI05-13

Oil spray nozzle ..................................................... DI05-15

Oil pan assembly .................................................. DI05-16

TROUBLE DIAGNOSIS ............................................. DI05-24

SPECIAL TOOLS AND EQUIPMENT ........................ DI05-25

DI05-2

CHANGED BY

EFFECTIVE DATE

AFFECTED VIN

LUBRICATION SYSTEM

DI ENG SM - 2004.9

LUBRICATION SYSTEM

Cylinder head cover

Oil dipstick

Oil separator

Oil filter

Oil pump

Oil pan

Oil cooler

Oil pressure switch

DI05-3

CHANGED BY

EFFECTIVE DATE

AFFECTED VIN

LUBRICATION SYSTEM

DI ENG SM - 2004.9

LUBRICATION SYSTEM LAYOUT

Cylinder head

Cylinder block

Main oil gallery:

φ 16

Hole to cylinder head:

φ 9

Main bearing hole:

φ 7

Chain and injection pump:

φ 7

Return hole:

φ 14

Chain nozzle:

φ 1

HP pump bearing:

φ 6
