SsangYong Stavic / SsangYong Rodius (2005 year). Manual - part 62

1F-90

CHANGED BY

EFFECTIVE DATE

AFFECTED VIN

ENGINE CONTROLS

M162 GSL ENG SM - 2005.7

ENGINE DATA DISPLAY TABLE

* Condition: Warmed up, idle, P/N or neutral

Parameter

Unit

Value

SPECIFICATIONS

Engine coolant temp.

Intake air temp.

Engine rpm

Regular rpm

Engine load

Mass air flow meter

Throttle position angle

Spark advance

Indicated engine torque

Injection time

Battery voltage

Front axle speed

Rear axle speed

Accel. Pedal position 1

Accel. Pedal position 2

Throttle position 1

Throttle position 2

Fuel integrator

Oxygen sensor

A/c s/w condition

Full load state

Shift gear state (A/T)

A/c control state

Clutch switch (M/T)

Cam actuator state

Knocking control

Protect mission

Purge control valve

Lambda function

Catalyst heating

Overrun fuel cut

Ful l fuel cut

Brake switch

Cruise control status

°C

rpm

Kg/h

°TA

°CA

Km/h

1=ON/0=OFF

greater than 95°C after warm up

-40 ~ 130°C (varies with ambient

temp. or engine mode)

700 ± 50 (P/N), 600 ± 50 (D)

18 ~ 25 %

16 ~ 25 Kg/h

0°TA (up to 100°TA at t he wi de

open throttle)

°CA (6 ~ 9°CA)

Varies with engine condition

3 ~ 5 ms

13.5 ~ 14.1V (engine running)

0 ~ 265 Km/h

0.4 ~ 4.8 V

0.2 ~ 2.4 V

0.3 ~ 4.6 V

0.8 ~ 1.2

100 ~ 900 mv

1F-91

CHANGED BY

EFFECTIVE DATE

AFFECTED VIN

ENGINE CONTROLS

M162 GSL ENG SM - 2005.7

FASTENER TIGHTENING SPECIFICATIONS

Application

Camshaft position sensor retaining bolts

Canister mounting bolts

Coolant temperature sensor

Crankshaft position sensor retaining bolt

Engine Control Module (ECM) mounting bracket nuts

Fuel filter mounting bracket bolt

Fuel filter lines

Fuel pressure test connector

Fuel rail assembly bolts

Fuel return and supply lines

Fuel tank retaining nuts

Intake air duct mounting bolts

Knock sensor mounting bolt

Oxygen sensor

Pedal position censor mounting bolts and nut

Throttle body bolts

Lb-Ft

Lb-In

106

1F-92

CHANGED BY

EFFECTIVE DATE

AFFECTED VIN

ENGINE CONTROLS

M162 GSL ENG SM - 2005.7

FUEL SYSTEM SPECIFICATION

Use Only Unleaded Fuel Rated at
89 Octane or Higher

Fuel quality and additives contained in fuel have a signifi-
cant effect on power output, drivability, and life of theengine.

Fuel with too low an octane number can cause engine
knock.

Caution

Use of fuel with an octane number lower than 89 may
damage engine and exhaust system.

Notice

To prevent accidental use of leaded fuel, the nozzles
for leaded fuel are larger, and will not fit the fuel filler
neck of your vehicle.

Do Not Use Methanol

Fuels containing methanol (wood alcohol) should not be
used in vehicle.

This type of fuel can reduce vehicle performance and dam-
age components of the fuel system.

Caution

Use of methanol may damage the fuel sys-tem.

Vehicle Fueling from Drums or
Storage Containers

For safety reasons (particularly when using noncom-
mercial fueling systems) fuel containers, pumps and

hoses must be properly earthed.

Static electricity build up can occur under certain atmo-
spheric and fuel flow conditions if unearthed hoses, par-
ticularly plastic, are fitted to the fuel-dispensing pump.

It is therefore recommended that earthed pumps with in-
tegrally earthed hoses be used, and that storage con-
tainers be properly earthed during all noncommercial fu-
eling operations.

TEMPERATURE VS RESISTANCE

°C

°F

ECT Sensor

IAT Sensor

ohms (

Ω)

130

120

110

100

-10

-20

-30

-40

266

248

230

212

194

176

158

140

122

113

-4

-22

-40

111.6

143

202

261

340

452

609

835

1166

1662

2420

3604

5499

8609

13850

22960

39260

102

127

159

202

261

340

452

609

835

1166

1662

2420

3604

5499

8609

13850

22960

39260

Temperature vs Resistance Values (Approximate)

1F-93

CHANGED BY

EFFECTIVE DATE

AFFECTED VIN

ENGINE CONTROLS

M162 GSL ENG SM - 2005.7

SPECIAL TOOLS AND EQUIPMENT

Name and Part Number

A9922 0012A (103 589 00 21 00)

Fuel Pressure Gauge
