03-24

When seating

When jumping

(3) Operation of center seat

Pull up the center seat when to jump

Push down the center seat when to seat

-

-

03-25

7410-01

Seat back flat cable

(4) Rear 1st & 2nd row seat mechanisms

Seat back folding cable

Flat lever

Seat back

folding cable

Seat back

flat cable

Folding lever

Jumping mechanism

Sliding lever

Sliding cable

03-26

(5) Operation of rear seat (Rear 1st and 2nd seat)

Seat sliding

▶

Front

Rear

03-27

7410-01

Rear 1st/2nd seat

Rear 2nd

Rear 1st

(6) Seat back flat

- When to recline or to flat fully.

(7) Seat back folding

- Fold the rear 1st or 2nd raw seat back to put something on or to utilize it as a table.
