03-16

▶ 2 passengers with loading

Front seat : Move to the far end

Rear 1st seat : Middle / Back folding

Rear 2nd seat: Middle / Back folding

Rear 3rd seat : Fix/ Back folding

·
·
·
·

03-17

7410-01

5) Sliding-Moving Amount

Item

Sliding distance

Front seats (A)

228 mm

Rear 1st row seats (B)

380 mm

Rear 2nd row seats (C)

340 mm

Total length of rear seat rail

1,610 mm

03-18

Headrest Height Adjustment

To adjust the height of the headrest, raise
the headrest without operating the
headrest support sleeve (A) and lower it
while pressing the headrest support
sleeve.
(However, raise the headrest while
pressing the headrest support sleeve (A)
in order to remove it.)

4. FRONT SEAT

1) To Adjust Front Seat

While the driver seat is provided as two models: a power seat and a manual seat, the manual seat is

only used for front passenger seat.

To adjust headrest

▶

To adjust headrest tilting

Move the headrest to the arrow direction
to adjust the angle.

03-19

7410-01

Power Seat

To adjust seat slide

Moving the slide switch forward and rearward
activates the slide motor to move the seat
forward and rearward.

To adjust seat back angle

When moving the upper part of the recline
switch forward/backward, the seatback angle is
adjusted as the recline motor rotates the rail.

Manual Seat

To adjust seat slide

To move the seat forward or backward, pull and
hold the seat slide lever up and move the seat.

To adjust seat back angle

To fold the seatback, pull the seatback lock
release lever to release the lock. Then, lean
back to the desired angle and release the lever.

To adjust seatback

▶
