11-6

Radio antenna specification changed

Changed to micro pole antenna from glass antenna (with radio antenna amplifier)

11-7

8910-05

3. CAUTIONS AND WARNING FOR SAFETY

Ssangyong is not liable for any personal injury and material damage, caused by violation of traffic

regulations or neglect of observing actual traffic and driving situations.

Colors on display figures in this manual may differ from actual display due to publication concerns.

-

-

Do not disassemble or modify this system.

If doing so, it may cause an accident, fire or electric shock.

Do not use the system if it is malfunctioning (sound or video output problem).

Doing so may lead to an accident or electric shock.

Please contact a Ssangyong service dealer immediately.

The system should be used only when the engine is started.

Using the system for an extended period of the with the engine off may discharge the battery.

Do not leave beverages or foreign materials around the system.

If they enter the system, they may cause a fire.

The system may break down if a disc not supported by this system is inserted.

Do not apply impact to or drop this system.

It might cause malfunction.

Never leave the system in a hot or cold place for an extended period of time. Therefore, do not park
the vehicle in a hot or cold place. The ambient temperature should be -30℃ ~ +80℃ for

proper operation.

-

-

-

-

-

-

-

11-8

Front door speaker

2. LAYOUT

Handsfree microphone

Steering wheel switch

1. OVERVIEW

The audio head unit is fitted with the Bluetooth handsfree for convenience. And, it has a micro pole

antenna and its own integrated amplifier to improve the radio frequency reception rate and to provide

the high-quality sound.

Audio head unit

Front tweeter speaker

USB/AUX jack assembly

11-9

8910-05

Micro pole antenna

Quarter speaker

Handsfree microphone

Tweeter speaker

Audio head unit

Steering wheel switch

USB/AUX jack assembly
