7. CODING AND INITIALIZATION

1) Engine Variant Coding

Unit

Selection

Description

PTC auxiliary heater

NO

For PTC auxiliary heaterequipped vehicle,
select"YES".

YES

Glow plug

Relay (K-line)

Select "AQGS".

AQGS (CAN)

Transmission

MT 5-speed

Select the appropriate system.

MT 6-speed

AT 5-speed (DC 5AT)

AT 6-speed (DSI 6AT)

AT 7-speed (DC 7AT)

Pressure sensor
forA/C refrigerant

NO

Select “Refrigerant pressure sensor”.

Refrigerant Pressure Sensor

Immobilizer

NO

Select "YES" if the vehicle has
immobilizer.

YES

Vehicle speed input
type

CAN

Select "CAN" if the vehicle has ABS or
ESP

WIRE

Cooling fan

Relay

Select "PWM".

PWM

Auto cruise

NO

Select "YES" if the vehicle hascruise
control.

YES

Engine level control

NO

Select "NO".

YES

G-sensor

NO

ABS: Select “NO”.
4WD ABS or ESP: Select “YES”.

YES

SMART key

NO

Select "NO".

YES

01-16

2) Chassis Variant Coding

Unit

Selection

Description

Region

GENERAL

Select the region.

EUROPE

EAS

NOT EQUIPPED

Select "NO".

ECS

EAS 2-corner

EAS 4-corner

EPB

NO

Select "NO".

YES

Telematics

NO

Select "NO".

YES

T/M shift lever

DC lever (CAN)

A/T: Select “DURA lever (CAN)”.
M/T: Select “M/T”.

DURA lever (CAN)

M/T

DSI lever (NO-CAN)

Brake system

NOT EQUIPPED

Select “ABS” or “ESP”.

ABS

TCS

ESP

SSPS

NO

Select "NO".

YES

4WD

2WD

Select “2WD” or “P/T 4WD”.

TOD

P/T 4WD

AWD

Transmission

M/T

Select “M/T” or “DC AT”.

DC AT

DSI AT

TPMS

NO

Select "NO".

YES

01-17

0000-00

Unit

Selection

Description

Sedan/Limousine

Sedan (RV)

Select "Sedan (RV)".

Limousine

Vehicle code
(Platform)

Rodius

Select "Rodius".

Rexton

Korando C

Kyron

Korando Sport

Vehicle code (Engine)

D32DT

Select “D20DTR”.

D27DT

D27DTP

D20DTR

ECU coding status

ECU not coded

Select “ECU coded”.

ECU coded

Signal not valid

Not defind

02-3

0000-00

Cylinder block

Piston protrusion

0.475 to 0.745mm

-

Piston ring

TOP ring end gap

0.20 to 0.40 mm

-

2nd ring end gap

0.35 to 0.50 mm

-

3rd ring end gap

0.2 to 0.40 mm

-

Offset

0.3mm -

Head gasket

Piston protrusion

0.475 to 0.540

1.2t

-

0.541 to 0.649

1.3t

-

0.650 to 0.745

1.4t

-

Valve

Clearance between
valve and piston

Intake

1.12 mm

-

Exhaust

1.09 mm

-

Valve recess

Intake

0.6 to 1.0 mm

-

Exhaust

0.6 to 1.0 mm

-

1. ENGINE ASSEMBLY

Unit

Description

Specification

Remark

Cylinder head

Height

131.9 to 132.1 mm

-

Flatness

below 0.1 mm

-

Valve protrusion

Intake valve

0.6 to 1.0 mm

-

Exhaust valve

0.6 to 1.0 mm

-

Flatness on manifold
side

Intake manifold

0.08 mm

-

Exhaust manifold

0.08 mm

-

Connecting rod

End play

0.5 to 0.31 mm

-

Camshaft

Axial end play

Intake

0.1 to 0.35 mm

-

Exhaust

0.1 to 0.35 mm

-

Camshaft position
sensor

Distance between Camshaft position
sensor and sprocket

0.20 to 1.80 mm

-
