SsangYong Rodius (2013 year). Manual - part 38

01-7

0000-00

1) Service Interval

Description

Daily

inspection

Weekly

inspection

Service interval

Engine oil & oil
filter

Inspection

Change every 20,000 km or 12 months
(The service interval should be
shortened under severe conditions)

General

Change every 15,000 km or 12 months
(The service interval should be
shortened under severe conditions)

Coolant

Inspection

Change every 200,000 km or 5 years

Air cleaner
element

Inspection

Diesel

Change every 20,000 km
(The service interval should
be shortened under severe
conditions)

General

Change every 15,000 km
(The service interval should
be shortened under severe
conditions)

Fuel filter

Change every 40,000 km (Draining
water from fuel filter: whenever
replacing the engine oil)

General

Change every 45,000 km (Draining
water from fuel filter: whenever
replacing the engine oil)

01-8

2) Specification and Capacity

Engine oil

Specification

Quality class: Ssangyong genuine engine oil (Total Quartz INEO
ECS 5W 30, SK ZIC SY 5W 30) or oil Approved by MB Sheet
229.51

Capacity

approx. 6.0 litter

Engine
coolant

Specification

Ssangyong genuine coolant Anti-Freeze SYC-1025

Capacity

approx. 11.5 litter

Severe condition

Frequent stop-and-go traffic, extended idling, short driving distance below 6 km, driving distance

below 16 km when the outside temperature remains below freezing

Driving in a hilly or mountainous terrain, sandy, or dusty area

High load driving such as trailer towing

Taxi, patrol service or delivery service (extended idling and excessive driving with low speed)

01-9

0000-00

4. CAUTION WHEN SERVICING THE ENGINE

1) Cleaness

Engine has a lot of precisely machined (grinding, polishing, lapping) surfaces. Thus, there should be

great cautions for cleaness when servicing the engine components. Apply the engine oil on the sliding

surfaces when assemblying the components. Every component should be disassembled and

reassembled in accordance with the correct sequences. Before servicing the engine, the negative

cable should be diconnected from the battery. Otherwise, some electric or electronic components

could be damaged.

2) Servicing

Before service work, be sure to disconnect battery negative (-) terminal to prevent damages by bad

wire and short.

To prevent the foreign material from getting into engine cylinder, cover the inlet of air cleaner if the

air cleaner has been removed.

(1) Lifting up the vehicle

Always keep the safety precautions.

To prevent the vehicle from rolling down, put the chocks under the tires (when using a 4-post lift).

Make sure to support the correct lifting points (when using a 2-post lift)

(2) Exhaust system

Wear the safety glove when removing the exhaust pipe.

Make sure that the exhaust pipe is cooled before removing it.

01-10

(3) Cautions before service

Prolonged exposure to the engine oil make cause a skin cancer or an irritation.

Used engine cotains the hazardous material that may cause the skin cancer. Do not allow the used

engine to make contact with your skin.

Make sure to wear the protection gloves and goggle when handling the engine oil. If contact

happens, rinse affected areas immediately with plenty of water. Do not wash it with gasoline or

solvent. If irritation persists, consult a doctor.

Improperly disposed engine oil can pollute the environment. Dispose used engine oil in accordance

with local environmental regulations.

(5) Tightening the fastener

If fine dust or foreign material enters into DI engine's fuel system, there can be serious damages

between HP pump and injectors. So, be sure to cover removed fuel system components with cap

and protect removed parts not to be contaminated with dirt. (Refer to cleanness in this manual

while working on DI engine fuel system)

When working on the fuel line between priming pump and injector (including return line), always

plug the openings with caps to prevent foreign materials or dust from entering to the openings and

connections.

The HP fuel supply pipe (HP pump to fuel rail) and HP fuel pipe (Fuel rail to injector) should be

replaced with new ones when removed.

Scalding hot coolant and steam could be blown out under pressure, which could cause serious injury.

Never remove the coolant reservoir cap when the engine and radiator are hot.

(4) Lubrication system

3) Fuel and Oil System

If work on the fluid system such as fuel and oil, working area should be well ventilated and smoking

should be prohibited.

Gasket or seal on the fuel/lubrication system should be replaced with new ones and bolts and nuts

should be tightened as specified.

Clean the mating surfaces before tightening.

Place the marks with paint to tighten by angle if the angle wrench is not available.
