06-2

Radiator grille

- The appearance of the radiator grille has been changed.
- The emblem on the radiator grille has been changed.

1. MAJOR CHANGES

Hood panel

The appearance of the hood panel has been changed.

Hood latch

The appearance of the hood latch safety hook has been
changed.

06-3

5110-00

Front impact

sensor mounting

Front end upper panel

Headlamp

aiming hole

Front bumper bracket

Front bumper

bracket

Headlamp

bracket

Front bumper

- The appearance of the front bumper has been changed.
- The front end upper panel has been newly applied.

Front end upper member

The front bumper bracket has been newly applied.

Headlamp member

- Aiming hole has been added because of the changed
  headlamp
- The install location of front impact sensor has been
  changed.
- The appearances of the front bumper bracket and
  headlamp bracket have been changed.

06-4

Rear quarter panel

The outline of the rear combination lamp mounting has been changed.

07-3

5110-01

Top view

Side view

Front side

Rear view

1. MAJOR DIMENSION
