04-6

Closing sunroof (Sliding close)

Open: 2-step open

2) Sunroof Sliding Opening/Closing

Pull down the switch briefly: auto sliding close

When pulling down the switch briefly, the sunroof is automatically closed. To stop the closing

sunroof, operate the switch to either direction.

-

Pull down and hold the switch: manual sliding close

The sunroof is closed as long as pulling down the switch.

-

Pull down the switch

-

Push up the switch

-

Push up the switch briefly: 2-step auto sliding open

When pushing up the switch briefly, the sunroof is automatically opened. Opening is carried out in 2

steps. In first step, the area 5 cm behind the sunroof is not opened. Push up the switch once again

in order to open the sunroof completely. The sunroof operation stops if you operate the switch

during its operation.

-

Push up and hold the switch: manual sliding open

The sunroof is opened as long as pushing up the switch.

-

04-7

7340-00

Tilt Up

3) Sunroof Tilt Up/Down

This function is to raise or lower the rear section of the sunroof.

When leaving the vehicle, make sure the sunroof is completely closed. The sunroof may look closed

but it might be tilted up.

Tilt Down

The rear side of the sunroof is tilted up when pulling down the sunroof switch with the sunroof

closed.

-

The rear side of the sunroof is tilted down when pushing up the sunroof switch with the sunroof

tilted up.

-

Pull down the switch

-

Push up the switch

-

04-8

When you drive this vehicle with the window or sunroof open at a certain position, you may feel

some pressure upon your ears or hear some noises similar to those from a helicopter. This happens

because of an influx in air through the window or sunroof and its resonance effect. If this happens,

adjust by opening the window or sunroof.

-

The anti-pinch function is deactivated just before the sunroof closes.

The sunroof safety function is just a safety supplementary system which cannot replace driver's care

and caution. Moreover, it may not be able to operate due to electric part or other conditions.

To prevent any body parts from being trapped by the sliding sunroof, an Anti-Pinch Function

automatically opens the sunroof when an object is trapped.

4) Sunroof Safety Function

Wind buffeting

▶

04-9

7340-00

3. SUNROOF OPEN WARNING

1) Warning Sound

When removing the key and then opening the door with the sunroof open, the warning sound is heard.

Closing the door stops the warning sound.

2) Message on Instrument Cluster

The following message is displayed on the screen in the instrument cluster.

General precaution for sunroof

Even though the sunroof can be operated when the engine is not running, operating the sunroof

repeatedly with the engine turned off will run down the battery. Operate the sunroof while the

engine is running.

When the sunroof operation is completed, release the switch. Keeping pressing the switch can

result in malfunction.

Especially in winter, never operate the sunroof if operation areas are iced. Wait until melted.

Make sure that the sunroof is completely closed when leaving the vehicle. Leaving the vehicle with

the sunroof open result in a theft. In addition, rain or snow can get into the vehicle through the

open sunroof.

When the sunroof is fully open, wind buffeting symptom can be worse. In this case, try to adjust

the sunroof position manually or open the sunroof into 1st first step until the wind buffeting is

disappeared.

Parts of the body can be trapped in the sunroof and can be struck by passing objects. Do not stick

hands, head or anything else out of the openings.

Remove any dirt and foreign material stuck on the edge of the sunroof glass periodically.

Noise can occur due to friction when operating the sunroof.

-

-

-

-

-

-

Supervision type
