03-26 (7) 5th Drive Gear (1.000) Middle & rear planetary gears, middle sun gear and rear sun gear rotated The rotating ratio of 1;1 is transferred to middle annulus gear (front planetary gear) because the middle planetary gear and sun gear in middle planetary gear set rotate simultaneously. At this moment, the rear planetary gear set rotates in 1:1 ratio (same in 4th gear). However, the front planetary gear set is not related to that, and the front sun gear rotates without load (idling) in 1:1 ratio. - - - Power flow ▶ Description 35R C OD C 26 B UD B LR B O.W.C 5th ● ● |
