01-13

0000-00

Description

Selection

Coding

Transfer case

2WD

2WD : 2WD
4WD : AWD

TOD

P/T 4WD

AWD

EPS

Not equipped

Select the appropriate system

Equipped

Select lever

BTRA lever

M/T : M/T lever
A/T : DURA lever

DC lever

DURA lever

M/T lever

EPB

Not equipped

Select : Not equipped

Equipped

Enable RON

conection

RON 89

Select : RON 95

RON 91

RON 93

RON 95

RON 97

RON 98

RON 100

Not defined

MIL

MIL - not illuminate

Select : MIL - illuminate

MIL - illuminate

Engine fan

Relay

Select : Relay

PWM

Coding is completed

NO

Select : YES

YES

01-14

Description

Selection

Coding

Immobilizer & Key

Non - IMMO

Select the appropriate system

BCM(IMMO)

SKM

Vehicle variant

message

Not defined

Select : Yes

No

Yes

Vehicle

Chairman

Select : KORANDO C

W200

REXTON

Musso

Kyron

KORANDO C

KORANDO (old)

Actyon Sport

Vehicle code,

transmission

M/T

M/T : M/T
A/T : NAGI/HPT

NAGI/HPT

BTRA A/T

ION 6 speed A/T

NAG2 A/T

TPMS

Not equipped

Select the appropriate system

Equipped

EBS(ABS/ESP)

Not equipped

Select the appropriate system

ABS

TCS

ESP

Telematics

Not equipped

Select : Not equipped

Equipped

01-15

0000-00

Description

Selection

Coding

EAS

Not equipped

Select : Not equipped

ECS

2 Corner EAS

4 Corner EAS

Domestic/Export

Domestic

Select the appropriate system

General export

EU export

01-16

2) Parameter Coding

Parameter

Range

Remark

Fuel characteristic

1 ~ 6

Idle RPM(P)

-50 ~ 127

Idle RPM(D)

-50 ~ 127

CO correction

-6.945 ~ 6.8907

Pedal progress coding

1 ~ 3

Idle RPM(P) - cold condition

-50 ~ 127

Idle RPM(D) - cold condition

-50 ~ 127
