Intake/exhaust Camshaft assembly

Components

▶

Intake Camshaft

HP pump drive gear

Exhaust

Camshaft

Connected to

vacuum pump

02-27

0000-00

Timing gear cover case (TGCC)

TGCC

Oil seal

Screw plug

02-28

Mass Balance Unit (MBU)

Fuel HP pump

HP pump gear

Crankshaft MBU

drive gear

MBU

HP pump

drive gear

02-29

0000-00

Oil pan assembly

8. OIL PAN

The oil pan in D20DTF engine improves the noise and vibration. Especially, the oil drainage is very easier

than before. And, A/C compressor bracket and the oil dipstick tube are mounted on the oil pan.

Components

▶

Oil drain plug

Dust cover

A/C compressor bracket

Oil dipstick tube hole
