04-28

Smart key not found warning deactivation conditions

If below conditions are met, the SKM sends the signal for [Smart key not found warning

deactivation] to deactivate the warning.

-

A smart key is found while the smart not found warning signal is output.

<IGN1 off> OR <Smart key in>

1.

2.

(2) Smart key detection warning

When a valid smart key sends the LOCK signal from outside of the vehicle or the outside door handle

switch is pressed with no smart key outside, the smart key detection warning signal is output, provided

that all the doors or the tailgate is closed with IGN OFF or ACC ON and a smart key is in the vehicle.

Smart key detection warning conditions

▶

When a valid smart key sends the LOCK signal from outside of the vehicle, the SKM sends the signals

for [external buzzer] and [smart key detection warning] to the BCM and instrument cluster through the

BCAN to inform the driver of the existence of a verified key inside the vehicle, provided that all the doors

or the tailgate is closed with IGN OFF or ACC ON and a smart key is in the vehicle.

Smart key inside vehicle warning

2.

If a smart key including immobilizer slot is identified as being in the vehicle after the outside door handle

switch is pressed, the SKM sends the signals for [external buzzer] and [smart key detection warning] to

the BCM and instrument cluster through the BCAN to inform the driver of the existence of a verified key

inside the vehicle.

These 2 warnings (external buzzer, smart key detection warning) continue for up to 10 sec. until the

warning conditions are deactivated under the above conditions.

The SKM stops these warnings immediately after the warning conditions are deactivated.

-

Smart key detection warning deactivation conditions

▶

Deactivation warning

1.

Function stop warning deactivation conditions

1.

When theft deterrent deactivated

The SKM sends the signals for [external buzzer] and [smart key detection warning

deactivation].

Smart key inside vehicle warning deactivation conditions

When the door is opened and then closed and no smart key is found, the SKM sends the

signals for [external buzzer] and [smart key detection warning deactivation].

-

-

04-29

8712-03

(4) Smart key battery discharge warning

(3) Smart key verification fail warning

When the verification is requested for ignition status change or engine starting and no verified smart key

is in the vehicle, the SKM sends the [smart key verification status] signal, which indicates that the

verification has failed, for up to 10 sec. until the verification fail conditions are deactivated.

Verification fail detection and transmission conditions

▶

When the ignition status is changed after a smart key is verified by the START switch ON input, the

SKM sends the verification status for 10 sec.

-

Normally, the smart key verification warning is one of the smart key fail conditions.

-

Ignition status change

(OFF ->ACC) / (OFF ->IGN)/(ACC ->IGN) / (IGN -> engine ON)

*

If above conditions are met again, the SKM re-verifies a smart key and sends the verification status for

another 10 sec.

When the ignition status is changed by the transponder verification while the smart key status is sent

through the BCAN, the SKM sends the smart key verification signal and also sends the transponder

verification signal for 10 sec.

-

-

If low smart key battery is detected during the verification process for ignition status change or engine

start, the SKM sends the signal for [smart key battery low voltage warning] to the BCM and instrument

cluster through the BCAN for up to 10 sec. until the warning condition is deactivated.

Smart key battery discharge confirmation and deactivation

▶

If the smart key battery low voltage is confirmed, the SKM sends the smart key battery low voltage

warning signal.

If the smart key battery is in normal condition, the SKM sends the smart key battery low voltage

warning deactivation signal.

The smart key is the last used key.

-

-

*

(5) Transponder verification fail warning

If a verified smart key is not found by the key verification process, the SKM sends the information that

indicates the key is not verified to the instrument cluster through the BCAN for up to 10 sec. until the

verification fail condition is deactivated.

The SKM sends the transponder verification warning when the verification has failed with the smart key

inserted into the immobilizer holder.

-

Transponder verification fail detection and transmission conditions

▶

When the ignition status is changed after the transponder is verified by the START switch ON input,

the SKM sends the transponder verification status for 10 sec.

-

04-30

Ignition status change

(OFF ->ACC) / (OFF ->IGN)/(ACC ->IGN) / (IGN -> engine ON)

*

If above conditions are met again, the SKM re-verifies the transponder and sends the verification

status for another 10 sec.

When the ignition status is changed by a smart key verification while the transponder verification is

processed, the SKM sends the signal for [transponder verification fail], and sends the smart key

verification status for 10 sec.

-

-

(6) Transmission position warning

When the gear selector lever is in a position other than P or N with IGN ON and engine started, the

SKM sends the [gear position warning] signal to the instrument cluster through the BCAN for up to 10

sec. until the operating conditions are deactivated.

Transmission position warning deactivation

▶

When re-attempting to start with IGN1 ON and transmission in P or N

-

(7) SKM error alert

The SKM sends the SKM error alert signal to the instrument cluster through the BCAN for up to 10 sec.

when an in ignition status related error or passive entry system error occurs.

SKM error transmission conditions

▶

When any of the following errors is detected and a DTC is set, the SKM sends the error alert signal for

10 sec.

B+ (power) low voltage

B+ (logic) low voltage

ACC ON fail

ACC OFF fail

IGN1 ON fail

IGN1 OFF fail

IGN2 ON fail

IGN2 OFF fail

Short circuit in START switch

1.

2.

3.

4.

5.

6.

7.

8.

9.

The SKM sends the corresponding signal only once for 10 sec. when any of the above errors is detected

with IGN OFF/ON. It sends the signal again when a new error occurs.

04-31

8712-03

(8) Brake not working alert

The SKM sends the brake not working alert signal for 10 sec. every time the ignition status is changed

after the 1st cycle (OFF-ACC-IGN-ACC-OFF) while the brake is not operated.

when the brake pedal is depressed, the system is reset and alert deactivation signal is sent.

when the 10 min. timer is terminated

-

-

(9) Clutch not working alert

The SKM sends the clutch not working alert signal for 10 sec. every time the ignition status is changed

after the 1st cycle (OFF-ACC-IGN-ACC-OFF)

while the clutch is not operated.

when the clutch pedal is depressed, the system is reset and alert deactivation signal is sent.

when the 10 min. timer is terminated

-

-

(10) Smart key slot detection alert

The SKM sends the smart key slot detection alert signal for 10 sec. when a smart key inserted into

the slot is detected with IGN OFF and the driver's door open.

-

(11) SKM alert priority

1

Smart key out alert

EXTERIOR

1

2

Smart key reminder alert

EXTERIOR

3

Smart key verification fail alert

INTERIOR

2

4

Transponder verification failure alarm

INTERIOR

5

Smart key battery low voltage alert

INTERIOR

6

Transmission position alert

INTERIOR

7

SKM error alert

INTERIOR

8

Brake alert

INTERIOR

9

Clutch alert

INTERIOR

10

Smart key slot reminder alert

INTERIOR

1

Warning cancellation requirements

▶

Warning cancellation requirements

▶

Warning transmission conditions

▶

Warning cancellation requirements

▶

when the smart key is removed, the alert deactivation signal is sent.

when the 10 min. timer is terminated

-

-
