01-6

Sun visor lamp

Glove box lamp

Front room lamp

2. INTERIOR LAMP SYSTEM LAYOUT

01-7

0000-00

Center room lamp

Luggage lamp

Door courtesy lamp

01-8

Steering wheel remote

control switch

Passenger door switch

Lower main panel

switch

Start/stop switch

Cruise control switch

Hazard warning switch

bezel assembly

Multifunction switch

FATC switch

Drive door main switch

& Outside rearview mirror

switch

3. SWITCH SYSTEM LAYOUT

01-9

0000-00

Center room lamp

switch

Front seat heated wire switch

(STD)

Rear door switch (RH)

Overhead console

switch

Rear door switch (LH)

Tailgate switch

Front seat heated wire switch

(DLX)

Luggage lamp switch

Driver power seat

switch
