02-3
0000-00
1. SPECIFICATIONS
System
Unit
Description
Specification
Intake
system
Air cleaner element
Filtering type
Dry, filter element
Filtering area
0.208m²
Service interval
EU: Change every 20,000 km
(But, shorten the service
interval under severe
conditions)
GEN: Clean every 7,500 km,
change every 15,000 km (But,
shorten the service interval
under severe conditions)
Air cleaner assembly
Weight
1.5kg
Operating temperature
-30 ~ 100℃
Capacity
8L
Intercooler
Core material
Aluminum
Size
510X122X67(WxHxT)
Tank material
Plastic (Molding)
Efficiency
80%
Exhaust
system
Turbocharger assembly
Max. temperature of turbine
housing
780 ℃
Diameter of turbine housing
ø40.0
Diameter of compressor
housing
ø46.8
Cooling type
Air cooled type
