01-6 1. GUIDELINES FOR SERVICE WORKS 1) For Safety To perform the service works easily ans safely, the service technicians must keep the proper working procedures and rules. This manual provides the useful instructions to the service technicians so that they can perform the servive works with standard working process, skills, tips in time. Please read this manual and follow the instructions carefully. Signal words such as “CAUTION” and “NOTE” have special meanings. indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury or property damage. However, above references and cautions cannot be inclusive measures, so should have habits of paying attentions and cautions based on common senses. indicates information to assist maintenance and instructions. 2) Equipment Korando is FF (Front Engine Front Drive) type vehicle, and engine and powertrain system are integrated into a module. Therefore, 2-post lift and general equipment are necessary when working on the engine and transmission. Major equipment: Engine and transmission jack, Engine stand, Engine crane, Transmission jack, Engine hanger - - Engine crane Engine stand Transmission jack |
