01-3

0000-00

1. LAYOUT

Right side view

Left side view

Rear view

Front view

01-4

2. MAJOR COMPONENTS

Front View

▶

Vacuum pump

Oil filter assembly

Camshaft position sensor

Power steering pump pulley

Water pump pulley

Alternator pulley

Idler pulley No. 1

A/C compressor pulley

Auto tensioner

Idler pulley No. 2

Isolation damper

Rear View

▶

E-EGR valve

Fuel temperature sensor

Fuel HP pump assembly

E-VGT actuator

Coolant temperature sensor

IMV valve

Magnetic triggering

Crankshaft position sensor

01-5

0000-00

Right side View

▶

Wide band oxygen sensor

Pre-CDPF pressure port

Rear exhaust gas temperature

sensor

CDPF assembly

E-VGT turbocharger

Post-CDPF pressure port

Oil drain plug

Left side View

▶

Thermostat assembly

Knock sensor 1 connector

Variable swirl valve assembly

Oil cooler assembly

E-EGR valve

Knock sensor 2 connector

E-EGR solenoid valve

EGR cooler

Electronic throttle body

T-MAP sensor

Oil level switch

Front exhaust gas temperature

sensor
