ELECTRICAL WIRING DIAGRAMS
ELECTRICAL WIRING DIAGRAMS
ELECTRICAL WIRING DIAGRAMS
ELECTRICAL WIRING DIAGRAMS
ELECTRICAL WIRING DIAGRAMS 2-7
2-7
2-7
2-7
2-7
2)
2)
2)
2)
2) W/H MAIN
W/H MAIN
W/H MAIN
W/H MAIN
W/H MAIN
•
W/H MAIN
1. C351
2. S201
3. G201
4. G202
5. Auto down unit
6. HLLD switch
7. OSRV switch
8. Rear wiper & washer switch
8-1. DLC
9. C201
10. Clutch switch "A"
11. Clutch switch "B" (Gasoline E/G)
12. Stop lamp switch
13. Dimmer & passing switch
14. Turn signal,FRT fog lamp & Light switch
15. Wiper switch
16. J201
17. C202
18. Immobilizer antenna
19. Ignition switch
20. Cruise control switch
21. Key reminder switch
22. C203
23. Acceleration pedal sensor
24. Kick down switch
25. REKES
26. ADD' (LH)
27. Diagnosis connector
28. Brake fluid switch
29. Locking hud solenoid (TCCU)
30. C116
31. Cluster "D"
32. Cluster "C"
33. Cluster "B"
34. Cluster "A"
35. J202
36. J202
37. J203
38. S203
39. 4WD switch
40. Hazard switch
41. Defroster switch
42. -
43. Antenna feeder cable
44. S204
45. Audio
46. -
47. SDM
48. G204
49. C204
50. Chime Bell
51. Buzzer
52. Acceleration sensor
53. G203
54. Cigar lighter
55. Central door lock relay
56. BTSI solenoid
57. A/Tsocket
58. BTSI "P" position sw
59. Mode switch
60. Shift motor
61. Speed sensor & clutch coil
62. VSS
63. C301
64. C302
65. C303
66. C304
67. TCM
68. TOD Resistor (Gasoline E/G)
69. G301
70. TOD or TCCU
71. FRT LH seat belt sw
72. Parking brake sw
73. W/D Burglar connector
74. Seat heater switch
75. STICS
76. G303
77. -
78. OVPR (Gasoline E/G)
79. C305
80. Seat belt sw (FRT RH)
81. EBCM (ADD)
82. G303
83. C205
84. Thermo amp
85. Passenger inflator
86. -
87. -
88. Front wiper motor
89. Siren
90. O2 sensor 1 / (Gasoline E/G)
91. EBCM (ABS) & Modulator (ABD)
92. J105
93. C113
94. C112
95. EGR solenoid (Diesel E/G)
96. C114 (Gasoline E/G)
97. C115 (Gasoline E/G)
98. J204 (Gasoline E/G)
99. S205
100. J205 (Gasoline E/G)
101. Antenna feeder cable
102. Auto antenna
103. C206
104. ECM (GSL) or Immobilizer unit (DSL)
105. EGR control unit (Diesel E/G)
106. G205
107. C361
108. O2 sensor 2 (Gasoline E/G)
FUSE
BOX
RELAY
BOX
FUSE &
RELAY BOX
A
10 11
12
13
14
15
17
16
18
19
20
21
22
28
29
30
26
27
31
32
33
34
35
36
37
38
39
40
41
43
83
88
89
90
91
93
94
95
92
96
97
98
99
102
101
100
106
107
104
105
103
108
84
85
44
8-1
47
48
49
50
51
52
53
45
55
54
56
57
58
60
61
62
63
64
65
66
67
68
71
72
73
74
75
76
78
79
80
81
82
69
70
59
23
24
25
1
3
4
2
5
9
6
7 8
