TRIP COMPUTER: general information (2/2)
Reading energy consumption
Manual reset
Select one of the trip settings, press and
values
hold switch 4 OK to reset the range.
Some vehicle equipment items con-
sume energy: the energy consumed
Automatic reset
by the vehicle may therefore differ from
The range is automatically reset at the
the energy consumed on the electric
end of a full recharge of the traction
counter.
battery to a value calculated based on
the energy consumption over the last
125 miles (200 km).
Interpreting some of the
values displayed after
resetting
Average energy consumption and
4
speed are all the more stable and
meaningful the greater the distance
Resetting the journey
travelled since the last reset.
parameters (reset button)
With one of the trip parameters se-
Resetting the estimated
lected as the display, press and hold
range
the
4 switch “OK” until the display
After a full recharge of the traction bat-
resets to zero.
tery, you can select two types of reset-
ting: manual or automatic.
Automatic resetting of the
journey parameters
Some on-board
computer infor-
Resetting occurs automatically when
mation appears on the navigation
the maximum value of any of the pa-
system display.
rameters is exceeded.
The trip settings mileage recorder
is reset simultaneously in the on-
board computer and the navigation
system.
1.84
TRIP COMPUTER AND WARNING SYSTEM: journey parameters (1/4)
The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.
Examples of selections
Interpreting the display selected
Consumption
a) Trip settings.
Current energy consumption.
+ 13,4
kWh
Average energy consumption.
The value is displayed after having travelled at least 400 metres since
12,8
the last reset.
kWh
Journey
Average speed since the last reset.
42,2
The value is displayed after driving 400 metres.
km/h
1284,7
Distance travelled since the last reset.
km
1.85
TRIP COMPUTER AND WARNING SYSTEM: journey parameters (2/4)
The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.
Examples of selections
Interpreting the display selected
b) Tyre pressure reset ➥ 2.18
+
Tyre pressure
12:00
c) Clock
1.86
TRIP COMPUTER AND WARNING SYSTEM: journey parameters (3/4)
The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.
Examples of selections
Interpreting the display selected
d) Service interval.
Service in
Distance remaining until the next service (displayed in miles/kilo-
metres), then when the service nears, several scenarios are possible:
1,210 miles
- range less than 930 miles (1,500 km) or one month: the message
or 3 months
“Service in” is displayed accompanied by the distance or the time;
- when a service is due, the message “Service due” is displayed ac-
companied by the nearest term (distance or time);
- range equal to 0 miles (0 km) or date of service reached: the
message “Service Required” is displayed accompanied by the
The vehicle requires a service as soon as possible.
Resetting the display after the service in accordance with the maintenance schedule.
The service interval must only be reset after a service which complies with the recommendations in the maintenance schedule.
Special note: To reset the service interval, press and hold one of the display reset buttons for approximately 10 seconds until
the display shows the mileage permanently.
1.87
TRIP COMPUTER AND WARNING SYSTEM: journey parameters (4/4)
The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.
Examples of selections
Interpreting the display selected
Settings
e) Vehicle settings personalisation menu ➥ 1.92.
(OK)
Tailgate open
f) Trip log.
Successive display:
- information messages;
- operating fault messages.
1.88
TRIP COMPUTER AND WARNING SYSTEM: information messages
These can help in the vehicle starting phase, or give information about a selection or a driving status.
Examples of information messages are given in the following pages.
Examples of messages
Interpreting the display selected
“Disconnect cable to start”
Indicates that the charging cord is still plugged into the vehicle.
“Parking Brake ON”
Indicates that the parking brake has been applied.
“Steering not locked”
Indicates that the steering column has not been locked.
Unplug, then plug in the vehicle.
“Check connections”
If the message still shows, this may be caused by the external charging conditions
or by the home installation.
Indicates a possible electrical fault or a defective charging cable: change the charg-
“Check charging station”
ing terminal or location or have the cable checked.
Indicates an electrical fault while charging. Restart charging.
“Power cut while charging”
If this does not work, have the electrical installation checked.
“Charging refused no contract”
Charging prohibited by your battery rental organisation. Rectify the situation.
1.89
TRIP COMPUTER AND WARNING SYSTEM: operating fault messages
These appear with the
warning light and mean that you should drive very carefully to an authorised dealer as
soon as possible. If you fail to follow this recommendation, you risk damaging your vehicle.
warning light stays on. Examples of operating fault messages are given in the following pages.
Examples of messages
Interpreting the display selected
«WARNING: Check Airbag»
Indicates a fault in the restraint system in addition to the seat belts. In the event of an
accident, it is possible that they may not be triggered.
«Check vehicle»
Indicates a fault on one of the pedal sensors or in the 12 V battery management
system.
«WARNING: Check Braking System»
Indicates wear or the need to check the braking system.
«Check Vehicle plug»
Indicates overheating at the vehicle-side charging socket. Wait for about 20 minutes
and try again. If this does not work, contact an authorised dealer.
«Check Electric System»
Indicates a fault in the traction system.
«Battery charging impossible»
Indicates a fault on the traction battery recharge system.
1.90
TRIP COMPUTER AND WARNING SYSTEM: warning message
These appear with the® warning light and require you to stop immediately, for your own safety, as soon as traffic
conditions allow. Stop your engine and do not restart it. Call an approved Dealer.
Examples of warning messages are given in the following pages. Note: the messages appear on the display either individually
or alternately (when there are several messages to be displayed), and may be accompanied by a warning light and/or a beep.
Examples of messages
Interpreting the display selected
«WARNING: Braking System»
Indicates a fault in the braking system.
«WARNING: Power Steering»
Indicates a fault in the steering.
«Electric motor failure»
Indicates that the vehicle is losing power.
«WARNING: Electric System»
Indicates a fault in the electric system.
“ Puncture “
Indicates that at least one wheel is punctured or severely underinflated.
1.91
VEHICLE SETTINGS CUSTOMISATION MENU (1/3)
Adjusting the settings
d) “Welcome”:
1
- External welcome;
Select a tab then the function to be
- Automatic fold-out of mirrors;
modified (the display depends on the
- Interior welcome;
vehicle equipment and country):
- Courtesy light auto mode.
a) “Driving”:
Depending on the function, select:
- Indicator volume.
- “ON” or “OFF” to activate or deacti-
b) “Access”:
vate;
- Release driver’s door;
or
– Lock doors during driving;
- a duration to adjust the time the lights
– Opening/closing in hands-free
are switched on (e.g. for the “Follow-
mode;
me-home lighting” function).
– Remote locking/Approach unlock-
Please refer to the multimedia instruc-
ing;
tions for further information.
- Distance locking sound;
- Silent mode;
Depending on the vehicle equipment,
- Automatic locking.
this function allows you to activate/de-
c) “Wiping and lighting”:
activate and adjust some of the vehi-
-
Follow-me-home lighting;
cle’s functions.
Wiping in reverse;
-
Automatic front wiping;
Vehicles fitted with a
Wipe after wash.
multimedia screen.
Accessing the settings menu
With the vehicle stationary, engine run-
ning, from the multimedia screen 1
select the “Settings” menu, then the
“Vehicle” tab then the “Car configura-
tion” menu to access the various set-
For safety reasons, carry
tings.
out any adjustments when
the vehicle is not being
driven.
1.92
VEHICLE SETTINGS CUSTOMISATION MENU (2/3)
Adjusting the settings
d) “DRIVING ASSIST”:
2
– Lane departure warning sound
Navigate using the 4 or 5 control to
volume;
select the function to be modified and
- Lane departure warning sensitiv-
press 6 “OK” to confirm (display may
ity;
vary according to vehicle equipment
- Lane departure warning vibration;
and country):
- Lane keeping assist sensitivity;
a) “DASHBOARD”:
- Blind spot warning;
- Language;
- Active braking;
- Unit;
- Speed warning.
3
- Style;
4
e) “LIGHTING”:
- Colour.
- Courtesy light auto mode;
b) “VEHICLE”:
- Automatic follow-me-home light-
- Rear windscreen wiping in re-
ing;
5
6
verse gear;
- Follow-me-home lighting: XX sec-
- Automatic windscreen wiping;
onds.
Vehicles not fitted with a
- Front/rear drip wiping function;
f)
“ACCESS”:
multimedia screen
- Exterior welcome.
- Lock doors during driving;
c) “PARKING ASSIST”:
- Opening/closing in hands-free
Accessing the settings menu on
- Beep volume.
mode;
display 2
- Unlock the driver’s door only;
With the vehicle stationary, press
- Automatic re-locking;
switch 3 as many times as required to
- Silent locking;
reach the “Vehicle” tab. Press repeat-
- Automatic opening/closing;
edly on the 4 or 5 switch to access the
- Automatic mirror fold-out.
“Settings” menu, then confirm by press-
ing 6 “OK”.
g) “RESET”.
=
function activated
<
function deactivated
1.93
VEHICLE SETTINGS CUSTOMISATION MENU (3/3)
To exit the menu, press 4 or 5 to access
2
“BACK” and confirm by pressing 6
“OK”. It may be necessary to carry out
this operation more than once.
3
4
5
6
Once a line has been selected, press 6
“OK" to adjust the function.
If you select either “PARKING ASSIST”
then “VOLUME”, or “DASHBOARD”
then “LANGUAGE”, you will have to
make a further selection (sound volume
of the parking distance control or in-
strument panel language). In this case,
make your selection and confirm it by
pressing 6 “OK”, the selected value is
shown by a =
in front of the line.
The vehicle settings personalisation
menu cannot be used when driving.
When driving, the instrument panel
display switches automatically to
trip computer.
1.94
CLOCK AND EXTERIOR TEMPERATURE (1/2)
6
9°C 12:00
1
2
5
4
3
Setting the time
Set the hour using control 2 or 3, then
Vehicles fitted with a multimedia
press switch 4 OK to confirm.
screen
Vehicles not fitted with a multimedia
screen
Set the minutes using control 2 or 3,
The time and exterior temperature are
then press switch 4 “OK” to confirm.
displayed on the multimedia screen 6.
Press the switch 1 as many times as re-
quired to reach the “Vehicle” tab.
Please refer to the multimedia instruc-
tions for further information.
Repeatedly press control 2 or 3 to set
the 5 clock.
Press and hold switch 4 “OK” until the
time display flashes.
1.95
CLOCK AND EXTERIOR TEMPERATURE (2/2)
External temperature
indicator
If the power supply is cut (battery
Special note:
disconnected, supply wire cut, etc.),
When the outside temperature is - 3°C
the clock must be reset.
to + 3°C, the °C characters flash (sig-
We recommend that you do not
nalling a risk of ice on the road).
adjust these settings while driving.
External temperature
indicator
As ice formation is related
to climatic exposure, local
air humidity and temperature, the
external temperature alone is not
sufficient to detect ice.
1.96
AUDIBLE AND VISUAL SIGNALS
Direction indicators
Move stalk 1 parallel to the steering
wheel and in the direction you are going
1
to turn it.
One-touch mode
When driving, it is possible that the
A
steering wheel may not be turned suf-
ficiently to return the stalk automatically
to its starting position.
2
In this case, briefly turn stalk 1 to the in-
termediate position, then release it: the
stalk returns to its original point and the
indicator light flashes three times.
Horn
Hazard warning lights
é
Press steering wheel boss A.
Press switch 2. This switch il-
luminates all four direction indicators
and the side-mounted indicator lights
Headlight flasher
simultaneously. It must only be used in
Pull stalk 1 towards you to flash the
an emergency to warn drivers of other
headlights.
vehicles that you have had to stop in
an area where stopping is prohibited or
unexpected or that you are obliged to
drive under special conditions.
Depending on the vehicle, the hazard
warning lights may come on automati-
cally under heavy deceleration. You can
switch them off by pressing switch 2.
1.97
EXTERIOR LIGHTING AND SIGNALS (1/6)
Dipped beam
k
headlights
1
2
1
Manual operation
Turn the ring 2 until the symbol is oppo-
site mark 3. This indicator light on the
instrument panel comes on.
Automatic operation
(depending on vehicle)
Turn ring 2 until the AUTO symbol is op-
3
posite mark 3: with the engine running,
the dipped beam headlights switch on
or off automatically depending on the
brightness of the light outside, without
any action on stalk 1.
Daytime running lights
Side lights
Your vehicle is fitted with daytime light-
Turn the ring 2 until the symbol
ing (depending on the version).
is opposite mark 3. This indicator light
on the instrument panel comes on.
The daytime running lights come on
automatically with no action on stalk 1
when the engine is started, and they go
off once the engine is switched off. This
must be in AUTO mode.
Before driving at night, check that the electrical equipment is operating
If driving on the left in a left-hand
correctly and adjust the headlight beams (if your vehicle is not carrying
drive vehicle (or vice versa), drivers
its normal load). As a general precaution, check that the lights are not ob-
must have the lights adjusted by an
scured (by dirt, mud, snow or objects being transported).
authorised dealer for the duration of
the trip.
1.98
EXTERIOR LIGHTING AND SIGNALS (2/6)
Automatic main beam
The main beam headlights come on au-
2
tomatically if:
1
headlights
- exterior light is weak;
Depending on the vehicle, this system
- no other vehicles or lighting are de-
switches the main beam headlights on
tected;
and off automatically. It uses a camera
- the vehicle speed is above approxi-
located behind the interior rear-view
mately 25 mph (40 km/h).
mirror to detect vehicles that are being
If any of the above conditions are not
followed and those coming in the oppo-
fulfilled, the system switches to dipped
site direction.
beam headlights.
3
Note: make sure the windscreen is not
obscured (dirt, mud, snow, condensa-
tion etc.).
To activate automatic main beam
headlights:
Main beam headlights
á
Turn ring 2 until the AUTO symbol is op-
With the engine running and
posite mark 3 and push the stalk 1.
the dipped beam headlights lit, push
stalk 1. This indicator light on the instru-
Warning light
comes on the in-
ment panel comes on.
The system may encounter difficul-
strument panel.
To return to the dipped headlight posi-
ties under certain conditions, inclu-
tion, pull the stalk 1 towards you again.
ding:
- extreme weather conditions (rain,
snow, fog, etc.);
- obstruction in front of the wind-
screen or camera;
- when a following or oncoming ve-
hicle has weak or hidden lighting;
- incorrect settings for the front
headlights;
- reflective systems;
– ...
1.99
EXTERIOR LIGHTING AND SIGNALS (3/6)
Operating faults
1
2
When the message “Check Automatic
Lighting” appears on the instrument
panel, the system is deactivated.
Consult an approved dealer.
3
Using the portable naviga-
tion system at night in the
windscreen area below the
Automatic main beam
camera may disturb the op-
headlights (continued)
eration of the “automatic main beam
headlights” system (risk of reflection
To deactivate automatic main beam
on the windscreen).
headlights:
- turn ring 2 to a position other than
AUTO;
or
The “automatic main beam
- pull the stalk 1.
headlights” system should
under no circumstances be
Warning light
goes out on the in-
used to replace driver atten-
strument panel.
tion and responsibility with regard
to vehicle lighting and adapting to
light, visibility and traffic conditions.
1.100
EXTERIOR LIGHTING AND SIGNALS (4/6)
Lights-on reminder buzzer
Welcome and goodbye
If the lights are on after the engine is
function
1
2
(depending on the vehicle)
switched off, a warning beep sounds
when the driver’s door is opened to
Once the function is activated, the day-
warn you that the lights are still on.
time running lights and the rear side
lights will light up automatically upon
detection of the card or when the vehi-
Operating faults
cle is unlocked.
If the
“Check lighting” message ap-
They switch off automatically:
- approximately one minute after light-
the k
warning light flashes on the
ing up;
instrument panel, this indicates a light-
- when starting the engine based on
ing fault.
the position of the lighting stalk;
Consult an authorised dealer.
or
Switching off the lights
- upon locking the vehicle.
The lights will go out automatically
when the engine is switched off, the
driver's door is opened or the vehicle
Activating/deactivating the
is locked. In this case, the next time
function
the engine is started the lights will be
With the vehicle stationary, engine run-
switched back on according to the posi-
ning, from the multimedia screen select
tion of the ring 2.
the “Settings” menu, “Vehicle” tab, the
Note: if the fog lights are lit, the lights
“Car configuration” menu, “Welcome”
are not switched off automatically.
then “External welcome”. Choose “ON”
or “OFF” to activate or deactivate the
function.
1.101
EXTERIOR LIGHTING AND SIGNALS (5/6)
With the engine lights switched off,
the 2 ring in AUTO, pull the lever 1 to-
1
2
wards you: the side lights and dipped
beam headlights will switch on for ap-
proximately 30 seconds along with the
š
and k
on the instrument
panel.
To increase this duration, you may pull
the stalk up to four times (total time re-
stricted to approximately two minutes).
On the instrument panel, the message
“lighting on _ _ _” followed by the re-
maining time will appear as confirma-
tion. You can then lock your vehicle.
“See-me-home lighting”
To switch off the lights before they go
out automatically, turn ring 2 to any po-
function
sition, then return it to position AUTO.
This function enables you to briefly
switch on the side lights and dipped
beam headlights (e.g. to provide light
when opening a gate).
1.102
EXTERIOR LIGHTING AND SIGNALS (6/6)
Rear fog light
Switching off the lights
Turn centre ring 4 on the stalk
Turn the centre ring 4 again until mark 3
1
2
3
4
until the symbol faces mark 3, then re-
is opposite the symbol for the fog lights
lease it.
that you wish to switch off. The corre-
sponding indicator light on the instru-
Operation of the fog lights depends on
ment panel goes out.
the exterior lighting selected, and an in-
dicator light will light up on the instru-
The front and rear fog lights switch off
ment panel.
when the exterior lights are switched
off.
To avoid inconveniencing other road
users, remember to switch off the rear
fog light when it is no longer needed.
Cornering lights
(depending on vehicle)
Driving in forward gear, whenever the
dipped beam headlights are on and
Front fog lights
under certain conditions (at speed, the
g
steering wheel at an angle, the indica-
Turn centre ring
4
on
the
tor lights on, etc.), when taking a corner
stalk 1 until the symbol faces mark 3,
one of the front fog lights will switch on
then release it.
to light the inside of the bend.
Operation of the fog lights depends on
In reverse, the two front fog lights
the exterior lighting position selected,
switch on automatically.
and an indicator light will light up on the
When driving in fog or snow, or
instrument panel.
when transporting objects which are
higher than the roof, the headlights
do not come on automatically.
The driver remains in full control of
switching on the fog lights: the indi-
cator lights on the instrument panel
inform you whether the fog lights
are lit (indicator light on) or not (indi-
cator light off).
1.103
HEADLIGHT BEAM ADJUSTMENT
Examples of positions for
adjusting
control A according to the load
Driver alone or with front passenger
0
A
All seats occupied
1
Driver with passengers and luggage
Switch A is used to adjust the height of
(or load) reaching the maximum
2
the headlight beams according to the
permissible all-up weight
load.
With the dipped beam headlights lit,
Driver without passengers and luggage
press or lift switch A as many times
(or load) reaching the maximum
3
as is necessary to select the required
permissible all-up weight
position on the instrument panel. The
position selected is displayed on the
* depending on the vehicle
instrument panel for approximately
30 seconds.
The table below gives some examples. In all cases, adjust control A accord-
Note: lights on, at each engine start-
ing to the vehicle load so that the road can be seen and other drivers are not
up the selected position is displayed on
dazzled.
the instrument panel for approximately
30 seconds.
If driving on the left in a left-hand drive vehicle (or vice versa), drivers must have
the lights adjusted by an authorised dealer for the duration of the trip.
1.104















Content      ..     3      4      5      6     ..
