EXTERIOR LIGHTING AND SIGNALS (2/2)
Lights-on warning buzzer
If the stalk is not returned to its ini-
tial position e
after the ignition is
switched off, a warning beep sounds
four times to warn you.
3
Retroreflectors 3
Remember to check the condition of
the side retroreflectors regularly. In the
event of damage, please replace them.
1.42
SCREEN WASHER, WIPER (1/2)
1
1
A
B
C
D
Windscreen wiper
Windscreen washer
n
With the ignition on, move
With the ignition on, pull stalk 1 towards
stalk 1:
you.
A park
B intermittent wiping
The wipers will pause for several
seconds between sweeps.
C normal wiping speed
D fast wiping speed
In the snow or ice, make sure that
the wiper blades are not stuck by
ice.
Keep an eye on the condition of the
blade. Replace the wiper blades
as soon as they begin to lose effi-
ciency: approximately once a year.
1.43
SCREEN WASHER, WIPER (2/2)
Efficiency of a wiper blade
Check the condition of the wiper
blades. How long they last depends
on you:
- it must remain clean: clean the
blade and the screen regularly
with soapy water;
- do not use it when the screen is
dry;
- free it from the screen when it has
not been used for a long time.
Replace wiper blades as soon as
their performance starts to diminish:
Before any action involving
Approximately every year (refer to
the windscreen
(washing
the information on “Wiper blades” in
the vehicle, de-icing, clean-
section 5).
ing the windscreen, etc.)
return stalk 1 to position A (park).
Precautions for using the
Risk of injury and/or damage.
wipers
- In freezing or snowy weather,
clear the screen before starting
the wipers (risk of motor over-
heating);
When working on the vehi-
- ensure that no objects are ob-
cle, ensure that the wind-
structing the travel of the blade.
screen wiper stalk is in po-
sition A (off).
Risk of injury.
1.44
Section 2: Driving
(Advice on use relating to fuel economy and the environment)
Starting, stopping the engine
2.2
Gear control
2.3
Handbrake
2.5
Vehicle range: advice
2.6
Environment
2.8
Charge meter
2.9
Eco-consumption
2.9
2.1
STARTING, STOPPING THE ENGINE
“Accessories” position A
Stopping the engine
No power-consuming device will oper-
Bring the key to
“Stop” position.
ate when the ignition is switched off.
Warning light goes out.
“On” position M
The ignition is switched on:
Start position D
Starting the engine
Turn the key to the D position and hold
it in this position until you hear a beep.
Release the key.
As soon as warning light stops
Driver’s responsibility
“Stop, steering and
flashing, your vehicle is ready to drive.
when parking or stopping
handbrake lock” position St
the vehicle
Never leave an animal,
To unlock: turn the key and the steering
child or adult who is not self-suffi-
wheel slightly.
cient alone on your vehicle, even for
To lock: remove the key and turn the
a short time.
steering wheel until the steering column
They may pose a risk of injury, such
locks.
as by starting the engine or activat-
To release the handbrake, please see
ing equipment.
the information on
“Handbrake” in
Section 2.
Risk of serious injury.
The vehicle cannot be started if the
charging cord is plugged in and
powered or if the charging flap is
open.
2.2
GEAR CONTROL (1/2)
Driving
Press switch D, a beep will sound.
During driving, press the accelerator
2
pedal to reach the speed desired.
D
Hill start
When setting off on a slope, release the
N
handbrake whilst pressing the brake
pedal before pressing the accelerator
pedal.
1
Steep hill start
R
When starting on steep hills:
- press the brake pedal with the left
foot to release the handbrake;
Display 1
Operation
- accelerate by pressing the acceler-
ator pedal with the right foot while
The display 1 on the instrument panel
- Switch on the ignition;
easing the left foot from brake pedal
indicates the selection control posi-
- start the engine;
to prevent the vehicle from revers-
tion 2.
- with your foot on the brake pedal,
ing.
release the handbrake (refer to the
information under “Handbrake” in
Reverse
Selection control 2
Section 2). It will now be possible to
D: forward
drive off.
Press the switch R.
The reversing light will come on as
N: neutral
Only engage D or R when the vehicle
soon as reverse gear is selected (igni-
is at a standstill, with your foot on
R: reverse
tion on). A beep sounds.
the brake and the accelerator pedal
released.
To protect the charging cord, always
check that it is properly stored in its
The vehicle can only be started if
housing before setting off.
the charging cord is unplugged from
the vehicle and stored away.
2.3
GEAR CONTROL (2/2)
Temporary stop
At a standstill and with the engine run-
ning, when position D or R is engaged,
a beep will sound and warning light
flashes until one of the following condi-
tions is met:
- brake pedal pressed;
N
- accelerator pedal pressed;
- press switch N;
- the handbrake is secured.
3
Parking the vehicle
With the vehicle at a standstill, press
switch N.
Warning light 3 comes on the instru-
ment panel.
Engage the handbrake (please see the
In the event of an impact to the underside of the vehicle (e.g.: striking a
“Handbrake” information in Section 2).
post, raised kerb or other street furniture), this may result in damage to
the vehicle (e.g.: twisted axle), the electrical circuit or the traction battery.
Do not touch the circuit elements or any fluids or liquids.
To prevent any risk of accident, have your vehicle checked by an authorised
dealer.
Risk of serious injury or electric shock.
NB: when the ignition is switched
off, the gear control automatically
switches to position N.
2.4
HANDBRAKE
To apply:
3
Pull lever 1 upwards and make sure the
vehicle is immobilised. Warning light 3
1
D
will come on on the instrument
panel.
Steep hill start
When starting on steep hills:
-
press the brake pedal with the left
2
foot to release the handbrake;
-
accelerate by pressing the acceler-
ator pedal with the right foot while
easing the left foot from brake pedal
to prevent the vehicle from revers-
ing.
Handbrake
Special conditions
It is not possible to release the hand-
To release:
brake when the 12 volt battery is dis-
With the ignition on:
charged.
- support on the brake
pedal and
You must recharge it (see “12V battery”
maintain it sunk ;
in Section 4) before you can release the
- press 2 ;
handbrake, or have the 12V battery re-
- gently pull lever 1 towards you, keep-
placed by an authorised dealer.
ing the 2 button pressed down;
- push the lever down as far as it will
go.
Make sure that the hand-
brake is properly released
When stationary and de-
when driving (red indicator
pending on the slope and/or
light off), otherwise over-
vehicle load, it may be nec-
The handbrake is a vehicle safety
heating may occur.
essary to pull up the hand-
measure. It cannot be released
brake at least two extra notches.
unless the ignition is switched on.
2.5
VEHICLE RANGE: recommendations (1/2)
In real usage, the range of an electric
vehicle may vary depending on several
factors over which you have partial con-
trol, which may make a considerable
difference to the vehicle range. These
factors are:
- speed and driving style;
- type of road;
- electrical accessories and equip-
ment;
- vehicle loading;
- tyres;
Speed and driving style
Drive at a constant speed.
Road type
High speeds will reduce your vehicle’s
Adapt your driving style to avoid ex-
Do not try to maintain the same speed
range.
cessive energy consumption. Please
up a hill, accelerate no more than you
A “sporty” driving style reduces your
refer to the information on the “Charge
would on the level. Keep your foot in
vehicle range: opt for a “lighter” driving
meter” in Section 2.
the same position on the accelerator
style.
Anticipate traffic changes by lifting your
pedal.
foot off the accelerator pedal in order to
recover energy.
2.6
VEHICLE RANGE: recommendations (2/2)
Use of electrical accessories
and equipment
In the event of freezing, manually
de-ice the windscreen (using a scraper)
to reduce usage of the de-icing/demist-
ing function and to save energy.
Please see the information on “Deicing,
demisting the windscreen” in Section 3.
The use of electrical accessories (GPS,
phone charger, etc.) reduces vehicle
range.
Vehicle loading
Avoid pointlessly overloading your ve-
hicle.
Tyres
An under-inflated tyre increases energy
For safety reasons, the use
consumption. Comply with the speci-
of tyres other than those
fied tyre pressures for your vehicle.
recommended by the man-
When replacing them, you must use
ufacturer is prohibited.
tyres made by the same manufacturer,
Failure to respect this recommen-
with the same dimensions, type and
dation may adversely affect stability,
structure as the originals.
behaviour, braking or the play be-
Please see the information on “Tyres”
tween the bodywork and the tyres...
in Section 5.
Some of these effects may lead to
the loss of control of the vehicle
under certain driving conditions,
and lead to an accident and serious
injury.
2.7
ENVIRONMENT
Your vehicle has been designed with
Please make your own
Recycling
respect for the environment in mind for
contribution towards
Your vehicle is 85% recyclable and
its entire service life: during production,
protecting the environment
95% recoverable.
use and at the end of its life.
too.
To achieve these objectives, many of
- Worn parts replaced in the course of
the vehicle components have been de-
Manufacture
routine vehicle maintenance (vehi-
signed to enable them to be recycled.
Your vehicle has been manufactured at
cle battery, etc.) must be disposed of
The materials and structures have
an industrial site which uses a progress
through specialist bodies.
been carefully designed to allow these
policy to reduce environmental impacts
components to be easily removed and
- At the end of the vehicle’s service
on rivers and natural areas (reduc-
reprocessed by specialist companies.
life, it should be sent to approved
tion of water and energy consumption,
centres to ensure that it is recycled.
In order to preserve raw material re-
visual and noise pollution, atmospheric
sources, this vehicle incorporates nu-
emissions and waste water, sorting and
- In all cases, comply with local legis-
merous parts made from recycled plas-
reusing waste).
lation.
tics or renewable materials (vegetable
or animal-derived materials such as
cotton or wool).
2.8
CHARGE METER/ECO-CONSUMPTION
A
B
C
Charge meter
Power recovery B
Eco-consumption (Éco ScorE)
This function shows the driver whether
The charge meter gives the driver a
When driving, if you lift your foot off the
their driving style is suitable for an opti-
real-time view of the vehicle’s remain-
accelerator pedal, the motor generates
mum vehicle range.
ing power.
electrical current during deceleration,
To display this function, press the end
and this energy is used to recharge the
of the windscreen wiper stalk as many
Power consumption A
traction battery.
times as necessary.
The traction battery supplies the elec-
trical energy required for the motor to
The squares C indicate increased
move the vehicle.
range: the more squares there are, the
more range there is remaining for the
vehicle.
Éco ScorE is calculated using the aver-
age from the last 1.8 miles (3 kilome-
tres) travelled. After the traction battery
is charged, it is calculated based on the
last 93 miles (150 kilometres).
2.9
Section 3: Your comfort
Windscreen de-icing, demisting
3.2
Passenger compartment storage, fittings
3.3
3.1
WINDSCREEN DE-ICING, DEMISTING
1
2
To exit this function
De-icing or demisting
Turn the end of stalk 1. Warning light 2
the windscreen
goes out on the instrument panel.
With the engine running, turn the end of
Demisting automatically stops approxi-
stalk 1. Warning light 2 lights up on the
mately 10 seconds after it is activated.
instrument panel.
This function enables quick electric
deicing/demisting.
Recommendations
In the event of freezing, manu-
ally de-ice the windscreen using a
scraper rather than the de-icing/de-
misting function in order to reduce
your energy consumption.
3.2
PASSENGER COMPARTMENT STORAGE, FITTINGS (1/4)
Accessories socket 3
Located in the storage compartment 1,
2
this is provided for connecting ac-
cessories approved by the Technical
Department with a maximum power of
5
65 watts (voltage of 12V).
1
4
3
6
Left-hand storage
Right-hand storage
compartment 1
compartment 4
To open, lift cover 2.
To open, lift cover 5.
To lock and unlock the storage com-
partment 4, insert the ignition key in
lock 6 and turn it.
Always leave the storage
compartment covers closed
Only connect accessories
when driving.
with a maximum power of
65 watts.
There is a risk of injury
when braking suddenly or in the
Fire hazard.
event of an accident.
3.3
PASSENGER COMPARTMENT STORAGE, FITTINGS (2/4)
A
7
10
8
B
Do not place an object or
pet on the storage space if
C
it has not first been secured
using a specific accessory
9
for the vehicle.
Rear storage space 10
Unclip the seatback A, then slide it
Risk of serious injury when braking
back and pull towards you.
sharply or in an impact.
To unlock the seat cushion B and the
Move the seat cushion B in 8, then pull
seatback A, insert the ignition key in
upwards to unclip the base.
lock 7 and turn it.
Push the seat cushion B and lift it
(movement C) to take it out from the
runners 9.
Note: when replacing, make sure you
lock the cushion and the seat back in
Ensure that no hard, heavy
place.
or pointed objects are
placed in the “open” storage
compartments in such a
way that they may fall onto passen-
gers during sudden turning, braking
The closure 7 enables the seat back
or in the event of an accident.
and cushion of the rear passenger
seat and the rear storage compart-
ment to be locked or unlocked.
3.4
PASSENGER COMPARTMENT STORAGE, FITTINGS (3/4)
A
11
7
8
B
C
9
Rear storage space
-
move the seat cushion B in 8, then
pull it upwards to unclip the base;
The rear seat can be transformed into a
storage space.
-
push the seat cushion B and lift it
(movement C) to take it out from the
- To unlock the seat cushion B and the
runners 9;
seatback A, insert the ignition key in
lock 7 and turn it;
-
depending on the vehicle, insert the
blanking cover 11 into the seatbelt
- unclip the seatback A, then slide it
housing. On vehicles fitted with it,
downwards and pull towards you;
the blanking cover 11 is located on
Ensure that no hard, heavy
the back of seatback A;
or pointed objects are
placed in the “open” storage
compartments in such a
way that they may fall onto passen-
gers during sudden turning, braking
or in the event of an accident.
3.5
PASSENGER COMPARTMENT STORAGE, FITTINGS (4/4)
A
Driver’s responsibility
Never use the storage
space as a booster seat for
7
a person or pet. Otherwise,
this could place your child or pet in
B
danger, or endanger the driver, in
the event of hard braking or impact.
9
Risk of death or serious injury.
– turn the seat B;
- insert the seat B into the runners 9;
- correctly position the seat B;
- clip the seatback A from top to
Driver’s responsibility
bottom;
Do not place any objects
- lock the seat cushion B and the seat-
in the storage space if this
back A using lock 7.
space is not secured using
the specific accessory for your ve-
hicle.
Please see an authorised dealer.
Risk of serious injury when braking
sharply or in heavy impacts.
Maximum load allowed in the rear
storage space: 10 kg, evenly distrib-
uted.
3.6
Section 4: Maintenance
Levels
4.2
brake fluid
4.2
windscreen washer reservoir
4.3
12 volt battery
4.4
Bodywork maintenance
4.6
Interior trim maintenance
4.8
4.1
LEVELS (1/2)
Topping up
After any operation on the hydraulic cir-
1
cuit, a specialist must replace the fluid.
Only use fluids approved by our
Technical Department (and taken from
a sealed container).
Replacement intervals
Refer to the Maintenance Document for
3
your vehicle.
2
Level 3
Brake fluid
It is normal for the level to drop as
the linings become worn, but it should
The level control should be read with
never drop below the MIN line.
the vehicle on level ground. This should
If you wish to check the disc wear your-
be checked frequently, and immedi-
self, you should obtain the document
ately if you notice even the slightest
explaining the checking procedure from
loss in braking efficiency.
our network or from the manufacturer’s
Accessing the brake fluid reservoir
website.
Unclip the upper bar 2 of the bonnet
before moving your hand in 1.
If there is an abnormal or repeated
drop in the fluid level, please consult
an authorised dealer.
4.2
LEVELS (2/2)
Jet
Use a pointed tool to adjust the height
of the windscreen washer jets.
5
4
Windscreen washer
reservoir
Topping up
Open flap 5.
Open cap 4 and fill until you see the
liquid. Then close the cap.
Liquid
Special windscreen washer fluid (prod-
uct with antifreeze in winter).
4.3

















Content      ..     1      2      3      4      ..
