METHODS OF RESTRAINT IN ADDITION TO THE FRONT SEAT BELTS (1/3)
These are made up of:
- Have the entire restraint
- a side support belt;
system checked following
- chest force limiters;
an accident.
- the driver’s airbag.
- No operation whatsoever
is permitted on any part of the
These systems are designed to act in-
system (airbags, electronic con-
dependently or together when the vehi-
trol units, wiring) and the system
cle is subjected to a frontal impact.
components must not be reused
Depending on the severity of the
on any other vehicle, even if iden-
impact, the system can trigger:
tical.
- the seat belt and side support belt
-
Only qualified personnel from
locking;
our Network may work on the air-
bags; otherwise the system may
– the front airbag.
trigger accidentally and cause
injury.
-
The electric trigger system may
only be tested by a specially
trained technician using special
equipment.
-
When scrapping your vehicle,
contact your authorised dealer
for disposal of the airbag gas
generators.
1.21
METHODS OF RESTRAINT IN ADDITION TO THE FRONT SEAT BELTS (2/3)
Side support belt
Driver’s front airbag
Please see the information on “Seat
This is fitted in the front seats.
belts” in Section 1.
An Airbag marking on the steering
wheel informs you of the presence of
Load limiter
this equipment.
Above a certain severity of impact, this
The airbag system consists of:
mechanism is used to limit the force of
- an airbag and its gas generator fitted
the belt against the body so that it is at
on the steering wheel;
an acceptable level.
- an electronic unit for system monitor-
ing which controls the gas generator
electrical trigger system;
- a single warning light å
on the
instrument panel.
The air bag system uses
pyrotechnic principles. This
explains why, when the air
bag inflates, it will gener-
ate heat, produce smoke (this does
not mean that a fire is about to start)
and make a noise upon detonation.
In a situation where an air bag is
required, it will inflate immediately
and this may cause some minor, su-
perficial grazing to the skin or other
problems.
1.22
METHODS OF RESTRAINT IN ADDITION TO THE FRONT SEAT BELTS (3/3)
All of the warnings below are given
so that the air bag is not obstructed
in any way when it is inflated and
also to prevent the risk of serious in-
juries caused by items which may be
dislodged when the air bag inflates.
Warnings concerning the
driver’s air bag
- Do not modify the steer-
ing wheel or the steering
wheel boss.
-
Do not cover the steering wheel
boss under any circumstances.
Operation
-
Do not attach any objects (badge,
This system is only operational when
logo, clock, telephone holder,
the ignition is switched on.
etc.) to the steering wheel boss.
If a severe frontal impact occurs, the
-
The steering wheel must not be
airbag inflates rapidly, cushioning the
removed (except by qualified per-
impact of the driver’s head and chest
sonnel from our Network).
against the steering wheel; the airbag
then deflates immediately after impact
-
Do not sit too close to the steering
so that the vehicle can be exited with-
wheel when driving: sit with your
out hindrance.
arms slightly bent (see Section 1
“Adjusting your driving position”).
This will allow sufficient space
for the air bag to deploy correctly
and to be fully effective.
1.23
ADDITIONAL METHODS OF RESTRAINT
All of the warnings below are given so that the air bag is not obstructed in any
1
way when it is inflated and also to prevent the risk of serious injuries caused
by items which may be dislodged when the air bag inflates.
The air bag is designed to complement the action of the seat belt. Both
the air bags and seat belts are integral parts of the same protection
system. It is therefore essential to wear seat belts at all times. If seat belts
are not worn, the occupants are exposed to the risk of serious injury in
the event of an accident. It may also increase the risk of minor superficial injuries
occurring when the air bag is deployed, although such minor injuries are always
possible with air bags.
The airbags are not always triggered if the vehicle overturns or in the event of a
rear impact, however severe. Impacts to the underside of the vehicle (such as
from a pavement or stones, etc.) can cause this system to be triggered.
-
Any work or modification to any part of the airbag system (airbags, ECU, wiring,
etc.) is prohibited (except by qualified personnel from an authorised dealer).
Operating faults
-
To ensure that the system is in good working order and to avoid accidental trig-
gering of the system which may cause injury, only qualified Network personnel
This warning light 1 å
will light up
may work on the air bag system.
on the instrument panel when the igni-
-
As a safety precaution, have the air bag system checked if your vehicle has
tion is switched on and then go out after
been involved in an accident, or is stolen or broken into.
a few seconds.
-
When selling or lending the vehicle, inform the user of these points and hand
If it does not come on when the ignition
over this driver’s handbook with the vehicle.
is switched on, or if it comes on when
the engine is running, there is a fault
-
When scrapping your vehicle, contact your approved dealer for disposal of the
with the system (airbags, etc.) in the
gas generator(s).
front seats.
Contact your approved dealer as soon
as possible. Your protection will be re-
duced until this fault is rectified.
1.24
CHILD SAFETY: General information (1/2)
Carrying children
Children, and adults, must be correctly
seated and strapped in for all journeys.
The children being carried in your vehi-
cle are your responsibility.
A child is not a miniature adult. Children
are at risk of specific injuries as their
muscles and bones have not yet fin-
ished growing. The seat belt alone
would not provide suitable protection.
Use a booster seat and ensure you use
it correctly.
A collision at
30 mph
Driver’s responsibility
(50 km/h) is the same as fall-
when parking or stopping
ing a distance of 10 metres.
the vehicle
Transporting a child without
Never leave an animal,
a restraint is the equivalent of allow-
child or adult who is not self-suffi-
ing him or her to play on a fourth-
cient alone on your vehicle, even for
Driver’s responsibility
floor balcony without railings.
a short time.
Never use the storage
Never travel with a child held in your
space as a booster seat for
arms. In the event of an accident,
They may pose a risk of injury, such
a child or a pet. Otherwise,
you will not be able to keep hold of
as by starting the engine or activat-
this could place your child or pet in
the child, even if you yourself are
ing equipment.
danger, or endanger the driver, in
wearing a seat belt.
Risk of serious injury.
the event of hard braking or impact.
If your vehicle has been involved
in a road accident, replace the
Risk of death or serious injuries.
booster seat and have the seat belts
checked.
1.25
CHILD SAFETY: General information (2/2)
Use
Set a good example by always fas-
Only a booster seat should be used.
tening your seat belt and teaching
The level of protection offered by the
your child:
booster seat depends on its ability to
- to strap themselves in correctly;
restrain your child and on its installa-
- to always get in and out of the car
tion. Incorrect installation compromises
at the kerb, away from busy traf-
the protection it offers the child in the
fic.
event of harsh braking or an impact.
Do not use a second-hand child
Before purchasing a booster seat,
seat or one without an instruction
check that it complies with the regula-
manual.
tions for your country and that it can be
fitted in your vehicle. Consult an author-
Check that there are no objects in
ised dealer to find out which booster
the vicinity of the child seat which
seats are recommended for your vehi-
could impede its operation.
cle.
Before fitting a booster seat, read the
manual and follow its instructions. If you
Never leave a child unat-
experience any difficulties during instal-
tended in the vehicle.
lation, contact the equipment manu-
facturer. Keep the instructions with the
Check that your child is
booster seat.
always strapped in and that
the belt is correctly set and adjusted.
Never allow your child to stick their
head out of the window.
Check that the child is in the correct
position for the entire journey, espe-
cially if asleep.
1.26
CHILD SAFETY: booster seat
Only a booster seat should be used.
Booster cushions
From 15 kg or 4 years, the child can
travel using a booster seat, which will
enable the seat belt to be adapted
Driver’s responsibility
to suit his/her size and shape. The
Never use the storage
booster seat cushion must be fitted with
space as a booster seat for
guides to position the seat belt on the
a child or a pet. Otherwise,
child’s thighs rather than the stomach.
this could place your child or pet in
It is recommended that you use a seat-
danger, or endanger the driver, in
back fitted with a belt strap guide which
the event of hard braking or impact.
can be adjusted in terms of height to
position the seat belt in the centre of the
Risk of death or serious injuries.
shoulder. It must never rest on the neck
or on the arm.
Choose a bucket type seat for optimum
side protection.
1.27
CHILD SAFETY: attaching a booster seat
Attachment via the seat belt
Do not use the booster seat
The seat belt must be adjusted to
if it risks loosening the seat
ensure that it is effective in the event of
belt restraining it: the base
harsh braking or an impact.
of the booster seat must not
Ensure that the strap paths indicated by
rest on the buckle and/or catch of
the booster seat manufacturer are re-
the seat belt.
spected.
Always check that the seat belt is cor-
rectly fastened by pulling it up, then
pulling it out fully whilst pressing on the
booster seat.
Check that the booster seat is correctly
held by moving it from side to side and
back to front: the booster seat should
remain firmly fixed in place.
Check that the booster seat has not
been installed at an angle.
The seat belt must never
be twisted or the tension
relieved. Never pass the
shoulder strap under the
arm or behind the back.
Check that the seat belt has not
been damaged by sharp edges.
If the seat belt does not operate nor-
mally, it will not protect the child.
Consult an approved dealer. Do not
use this seat until the seat belt has
been repaired.
No modifications may be
made to the component
parts of the restraint system
originally fitted: belts, seats
and their mountings.
1.28
CHILD SAFETY: installing a booster seat (1/3)
In the rear seat
For child safety, move the front seat
as far forward as possible to install a
booster seat, then move it back as far
as it will go, without allowing it to come
into contact with the child.
Check that the booster seat is resting
against the back of the vehicle seat.
Check that when installing
the booster seat in the vehi-
cle, it is not at risk of coming
loose from its base.
Make sure that the booster
seat or the child’s feet do
Always attach the booster seat to
not prevent the front seat
the vehicle even if it is not in use so
from locking correctly. Refer
that it does not come loose under
to the information on the “Front seat”
hard braking or upon impact.
in Section 1.
1.29
CHILD SAFETY: installing a booster seat (2/3)
²
Seat not suitable for fitting child
seats.
Seat which only allows a stand-
ardised “Universal” booster seat to be
installed using a seat belt.
Using a child safety system
which is not approved for
this vehicle will not correctly
protect the baby or child.
They risk serious or even fatal injury.
1.30
CHILD SAFETY: installing a booster seat (3/3)
The table below summarises the information already shown on the diagram on the previous page, to ensure the regula-
tions in force are respected.
Type of child seat
Weight of the child
Rear seat
Carrycot fitted across the vehicle
< 10 kg
X
Group 0
Rear-facing shell seat
< 10 kg and < 13 kg
X
Group 0 or 0+
rear-facing seat
< to 13 kg and 9 to 18 kg
X
Group 0+ and 1
Forward-facing seat
9 to 18 kg
X
Group 1
Booster seat
15 to 25 kg and 22 to 36 kg
UF (1)
Group 2 and 3
X = Seat not suitable for fitting child seats.
UF = Seat which only allows a standardised “Universal” booster seat to be installed using a seat belt; check that it can be fitted.
(1) place the back of the booster seat against the vehicle seatback and move the front seat backwards without allowing it to come
into contact with the child.
1.31
DRIVING POSITION
The equipment fitted, described below, DEPENDS ON THE VERSION AND COUNTRY.
7 and 12 door mirrors
1
2
3
4
5
6
To adjust the mirrors, press on the
mirror.
8 Key ignition switch.
9 Handbrake.
10 Controls for:
- forward gear,
- neutral,
- reverse.
11 Hazard warning lights switch.
12
11
10
9
8
7
1
Storage and accessories socket.
5
- Windscreen wiper/washer stalk,
2
Stalk:
- On-board computer information
readout control,
- horn,
- windscreen de-icer control.
- direction indicator lights,
6
Lockable storage.
– exterior lights,
- horn.
3
Instrument panel.
4
Location for driver’s airbag.
1.32
WARNING LIGHTS (1/3)
The presence and operation of the warning lights DEPEND ON THE EQUIPMENT AND COUNTRY.
Side light tell-tale light
Air bag warning light
u
å
This comes on when the igni-
Main beam headlight tell-tale
tion is switched on and goes out after a
á
light
few seconds.
If it does not come on when the ignition
A
Direction indicator lights
d
is switched on, or lights up when driv-
ing, there is a system fault.
Engine immobiliser system
Contact your approved Dealer as soon
ê
warning light
as possible.
Refer to the information on the “Engine
Charging cord plugged in
immobiliser” in Section 1.
warning light
Vehicle ready for driving
This comes on when the charging cord
warning light
is plugged into an electricity supply.
Please see the information on “Starting,
stopping the engine” in Section 2.
Instrument panelA: lights up when the
ignition is switched on.
If no lights or sounds are ap-
parent, this indicates a fault
Warning light
®
re-
in the instrument panel. This
quires you to stop immedi-
indicates that it is essential
ately, for your own safety,
to stop immediately (as soon as traf-
Warning light ø
means you
as soon as traffic conditions
fic conditions allow). Ensure that the
should drive very carefully to an
allow. Switch off the engine and do
vehicle is correctly immobilised and
authorised dealer as soon as
not restart it. Contact an approved
contact an approved Dealer.
possible. If you fail to follow this
Dealer.
recommendation, you risk damag-
ing your vehicle.
1.33
WARNING LIGHTS (2/3)
The presence and operation of the warning lights DEPEND ON THE EQUIPMENT AND COUNTRY.
STOP light
12 V battery charge warning
®
Ú
This lights up when the ignition
light
is switched on and goes out as soon as
If it comes on, limit the non-essential
the engine is started. It lights up at the
use of any energy-consuming equip-
same time as other warning lights, and
ment and accessories.
A
is accompanied by a beep.
If it stays on, see an authorised dealer
as soon as possible.
It requires you to stop immediately, for
If it comes on together with the warning
your own safety, as soon as traffic con-
light® and a beep, this indicates a
ditions allow. Switch off the engine and
fault in the 12V battery charging circuit.
do not restart it.
Stop as soon as traffic conditions allow
Contact an approved Dealer.
and contact an authorised dealer.
Special feature: On steep slopes, a
Handbrake on and brake cir-
warning light will come on and a beep
D
cuit incident warning light
will sound if the vehicle is travelling
at excessive speed. You must then
This comes on when the ignition is
Warning light
reduce your speed. Risk of damage to
switched on and goes out as soon as
ø
This lights up when the ignition
the engine. The warning light goes out
the handbrake is released.
is switched on and goes out as soon as
once the vehicle speed drops below the
If it comes on during braking and is ac-
the engine is started. It may comes on
maximum set level.
companied by the
®
warning light
in conjunction with other warning lights
and a beep, it indicates that the fluid
Windscreen de-icing warn-
on the instrument panel.
level in the circuit is low or that there is
ing light.
It means you should drive very care-
a braking system fault.
fully to an approved dealer as soon as
Stop as soon as traffic conditions allow
possible. If you fail to follow this recom-
and contact an approved Dealer.
mendation, you risk damaging your ve-
hicle.
1.34
WARNING LIGHTS (3/3)
The presence and operation of the warning lights DEPEND ON THE EQUIPMENT AND COUNTRY.
Low traction battery level
warning light
1
This comes on when the traction bat-
tery charge level has reached the re-
serve threshold. Please see the infor-
A
mation on “Displays and indicators” in
Section 1.
Electrotechnical system
warning light
If it lights up while driving, this means
there is an electrotechnical fault in the
“58 volt” electrical circuit. Please see an
authorised dealer as soon as possible.
When the vehicle is started or while
driving, if it flashes accompanied by
Electrotechnical
system
Gear selector 1 position indicator (N,
warning light
the
®
warning light and a beep,
D or R).
When the warning light comes on, this
this indicates that the charging flap is
indicates the traction battery or the
open or not correctly closed. Stop and
engine temperature is too high. Opt for
switch off the ignition, make sure that
a calmer driving style.
the charging cord is disconnected and
The warning light can be accom-
that the flap is fully closed.
panied by a drop in vehicle perfor-
Not used
mance.
ERROR Not used
+
Not used
1.35
DISPLAYS AND INDICATORS (1/2)
The presence and operation of the display and indicators DEPENDS ON THE LEVEL OF EQUIPMENT AND THE COUNTRY.
Immobilisation threshold imminent
2
When the battery reaches less than 6%
charge, a beep repeats every 20 sec-
onds and warning light
flashes on
and off.
Motor performance gradually de-
creases until the vehicle comes to a
stop.
Please see the information on “Towing:
in the event of energy loss” in Section 5.
1
3
Charge meter 2
Please refer to the information on the
“Charge meter” in Section 2.
Charge level 1
Reserve level
The gauge indicates the level of energy
When the battery reaches approxi-
Speedometer 3
remaining.
mately 12% charge, warning light
comes on, along with a beep.
In kilometres or miles per hour.
NB: Each time you switch off the igni-
To optimise your range, please see the
tion, the remaining energy level will be
information on
“Recommendations:
calculated.
saving energy” in Section 2.
Once you switch on the ignition again,
you will see a slight change in the level
display.
1.36
DISPLAYS AND INDICATORS (2/2)
Forecast range display features
4
- Sporty driving will strongly affect
the forecast range value. Once you
return to a calmer driving style, you
5
will need to drive for several miles to
return to an estimate that is closer to
the real situation;
- the forecast range displayed after
charging the traction battery is calcu-
lated based on the power consump-
tion over the last 93 miles (150 kilo-
metres) travelled.
Instrument panel in miles
6
It is possible to switch to km/h.
Display 4
Zones 6 of the instrument panel dis-
Press button 5 and switch on the igni-
play the information detailed below by
Press and hold button 5 to reset the trip
tion.
pressing button 5 repeatedly:
mileage recorder. The display must be
The speed measurement unit indica-
- estimated range;
set to “Trip mileage recorder”.
tor flashes for approximately three sec-
- total mileage recorder;
onds, then the new unit flashes on the
- trip mileage recorder;
display and is then lit up continuously:
- Eco score;
release button 5.
- clock (CS : Clock setting).
To return to miles, proceed in the same
manner.
Note: resetting is automatic when
the maximum capacity of any of the
memories is exceeded.
1.37
CLOCK
- repeatedly press button 2 as neces-
1
sary to adjust the hour;
- press and hold button 2 to confirm
the hours.
The minute display flashes;
2
- repeatedly press button 2 as neces-
sary to adjust the minutes;
- press and hold button 2 to confirm
the minutes.
With the ignition switched on, the
clock is displayed on the instrument
panel.
Adjusting the time on the
instrument panel 1
- Press button 2 in quick succession,
as many times as necessary, to
obtain the time adjustment mode;
- press and hold button 2.
The hour reading flashes;
1.38
AUDIBLE AND VISUAL SIGNALS
Direction indicators
Move stalk 1 parallel to the steering
wheel and in the direction you are going
to turn it.
2
1
When driving on the motorway, the
steering wheel is not often turned
0
enough to return the stalk automatically
to 0.
There is also an intermediate position
in which the switch may be held when
changing lanes.
When the stalk is released, it automati-
cally returns to 0.
Horn
Hazard warning lights
é
Press the end of stalk 1.
Press switch 2. This switch
lights up all four indicators simulta-
neously. It must only be used in an
Headlight flasher
emergency to warn drivers of other ve-
Pull stalk 1 towards you to flash the
hicles that you have had to stop in an
headlights.
area where stopping is prohibited or
unexpected or that you are obliged to
drive under special conditions.
1.39
HORN
Electric vehicles are particularly quiet.
This system enables you to warn
1
2
people of your presence - especially
pedestrians and cyclists.
Activating the system
With the engine running, turn centre
ring 1 on the stalk until the symbol
faces mark 2.
Deactivating the system
Turn the centre ring 1 to position 0
again.
1.40
EXTERIOR LIGHTING AND SIGNALS (1/2)
Main beam headlights
á
With the stalk A in position
A
k
, pull it towards you. An indicator
1
2
light on the instrument panel will come
on.
A
To return to the dipped headlights posi-
tion, pull stalk A towards you again.
Switching off the lights
e
Return the stalk to its original
position. When the engine is started,
the dipped headlights stay on. They will
go out once the engine is switched off.
Daytime running lights
Dipped beam
k
headlights
The dipped headlights come on without
using the stalk A when the engine is
Manual operation
started.
Turn end 1 of stalk A until the symbol is
opposite mark 2.
Side lights
With the ignition switched off, it is not
u
Turn end 1 of stalk A until the
possible to operate the lights (to avoid
symbol is opposite mark 2.
lights being used when parked).
The instrument panel lighting dims.
When the vehicle is driven at
maximum permissible load (refer
to the information on «Weights» in
section 6), you must have the dipped
beam headlights adjusted, while it is
being used, by an Approved Dealer.
1.41















Content      ..      1      2      3      ..
