FUSES (3/3)
Allocation of fuses
(the presence of certain fuse depends on the vehicle equipment level)
Symbol
Allocation
D
Direction indicator lights, hazard warning lights
×
Brake lights
Use the fuse allocation label in the
storage compartment to identify the
fuses.
f
Rear windscreen wiper
Certain fuses should only be re-
placed by a qualified professional.
These fuses are not listed on the
One-touch electric windows
label.
Only change the fuses represented
Ý
Towbar socket
on the label.
Multimedia accessories socket, multimedia
î
screen
Check the fuse in question
Cigarette lighter, front and rear second row
and replace it, if neces-
Æ
accessories sockets
sary, by a fuse of the same
rating.
If a fuse is fitted where the rating is
too high, it may cause the electrical
circuit to overheat (risk of fire) in the
event of an item of equipment using
an excessive amount of current.
5.19
WIPER BLADES: replacement (1/2)
B
A
1
3
2
4
Replacing windscreen wiper
To refit
blades 2
To refit the wiper blade 2, insert it in its
housing in the arm 3, then clip it until
To replace the wipers, first put them in
you hear a click. Make sure that the
the service position B.
blade is correctly locked in position.
With the ignition on and the engine
To return the blades to lowered posi-
Keep monitoring the condition of the
stopped:
tion, make sure that the blades are
wiper blades. How long they last de-
- set the stalk 1 to position A twice in
folded down onto the windscreen then
pends on you:
succession (single sweep): the wiper
set the 1 stalk to position A (single
blades will stop in the service posi-
- clean the blades and the wind-
sweep): the windscreen wiper blades
tion B away from the bonnet;
screen regularly with soapy
will fold into the bonnet when the igni-
- press the button 4 firmly then remove
water;
tion is switched on.
the blade upwards.
- do not use them when the wind-
screen is dry;
- free them from the windscreen
when they have not been used
for a long time.
5.20
WIPER BLADES: replacement (2/2)
To refit
To refit the wiper blade, proceed in re-
5
verse order to removal. Make sure that
the blade is correctly locked in position.
C
- In frosty weather, make
sure that the wiper blades
are not stuck by ice
(to
6
avoid the risk of the motor
overheating).
- Check the condition of the wiper
blades.
They should be replaced as soon
Rear screen wiper blade 5
as they become less efficient: ap-
proximately once a year.
Stalk in stop position (deactivated):
When changing the blade, when it
-
lift the wiper arm 6;
has been removed, do not let the
-
pivot the rear screen wiper blade 5
wiper arm fall against the window:
(C movement) until it unclips;
risk of breaking the window.
Keep monitoring the condition of the
-
release rear screen wiper blade 5 by
wiper blades. How long they last de-
pulling on it.
pends on you:
- clean the blades and the wind-
screen regularly with soapy
water;
Before changing the rear
- do not use them when the wind-
wiper blade, make sure the
screen is dry;
stalk is in the stop position
(deactivated).
- free them from the windscreen
when they have not been used
Risk of injury.
for a long time.
5.21
TOWING: breakdown (1/3)
Before any towing, including on a flat-
bed truck, put the gear control in N po-
sition, unlock the steering column and
release the parking brake.
The speed specified by current legis-
lation for towing must always be ob-
served.
If you are driving the towing vehicle,
do not exceed the permissible towing
weight for your vehicle ➥ 6.6.
To carry out breakdown recovery on
a flatbed or to tow the vehicle using a
towing point (see the next page), ob-
serve the following instructions:
- card in the passenger compartment,
-
press the engine Start button for
Choice of towing
press the engine start button;
more than two seconds. The acces-
It is strictly forbidden to tow the vehicle
- set the gear control to position N
sories functions are supplied: you
with the front wheels on the ground.
➥ 2.5: the steering column unlocks
can use the vehicle lighting functions
and the parking brake is released;
(hazard warning lights, brake lights,
etc.). At night the vehicle lights must
be on;
-
once you have finished towing, press
Leave the card in the vehi-
the engine start button for more than
cle during towing.
two seconds (risk of discharging the
Risk of the steering
battery).
column locking.
Do not leave the tools unse-
cured inside the vehicle as
they may come loose under
braking.
5.22
TOWING: breakdown (2/3)
Access to towing points
Only use the front 2 and rear 5 towing
4
points (never use the driveshafts or any
other part of the vehicle). These towing
A
points may only be used for pulling.
They must never be used for lifting the
vehicle directly or indirectly.
1
B
Screw in the tow eye 3 by hand as far
5
as possible.
You must only use the towing eye 3.
2
3
3
Standard version
Rear towing point
Press and hold the area A while pulling
Front towing point
area B (using a flat-blade screwdriver
Press the upper section of the flap 1 to
or similar) to open the flap 4.
tilt it.
Ensure that the towing eye
is bolted correctly.
- Use a rigid towing bar. If a rope or cable is used (where the law allows
Risk of losing the towed
this), the vehicle being towed must be able to brake.
object.
- A vehicle must not be towed if it is not fit to be driven.
- Avoid accelerating or braking suddenly when towing, as this may result
in damage being caused to the vehicle.
When the engine is stopped,
- In all cases, it is advisable not to exceed 15.5 mph (25 km/h).
steering and braking assist-
ance are not operational.
5.23
TOWING: breakdown (3/3)
8
6
5
6
2
7
3
3
Sport version
Pull the part 6 to remove it and access
Rear towing point
the front towing point 2. The part 6 is
Insert a flat-blade screwdriver or simi-
Front towing point
held by a link in prevent it from being
lar in the recess provided, then pull to
lost.
Insert a finger through a hole in the
open the flap 8.
front bumper grille and push the clip 7
upwards to unclip the part 6.
5.24
OPERATING FAULTS (1/6)
The following advice will enable you to carry out quick, temporary repairs. For safety reasons you should always contact
an approved dealer as soon as possible.
FAULTS
POSSIBLE CAUSES
WHAT TO DO
Impossible to charge the traction bat-
The outdoor temperature is lower
Recharge your vehicle in a more suitable
tery.
than -26°C.
environment. If necessary ➥ 5.22.
The charging flap warning light flashes
red.
No electrical current in the wall
Check your installation (circuit breaker, pro-
socket or poor connection of the
grammer, etc.).
cable in the domestic socket.
Check the connections (charging socket,
etc.) ➥ 1.8.
The cord is defective.
Please see an authorised dealer to replace
it.
Impossible to charge the traction bat-
The charging cord is not correctly
Plug the charging cable correctly in to the
tery.
locked to the vehicle.
vehicle ➥ 1.8.
The charging flap warning light flashes
blue.
5.25
OPERATING FAULTS (2/6)
FAULTS
POSSIBLE CAUSES
WHAT TO DO
The card does not lock or unlock
Card battery is flat.
Replace the battery or have it replaced. You will
the doors.
still be able to lock, unlock, and start your vehicle
➥ 1.33 and ➥ 2.2.
Use of appliances operating on the
Stop using the devices or use the key provided
same frequency as the remote con-
➥ 1.33.
trol (mobile phone, etc.).
Vehicle located in a high electro-
Use the key that is built into the card ➥ 1.33.
magnetic radiation zone.
Secondary
12 volt battery dis-
charged.
Desynchronisation of the card.
Unlock the driver’s door by inserting the key in-
tegrated in the card into the door lock ➥ 1.33 then
place the card in the placement area ➥ 2.2 and
press the “START” button to synchronise the
card.
The message “Place the card
The card battery is flat or the card is
Check the card battery status or place the card in
near the START button” appears
out of synch.
the placement area ➥ 2.2 provided for this pur-
on the instrument panel.
pose.
5.26
OPERATING FAULTS (3/6)
FAULTS
POSSIBLE CAUSES
WHAT TO DO
Steering becomes heavy.
Assistance overheating.
Drive carefully at reduced speed, be aware of the
level of force in the steering wheel needed to turn
the wheels.
Fault with the electric assistance
Consult an authorised dealer.
motor.
Fault in the assistance system.
The steering column remains
Steering wheel locked.
Move the steering wheel while pressing the
locked.
engine start button ➥ 2.2.
5.27
OPERATING FAULTS (4/6)
Electrical equipment
POSSIBLE CAUSES
ACTION REQUIRED
Vibrations.
Tyres not inflated to correct pressures, Check the tyre pressures. If this is not the
incorrectly balanced or damaged.
problem, have them checked by an ap-
proved Dealer.
The wipers do not work.
Wiper blades stuck.
Free the blades before using the wipers.
Broken windscreen wiper fuse.
Consult an approved dealer.
Blown rear screen wiper fuse (intermit- Replace the fuse or have it replaced
tent, permanently stopped).
➥ 5.17.
Motor fault.
Consult an approved dealer.
The wiper does not stop.
Faulty electrical controls.
Consult an approved dealer.
Direction indicators flashing more quickly. LED blown.
Consult an approved dealer.
The indicators are
On one side only: LED blown.
Consult an approved dealer.
not working.
On both sides:
- blown fuse;
Replace the fuse or have it replaced
➥ 5.17.
- faulty flasher unit.
Needs replacing: please see an autho-
rised dealer.
5.28
OPERATING FAULTS (5/6)
Electrical equipment
POSSIBLE CAUSES
ACTION REQUIRED
The headlights
Only one:
- LED blown;
Consult an approved dealer.
are not working.
- disconnected wire or incorrectly-posi- Check and reconnect the wire or the con-
tioned connector.
nector.
Both:
the circuit is fused.
Check and replace if necessary.
The headlights do not switch off.
Faulty electrical controls.
Consult an approved dealer.
Traces of condensation in the headlights Traces of condensation may be a natu-
or rear lights.
ral phenomenon caused by variations in
temperature and humidity.
In this case, the traces will disappear
slowly once the lights are switched on.
5.29
OPERATING FAULTS (6/6)
Stopped
POSSIBLE CAUSES
ACTION REQUIRED
The air conditioning and ventilation fan
This is not necessarily a fault, the air con-
switch on after the ignition is switched
ditioning compressor and the ventilation
off or when the vehicle is being
fan switch on to regulate the temperature
charged.
of the system when the exterior tempera-
ture is low.
The air conditioning compressor and the
Consult an approved dealer.
ventilation fan switch on for more than
30 minutes when the ignition is switched
off.
The programmable air conditioning One of the usage conditions is not com-
➥ 3.17.
fails to work.
plied with
(the traction battery is not
charged, etc).
The passenger compartment air con-
This is not necessarily a fault, the system
To enter the extended life on board mode,
ditioning and the heating functions
switches off by default to preserve battery
press the Start button without pressing
are switched off with no action by the
autonomy or optimise recharging.
the brake pedal. The air conditioning nev-
user, even if the battery is sufficiently
ertheless stops after a few minutes.
charged.
You can always reactivate the system
by pressing the air conditioning controls
➥ 3.6 ➥ 3.11.
Electrical fault.
Consult an approved dealer.
5.30
Section 6: Technical Specifications
Vehicle identification plates
6.2
Technical Information for the emergency services
6.3
Engine identification, engine specification
6.4
Dimensions
6.5
Weights
6.6
Towing weights
6.6
Replacement parts and repairs
6.7
Service sheets
6.8
Anticorrosion check
6.14
6.1
VEHICLE IDENTIFICATION PLATES
A
1
2
3
4
5
A
9
6
7
8
The information shown on the ve-
4
MMAC (Maximum permissible
hicle identification plate should be
all-up weight).
quoted on all correspondence or
5
MTR (Gross train weight: vehicle
orders.
fully loaded, with trailer).
6
MMTA (Maximum Permissible
The presence and location of the in-
Weight) front axle.
formation depends on the vehicle.
7
MMTA rear axle.
8
Area reserved for related or addi-
Vehicle identification plate A
tional entries.
1
Manufacturer name.
9
Paint reference (colour code).
2
EC design number or approval
number.
B
3
Identification number.
Depending on the vehicle, this
information is also given on
markingB.
6.2
TECHNICAL INFORMATION FOR THE EMERGENCY SERVICES
A
A
The QR Code on the A label allows
emergency workers using a tablet or
smartphone to immediately access the
technical information useful for working
on the vehicle in the event of an acci-
dent.
Ensure that the A label is always visible
and present on the windscreen as well
as the rear screen.
Any modification or damage would
prevent access to the information.
6.3
ENGINE IDENTIFICATION, ENGINE SPECIFICATION
A
1
2
A
3
Please quote the information on the
Engine specification
engine plate or label A in all corre-
Engine type: 6AM
spondence or orders.
(Location varies depending on engine)
1
Engine type.
2
Engine suffix.
3
Engine serial number.
6.4
DIMENSIONS (in metres)
0,800
2,685
0,715
1,555 to 1,565
4,200
1,505*
1,545 to 1,555
* Unladen
1,768 to 1,782**
**
2,055 with rear view mirrors open
1,860 with rear view mirrors folded away
6.5
WEIGHTS (in kg)
The weights indicated for a basic vehicle without options: they vary depending on your vehicle’s equipment. Consult
your approved Dealer.
Maximum Permissible All-Up Weight (MMAC)
Maximum Permissible Weight (MMTA)
Weights indicated on the vehicle identification plate ➥ 6.2
Gross Train Weight (MTR)
Braked Trailer Weight*
found by calculating: MTR - MMAC
Unbraked Trailer Weight*
500 kg
Permissible nose weight*
75 kg
Maximum permissible load on roof
80 kg (including carrying device)
* Towing weight (towing a caravan, boat, etc.)
Towing is prohibited when the MTR - MMAC calculation is equal to zero, or when the MTR is equal to zero (or is not listed) on
the identification plate.
- It is important to respect local towing regulations in force, specifically those set out in the Highway Code. Contact an approved
Dealer for any modifications to towing equipment.
- When towing, under no circumstances may the total train weight (vehicle + trailer) be exceeded. However the following is
permitted:
- rear MMTA exceeded by no more than 15%;
- maximum MMAC exceeded by no more than 10% or 100 kg (whichever is reached first).
In either case, the maximum speed of the towing assembly must not exceed 62 mph (100 km/h) and the tyre pressure must
be increased by 0.2 bar (3 PSI).
- The engine output and climbing capability are reduced with altitude. We recommend that the maximum load be reduced by 10%
at an altitude of 1,000 metres and by an additional 10% for each 1,000 metres thereafter.
6.6
REPLACEMENT PARTS AND REPAIRS
Original parts are based on strict specifications and are subject to highly-specialised tests. Therefore, they are of at least the same
level of quality as the parts fitted originally.
If you always fit genuine replacement parts to your vehicle, you will ensure that it performs well. Furthermore, repairs carried out
within the manufacturer’s Network using original parts are guaranteed according to the conditions set out on the reverse of the
repair order.
6.7















Content      ..     16      17      18
