BODYWORK MAINTENANCE (3/3)
Vehicles with a matte paint
Using a roller type car wash
Cleaning the headlights,
finish
Return the wiper stalk to the park posi-
sensors and cameras
This type of paint requires certain pre-
tion ➥ 1.121. Check the mounting of ex-
Use a soft cloth or cotton wool. If this
cautions.
ternal accessories, additional lights and
does not clean them properly, moisten
rear view mirrors, and ensure that the
the cloth with soapy water, then wipe
You should do the following
wiper blades are secured with adhesive
clean using a soft damp cloth or cotton
tape.
wool.
Wash the vehicle by hand using plenty
of water, using a soft cloth or a gentle
Remove the radio aerial mast if your
Finally, dry off carefully with a soft dry
sponge.
vehicle is fitted with this equipment.
cloth.
Remember to remove the tape and refit
Do not use cleaning products con-
Do not do the following
the antenna after washing.
taining alcohol or utensils (e.g.: a
Use wax-based products (polishing).
scraper).
Rub too hard.
Wash the vehicle in a roller-type car
wash.
Attach stickers to the paintwork (risk of
leaving marks).
Washing the vehicle
Never wash the engine
compartment, the charging
Wash the vehicle
connection or the traction
using a high-pressure
battery with a high-pressure jet.
cleaning device.
This risks damaging the electric
circuit.
Never wash the vehicle while it is
charging.
Risk of electric shock and a risk
to life.
4.13
INTERIOR TRIM MAINTENANCE (1/2)
A well-maintained vehicle will last
Glass instrument panel
Textiles (seats, door trim, etc)
longer. It is therefore recommended to
(e.g. instrument panel, clock, exterior
Vacuum-clean the textiles regularly.
maintain the interior of the vehicle regu-
temperature display etc.)
larly.
Use a soft cloth (or cotton wool).
Liquid stain
A stain should always be dealt with
If this does not clean them properly,
Use soapy water.
swiftly.
use a soft cloth (or cotton wool) slightly
Dab lightly (never rub) with a soft cloth,
Whatever type of stain is on the trim,
moistened with soapy water and then
rinse and remove the excess.
use cold (or tepid) soapy water with
wipe clean using another soft damp
natural soap.
cloth or cotton wool.
Solid or pasty stain
Detergents (washing-up liquid, pow-
Finally, dry off carefully with a soft dry
Carefully remove the excess solid or
dered products, alcohol-based prod-
cloth.
pasty material immediately using a
ucts) should not be used.
spatula (working from the edges to the
Do not use products containing alco-
Use a soft cloth.
hol and/or spray fluids on the area.
centre to avoid spreading the stain).
In the case of a liquid stain, clean as
Rinse and wipe up excess water.
indicated.
Seat belts
Special instructions for sweets or
Multimedia screen
These must be kept clean.
chewing gum
Maintenance of the screen may depend
Use products selected by our Technical
Place an ice cube on the stain to solid-
on the type of multimedia equipment.
Department
(approved outlets) or
ify it then proceed as for a solid stain.
Please refer to the multimedia instruc-
warm, soapy water and a sponge and
tions for further information.
wipe with a dry cloth.
Detergents or dyes must not be used
under any circumstances.
For further recommendations on
maintaining the interior and/or in
the event of unsatisfactory results,
please consult an approved dealer.
4.14
INTERIOR TRIM MAINTENANCE (2/2)
Removal/replacing removable
You should not:
equipment originally fitted in
Position objects such as deodorants,
the vehicle
scents etc. near air vents as this could
damage your dashboard trim.
If you need to remove equipment in
order to clean the passenger com-
partment (for example, mats), always
ensure that they are correctly refitted
and are the right way around (the driv-
Use high-pressure
er’s mat should be fitted on the driver’s
cleaning equipment or
side, etc.) and fit them with the compo-
sprays inside the pas-
nents supplied with the equipment (for
senger compartment:
example, the driver mat should always
without careful use, this equipment
be fixed using the pre-fitted mounting
could impair the correct functioning
components).
of the electrical or electronic compo-
With the vehicle stationary, always
nents in the vehicle, or have other
ensure that nothing will impede driving
detrimental effects.
(anything obstructing the pedals, heel
wedged by the mat etc.).
4.15
Section 5: Practical Advice
Tyre inflation kit
5.2
Tool kit
5.5
Tyres (tyre and wheel safety, use in winter)
5.6
Headlights (changing bulbs)
5.10
Rear lights (changing bulbs)
5.11
Indicator lights (changing bulbs)
5.12
interior lighting: changing bulbs
5.13
“Hands-free” card: battery
5.14
Accessories
5.16
Fuses
5.17
Wipers (replacing blades)
5.20
Towing
5.22
Operating faults
5.25
5.1
TYRE PRESSURE KIT (1/3)
Do not attempt to use the
The kit is only approved for
B
inflation kit if the tyre has
inflating the tyres of the ve-
been damaged as a result
hicle originally equipped
of driving with a puncture.
with the kit.
You should therefore carefully check
It must never be used to inflate
A
the condition of the tyre sidewalls
the tyres of another vehicle, or any
before any operation.
other inflatable object (rubber ring,
rubber boat, etc.).
Driving with underinflated, flat or
punctured tyres can be dangerous
Avoid spillage on skin when han-
and may make the tyre impossible
dling the repair product bottle. If
to repair.
droplets do leak out, rinse them off
with plenty of water.
This repair is temporary.
Keep the repair kit away from chil-
A tyre which has been punctured
dren.
should always be inspected (and re-
paired, where possible) as soon as
Do not dispose of the empty bottle
The kit repairs tyres when
possible by a specialist.
in the countryside. Return it to your
tread A has been dam-
approved dealer or to a recycling or-
aged by objects smaller
When taking a tyre which has been
ganisation.
than 6 mm. It cannot repair
repaired using this kit to be replaced,
all types of puncture, such as cuts
you must inform the specialist.
The bottle has a limited service
larger than 6 mm, or cuts in tyre
life which is indicated on its label.
When driving, vibration may be felt
sidewall B.
Check the expiry date.
due to the presence of the repair
Ensure also that the wheel rim is in
product injected into the tyre.
Contact an approved dealer to re-
good condition.
place the inflation tube and repair
product bottle.
Do not pull out the foreign body
causing the puncture if it is still in
the tyre.
5.2
TYRE PRESSURE KIT (2/3)
With the engine running and hand-
If a minimum pressure of 1.8 bar is
brake applied:
not reached after 15 minutes, repair
is not possible; do not drive the ve-
- disconnect any accessories previ-
hicle but contact an approved dealer.
ously connected to the vehicle’s ac-
cessories sockets;
- refer to the information on the in-
2
flation kit compressor located in
1
the luggage compartment of the ve-
hicle and follow the instructions;
- inflate the tyre to the recommended
pressure ➥ 4.7;
Before using this kit, park
- after a maximum of 15 minutes, stop
the vehicle at a sufficient
inflating and read the pressure (on
distance from traffic, switch
pressure gauge 2);
on the hazard warning
In the event of a puncture, use the kit
Note: while the bottle is emptying (ap-
lights, apply the handbrake, ask all
located in the boot.
proximately 30 seconds), the pressure
passengers to leave the vehicle and
gauge 2 will indicate briefly a pressure
keep them away from traffic.
Vehicle fitted with a tyre pressure
of 6 bar, then the pressure drops.
monitoring system
- Adjust the pressure: to increase
In the event of under-inflation (punc-
it, continue inflation with the kit; to
tures, etc.), the
warning light
reduce it, press button 1.
appears on the instrument panel
If the vehicle is parked on
➥ 2.22.
the hard shoulder, you must
warn other road users of
your vehicle’s presence
with a warning triangle or with other
devices as per the legislation apply-
ing to the country you are in.
5.3
TYRE PRESSURE KIT (3/3)
- Start immediately and drive at a
speed between 12 to 37 mph (20 to
60 km/h) in order to distribute the
3
product evenly in the tyre; after driv-
ing a distance of 2 miles (3 km), stop
Please be aware that a
and check the pressure.
poorly tightened or miss-
- If the pressure is higher than 1.3 bar
ing valve cap can make the
but lower than the recommended
tyres less airtight and may
pressure (refer to the label affixed to
lead to pressure loss.
the edge of the driver’s door), adjust
it. Otherwise, contact an approved
Always use valve caps identical to
dealer: the tyre cannot be repaired.
those fitted originally and tighten
them fully.
Precautions when using the
kit
Once
the
tyre is
correctly inflated,
The kit should not be operated for more
remove the kit: unscrew the inflation
than 15 consecutive minutes.
adapter slowly from the container 3 to
The container must be replaced after
Following repair with the kit,
prevent any product spatter and store
the first use even if liquid remains
do not travel further than
the container in plastic packaging to
inside.
124 miles (200 km).
prevent product leaks.
In addition, reduce your
- Affix the driving recommendation
speed and under no circumstances
label (located under the container) to
exceed 50 mph (80 km/h). The
the dashboard where the driver can
sticker, which you must affix in a
see it.
prominent position on the dash-
- Put the kit away.
Nothing should be placed
board, reminds you of this.
- At the end of this initial inflation op-
around the driver’s feet
eration, air will still escape from the
Depending on the country or local
as such objects may slide
tyre. You must drive a short distance
legislation, a tyre repaired with the
under the pedals during
in order to seal the hole.
inflation kit may need to be replaced.
sudden braking manoeuvres and
obstruct their use.
5.4
TOOL KIT
After use, ensure the tools are correctly
1
2
3
stored.
A
B
The tools included in the tool kit depend
on the vehicle.
The tool kits A and B are located in the
luggage compartment side pockets.
Open the flaps of the side pockets to
access the tools.
The tool kit A consists of the tyre infla-
tion kit compressor 1 ➥ 5.2 and the
Do not leave the tools un-
towing eye 2 ➥ 5.22.
secured inside the vehicle
The tool kit B includes the bottle of an-
as they may come loose
ti-puncture product 3 ➥ 5.2.
under braking. After use,
check that all the tools are correctly
clipped into the tool kit, then position
it correctly in its housing to reduce
the risk of injury.
5.5
TYRES (1/4)
The tyres are the only contact between
When the tyre tread has been worn to
the vehicle and the road, so it is essen-
1
the level of the wear indicators, they
tial to keep them in good condition.
become visible2: it is then necessary
to replace your tyres because the tread
You must make sure that your tyres
rubber is no more than 1.6 mm deep,
comply with the local regulations set
resulting in poor roadholding on wet
out in the Highway Code.
roads.
An overloaded vehicle, long journeys
by motorway, particularly in very hot
weather, or continual driving on poorly
surfaced minor roads will lead to more
rapid tyre wear and affect safety.
2
Maintaining the tyres
The tyres must be in good condition
and the tread form must have sufficient
depth; tyres approved by our Technical
Department have tread wear indica-
tors 1, which are wear warning strips
moulded into the tread at several
points.
Incidents which occur when
driving, such as striking the
kerb, may damage the tyres
and wheel rims, and could
also lead to misalignment of the
front or rear axle geometry. In this
case, have the condition of these
checked by an approved dealer.
5.6
TYRES (2/4)
Tyre pressures
Pressures should be checked when the
Vehicle fitted with a tyre pressure
tyres are cold; ignore higher pressures
monitoring system
Adhere to the tyre pressures. The tyre
which may be reached in hot weather
pressures should be checked at least
In the event of under-inflation (punc-
or following a journey at high speed.
once a month and additionally before
tures, etc.), the
warning light
any long journey (refer to the label af-
If tyre pressures cannot be checked
appears on the instrument panel
fixed to the edge of the driver’s door)
when the tyres are cold, the normal
➥ 2.22.
➥ 4.7.
pressures must be increased by 0.2 to
0.3 bar (or 3 PSI).
Never deflate a hot tyre.
Incorrect tyre pressures
lead to abnormal tyre wear
and unusually hot running.
These are factors which
may seriously affect safety and lead
to:
- poor road holding;
- risk of bursting or tread separa-
tion.
Please be aware that a
The pressure depends on the load
poorly tightened or miss-
and the speed of use. Adjust the
ing valve cap can make the
pressure according to the condi-
tyres less airtight and lead
tions of use (refer to the label affixed
to pressure loss.
to the edge of the driver’s door).
Always use valve caps identical to
It is not permissible to ex-
those fitted originally and tighten
change the
18” and
20”
them fully.
front wheels (tyres and/or
rims) with the rear wheels.
5.7
TYRES (3/4)
Fitting new tyres
Use in winter
Snow or Winter tyres
To fit new tyres, consult an approved
Chains
We would recommend that these be
dealer.
fitted to all four wheels to ensure that
For safety reasons, fitting snow
your vehicle retains maximum adhe-
chains to the rear axle is strictly for-
sion.
bidden.
Warning: These tyres sometimes have
Chains cannot be fitted to tyres which
a specific direction of rotation and a
are larger than those originally fitted to
maximum speed index which may be
the vehicle.
lower than the maximum speed of your
For your safety, please re-
One-way tyres
vehicle.
spect the speed limit.
An one-way tyre must only be fitted in
When they need to be re-
one direction. You must observe this di-
placed, only tyres of the
rection.
same make, size, type and profile
should be used on a single axle.
If an one-way tyre must be fitted in the
opposite to its direction of rotation fol-
They must: either have a load ca-
lowing a puncture, drive with caution,
pacity and a speed capacity at
particularly on a wet road, because the
least equal to the original tyres,
tyre specifications will not be adapted.
or correspond to those recom-
mended by your authorised
dealer.
Chains may only be fitted
Failure to heed these instructions
to tyres of the same size
could endanger your safety and
as those originally fitted to
affect your vehicle’s roadworthi-
your vehicle.
ness.
Chains may be fitted, provided that
Risk of loss of control of the ve-
they are specific chains. We would
hicle.
Vehicles fitted with 20”
advise you to consult an approved
wheels.
dealer.
The use of chains or other
specific equipment (snow
socks, etc.) is strictly forbidden.
5.8
TYRES (4/4)
Studded tyres
This type of equipment may only be
used for a limited period and as laid
down by local legislation. It is neces-
sary to observe the speed specified by
current legislation.
These tyres must, at a minimum, be
fitted to the two front wheels.
Note: the use of snow tyres, winter
tyres or studded tyres significantly re-
duces the vehicle range.
In all cases, we would recommend
that you contact an approved Dealer
who will be able to advise you on
the choice of equipment which is
most suitable for your vehicle.
5.9
FRONT HEADLIGHTS: replacing the bulbs
1
2
LED dipped beam/main beam
headlights 1
Please see an authorised dealer.
LED daytime running
Any operation on (or modi-
lights/side lights/direction
fication to) the electrical
indicators 2
system must be performed
Please see an authorised dealer.
by an approved dealer
since an incorrect connection might
damage the electrical equipment
(harness, components and in partic-
ular the alternator). In addition, your
Dealer has all the parts required for
fitting these units.
5.10
REAR LIGHTS AND SIDE LIGHTS: changing bulbs (1/2)
1
LED direction indicator/brake
and side lights 3
Consult an approved dealer.
3
2
High-level LED brake light 1
Consult an approved dealer.
LED reversing lights and rear
fog lights 2
Consult an approved dealer.
5.11
REAR AND SIDE LIGHTS: changing bulbs (2/2)
4
5
LED number plate lights 4
Indicator lights 5
Consult an approved dealer.
Consult an approved dealer.
5.12
INTERIOR LIGHTING: changing bulbs
3
1
2
4
Reading lights 1 and 2
Courtesy mirror lights 3
Luggage compartment light 4
Consult an authorised dealer.
Please consult an authorised dealer.
Consult an authorised dealer.
5.13
“HANDS-FREE” CARD: battery (1/2)
1
A
The batteries are available from ap-
proved Dealers, and their service
life approximately two years. Check
that there is no dye on the battery:
risk of an incorrect electrical con-
2
tact.
Replacing the battery
When refitting, proceed in the reverse
If they need to be replaced,
order, then press one of the buttons on
be sure to use the same
When the message “Keycard Battery
the card four times, close to the vehicle:
or equivalent type of bat-
Low” appears on the instrument panel,
the next time the vehicle is started, the
tery (consult an Approved
replace the battery in the card:
message will disappear.
Dealer).
- slide the rear casing 1 downwards
while pressing on zone A;
Check that the cover is clipped shut.
- remove the battery cover 2;
Note: Do not touch the electronic circuit
- remove the battery by pressing on
or contacts on the card when replacing
one side and lifting the other;
the battery.
When replacing:
- replace it according to the direction
and template indicated inside the
- make sure that the batter-
cover.
ies are correctly inserted.
Risk of explosion.
- if the flap does not close cor-
rectly, do not use the card and
keep out of reach of children.
5.14
“HANDS-FREE” CARD: battery (2/2)
Operating faults
If the battery is too weak to ensure cor-
rect operation, you will still be able to
start and lock/unlock the vehicle
➥ 1.33.
Precautions relating to
batteries:
- keep (new or used) bat-
teries out of reach of chil-
dren;
- do not swallow batteries;
Risk of chemical burns which
may lead to death.
- if ingested or inserted into any
part of the body, consult a doctor
as soon as possible.
Do not throw away your used bat-
teries; give them to an organisation
responsible for collecting and recy-
cling batteries.
5.15
ACCESSORIES
Electrical and electronic accessories
Before installing this type of accessory (particularly for transmitters/receivers: frequency bandwidth, power level, po-
sition of the aerial, etc.), make sure it is compatible with your vehicle. You can get advice from an authorised dealer.
Before connecting an accessory to a socket, please ensure that you do not exceed the maximum power authorised for
the socket ➥ 3.21 ➥ 3.31. Fire hazard.
No work may be carried out on the vehicle’s electrical or radio circuits, except by approved Dealers: an incorrectly connected
system may result in damage being caused to the electrical equipment and/or the components connected to it.
If the vehicle is fitted with any aftermarket electrical equipment, make sure that the installation is correctly protected by a fuse.
Establish the rating and position of this fuse.
Using the diagnostic socket
The use of electronic accessories on the diagnostic socket may cause serious disturbance to the vehicle’s electronic systems.
For your safety we recommend that you use only electronic accessories approved by the manufacturer, consult an Approved
Dealer. Serious accident risk.
Use of transmission/receiving devices (telephones, CB equipment etc.).
Telephones and CB equipment with integrated aerials may cause interference to the electronic systems originally fitted to the
vehicle: it is advisable only to use equipment with an external aerial. Furthermore, we remind you of the need to conform
to the legislation in force concerning the use of such equipment.
Fitting after-market accessories
If you wish to install accessories on the vehicle: please contact an authorised dealer. Also, to ensure the correct operation of
your vehicle, and to avoid any risk to your safety, we recommend that you use only accessories specifically designed for your
vehicle, which are the only accessories for which the manufacturer will provide a warranty.
If you are using an anti-theft device, only attach it to the brake pedal.
Obstructions to the driver
On the driver’s side, only use mats suitable for the vehicle, attached with the pre-fitted components, and check the fitting reg-
ularly. Do not lay one mat on top of another. There is a risk of wedging the pedals
5.16
FUSES (1/3)
1
C
3
B
A
2
Fuse box
Once open, turn the stops 2 a quarter of
Unhook the 3 wire to release the stor-
a turn (movements B and C) to remove
age compartment door to access the
If any electrical component does not
them.
fuse box.
work, check the condition of the fuses.
The fuses are accessible behind the
storage compartment A. Open the stor-
age compartment door A using the
open button 1.
5.17
FUSES (2/3)
4
5
Tilt the storage compartment door A
Tweezers 5
downwards as far as it will go.
Remove the fuse using the tweezers 5
You have direct access to the fuse com-
located on the fuse plate.
partment 4.
To remove the fuse from the tweezers,
slide the fuse to the side.
It is not advisable to use the free fuse
Check the fuse in question
locations.
and replace it, if neces-
sary, by a fuse of the same
rating.
If a fuse is fitted where the rating is
too high, it may cause the electrical
circuit to overheat (risk of fire) in the
In accordance with local legislation
event of an item of equipment using
or as a precautionary measure:
an excessive amount of current.
Obtain an emergency kit containing
a set of spare bulbs and fuses from
an approved Dealer.
5.18















Content      ..     15      16      17      18     ..
