Renault Megane Electric (2022 year). Manual in english - page 9





LANE DEPARTURE PREVENTION (5/6)
- “Lane departure anticipation”: adjust
Operating faults
the line detection sensitivity level. To
When the system detects an operating
do this, select:
fault, the left-hand and right-hand line
- “Late”: line detected when cross-
ing;
indicators and the
warning light
2
remain in grey on the instrument panel.
- “Standard”: line detected on ap-
proach;
In some cases, they are accompanied
by:
- “Early”: line detected nearby.
- the message “Driving assist unavail-
Please refer to the multimedia instruc-
able”;
tions for further information.
- the
warning light and the
message “Check Driving assist” or
the message “Check Front camera”.
Consult an approved dealer.
Adjustment
To access the multimedia screen func-
tion settings 2, refer to the multimedia
instructions:
- “Alert vibration”: adjust the “Lane de-
parture warning” function steering
wheel vibration level;
2.41
LANE DEPARTURE PREVENTION (6/6)
This function is an additional driving aid. This function is not under any circumstances intended to replace the due care
and attention of the driver, who should at all times be in control of the vehicle.
System servicing/repairs
- In the event of an impact, the camera alignment may be changed, and its operation may consequently be affected. Deactivate
the function and consult an authorised dealer.
- Any work in the area where the camera is located (repairs, replacements, windscreen modifications etc.) must be carried
out by a qualified professional.
Only an authorised dealer is qualified to service the system.
In the event of system disturbance
Some conditions can disturb or damage the operation of the system, such as:
- windscreen obscured (by dirt, ice, snow, condensation etc.);
- a complex environment (tunnel etc.);
- poor weather conditions (snow, rain, hail, black ice etc.) ;
- poor visibility (night, fog etc.);
- the road markings are irregular or difficult to distinguish (e.g. partially erased, excessive spacing, uneven road surface, etc.)
;
- being dazzled (glaring sun, lights of vehicles travelling in the opposite direction etc.);
- the road is narrow, winding or undulating (tight bends etc.);
- closely following a vehicle travelling in the same lane.
In this case, the function “Lane crossing prevention” may trigger incorrectly or not at all.
Risk of unwanted, incorrect correction or no correction of trajectory.
Deactivating the function
You must disable the function if:
- the area of the camera has been damaged (on the windscreen side or the interior rear-view mirror side);
- the road is slippery (snow, black ice, aquaplaning, gravel etc.) ;
- poor visibility (night, fog etc.);
- the windscreen is cracked or distorted (do not carry out windscreen repairs in this area; have it changed by an Authorised
Dealer);
- the vehicle is towing a trailer or a caravan;
- the vehicle is entering an area with several surface markings (an area with road works etc.).
2.42
BLIND SPOT WARNING (1/6)
B
A
C
A
B
Using information from the sensors in-
Special feature
stalled on each side of the rear bumper
Ensure that the C area around the
(area C), the function warns the driver:
radars on each side of the rear bumper
- when another vehicle is in the blind
are not obstructed (by dirt, mud, snow
spot area A and travelling in the
The function does not notify the
etc.)
same direction as your vehicle;
driver if the other vehicles are not
If a radar is obscured, the message
moving.
and/or
“Side radars no visibility” will appear on
the instrument panel. Clean the area
- when there is a risk of collision with a
This function is an addi-
where the sensors are located.
vehicle that is in the B area and driv-
ing faster than you on an adjoining
tional driving aid. This func-
lane.
tion is not under any cir-
cumstances intended to
The function warns you when your ve-
replace the due care and attention
hicle is travelling at a speed above ap-
of the driver, who should at all times
proximately 9 mph (15 km/h).
be in control of the vehicle.
2.43
BLIND SPOT WARNING (2/6)
2
1
3
Activation/deactivation
Indicator 2
To activate or deactivate the function
An indicator light 2 is located on each
via the multimedia screen 1, refer to the
rear view mirror 3.
multimedia instructions.
Note:
Select ON or OFF.
- clean the rear view mirrors 3 regu-
larly, so that the indicator lights 2 can
be seen properly;
- if you overtake another vehicle, the 2
indicator will only come on if that ve-
hicle remains in your vehicle’s blind
spot A long enough.
The system’s detection range oper-
ates according to a standard lane
width. When driving in a narrow
lane, the function can warn you
when a vehicle is detected beyond
the adjacent lane.
2.44
BLIND SPOT WARNING (3/6)
Display E
Conditions for non-function
2
Direction indicator activated, the 2
- When driving on a road with tight
warning light flashes when the func-
bends;
tion detects a vehicle in the blind spot
- in reverse.
warning area and/or a vehicle is rapidly
D
approaching from the rear on the side
If the vehicle is equipped with a towbar
towards which you will turn the wheel.
recognised by the system, the mes-
If you cancel the direction indicator, the
sage “Trailer: blind spot warning off” is
function will return to the initial warning
displayed on the instrument panel in-
(display D).
forming you that the function is not op-
erational.
E
For information on the range of equip-
ment adapted to your vehicle, we advise
you to consult an approved Dealer.
Display D
First warning: direction indicator not
activated, the 2 warning light indicates
that a vehicle is detected in the blind
spot area and/or that a vehicle is rap-
idly approaching from the rear in an ad-
jacent lane.
When the engine is started, the
system adopts the last status saved
before the ignition was switched off
(refer to the previous pages).
2.45
BLIND SPOT WARNING (4/6)
Operating faults
If the system detects a fault, the mes-
sage “Side radars to check” is displayed
on the instrument panel. Consult an ap-
proved dealer.
-The system’s detection
range operates according
to a standard lane width. If
you are driving in wide traf-
fic lanes, the system might not
be able to detect a vehicle in the
blind spot.
- The system might be disrupted
momentarily if it is exposed to
strong electromagnetic waves
(as beneath high-tension power
lines) or to very poor weather
conditions
(heavy rain, snow
etc.). Remain aware of driving
Due to the presence of sensors
conditions.
behind the bumper, it is advisable to
entrust any operation on the bumper
There is a risk of accidents.
(repair, replacement, paintwork,
etc.) to a qualified professional.
2.46
BLIND SPOT WARNING (5/6)
This function is an additional driving aid. This function is not under any circumstances intended to replace the due care
and attention of the driver, who should at all times be in control of the vehicle.
The driver should always adapt their speed to the traffic conditions, regardless of the system indications.
The system should under no circumstances be taken to be an obstacle detector or an anti-collision system.
System servicing/repairs
- In the event of an impact, radar alignment may be changed, and its operation will consequently be affected. Deactivate the
function and consult an authorised dealer.
- Any work in the area where the radars are located (repairs, replacements, etc.) must be carried out by a qualified profes-
sional.
Only an authorised dealer is qualified to service the system.
System disturbance
Some conditions can disturb or damage the operation of the system, such as:
- complex surroundings (metal bridges, tunnels, roads with barriers at the edge, etc.);
- poor weather conditions (snow, hail, black ice, etc.).
Risk of false alarms or absence of warnings
In the event of the system behaving abnormally, deactivate it and consult an authorised dealer.
2.47
BLIND SPOT WARNING (6/6)
Limitation of the system operation
- The radar area should be kept clean and free of any modifications in order to ensure the proper operation of the
system.
- Small objects moving close to the vehicle (motorcycles, bicycles, pedestrians, etc.) may not be recognised by the system.
- When turning into a bend, the radars may temporarily cease to detect vehicles in adjacent lanes.
- The function may warn you late if two other vehicles are approaching from the rear, driving side by side in the adjacent lanes
(i.e. driving on a 3-lane road) at a much higher speed than your vehicle.
- The system may not provide a warning when the other vehicles are travelling at a significantly different speed.
- If the vehicle is being overtaken by a long vehicle (e.g. heavy goods vehicle overtaking at a similar speed to the vehicle) the
system may interrupt the warning before the end of the manoeuvre.
- The vehicle is travelling on a winding road.
Deactivating the function
You must disable the function if:
- the radar area has been damaged (rear bumper);
- the vehicle is fitted with a towbar that is not recognised by the system.
2.48
SAFE DISTANCE ALERT (1/3)
Location of the camera 1
1
3
Make sure the windscreen is not ob-
scured (by dirt, mud, snow, condensa-
tion etc.).
Location of the radar 2
Ensure that the radar area is not ob-
structed (by dirt, mud, snow, a badly
fitted front number plate), impacted,
modified (including painting) or hidden
by any accessory fitted on the front of
the vehicle (on the grille or logo etc.).
2
Using the information from the radar 2
Activation/deactivation from
and camera 1, this function informs the
the multimedia screen 3
driver of the time interval between their
From the “Vehicle” World of your 3 mul-
vehicle and the vehicle in front so that a
timedia screen, press the “Driving as-
safe stopping distance between the two
sistance” menu.
vehicles can be maintained.
Activate or deactivate the “Following
The function is activated when the ve-
distance” function.
hicle speed is between about 19 and
93 mph or 99 mph (30 and 150 or 160
This function is an addi-
km/h), depending on the vehicle.
tional driving aid. This func-
tion is not under any cir-
cumstances intended to
replace the due care and attention
of the driver, who should at all times
Each time the vehicle is started,
be in control of the vehicle.
the function continues the mode
saved the last time the engine was
stopped.
2.49
SAFE DISTANCE ALERT (2/3)
- C (orange): the time interval falls be-
8
tween around 1 and 2 seconds (in-
A
sufficient distance between the two
vehicles);
- D (red): the time interval is less than
B
or equal to around one second (very
insufficient distance between the two
The measurement is dis-
vehicles).
played for information: the
If the interval between the two vehicles
system does not carry out
C
is less than around 0.5 seconds, notifi-
any action on the vehicle.
cation 8, display D, will remain lit red on
This function is not designed for use
the instrument panel.
in urban conditions or for a dynamic
D
Under certain conditions, the time inter-
driving style (sudden cornering, ac-
val may not be displayed:
celeration, braking, etc.), but rather
for stable driving conditions.
- while cornering;
Operation
The function does not interact with
- when changing lane;
With the function activated, the 8 in-
the braking system.
dicator is displayed on the instrument
- if the vehicle in front is sufficiently far
The radar and camera zones must
panel and informs the driver of the dis-
or outside the range of the radar or
be kept clean and free of any tam-
tance between their vehicle and the ve-
camera.
pering in order to ensure the proper
hicle in front.
operation of the system.
- A (grey): function not operational;
Any work carried out in the area
- A (green): no vehicle detected;
where the radar or camera is lo-
cated (repairs, replacements, wind-
- B (green): the time interval is greater
screen and/or bumper modifica-
than or equal to around two seconds
tions, etc.) must be carried out by a
(distance between the two vehicles
qualified professional.
adapted to your speed);
2.50
SAFE DISTANCE ALERT (3/3)
This function is an additional driving aid. This function is not under any circumstances intended to replace the due care
and attention of the driver, who should at all times be in control of the vehicle.
System servicing/repairs
- In the event of an impact, the radar and/or camera alignment may be changed and its operation may consequently be af-
fected. Deactivate the function and consult an authorised dealer.
- Any work carried out in the area where the radar and/or camera is located (replacements, repairs, windscreen and/or
bumper modifications, etc.) must be carried out by a qualified professional.
Only an authorised dealer is qualified to service the system.
In the event of system disturbance
- obstruction of the windscreen or the bumper (by dirt, glass, snow, condensation, etc.);
- a complex environment (metal bridge, tunnel etc.);
- poor weather conditions (snow, hail, black ice etc.);
- poor visibility (night, fog etc.);
- poor contrast between the vehicle preceding it and the surrounding area (e.g. white vehicle in a snowy area etc.) ;
- being dazzled (glaring sun, lights of vehicles travelling in the opposite direction etc.);
- the road is narrow, winding and undulating (tight bends etc.)
Risk of erroneous false alarms.
2.51
ADVANCED SAFETY (1/17)
The “Advanced safety” system com-
1
prises:
- active emergency braking;
and
3
- emergency lane departure preven-
tion.
The “Advanced safety” system uses
information from the camera 1, front
radar 2 and, depending on the vehicle,
side radars 3.
2
Location of the camera 1
Location of the side radars 3
Make sure the windscreen is not ob-
Ensure that the radar area is not ob-
scured (by dirt, mud, snow, condensa-
structed (by dirt, mud, snow etc.), im-
tion etc.).
pacted or modified (including paintwork
etc.).
Location of the front radar 2
Ensure that the radar area is not ob-
structed
(dirt, mud, snow, a badly
fitted/attached front number plate), im-
This system provides an
pacted, modified (including paintwork)
additional driving aid.
or hidden by any accessory fitted on
This system is not, under
the front of the vehicle (on the front
any circumstances, in-
bumper, logo, etc.)
tended to replace the due care and
Depending on the sensitivity setting
attention of the driver, who should at
selected, the “Lane crossing pre-
all times be in control of the vehicle.
vention” function may operate prior
to operation of the “Emergency lane
departure prevention” system.
2.52
ADVANCED SAFETY (2/17)
4
Activating, deactivating the system
from the multimedia screen 4
From the “Vehicle” World on your multi-
media screen 4, press the “Driving as-
sistance” menu, then the “Advanced
safety” menu to access the activation/
deactivation of the function.
The
warning light appears in
yellow on the instrument panel when
the system is deactivated.
When the system is activated, the
warning light disappears.
This system is reactivated each time
the ignition is switched on.
2.53
ADVANCED SAFETY (3/17)
The system informs the driver if there
1
is a risk of head-on collision to enable
appropriate emergency manoeuvres
(pressing the brake pedal and/or turn-
ing the steering wheel).
Depending on the reactivity of the
driver, the system can assist with brak-
ing in order to limit damage or prevent
a collision.
2
Active emergency braking
The system uses information from the
radar 2 and the camera 1 to determine
the distance from your vehicle:
- from the vehicle ahead in the same
lane;
or
This system can apply maximum
- from any oncoming vehicles in the
This function is an addi-
braking to the vehicle until it is
context of a manoeuvre to change
tional driving aid.
completely stationary if necessary.
direction;
or
This function is not under
For safety reasons, always wear
any circumstances in-
your seat belt when travelling in
- surrounding pedestrians and cy-
tended to replace the due care and
your vehicle and make sure that it
clists.
attention of the driver, who should at
is loaded so that no items can be
all times be in control of the vehicle.
thrown forward and hit the occu-
pants.
2.54
ADVANCED SAFETY (4/17)
Collision risk alert
Note: if the driver uses the vehicle con-
trols (steering wheel, pedals, etc.) the
The
red warning light or, de-
system may delay certain operations or
pending on the vehicle, the display 5
not activate.
and the “Brake” message appears on
the instrument panel, accompanied by
a beep and a haptic warning (micro
braking according to the sensitivity
5
level and speed).
If the driver presses the brake pedal
and the system still detects a risk of
collision, the braking force may be in-
creased if it is not sufficient to prevent
the collision.
Triggering of braking
Active emergency braking
If the driver fails to react following the
(continued)
alert and collision becomes imminent.
Detection of vehicles
If active emergency braking has caused
When driving, from approximately
the vehicle to stop, the vehicle is kept
5 mph (8 km/h), if there is a risk of col-
stationary for a short time. Beyond this
lision with the vehicle in front or with a
time limit, the vehicle must be held sta-
vehicle moving in the opposite direc-
tionary by the driver keeping their foot
tion when changing direction or with a
on the brake pedal.
stationary vehicle, the system will warn
you of a risk of collision or may trigger
In the event of emergency manoeu-
braking.
vre, you can stop braking at any
moment by:
- tapping the accelerator pedal;
or
- turning the steering wheel as a
collision avoidance manoeuvre.
2.55
ADVANCED SAFETY (5/17)
Active emergency braking
Special features of stationary
(continued)
vehicles
Stationary vehicles are detected when
Special features of oncoming
your vehicle is being driven at a speed
vehicles in the context of a
between approximately 5 mph (8 km/h)
manoeuvre to change direction
and 50 mph (80 km/h). The system is
When you wish to change direction
not active and does not emit a warning
(e.g. A), oncoming vehicles travelling
for stationary vehicles when you exceed
at approximately 18 mph (30 km/h) to
approximately 50 mph (80 km/h).
35 mph (55 km/h) are detected by the
system when:
A
Special features of warnings
- your vehicle is travelling at a speed
Depending on the speed, the warning
between approximately
5 mph
and braking may be activated simulta-
(8 km/h) to 12 mph (20 km/h);
neously.
- you have activated the direction indi-
cator light.
The system is otherwise inactive
and does not trigger an alert.
This function is an addi-
tional driving aid.
This function is not under
any circumstances in-
tended to replace the due care and
attention of the driver, who should at
all times be in control of the vehicle.
2.56
ADVANCED SAFETY (6/17)
Active emergency braking
Note: if the driver uses the vehicle con-
(continued)
trols (steering wheel, pedals, etc.) the
system may delay certain operations or
Detection of pedestrians and
not activate.
cyclists
When driving at a speed between ap-
proximately 5 mph (8 km/h) and 53 mph
(85 km/h), if there is a risk of collision
5
with a cyclist or pedestrian, the system:
-
warns you of a collision risk:
the
red warning light, or, de-
pending on the vehicle, the display 5
and the message “Brake” appear on
the instrument panel, accompanied
by a beep.
If active emergency braking has caused
If the driver presses the brake pedal
the vehicle to stop, the vehicle is kept
and the system still detects a risk of
stationary for a short time. Beyond this
collision, the braking force may be
time limit, the vehicle must be held sta-
increased if it is not sufficient to pre-
tionary by the driver keeping their foot
vent the collision;
on the brake pedal.
-
may trigger braking:
if the driver fails to react following
the alert and collision becomes im-
minent.
In the event of emergency manoeu-
vre, you can stop braking at any
moment by:
- tapping the accelerator pedal;
or
- turning the steering wheel as a
collision avoidance manoeuvre.
2.57
ADVANCED SAFETY (7/17)
Temporarily not available
If this is not the case, this may arise from
4
another cause; contact an Approved
If the system detects a temporary fault
Dealer.
the
warning light illuminates, or
Operating faults
depending on the vehicle, the
When the function detects an operat-
warning light illuminates in yellow on
the instrument panel.
The possible causes are:
or, depending on the vehicle,
-
the system is temporarily blinded
and
, appear in yellow on
(glare from the sun, dipped beam
the instrument panel accompanied by
headlights, bad weather conditions
the message “Check Front camera” or
etc.). The system will be operational
“Front radar to check” or “Check Driving
again when visibility conditions are
assist “.
better;
Consult an approved dealer.
Active emergency braking
-
the system is temporarily interrupted
(continued)
(e.g. the windscreen, front or rear
bumper or logo is obscured by dirt,
Settings
mud, snow, condensation, etc.). In
From the "Vehicle” World on your mul-
this case, park the vehicle and switch
timedia screen 4, press the “Driving as-
off the engine. Clean the windscreen
sistance” menu, then the “Advanced
and front bumper. The next time
safety” menu to access the following
the engine is started, after five or
settings:
ten minutes of driving, the warning
light and the message disappear.
“Warning anticipation”: adjust the alert
sensitivity level. To do this select:
- “Late”;
- “Standard”;
– “Early”.
2.58
ADVANCED SAFETY (8/17)
Active emergency braking
This function is an additional driving aid. This function is not under any circumstances intended to replace the due care
and attention of the driver, who should at all times be in control of the vehicle. The triggering of this function may be
delayed or prevented when the system detects clear signs of control of the vehicle by the driver (action on the steer-
ing wheel, pedals etc.).
The system cannot be activated:
- if the gear control is in neutral position;
- when the parking brake is activated;
- when the Electronic Stability Program (ESC) has been triggered.
System servicing/repairs
- In the event of an impact, the radar and/or camera alignment may be changed and its operation may consequently be af-
fected. Deactivate the function and consult an authorised dealer.
- Any work in the area where the radar and/or camera is located (repairs, replacements, windscreen modifications, etc.) must
be carried out by a qualified professional.
Only an authorised dealer is qualified to service the system.
2.59
ADVANCED SAFETY (9/17)
System disturbance
Some conditions can disturb or damage the operation of the system, such as:
- a complex environment (metal bridge, tunnel etc.);
- poor weather conditions (snow, rain, hail, black ice etc.);
- poor visibility (night, fog etc.);
- poor contrast between the object (vehicle, pedestrian etc.) and the surrounding area (e.g. pedestrian dressed in white lo-
cated in a snowy area etc.) ;
- being dazzled (glaring sun, lights of vehicles travelling in the opposite direction etc.);
- windscreen obscured (by dirt, ice, snow, condensation etc.);
- ...
In these conditions, the system may not react, may warn the driver or may brake inadvertently.
Limitation of the system operation
- Each time the vehicle is started, the system carries out a calibration according to the vehicle surroundings and may be in-
active for a length of time between approximately two to five minutes of driving;
- an oncoming vehicle will not trigger any warning or system action if the conditions in the paragraph “Special features of on-
coming vehicles in the context of a manoeuvre to change direction” are not met (see previous pages);
- the radar and camera zones must be kept clean and free of any modifications in order to ensure the proper operation of the
system;
- the system may not respond to small vehicles such as motorbikes as effectively as to other vehicles;
- the system may not operate properly when the road surface is slippery (rain, snow, black ice, etc.);
- to ensure correct operation, the system needs to distinguish the complete outline of the pedestrian. So the system cannot
detect:
- pedestrians in the darkness or in poor lighting conditions;
- partially visible pedestrians:
- pedestrians less than approximately 80 cm tall;
- pedestrians carrying large objects;
- ...
In these conditions, the system may not react, may warn the driver or may brake inadvertently.
2.60
ADVANCED SAFETY (10/17)
Deactivating the function
You must disable the function if:
- the brake lights are not functioning;
- the area of the camera has been damaged (e.g. on the inside or outside of the windscreen);
- the front of the vehicle was damaged (impact, distortion, scratch on the radar etc.);
- the vehicle is being towed (breakdowns);
- the windscreen is cracked or distorted (do not carry out windscreen repairs in this area; have it changed by an approved
dealer);
- you are not driving on a paved road;
- the vehicle is on a roller bench in a workshop.
In the event of the system behaving abnormally, deactivate it and consult an authorised dealer.
Halting the function
You can halt the active braking function at any time by tapping the accelerator pedal or by turning the steering wheel in a col-
lision avoidance manoeuvre.
2.61















Content      ..     7      8      9      10     ..
