PUNCTURE, EMERGENCY SPARE WHEEL (3/3)
To refit the wheel carrier:
- use the wheelbrace 8 to screw fully
the nut clockwise (reverse move-
ment A);
8
A
– make sure you lock the wheel carrier
in place;
8
- refit the blanking cover, then the
cover 9.
Note: 4-door version vehicle, store the
punctured wheel in the boot.
9
11
B
10
Emergency spare wheel 11
-
under the vehicle, lift then push
(movement B) the handle 10 to lower
It is located under the vehicle.
the wheel carrier on the ground;
To get to it:
-
pull the wheel 11 towards you, a
– in the luggage compartment, lift the
plastic guide located under the
Make sure that the wheel
cover 9 from the luggage compart-
wheel makes it easy to move;
carrier is always locked,
ment carpet;
with or without the emer-
-
remove the plastic guide from the
gency spare wheel inside.
- remove blanking cover;
wheel before fitting it to the vehicle.
There is a risk of accidents.
- only use the wheel brace 8 (using
a different tool could damage the
mechanism) to unscrew fully the nut
When the emergency spare
anti-clockwise (movement A), and
wheel is located underneath
the wheel will lower to the ground;
the vehicle, it is vital to take
Do not touch the exhaust
the emergency spare wheel
system.
out before lifting the vehicle.
Risk of burns.
Risk of injury.
5.4
TYRE PRESSURE KIT (1/3)
B
Do not attempt to use the
The kit is only approved for
inflation kit if the tyre has
inflating the tyres of the ve-
been damaged as a result
hicle originally equipped
of driving with a puncture.
with the kit.
A
You should therefore carefully check
It must never be used to inflate
the condition of the tyre sidewalls
the tyres of another vehicle, or any
before any operation.
other inflatable object (rubber ring,
rubber boat, etc.).
Driving with underinflated, flat or
punctured tyres can be dangerous
Avoid spillage on skin when han-
and may make the tyre impossible
dling the repair product bottle. If
to repair.
droplets do leak out, rinse them off
with plenty of water.
This repair is temporary
Keep the repair kit away from chil-
A tyre which has been punctured
dren.
should always be inspected (and re-
paired, where possible) as soon as
Do not dispose of the empty bottle
The kit repairs tyres when
possible by a specialist.
in the countryside. Return it to your
tread A has been dam-
approved dealer or to a recycling or-
aged by objects smaller
When taking a tyre which has been
ganisation.
than 4 mm. It cannot repair
repaired using this kit to be replaced,
all types of puncture, such as cuts
you must inform the specialist.
The bottle has a limited service
larger than 4 mm, or cuts in tyre
life which is indicated on its label.
When driving, vibration may be felt
sidewall B.
Check the expiry date.
due to the presence of the repair
Ensure also that the wheel rim is in
product injected into the tyre.
Contact an approved dealer to re-
good condition.
place the inflation tube and repair
product bottle.
Do not pull out the foreign body
causing the puncture if it is still in
the tyre.
5.5
TYRE PRESSURE KIT (2/3)
Engine running, handbrake applied:
Note: While the container empties
3
4
5
6
(approx.
30 secs), the pressure
-
Connect the compressor hose 4 to
gauge 6 briefly shows pressure up to
the container inlet 9;
6 bar, then the pressure drops.
-
remove the cap from the container
inflation adapter 3;
-
Adjust the pressure: to increase
unscrew the valve cap on the rele-
it, continue inflation with the kit; to
vant wheel and screw on the contai-
reduce it, press button 8.
7
ner’s inflation adapter 3;
-
disconnect any accessories pre-
viously connected to the vehicle’s
accessories sockets;
-
the end piece 7 must be plugged in
to the vehicle accessories socket;
9
8
-
press the 5 switch to inflate the
tyre to the recommended pressure
➥ 4.13 ;
In the event of a puncture, use the kit
-
after a maximum of 15 minutes, stop
located in the luggage compartment
inflating and read the pressure (on
Before using the kit, park
or underneath the luggage compart-
pressure gauge 6).
the vehicle at a sufficient
ment floor (depending on the vehicle).
distance from traffic, switch
➥ 3.54.
on the hazard warning
Vehicle fitted with a tyre pressure
lights, apply the parking brake, ask
monitoring system
all passengers to leave the vehicle
In the event of under-inflation (punc-
and keep them away from traffic.
tures, under-inflation etc.), the
warning light appears on the instrument
panel. ➥ 2.32.
If the vehicle is parked on the hard shoulder, you must warn other road
users of your vehicle’s presence with a warning triangle or with other de-
vices as per the legislation applying to the country you are in.
5.6
TYRE PRESSURE KIT (3/3)
Once the tyre is correctly inflated,
Precautions when using the
remove the kit:
kit
3
-
Slowly unscrew the inflation
The kit should not be operated for more
adapter 3 to prevent any repair prod-
than 15 consecutive minutes.
uct from escaping and store the con-
tainer in plastic packaging to prevent
the product from leaking.
-
Affix the driving recommendation
label (located under the container) to
Nothing should be placed
the dashboard where the driver can
around the driver’s feet
see it.
as such objects may slide
- Put the kit away.
under the pedals during
At the end of this initial inflation op-
sudden braking manoeuvres and
eration, air will still escape from the
obstruct their use.
tyre. You must drive a short distance
in order to seal the hole.
If a minimum pressure of 1.8 bar is
-
Start immediately and drive at be-
not reached after 15 minutes, repair
tween
12 and 40 mph (20 and
is not possible; do not drive the ve-
Following repair with the kit,
60 km/h) in order to distribute the
hicle but contact an approved dealer.
do not travel further than
product evenly in the tyre and, after
120 miles (200 km). In addi-
driving for 2 miles (3 km), stop and
tion, reduce your speed and
check the pressure.
under no circumstances exceed
-
If the pressure is greater than 1.3 bar
48 mph (80 km/h). The sticker,
Please be aware that a
but less than the recommended
which you must affix in a prominent
poorly tightened or miss-
pressure, re-adjust it (refer to the
position on the dashboard, reminds
ing valve cap can make the
label affixed to the edge of the driv-
you of this.
tyres less airtight and may
er’s door), otherwise contact an ap-
Depending on the country or local
lead to pressure loss.
proved dealer: repair is not possible.
legislation, a tyre repaired with the
Always use valve caps identical to
inflation kit may need to be replaced.
those fitted originally and tighten
them fully.
5.7
TOOLS (1/2)
1
2
3
3
Tool kit
Tool box
(depending on vehicle)
(depending on vehicle)
To access the tool kit 1, raise the lug-
To access the tool box, unlock the
gage compartment carpet and/or
mounting(s) 2 by one quarter of a turn,
mobile floor ➥ 3.54.
then remove the flap 3.
The tool box is held in place by a strap.
2
3
5.8
TOOLS (2/2)
Towing hitch 9
5
➥ 5.39
6
Wheelbrace 10
4
Locks or unlocks the wheel bolts and
tow eye 9.
7
10
9
8
Do not leave the tools un-
secured inside the vehicle
as they may come loose
under braking. After use,
The presence of the tools depends on
Hubcap tool 7
check that all the tools are correctly
the vehicle.
This tool is used to remove the wheel
clipped into the tool kit, then posi-
trims.
tion it correctly in its housing: risk of
injury.
Jack 5
If wheel bolts are supplied in the
On vehicles equipped with a tool kit,
Screw guide 8
tool kit, only use these bolts for the
push towards the front of the vehicle
For tightening/loosening wheel bolts on
emergency spare wheel: refer to the
the 4 clip on the tool kit and remove the
vehicles fitted with alloy wheels
label affixed to the emergency spare
jack.
wheel.
Fold the jack correctly before refitting it
The jack is designed for wheel
in its housing (ensure that the wheel-
changing purposes only. Under no
brace 6 is correctly positioned).
circumstances should it be used for
carrying out repairs underneath the
vehicle or to gain access to the un-
derside of the vehicle.
5.9
HUBCAP
D
1
B
C
A
2
Remove using the hubcap tool 1 (lo-
cated in the tool kit) by connecting the
hook in the recess provided next to the
valve 2 (to attach the metal clip).
To refit it, align it with valve 2. Push the
retaining hooks in fully, starting with
side A near the valve, followed by B
and C, finishing at D opposite the valve.
Note: if you are using anti-theft bolts
Do not leave the tools un-
➥ 5.11.
secured inside the vehicle
as they may come loose
under braking. After use,
check that all the tools are correctly
clipped into the tool kit, then posi-
tion it correctly in its housing: risk of
injury.
5.10
CHANGING A WHEEL (1/2)
Vehicles equipped with a jack
and wheelbrace
If necessary, remove the wheel trim.
Use the wheelbrace 2 to slacken off the
wheel bolts. Position it so as to be able
2
to push from above.
Place the jack 3 horizontally; the jack
1
head must be lined up with the sill clos-
est to the wheel concerned, as shown
by an arrow 1.
3
Crank up the jack by hand at first to
align the base plate (which should be
inclined further inwards than the jack
When the emergency spare
head).
wheel is located underneath
Switch on the hazard warn-
the vehicle, it is vital to take
Turn the wheelbrace until the wheel lifts
ing lights.
the emergency spare wheel
off the ground.
out before lifting the vehicle.
Keep the vehicle away from
traffic and on a level surface
Risk of injury.
where it will not slip.
Apply the parking brake and engage
a gear (first or reverse, or P for auto-
If the vehicle is parked on
matic transmissions).
the hard shoulder, you must
Ask all the passengers to leave the
warn other road users of
vehicle and keep them away from
your vehicle’s presence
traffic.
with a warning triangle or with other
devices as per the legislation apply-
ing to the country you are in.
5.11
CHANGING A WHEEL (2/2)
Undo the bolts and take off the wheel.
Vehicle fitted with a tyre pressure
monitoring system
Fit the emergency spare wheel onto
the hub and rotate it until the mounting
In the event of under-inflation (punc-
holes in the wheel coincide with those
tures, under-inflation etc.), the
of the hub.
warning light appears on the instrument
If bolts are supplied with the emergency
panel. ➥ 2.32.
spare wheel, only use these bolts for
the emergency spare wheel. Tighten
the bolts, checking that the wheel is
correctly positioned on its hub and un-
screw the jack.
With the wheel on the ground, tighten
the bolts fully and have the tightness of
the bolts checked and the emergency
spare wheel pressure checked as soon
as possible.
Note: 4-door version vehicle, when the
Anti-theft bolt
emergency spare wheel is located un-
derneath the vehicle, place the punc-
If you use anti-theft bolts, fit these
tured wheel in the boot.
nearest the valve (wheel embel-
lisher may not be able to fit).
If you have a puncture, re-
place the wheel as soon as
possible.
A tyre which has been punc-
tured should always be inspected
(and repaired, where possible) by a
specialist.
5.12
TYRES (1/3)
The tyres are the only contact between
When the tread has worn down to the
the vehicle and the road, so it is essen-
wear warning strips, these strips will
tial to keep them in good condition.
become visible 2: it is then necessary
to replace your tyres because the tread
You must make sure that your tyres
rubber is now only 1.6 mm deep at
con- form to local road traffic regula-
2
most, resulting in poor road holding
tions.
on wet roads.
An overloaded vehicle, long journeys
1
by motorway, particularly in very hot
weather, or continual driving on poorly
surfaced minor roads will lead to more
rapid tyre wear and affect safety.
Maintaining the tyres
The tyres must be in good condition
and the tread form must have sufficient
depth; tyres approved by our Technical
Department have tread wear indica-
tors 1 which are indicators moulded
into the tread at several points.
Incidents which occur when
driving, such as striking the
kerb, may damage the tyres
and wheel rims, and could
also lead to misalignment of the
front or rear axle geometry. In this
case, have the condition of these
checked by an approved dealer.
5.13
TYRES (2/3)
Tyre pressures
The pressures should be checked cold:
Vehicle fitted with a tyre pressure
ignore higher pressures which may be
monitoring system
Adhere to the tyre pressures (including
reached in hot weather or following a
the emergency spare wheel). The tyre
In the event of under-inflation (punc-
high speed journey.
pressures should be checked at least
tures, under-inflation etc.), the
once a month and additionally before
If the tyre pressures cannot be checked
warning light appears on the instrument
any long journey (refer to the label af-
when the tyres are cold, increase the
panel. ➥ 2.32.
fixed to the edge of the driver’s door).
pressures from 0.2 to 0.3 bar (or 3 PSI).
Never deflate a hot tyre.
Emergency spare wheel
Special note
➥ 5.2, ➥ 5.11.
Depending on the vehicle, there may
be an adapter which needs to be posi-
tioned on the valve before air is added.
Changing wheels around
Incorrect tyre pressures
This practice is not recommended.
lead to abnormal tyre wear
and unusually hot running.
These are factors which
may seriously affect safety and lead
to:
- poor road holding,
- risk of bursting or tread separa-
tion.
Please be aware that a
The pressure depends on the load
poorly tightened or miss-
and the speed of use. Adjust the
ing valve cap can make the
pressure according to the condi-
tyres less airtight and lead
tions of use (refer to the label affixed
to pressure loss.
to the edge of the driver’s door).
Always use valve caps identical to
those fitted originally and tighten
them fully.
5.14
TYRES (3/3)
Fitting new tyres
Use in winter
Studded tyres
Snow or Winter tyres
This type of equipment may only be
used for a limited period and as laid
We would recommend that these be
down by local legislation. It is neces-
fitted to all four wheels to ensure that
For your safety, please re-
sary to observe the speed specified by
your vehicle retains maximum adhe-
spect the speed limit.
current legislation.
sion. Warning: These tyres sometimes
These tyres must, at a minimum, be
When they need to be re-
have a specific direction of rotation and
fitted to the two front wheels.
placed, only tyres of the
a maximum speed index which may be
same make, size, type and profile
lower than the maximum speed of your
Chains
should be used on a single axle.
vehicle.
For safety reasons, fitting snow
They must: either have a load ca-
chains to the rear axle is strictly for-
pacity and a speed capacity at
bidden.
least equal to the original tyres,
Chains cannot be fitted to tyres which
or correspond to those recom-
are larger than those originally fitted to
mended by your authorised
Snow chains may only be
the vehicle.
dealer.
fitted to tyres of the same
size as those originally
Failure to heed these instructions
fitted to your vehicle.
could endanger your safety and
affect your vehicle’s roadworthi-
ness.
Risk of loss of control of the ve-
17” wheels and larger
hicle.
cannot be fitted with
Changing a wheel
chains.
As the tyre pressure moni-
tor may take several min-
If you wish to use special
utes to correctly determine
equipment, please consult an au-
the positions of the wheels and the
thorised dealer.
pressure values after driving, check
the tyre pressures following any op-
eration.
In all cases, we would recommend that you contact an authorised dealer who will
be able to advise you on the choice of equipment which is most suitable for your
vehicle.
5.15
FRONT HEADLIGHTS: replacing the bulbs (1/2)
Front fog lights 4
Please see an authorised dealer.
Any operation on (or modi-
2
fication to) the electrical
Additional lights
1
system must be performed
If you wish to fit fog lights to your ve-
by an approved dealer
hicle, please see an authorised dealer.
since an incorrect connection might
damage the electrical equipment
(harness, components and in par-
3
ticular the alternator). In addition,
your Dealer has all the parts re-
quired for fitting these units.
4
Vehicles with LED headlights
The bulbs are under pres-
Daytime running lights/side lights/
sure and can break when
direction indicators 1
replaced.
Please see an authorised dealer.
Risk of injury.
Main beam headlights 2
Please note when work-
Please see an authorised dealer.
ing close to the engine that
it may be hot. In addition,
Dipped beam headlights 3
the engine cooling fan may
Please see an authorised dealer.
start at any moment. The
warning light in the engine compart-
ment reminds you of this.
Risk of injury.
5.16
FRONT HEADLIGHTS: replacing the bulbs (2/2)
5
6
10
11
A
B
7
8
9
Vehicles with Halogen
Halogen main beam headlight 5
Front fog lights 8
- Access the bulb holder via the un-
headlights
To change the bulb:
derneath of the vehicle;
- open the bonnet;
Daytime running lights/side lights/
- unclip the access flap 9;
- remove cover A;
direction indicators 7
- turn the bulb holder a quarter turn;
- pull the bulb holder 10;
Please see an authorised dealer.
- remove the bulb.
- remove the bulb.
Type of bulb: H16.
Halogen dipped beam headlight 6
Type of bulbs 5 and 6: H7.
Once the bulb has been replaced,
To change the bulb:
It is essential to use anti-U.V. 55W
check that it is properly secured.
- open the bonnet;
bulbs so as not to damage the plastic
- remove cover B;
on the headlights.
- Turn the bulb holder a quarter
Do not touch the bulb glass. Hold it
turn 11;
by its base.
– remove the bulb.
To comply with local legislation, or
When the bulb has been changed,
as a precaution, you can obtain an
make sure you refit the cover correctly.
emergency kit containing a set of
spare bulbs and fuses from an ap-
proved dealer.
5.17
REAR LIGHTS AND SIDE LIGHTS: replacing the bulbs (1/7)
Rear fog lights 6 or 7
5
The front bumper needs to be removed;
consult an authorised dealer.
Bulb type: P21W.
1
2
2
3
4
7
6
5-door version
Direction indicators 4
Consult an approved dealer.
Brake/side lights 1
Consult an approved dealer
High level brake light 5
Consult an approved dealer.
Side lights 2
Consult an approved dealer.
Reversing light 3
Consult an approved dealer.
The bulbs are under pres-
sure and can break when
replaced.
Risk of injury.
5.18
REAR LIGHTS AND SIDE LIGHTS: replacing the bulbs (2/7)
8
9
10
Number plate lights 8
Side repeaters 9 and welcome
lighting 10
Consult an approved dealer.
The wing mirror needs to be removed;
consult an authorised dealer.
5.19
REAR LIGHTS AND SIDE LIGHTS: replacing the bulbs (3/7)
Rear fog lights 6 or 7
The front bumper needs to be removed;
consult an authorised dealer.
Bulb type: P21W.
1
5
2
2
3
4
6
7
Estate version
Direction indicators 4
Consult an approved dealer.
Brake/side lights 1
Consult an approved dealer
High level brake light 5
Consult an approved dealer.
Side lights 2
Consult an approved dealer.
Reversing light 3
Consult an approved dealer.
The bulbs are under pres-
sure and can break when
replaced.
Risk of injury.
5.20
REAR LIGHTS AND SIDE LIGHTS: replacing the bulbs (4/7)
12
13
14
Number plate lights 8
Side repeaters 9 and welcome
lighting 10
Consult an approved dealer.
The wing mirror needs to be removed;
consult an authorised dealer.
5.21
REAR LIGHTS AND SIDE LIGHTS: replacing the bulbs (5/7)
5
7
6
2
4
1
3
4-door version
Access to the bulb holders 6 and 7
Brake light 1
Open the boot, remove the cover 4 to
Turn bulb holder 6 a quarter of a turn
Side light 3
access the screw 5 and undo it.
and take out the bulb.
Consult an approved dealer.
Remove the rear lights unit.
Bulb type: P21W.
Refit the bulb holder and push the unit
Direction indicator light 2
in fully until it locks in place.
Turn bulb holder 7 a quarter of a turn
Check that the light is properly locked
and take out the bulb.
in position.
Bulb type: PY21W.
Tighten the screw 5 and reposition the
cover 4.
5.22
REAR LIGHTS AND SIDE LIGHTS: replacing the bulbs (6/7)
10
8
9
11
Reversing light
Turn bulb holder 9 a quarter of a turn
High level brake light 10
and take out the bulb.
From the boot, unclip the cover on the
Consult an approved dealer.
interior trim of the boot lid 8 using a
Bulb type: W16W.
screwdriver or similar tool.
Refitting
Rear fog lights 11
To refit, proceed in the reverse order,
The front bumper needs to be removed;
taking care not to damage the wiring.
consult an authorised dealer.
Bulb type: P21W.
The bulbs are under pres-
sure and can break when
replaced.
Risk of injury.
5.23
REAR LIGHTS AND SIDE LIGHTS: replacing the bulbs (7/7)
12
14
15
13
Number plate lights with
LED number plate lights 13
Side repeaters 14 and
conventional bulbs 12
(depending on vehicle)
welcome lighting 15
(depending on vehicle)
Consult an approved dealer
The wing mirror needs to be removed;
- Unclip the light 12 using a tool such
consult an authorised dealer.
as a flat-blade screwdriver;
- remove the light cover to gain access
to the bulb.
Bulb type: W5W.
The bulbs are under pres-
sure and can break when
replaced.
Risk of injury.
5.24















Content      ..     15      16      17      18     ..
