REAR HEADRESTS (2/2)
A
3
B
2
1
1
Storage position for the side
headrests
Press the button 1 and, depending on
the vehicle:
- fully lower (movement A) the head-
rest 2, or
- lower and tilt
(movement B) the
headrest 3 fully forwards.
3.43
REAR BENCH SEAT (1/2)
The configuration of the
two-seat bench with the
1
small seatback B pulled
down, does not allow the
central seat to be used as it would
be impossible to buckle the seat belt
(belt buckles inaccessible).
B
A
2
When refitting the seat-
back, make sure it is cor-
rectly locked in place.
To manually fold down the
Pull the control 1 and lower the seat-
If seat covers are fitted,
back A.
make sure these do not prevent the
seatbacks
seatback latch from locking in.
To replace the seatback, proceed in
Ensure that the front seats are far
Make sure that the seat belts are
the reverse order to removal.
enough forward.
positioned correctly.
Refit the seatback and click it back into
Raise the side headrests to the highest
Reposition the headrests.
place.
position and lower the central headrest
fully.
Depending on the vehicle, put the seat
belt in the belt guide 2 to avoid damag-
ing it, or buckle it its own unit. This will
prevent the seat belt becoming trapped
When moving the rear
when the seat is returned to its position
seats, ensure that nothing
for use. In all cases, check that the seat
obstructs the anchorage
belts are operating correctly.
For safety reasons, carry
points (passenger’s arm or
out any adjustments when
leg, a pet, gravel, cloth, toys, etc.).
the vehicle is not being
driven.
3.44
REAR BENCH SEAT (2/2)
Conditions of use
- Vehicle stationary;
- luggage compartment lid open;
- rear seat belts locked.
Operating faults
If all user conditions have been ful-
filled and the folding action still fails to
operate, please contact an authorised
3
dealer.
To automatically fold down
the seatbacks (flat position)
(Estate version)
From the boot, pulling the control 3
enables you to automatically unlock the
rear bench seatbacks to get a flat floor.
When moving the rear
seats, ensure that nothing
obstructs the anchorage
points (passenger’s arm or
leg, a pet, gravel, cloth, toys, etc.).
3.45
LUGGAGE COMPARTMENT: 4 DOOR VERSION (1/3)
Depending on the vehicle, there are
various ways to unlock and operate the
luggage compartment lid:
- using the locking/unlocking button
on the remote control key ➥ 1.4;
- using the locking/unlocking button
on the card ➥ 1.9;
- via the external boot lid control;
2
1
- using the hands-free function;
- using the dashboard control.
Manual controls
To open
Depending on the vehicle, press the
dashboard control 1 or the button 2, the
tailgate opens automatically.
When opening or closing the lug-
Note: ensure that the surrounding
gage compartment lid, ensure that
space is sufficient to permit operation
nothing obstructs the manoeuvre.
of the boot lid before you open it.
As a safety precaution,
Ensure that nobody is close
the doors should only be
to the moving parts when
opened or closed when the
opening/closing the boot lid.
vehicle is stationary.
Risk of injury.
Risk of injury.
3.46
LUGGAGE COMPARTMENT: 4-DOOR VERSION (2/3)
The sensor detects the approach and
then the removal of your foot and trig-
gers the opening of the boot lid.
Do not keep your foot in the air. Perform
the movement without stopping and wi-
thout touching the rear bumper.
A
2
B
To close
Using the hands-free function
Lower the boot lid using the handle
The hands-free function enables
inside the boot to assist you.
access to the luggage compartment
when you have your hands full.
Ensure that the card is approximately
Disable the
“hands-free”
1 metre away in the central area of the
function before you:
rear bumper of the vehicle (area B).
- wash the vehicle in a
With the ignition off, stand approxi-
roller-type car wash;
mately 45 cm from the vehicle’s rear
- wash the vehicle by hand;
bumper and move your foot forwards
- handle the towbar;
and backwards in area A.
- ...
Risk of accidental opening of the
luggage compartment lid which
may cause injury.
3.47
LUGGAGE COMPARTMENT: 4-DOOR VERSION (3/3)
Activation/deactivation of the
User precautions
hands-free function
- Before opening the tailgate, ensure
To activate or deactivate the function,
that the surrounding space is suffi-
refer to the multimedia instructions.
cient to permit operation of the tail-
gate. Otherwise, stop the movement
Select “ON” or “OFF”.
of the boot lid before it makes con-
tact.
Usage features of the hands-free
function
- The system may experience tempo-
-
The hands-free function is no longer
rary difficulties if one of the sensors
3
integrated in the rear of the bumper
available after a few days of lack of
is obscured (by dirt, mud, snow, grit-
movement of the vehicle, or after
ting salt, etc.). Clean the sensors. If
around 15 minutes if the vehicle is
there is still a problem, contact an
unlocked. To reactivate it, use the
approved dealer.
unlocking button on the card.
Note: in very cold weather conditions,
-
The hands-free function is only avail-
the automatic opening may not work if
Opening the doors manually
able if the vehicle is stationary and
the tailgate seals are frozen.
from the inside
the engine is switched off (and not
on standby with the Stop and start
If it is impossible to unlock the tailgate,
function).
it can be done manually from inside:
-
The ‘hands-free’ feature may not
- access the luggage compartment by
work if the vehicle is equipped with a
folding forward the seatback(s) of
towbar or is in an area of high elec-
the rear bench seat;
tromagnetic radiation.
- insert a flat-blade screwdriver or
The attachment of any
similar under the carpet above the
carrying device (bike rack,
mechanism 3 and slide the unit as
luggage box etc.) resting on
shown in the illustration;
the luggage compartment
lid is prohibited. To install a carrying
- push the boot lid to open it.
device on your vehicle, contact an
Approved Dealer.
3.48
LUGGAGE COMPARTMENT: 5-DOOR VERSION
2
1
3
To open
Opening manually from
Press button 1 and lift the tailgate.
inside the vehicle
To close
Special note:
Lower the tailgate using the handles 2
If it is impossible to unlock the tailgate,
inside the tailgate to help you.
it can be done manually from inside:
- access the luggage compartment by
folding forward the seatback(s) of
the rear bench seat;
The attaching of any carry-
ing device (bike rack, lug-
- insert a pencil or similar object in
gage box, etc.) resting on
recess 3 and slide the unit as shown
the luggage compartment
in the illustration;
lid is prohibited. To install a carrying
- push the tailgate to open it.
device on your vehicle, contact an
Approved Dealer.
3.49
REAR PARCEL SHELF
1
2
Removal
Unclip the rear parcel shelf 2 and pull it
towards you.
Unhook the two cords 1 (tailgate side).
To refit it, proceed in reverse order to
removal.
Do not place any heavy or
hard object on the parcel
shelf. These may pose a
risk to the vehicle occu-
pants if the driver has to brake sud-
denly or if the vehicle is involved in
an accident.
3.50
LUGGAGE COMPARTMENT COVER
A
B
2
2
3
C
3
1
4
A
1
To remove the flexible
Removing/refitting the
Luggage compartment cover
section of the luggage
luggage cover 2
storage 2
compartment cover 2
Slide section 3 (movement A) and lift
Lift section 4 of the luggage compart-
Press handle 1 to release the pins from
the right-hand side (movement B) of
ment floor.
their mounting points located on each
the roller at the same time.
Pivot the luggage cover so that the
side of the luggage compartment.
Then lift the left-hand side of the roller
handle 1 is visible and towards the front
Allow the luggage cover to roll up.
and then remove the assembly.
of the vehicle.
To refit the luggage cover, carry out this
Store the luggage cover, handle 1 for-
procedure in reverse.
wards, firstly by inserting the left-hand
side into its housing, then insert the
right-hand side (movement C) by slid-
ing section 3 (movement A).
Close the luggage compartment floor.
Do not place any heavy or solid objects on the luggage cover. These may
pose a risk to the vehicle occupants if the driver has to brake suddenly or
if the vehicle is involved in an accident.
3.51
LUGGAGE NET (1/2)
A
1
B
2
3
5
4
Depending on the vehicle, this may be
Fitting the luggage net
- if using the net for the first time, to
used when transporting animals or lug-
access the anchorage points 4 lo-
behind the front seats
gage to isolate them from the passen-
cated under the carpet, contact an
ger section.
Inside the vehicle on each side:
Approved Dealer;
It can be positioned:
– lower cover 1 to gain access to the
- attach the two hooks 5 for the net
anchoring points for the top part of
straps 3 to the anchoring points 4;
- behind the rear seats A;
the luggage net;
- adjust the net strap 3 so that it is taut.
– behind the front seats B.
- insert the top rod of net 2 into the an-
choring points;
The luggage net is de-
signed to retain a maximum
weight of 10 kg.
Do not install the luggage net in this position when a passenger is occu-
Risk of injury.
pying a rear seat.
3.52
LUGGAGE NET (2/2)
6
6
7
8
9
10
Fitting the luggage net
- fix the net belt hook 9 onto the ancho-
ring points 10;
behind the rear seats
- adjust net strap 8 so that it is taut. The
Inside the vehicle on each side:
seatbacks must not touch the luggage
- lift cover 6 to access the luggage net
net.
upper mounting rail;
- insert upper rod 7 for the net into the
rail;
3.53
BOOT STORAGE SPACE AND FITTINGS (1/5)
3
4
1
1
3
3
2
2
Storage under the carpet
The false floor can be attached using
the hook 4 in the housing 3.
To gain access to this, lift the boot
carpet 1 using the tab 2.
Always place objects being trans-
ported so that the heaviest items
are resting against the back of the
rear bench seat.
3.54
BOOT STORAGE SPACE AND FITTINGS (2/5)
5
6
A
A
B
B
C
7
Mobile floor
Storage position
Separation position
(Estate version)
This enables more space for storage in
This enables you to compartmentalise
It is made up of two independent
the luggage compartment:
the boot into two separate spaces.
parts, A and B.
- Remove part B then part A of the
Slide your fingers under the spaces 7.
When the rear seats are folded down,
mobile floor;
this position provides a flat floor.
- place part A then part B under the
supports 5 and 6.
Maximum load allowed on the
mobile floor when flat: 50 kg evenly
distributed.
3.55
BOOT STORAGE SPACE AND FITTINGS (3/5)
10
9
9
A
C
B
8
Lift part C into the vertical position until
Storage under floor
Lift part A using handle 10 and place it
it locks.
on the lugs 9.
To access it, lift part B of the mobile
floor using the handle 8, then place it on
part A.
3.56
BOOT STORAGE SPACE AND FITTINGS (4/5)
11
11
11
Anchorage points
Attachment points 11.
If your vehicle is not equipped with
anchorage points, you can get them
from an authorised dealer.
Always position the heaviest items directly on the floor. Use the lashing
points 11 on the boot floor, if these are fitted to the vehicle. The luggage
should be loaded in such a way that no items will be thrown forward and
Always place objects being trans-
strike the occupants if the driver has to brake suddenly. Fasten the rear
ported so that the heaviest items
seat belts, even if the seats are not occupied.
are resting against the back of the
rear bench seat.
3.57
BOOT STORAGE SPACE AND FITTINGS (5/5)
12
12
13
Bag hooks 12
Storage compartment 13
(Estate version)
Maximum weight per hook: 5 kg.
3.58
TRANSPORTING OBJECTS IN THE LUGGAGE COMPARTMENT
Always position the objects transported
so that the largest surface is against:
- The rear bench seatback, for normal
loading (example A);
A
1
- The front seatbacks with the rear
B
seatbacks folded down, as is the case
for maximum loads (example B).
Always position the heavi-
If you have to place objects on the folded
est items directly on the
seatback, it is necessary that you lower
floor. Use the lashing
the headrests before folding the seat-
points 1 on the boot floor, if
back so that it can be folded as flat as
these are fitted to the vehicle. The
possible against the seat.
luggage should be loaded in such a
way that no items will be thrown for-
ward and strike the occupants if the
driver has to brake suddenly. Fasten
the rear seat belts, even if the seats
are not occupied.
3.59
TRANSPORTING OBJECTS towbar
A
Permissible nose weight, maxi-
mum permissible towing weight
A: 896 mm maximum (5-door version).
braked and unbraked: ➥ 6.12.
A: 1120 mm maximum (Estate version).
Choice and fitting of towing
A: 1127 mm maximum (4-door version).
equipment
Maximum weight of towing equip-
ment:
Any towing device must not ob-
- 36 kg (5-door version);
struct any lighting component or
the number plate when not in use.
- 37 kg (4-seater and estate ver-
Towing devices (ball, hook, etc.)
sions).
which can be removed without tools
For fitting and conditions of use,
and retractable objects must be re-
refer to the equipment’s fitting in-
moved or repositioned when they
structions.
are not in use.
Please keep these instructions with
Do not touch the exhaust
In all cases, you must comply with
the rest of the vehicle documenta-
system.
the regulations of the particular
tion.
country you are in.
Risk of burns.
3.60
ROOF BARS (1/2)
1
1
1
Access to the mounting
Vehicles not fitted with longitudinal
roof bars
points
Open the doors to access the mount-
ing points 1.
If original roof bars, ap-
For information on the range of equipment adapted to your vehicle, we advise you
proved by our Technical
to consult an approved Dealer.
Department, are supplied
with screws, only use these
Refer to the fitting instructions for information on how to fit roof bars and condi-
screws for attaching the roof bars to
tions of use.
the vehicle.
Please keep these instructions with the rest of the vehicle documentation.
Maximum permissible load on roof rack: ➥ 6.12.
3.61
ROOF BARS (2/2)
Precautions during use
2
Handling the tailgate
Before handling the tailgate, check the
objects and/or accessories (bike rack,
3
roof box, etc.) fitted to the roof bars:
these must be correctly positioned and
secured, so as not to hinder the opera-
tion of the tailgate.
Vehicles fitted with longitudinal roof
bars
The attachment inserts 3 are located on
the longitudinal roof bars 2.
The attaching of any carry-
ing device (bike rack, lug-
gage box, etc.) resting on
the luggage compartment
lid is prohibited. To install a carrying
device on your vehicle, contact an
Approved Dealer.
3.62
Section 4: Maintenance
Bonnet
4.2
Engine oil level: general information
4.4
Engine oil level: topping up and filling
4.5
Oil change
4.7
Levels:
4.8
engine coolant
4.8
brake fluid
4.9
windscreen washer reservoir
4.10
Filters
4.10
Battery
4.11
Tyre Pressure
4.13
Bodywork maintenance
4.15
Interior trim maintenance
4.18
4.1















Content      ..     13      14      15      16     ..
