ADDITIONAL METHODS OF RESTRAINT
All of the warnings below are given so that the air bag is not obstructed in any way when it is inflated and also to prevent
the risk of serious injuries caused by items which may be dislodged when the air bag inflates.
The air bag is designed to complement the action of the seat belt. Both the air bags and seat belts are integral parts of
the same protection system. It is therefore essential to wear seat belts at all times. If seat belts are not worn, the occu-
pants are exposed to the risk of serious injury in the event of an accident. It may also increase the risk of minor super-
ficial injuries occurring when the air bag is deployed, although such minor injuries are always possible with air bags.
If the vehicle should overturn or suffer a rear impact, however severe, the pretensioners and air bags are not always triggered.
Shocks to the underbody of the vehicle, e.g. from pavements, potholes or stones, can all trigger these systems.
- No work or modification whatsoever may be carried out on any part of the air bag system (air bags, pretensioners, compu-
ter, wiring harness, etc.), except by qualified personnel from an approved dealer.
- To ensure that the system is in good working order and to avoid accidental triggering of the system which may cause injury,
only qualified Network personnel may work on the air bag system.
- As a safety precaution, have the air bag system checked if your vehicle has been involved in an accident, or is stolen or
broken into.
- When selling or lending the vehicle, inform the user of these points and hand over this driver’s handbook with the vehicle.
- When scrapping your vehicle, contact your approved dealer for disposal of the gas generator(s).
1.42
CHILD SAFETY: General information (1/2)
Carrying children
Please ensure that you comply with the
legislation of your country.
Children, and adults, must be correctly
seated and strapped in for all journeys.
The children being carried in your vehi-
cle are your responsibility.
Driver’s responsibility
A child is not a miniature adult. Children
when parking or stopping
are at risk of specific injuries as their
the vehicle
muscles and bones have not yet fin-
ished growing. The seat belt alone
Never leave an animal,
would not provide suitable protection.
child or adult who is not self-suffi-
Use an approved child seat and ensure
cient alone on your vehicle, even for
you use it correctly.
a short time.
They may pose a risk to themselves
or to others by starting the engine,
A collision at 30 mph (50
activating equipment such as the
km/h) is the same as fall-
electric windows or by locking the
ing a distance of 10 metres.
doors.
Transporting a child without
Also, in hot and/or sunny weather,
a restraint is the equivalent of allow-
please remember that the tempera-
ing him or her to play on a fourth-
ture inside the passenger compart-
floor balcony without railings.
ment increases very quickly.
Never travel with a child held in your
arms. In the event of an accident,
RISK OF DEATH OR SERIOUS
you will not be able to keep hold of
INJURY.
To prevent the doors being
the child, even if you yourself are
opened, use the “Child lock”
wearing a seat belt.
feature. ➥ 1.17.
If your vehicle has been involved in
a road accident, replace the child
seat and have the seat belts and
ISOFIX anchorage points checked.
1.43
CHILD SAFETY: General information (2/2)
Using a child seat
Set a good example by always fas-
The level of protection offered by the
tening your seat belt and teaching
child seat depends on its ability to re-
your child:
strain your child and on its installation.
- to strap themselves in correctly;
Incorrect installation compromises the
- to always get in and out of the car
protection it offers the child in the event
at the kerb, away from busy traf-
of harsh braking or an impact.
fic.
Before purchasing a child seat, check
Do not use a second-hand child
that it complies with the regulations for
seat or one without an instruction
the country you are in and that it can
manual.
be fitted in your vehicle. Consult an ap-
proved dealer to find out which seats
Check that there are no objects in
are recommended for your vehicle.
the vicinity of the child seat which
could impede its operation.
Before fitting a child seat, read the
manual and respect its instructions. If
you experience any difficulties during
Never leave a child unat-
installation, contact the manufacturer
tended in the vehicle.
of the equipment. Keep the instructions
Check that your child is
with the seat.
always strapped in and that
the belt or safety harness used is
correctly set and adjusted. Avoid
wearing bulky clothing which could
cause the belts to slacken.
Never let your child put their head or
arms out of the window.
Check that the child is in the correct
position for the entire journey, espe-
cially if asleep.
1.44
CHILD SAFETY: choosing a child seat
Rear-facing child seats
Forward-facing child seats
Booster cushions
A baby’s head is, proportionally, heavier
Up to 18 kg or 4 years, the child may
From 15 kg or 4 years, the child can
than that of an adult and its neck is very
travel on a forward-facing seat.
travel using a booster seat, which will
fragile. Transport the child in this po-
enable the seat belt to be adapted
Choose your seat according the child’s
sition for as long as possible (until the
to suit his/her size and shape. The
size: their head and abdomen are the
age of 2 at the very least). It supports
booster seat cushion must be fitted with
areas which must be most protected. A
both the head and the neck.
guides to position the seat belt on the
forward-facing child seat which is firmly
child’s thighs rather than the stomach.
Choose a bucket type seat for best side
attached to the vehicle will reduce the
It is recommended that you use a seat-
protection and change it as soon as the
risk of impact to the head. Ensure your
back fitted with a belt strap guide which
child’s head is higher than the shell.
child travels in a forward-facing seat
can be adjusted in terms of height to
with a harness for as long as their size
position the seat belt in the centre of the
permits.
shoulder. It must never rest on the neck
Choose a bucket type seat for optimum
or on the arm.
side protection.
Choose a bucket type seat for optimum
side protection.
1.45
CHILD SAFETY: choosing a child seat mounting (1/4)
There are two ways of attaching child
Attachment via the seat belt
seats: via the seat belt or using the
The seat belt must be adjusted to
ISOFIX system.
ensure that it is effective in the event of
harsh braking or an impact.
Ensure that the strap paths indicated
by the child seat manufacturer are re-
spected.
Always check that the seat belt is cor-
rectly fastened by pulling it up, then
pulling it out fully whilst pressing on the
child seat.
Check that the seat is correctly held by
moving it from side to side and back
to front: the seat should remain firmly
fixed.
Check that the child seat has not been
installed at an angle and that it is not
The seat belt must never
resting against a window.
be twisted or the tension
relieved. Never pass the
shoulder strap under the
arm or behind the back.
Check that the seat belt has not
been damaged by sharp edges.
If the seat belt does not operate nor-
mally, it will not protect the child.
Do not use the child seat
Consult an approved dealer. Do not
if it may unfasten the seat
use this seat until the seat belt has
belt restraining it: the base
been repaired.
of the seat must not rest on
the buckle and/or catch of the seat
belt.
1.46
CHILD SAFETY: choosing a child seat mounting (2/4)
Attachment using the ISOFIX
Attach the child seat with the ISOFIX
system
locks, if these are provided. The ISOFIX
system allows quick, easy, safe fitting.
Approved child seats ISOFIX are stand-
ardised in accordance with current reg-
The ISOFIX system consists of 2 rings
ulations if any of the four cases below
and, in some cases, a third ring.
applies:
- ISOFIX universal 3-point forward-
facing seat;
- ISOFIX semi-universal 2-point seat;
- Specific;
- i-Size Which has:
- either a belt which attaches to the
third ring of the seat concerned;
- or a strut that rests on the vehi-
cle floor, compatible with the ap-
proved seat i-Size, the role of
No modifications may be
which is to prevent the child seat
made to the component
from moving in the event of a col-
parts of the restraint system
lision.
(ISOFIX seat belts, seats
and their mountings) originally fitted.
In the latter three cases check that your
child seat can be installed by consulting
the list of compatible vehicles.
Before using an ISOFIX
child seat that you pur-
chased for another vehicle,
check that its installation is
authorised. Consult the list of ve-
hicles which can be fitted with the
seat from the equipment manufac-
turer.
1.47
CHILD SAFETY: choosing a child seat mounting (3/4)
The rings are located on the rear seat-
backs and indicated by the symbol .
In all cases, attach the strap hook to the
corresponding ring 3 or 4 and place the
seat in the desired position.
Pull the belt so that the back of the child
1
seat comes into contact with the back
of the vehicle seat.
4
3
2
Attachment using the ISOFIX
The third ring 3 or 4 is used to attach
system
the upper strap on some seats ISOFIX.
Check that the seatback
of the forward-facing child
The two rings 1 are located between
seat is in contact with the
the seatback and the seat base of the
seatback of the vehicle
seat and are identified by a marking. To
seat. In this case, the child seat may
position and lock the child seat on the
not always rest on the seat base of
rings 1, insert the child seat mountings
the vehicle seat.
in the access guides 2.
The ISOFIX anchorage points have been exclusively designed for child
The child seat strap must
seats with the ISOFIX system. Never fit a different type of child seat, seat
be attached to the corre-
belt or other objects to these anchorage points. Check that nothing is ob-
sponding ring.
structing the anchorage points.
Do not use any other
If your vehicle has been involved in a road accident, have the ISOFIX anchorage
mounting point.
points checked and replace your child seat.
1.48
CHILD SAFETY: choosing a child seat mounting (4/4)
The rings are located behind the rear
seats and indicated by the symbol .
3
Attach the strap hook to the corre-
sponding ring 3 and place the vehicle
seat in the desired position.
Pull the belt so that the back of the child
1
seat comes into contact with the back
of the vehicle seat.
2
2
Attachment using the ISOFIX
The third ring 3 is used to attach the
system
upper strap on some seats ISOFIX.
Check that the seatback
(4-door version)
of the forward-facing child
The two rings 1 are located between
seat is in contact with the
the seatback and the seat base of the
seatback of the vehicle
seat and are identified by a marking. To
seat. In this case, the child seat may
position and lock the child seat on the
not always rest on the seat base of
rings 1, insert the child seat mountings
the vehicle seat.
in the access guides 2.
The ISOFIX anchorage points have been exclusively designed for child
The child seat strap must
seats with the ISOFIX system. Never fit a different type of child seat, seat
be attached to the corre-
belt or other objects to these anchorage points. Check that nothing is ob-
sponding ring.
structing the anchorage points.
Do not use any other
If your vehicle has been involved in a road accident, have the ISOFIX anchorage
mounting point.
points checked and replace your child seat.
1.49
CHILD SAFETY: fitting a child seat, general information (1/2)
Some seats are not suitable for fitting
The types of child seat indicated may
After installing the child seat, when this
child seats. The diagram on the follow-
not be available. Before using a differ-
is possible, you can move the vehi-
ing page shows you how to attach a
ent child seat, check with the manufac-
cle seat forward if necessary (so as to
child seat.
turer that it can be fitted.
leave enough space in the rear seats
for passengers or other child seats).
In the front seat
For a rear-facing child seat, do not let
The laws concerning children travel-
it touch the dashboard or move it to the
ling in the front passenger seat differ in
furthest forward position.
every country. Consult the legislation in
Do not change other settings after in-
Fit the child seat in a rear
force and follow the indications on the
stalling the child seat.
seat wherever possible.
diagram on the following page.
Make sure the child seat or
Before fitting a child seat in this seat (if
the child’s feet do not pre-
authorised):
vent the front seat from locking cor-
- lower the seat belt as far as possible;
rectly. ➥ 1.21.
- move the seat as far back as possi-
ble;
Check that when installing the child
- gently tilt the seatback away from
seat in the vehicle it is not at risk of
vertical (approximately 25°);
coming loose from its base.
- on equipped vehicles, raise the seat
If you have to remove the headrest,
base as far as possible.
check that it is correctly stored so
In all cases, when the vehicle is
that it does not come loose under
equipped with an adjustable headrest,
harsh braking or impact.
fully raise the seat headrest so that it
Always attach the child seat to the
does not interfere with the child seat
vehicle even if it is not in use so that
➥ 1.20.
it does not come loose under harsh
braking or impact.
RISK
OF
DEATH
OR
SERIOUS INJURY: before
fitting a rear-facing child
seat in this seat, make sure
that the airbag has been deacti-
vated ➥ 1.58.
1.50
CHILD SAFETY: fitting a child seat, general information (2/2)
In the rear seat
A carrycot can be installed across the
vehicle and will take up at least two
seats. Position the child with his or her
feet nearest the door.
Move the front seat as far forward as
possible to install a rear-facing child
seat, then move back the seat in front
as far as it will go, although without al-
lowing it to come into contact with the
child seat.
For the safety of a child in the facing
forwards, move the seat as far back as
possible and move the seat in front of
the child forward, remembering to move
the seatback forwards to avoid contact
A child seat with floor sup-
between the seat and the child’s legs.
ports must never be in-
stalled on the rear centre
Always remove the headrest from the
When fitting a child seat
seat.
rear seat on which the child seat is po-
(Group 2 or 3 booster seat),
sitioned. ➥ 3.42. If necessary, position
RISK OF DEATH OR SERIOUS
check that the seat belts
the rear vehicle seat as far back as pos-
INJURY.
operate
(wind) correctly:
sible. This must be done before fitting
➥ 1.29. If necessary, adjust the posi-
the child seat.
tion of the vehicle seat.
Check that the child seat is resting
against the back of the vehicle seat.
Fit the child seat in a rear
seat wherever possible.
To install an ISOFIX seat in
Ensure that the child seat
this seat, detach the central
or the child’s feet do not
seat belt by hand before engaging
prevent the front seat from
the bolts.
locking correctly. ➥ 1.21 or
➥ 3.44.
1.51
CHILD SEATS: attachment by seat belt (1/3)
The table below summarises the information already shown in the diagram on the following pages, to ensure the appli-
cable regulations are respected.
Front passenger
Type of child seat
Weight of the child
Rear side seats
Rear centre seat
seat
Carrycot
fitted
across the vehicle
< 10 kg
X
U (2)
X
Group 0
Rear-facing shell
seat
< 10 kg and < 13 kg
U (1) (5)
U (3)
U (3)
Groups 0 or 0 +
Shell seat/rear-facing
seat
< 13 kg and 9 to 18 kg
U (1) (5)
U (3)
U (3)
Groups 0+ and 1
Forward-facing seat
9 to 18 kg
X
U (4)
U (4)
Group 1
Booster seat
15 to 25 kg and 22 to
X
U (4)
X
Groups 2 and 3
36 kg
(1) RISK OF DEATH OR SERIOUS INJURY: before fitting a child seat in the front passenger seat, make sure that the
front passenger airbag has been deactivated. ➥ 1.58.
1.52
CHILD SEATS: attachment by seat belt (2/3)
X = Seat not suitable for fitting child seats of this type.
U = Seat which allows a child seat with “Universal” approval to be installed using a seat belt; check that it can be fitted.
(2) A carrycot can be installed across the vehicle and will take up at least two seats. Position the child with his or her feet nearest
the door.
(3) If necessary, position the vehicle seat as far back as possible. Move the front seat as far forward as possible to install a rear-
facing child seat, then move back the seat in front as far as it will go, although without allowing it to come into contact with the
child seat.
(4) In all situations, remove the rear headrest of the seat on which the child seat is positioned. This must be done before fitting the
child seat. ➥ 3.42. Move the seat in front of the child forwards, move the seatback forward to avoid contact between the seat
and the child’s legs.
(5) Raise the seat to the maximum and position it as far back as possible, tilting the seatback slightly (approximately 25°).
1.53
CHILD SEATS: attachment by seat belt (3/3)
Fitting diagram
³
Check the status of the airbag
before fitting a child seat or allowing a
passenger to use the seat.
Seat not suitable for fitting
²
child seats.
Child seat attached using the belt
¬
Seat which allows a child seat
with “Universal” approval to be attached
by a seat belt.
Using a child safety system
which is not approved for
RISK OF DEATH OR
this vehicle will not correctly
SERIOUS INJURY: before
protect the baby or child.
fitting a child seat in the
They risk serious or even fatal injury.
front passenger seat, make
sure that the front passenger airbag
has been deactivated. ➥ 1.58.
1.54
CHILD SEATS: attachment using the isofix system (1/3)
Fitting diagram
Child seat fitted using the ISOFIX
mounting
Seat which allows an ISOFIX
child seat to be fitted.
±
The rear seats are fitted with
an anchorage point which allows a
forward-facing ISOFIX child seat with
universal approval to be attached. The
anchorage points are located on the
backs of the rear seats.
Seat which does not allow a
²
child seat to be fitted.
Using a child safety system
which is not approved for
RISK OF DEATH OR
this vehicle will not correctly
SERIOUS INJURY: before
protect the baby or child.
fitting a child seat in the
They risk serious or even fatal injury.
front passenger seat, make
sure that the front passenger airbag
has been deactivated. ➥ 1.58.
1.55
CHILD SEATS: attachment using the isofix system (2/3)
The table below summarises the information already shown on the diagram on the previous pages, to ensure the regula-
tions in force are respected.
Weight of
Seat size
Front passenger
Type of child seat
Rear side seats
Rear centre seat
the child
[Gabarit]
seat
Carrycot fitted across
F, G
the vehicle
< 10 kg
X
X
X
[L1, L2]
Group 0
Rear-facing shell seat
E
< 13 kg
X
IL (1)
X
Groups 0 or 0 +
[R1]
Rear-facing seat
< 13 kg and 9 to
C, D
X
IL (1)
X
Groups 0 + or 1
18 kg
[R3, R2]
Forward-facing seat
A, B, B1
9 to 18 kg
X
IUF - IL (2)
X
Group 1
[F3, F2, F2X]
Booster seat
15 to 25 kg and
[B2]
X
IUF - IL (2)
X
Groups 2 or 3
22 to 36 kg
Seat i-Size
X
i-U
X
(1) RISK OF DEATH OR SERIOUS INJURY: before fitting a child seat in the front passenger seat, make sure that the
front passenger airbag has been deactivated. ➥ 1.58.
1.56
CHILD SEATS: attachment using the isofix system (3/3)
X = Seat not suitable for fitting child seats ISOFIX.
IUF/IL = On equipped vehicles, seat which allows an approved “Universal/semi-universal” or “vehicle specific” child seat to be at-
tached using the ISOFIX system; check that it can be fitted.
i-U = Suitable for the i-Size restraint devices in the “universal” forward-facing and backward-facing category.
(1) If necessary, position the vehicle seat as far back as possible. Move the front seat as far forward as possible to install a rear-
facing child seat, then move back the seat in front as far as it will go, although without allowing it to come into contact with the
child seat.
(2) In all situations, remove the rear headrest of the seat on which the child seat is positioned. This must be done before fitting the
child seat. ➥ 3.42. Move the seat in front of the child forwards, move the seatback forward to avoid contact between the seat
and the child’s legs.
The size of the ISOFIX child seat is indicated by a letter:
- A, B and B1 [F3, F2, F2X]: for forward-facing seats in group 1 (9 to 18 kg);
- C and D [R3, R2]: shell seat or rear-facing seats in group 0+ (less than 13 kg) or group 1 (9 to 18 kg);
- E [R1]: rear-facing shell seats in group 0 (less than 10 kg) or 0+ (less than 13 kg);
- F and G [L1, L2]: cots in group 0 (less than 10 kg);
- [B2]: boosters in groups 2 and 3 (15 to 25 kg and 22 to 36 kg).
1.57
CHILD SAFETY: deactivating, activating the front passenger airbag (1/3)
The front passenger airbag
should only be activated or
2
deactivated when the vehi-
cle is stationary with the
ignition off.
If it is interfered with when the ve-
hicle is being driven, indicator lights
å
Switch the ignition off then on again
1
to reset the air bag in accordance
with the lock position.
Deactivating the front
To deactivate the l’airbag: with the
vehicle stationary and the ignition
passenger airbag
off, push and turn lock 1 to the OFF po-
Before installing a child seat on the
sition.
front passenger seat:
With the ignition on, you must check
DANGER
- check that the child seat can be in-
stalled on this seat;
that the warning light ¹
is lit on the
Since operation of the front
display 2.
passenger airbag is not
- You must deactivate the airbag in
compatible with the po-
the case of a child seat that is facing
This light remains permanently lit to
sition of a rear-facing child seat,
backwards.
let you know that you can fit a child
NEVER fit a rear-facing child re-
seat.
straint system in a seat protected
by an ACTIVATED front AIRBAG .
This can lead to the DEATH of the
CHILD or SERIOUS INJURY.
1.58
CHILD SAFETY: deactivating, activating the front passenger airbag (2/3)
A
A
3
The markings on the dashboard and
labels A on each side of the passen-
ger sun visor 3 (example: label shown
above) remind you of these instruc-
tions.
DANGER
Since operation of the front
passenger airbag is not
compatible with the po-
sition of a rear-facing child seat,
NEVER fit a rear-facing child re-
straint system in a seat protected
by an ACTIVATED front AIRBAG.
This can lead to the DEATH of the
CHILD or SERIOUS INJURY.
1.59
CHILD SAFETY: deactivating, activating the front passenger airbag (3/3)
Operating faults
2
It is forbidden to fit a rear-facing child
seat to the front passenger seat if the
airbag activation/deactivation system is
faulty.
Allowing any other passenger to sit in
that seat is not recommended.
Contact your approved dealer as soon
as possible.
1
Activating the front
To reactivate the airbag: with the
vehicle stoppedand the ignition off,
passenger airbag
push and turn lock 1 to the ON position.
You should reactivate the airbag as
With the ignition switched on, you must
The front passenger airbag
soon as you remove the child seat from
must only be activated or
the front passenger seat to ensure the
check that the warning light ]
is
deactivated when the vehi-
protection of the front passenger in the
out and that the warning light
cle is stationary with the
event of an impact.
comes on the display 2 after each start-
ignition off.
up for around 60 seconds.
If it is interfered with when the ve-
The front passenger airbag is activated.
hicle is being driven, indicator lights
å
Switch the ignition off then on again
to reset the air bag in accordance
with the lock position.
1.60
AUDIBLE AND VISUAL SIGNALS
Direction indicators
1
Move stalk 1 parallel to the steering
wheel and in the direction you are going
to turn it.
One-touch mode
2
When driving, it is possible that the
steering wheel may not be turned suf-
A
ficiently to return the stalk automatically
to its starting position.
In this case, briefly turn stalk 1 to the in-
termediate position, then release it: the
stalk returns to its original point and the
indicator light flashes three times.
Horn
Hazard warning lights
é
Press the steering wheel boss A to ac-
Press switch 2. This switch ac-
tivate the horn.
tivates all four direction indicators and
the side indicator lights simultaneously.
It must only be used in an emergency to
Headlight flasher
warn drivers of other vehicles that you
Pull stalk 1 towards you to flash the
have had to stop in an area where stop-
headlights.
ping is prohibited or unexpected or that
you are obliged to drive under special
conditions.
Depending on the vehicle, the hazard
warning lights may come on automati-
cally under heavy deceleration. You can
switch them off by pressing switch 2.
1.61
DRIVER’S POSITION, LEFT-HAND DRIVE (1/2)
1
2
3
4
5
6
7
8
1
9
10
2
1
11
12
2
1
26
23
22
21
20
19
15
14
13
18
25
16
24
17
1.62

















Content      ..     1      2      3      4      ..
