Renault Express (2022 year). Manual in english - page 12





INTERIOR LIGHTING: changing bulbs (4/5)
18
16
16
19
17
Glove box light 16
Remove the bulb concerned.
Luggage compartment
(depending on the vehicle)
Bulb type: W5W.
light 18
Unclip light 16 using a flat-blade screw-
Unclip light 18 (using a flat-blade screw-
driver or similar) by pressing on the
driver or similar), by pressing on tab 19
tab 17 to move the light towards the
to move the light towards the inside of
inside of the unit.
the luggage compartment.
Remove the bulb concerned.
Type of bulb: W5W.
The bulbs are under pres-
sure and can break when
replaced.
Risk of injury.
5.25
INTERIOR LIGHTING: changing bulbs (5/5)
20
22
21
Release the lens 20 and access the
LED light 22
bulb 21.
Consult an approved dealer.
Type of bulb 21: W5W.
The bulbs are under pres-
sure and can break when
replaced.
Risk of injury.
5.26
FUSES (1/4)
3
1
Use the fuse allocation label in the
storage compartment to identify the
fuses.
Certain fuses should only be re-
placed by a qualified professional.
2
A
These fuses are not listed on the
label.
Only change the fuses represented
Fuse box
Tweezers 2
on the label.
If any electrical component does not
Remove the fuse using tweezers 3, lo-
work, check the condition of the fuses.
cated at the back of flap 1.
Fuses in the passenger compart-
To remove the fuse from the tweezers,
ment A
slide the fuse to the side.
Check the fuse in question
and replace it, if necessary,
Unlock the handle 2 and pull to open
It is not advisable to use the free fuse
with a fuse of the same
the flap 1.
locations.
rating.
Depending on the vehicle, to identify
If a fuse is fitted where the rating is
the fuses, refer to the fuse allocation
too high, it may cause the electrical
label located at the back of the flap 1
circuit to overheat (risk of fire) in the
and shown on the following pages.
event of an item of equipment using
To comply with current legislation, or
an excessive amount of current.
as a precaution, you can obtain an
emergency kit from your approved
dealer containing a set of spare
bulbs and fuses.
5.27
FUSES (2/4)
Before carrying out any
action in the engine com-
partment, you must switch
B
off the ignition. ➥ 2.3.
C
Please note when work-
ing close to the engine that
it may be hot. The engine
Fuses in the engine compartment B
cooling fan may also start
and C
at any moment. The
warning
Some functions are protected by fuses
light in the engine compartment re-
located in the engine compartment in
minds you of this.
units B and C.
However, because of their reduced
Risk of injury.
accessibility, we advise you to have
your fuses replaced by an approved
dealer.
When working in the engine
compartment, ensure that
the windscreen wiper stalk
is in the park position.
Risk of injury.
5.28
FUSES (3/4)
Allocation of fuses
(the presence and location of fuses depends on the vehicle equipment level)
Symbol
Allocation
Symbol
Allocation
Ì
Horn
Seat belt warning
Front window winder, electric front windows
Instrument panel
Central door locking
Towbar socket
Front, rear and luggage compartment accesso-
Heated seats, diagnostic socket
ries 12V socket, USB sockets
Courtesy lights, luggage compartment lighting,
ABS - ESC, brake switch, clutch switch, engine
n
glove box lighting, energy management unit
immobiliser
U
Rain/light sensor
Ä
Injection, passenger compartment unit
Á
Front headlights
Starter
K
G
Front and rear fog lights
Å
Airbag, seat belt pretensioners
Windscreen washer pump, windscreen wipers,
D
Direction indicator lights
E
wireless charging
Brake lights, reversing lights
f
Windscreen wiper
5.29
FUSES (4/4)
Allocation of fuses
(the presence and location of fuses depends on the vehicle equipment level)
Symbol
Allocation
yṪ
Air conditioning control panel
Air conditioning control panel, accessories sock-
ets, radio
Cigarette lighter
Power-assisted steering
Interface for superstructures
Rear view electric mirrors control
Heated rear view mirrors
EMM
Energy management unit
RADIO
Radio, multimedia, diagnostic socket
5.30
RADIO FREQUENCY REMOTE CONTROL: batteries (1/2)
The batteries are available from ap-
proved Dealers, and their service
life approximately two years.
Check that there is no dye on the
battery: risk of an incorrect electri-
cal contact.
2
1
If they need to be replaced,
be sure to use the same
1
or equivalent type of bat-
Replacing the battery
Note: it is not advisable to touch the
tery (consult an Approved
electronic circuit in the key cover when
Dealer).
Open the case at slot 1 using a flat-
replacing the battery.
blade screwdriver or similar, and re-
place the battery 2, observing the type
and polarity shown on the back of the
cover.
Check that the cover is clipped shut.
When replacing:
- Make sure that the batter-
ies are correctly inserted.
Risk of explosion.
- Do not use the remote control if
the cover does not close prop-
erly.
5.31
RADIO FREQUENCY REMOTE CONTROL: batteries (2/2)
Operating faults
If the battery is too weak to ensure cor-
rect operation, you will still be able to
start and lock/unlock the vehicle ➥ 1.6.
Precautions relating to
batteries:
- keep (new or used) bat-
teries out of reach of chil-
dren;
- do not swallow batteries;
Risk of chemical burns which
may prove fatal.
- if ingested or inserted into any
part of the body, consult a doctor
as soon as possible.
Do not throw away your used bat-
teries; give them to an organisation
responsible for collecting and recy-
cling batteries.
5.32
BATTERY: troubleshooting (1/2)
To avoid all risk of sparks:
Connecting a battery charger
-
Ensure that any power consumers
The battery charger must be com-
(courtesy lights etc.) are switched off
patible with a battery with nominal
before disconnecting or reconnect-
voltage of 12 volts.
ing a battery;
Do not disconnect the battery when the
-
when charging, stop the charger
engine is running. Follow the instruc-
before connecting or disconnecting
tions given by the manufacturer of
the battery;
the battery charger you are using.
-
to avoid creating a short circuit be-
Handle the battery with care
tween the terminals, do not place
as it contains sulphuric acid,
metal objects on the battery;
which must not come into
contact with eyes or skin. If
-
always wait at least one minute after
it does, wash the affected area with
the engine has been switched off
plenty of cold water. If necessary,
before disconnecting a battery;
consult a doctor.
-
make sure that you reconnect the
Keep naked flames, red hot objects
battery terminals after refitting.
and sparks away from the battery
components as there is a risk of
explosion.
Special procedures may be
Please note when working close to
required to charge some
the engine that it may be hot. In ad-
batteries. Contact your ap-
dition, the engine cooling fan may
proved dealer.
Avoid all risk of sparks which may
start at any moment. The
cause an immediate explosion, and
warning light in the engine compart-
charge the battery in a well venti-
ment reminds you of this.
Before carrying out any
lated area.
Risk of injury.
action in the engine com-
partment, you must switch
Risk of serious injury.
off the ignition. ➥ 2.3 .
5.33
BATTERY: troubleshooting (2/2)
Starting the vehicle using the
battery from another vehicle
If you have to use the battery from an-
other vehicle to start, obtain suitable
1
4
jump leads (with a large cross section)
4
from an approved dealer or, if you al-
ready have jump leads, ensure that
B
they are in perfect condition.
The two batteries must have an iden-
tical nominal voltage of 12 volts. The
A
battery supplying the current should
have a capacity (amp-hours, Ah) which
1
3
2
is at least the same as that of the dis-
charged battery.
Ensure that there is no risk of contact
Connect positive (+) lead A to (+) termi-
between the two vehicles (risk of short
nal 1 of the discharged battery, then to
circuiting when the positive terminals
(+) terminal 2 of the battery supplying
are connected) and that the discharged
the current.
battery is properly connected. Switch
off your vehicle ignition.
Connect the negative cable (-) B to the
(-) 3 terminal of the battery supplying
Start the engine of the vehicle supply-
the current and then to the (-) 4 termi-
ing the current and run it at an interme-
nal of the discharged battery.
Check that there is no con-
diate engine speed.
Start the engine as normal. As soon as
tact between leads A and B
it starts, disconnect cables A and B in
and that the positive lead A
reverse order (4-3-2-1).
is not touching any metal
parts on the vehicle supplying the
current.
Risk of serious injury and/or
damage to the vehicle.
5.34
WIPER BLADES: replacement (1/2)
C
1
2
3
A
4
5
G
B
F
D
E
Replacing windscreen wiper
-
press the tab 3 and slide the wiper
To refit
blade downwards until the hook 5
blades 2
To refit the wiper blade, proceed in re-
on the wiper arm is released (move-
To replace the wipers, first put them in
verse order of removal. Make sure that
ment D);
the service positionC.
the blade is correctly locked in position.
-
slide the blade (movement E) then
Ignition switched off:
To return the blades to lowered po-
lift it (movement F) to release it.
sition, make sure that the blades are
- set the stalk 1 to position B (fast
folded down onto the windscreen then
wiping speed function): the wiper
set the 1 stalk to position A (off): the
blades will stop in service position C
windscreen wiper blades will fold into
away from the bonnet;
the bonnet when the ignition is switched
- lift the wiper arm 4;
on.
- turn the blade horizontally (move-
ment G);
5.35
WIPER BLADES: replacement (2/2)
To refit
To refit the wiper blade, proceed in re-
verse order of removal. Make sure that
6
the blade is correctly locked in position.
H
7
Before changing the rear
wiper blade, make sure the
stalk is in the stop position
(deactivated).
Risk of injury.
Replacing the rear screen
- In frosty weather, make
wiper blade 7
sure that the wiper blades
are not stuck by ice
(to
-
With the ignition switched off, lift
avoid the risk of the motor
wiper arm 6;
overheating).
-
pivot the blade 7 until some resist-
ance is met;
- Check the condition of the wiper
pull the blade to release it (move-
Check the condition of the wiper
blades.
ment H).
blades. You are responsible for their
Replace the wiper blades as soon
service life:
as they begin to lose efficiency
- clean the blades, windscreen and
(approximately once a year).
rear screen regularly with soapy
water;
Whilst changing the blade, take care
- do not use them when the wind-
not to drop the arm onto the window
screen or rear screen are dry;
after it has been removed as this
- free them from the windscreen or
may break the window.
rear screen when they have not
been used for a long time.
5.36
TOWING: breakdown (1/2)
Steering column unlocking
Insert the key in the ignition switch and
turn it to the “On” position. Put the lever
in neutral.
The steering column unlocks, the ac-
cessory functions are powered: you
can use the vehicle’s lights (direction
indicators, brake lights, etc.). At night
the vehicle must have its lights on.
The speed specified by current legis-
lation for towing must always be ob-
served. If you are driving the towing
vehicle, do not exceed the permissible
towing weight for your vehicle. ➥ 6.9.
Do not remove the key from
When the engine is stopped,
the ignition when the vehi-
steering and braking assist-
cle is being towed.
ance are not operational.
5.37
TOWING: breakdown (2/2)
- Use a rigid towing bar.
If a rope or cable is used
(where the law allows this),
the vehicle being towed
must be able to brake.
- A vehicle must not be towed if it is
1
not fit to be driven.
4
2
- Avoid accelerating or braking
suddenly when towing, as this
2
may result in damage being
caused to the vehicle.
- When towing a vehicle, it is ad-
3
visable not to exceed 15 mph
5
(25 km/h).
Only use the front 1 and rear 4towing
Access to towing points
points (never use the driveshafts or any
Unclip cover 3 or 5 by inserting a flat-
other part of the vehicle).
blade screwdriver or similar under the
These towing points may only be used
cover.
for pulling. They must never be used for
Tighten towing hitch 2 fully: as much
lifting the vehicle directly or indirectly.
as possible by hand at first, then finish
tightening it using the wheelbrace.
Only use the towing eye 2 and the
wheelbrace located in the boot ➥ 5.9.
Ensure that the towing eye
Do not leave the tools unse-
is bolted correctly.
cured inside the vehicle as
they may come loose under
Risk of losing the towed
braking.
object.
5.38
FITTED AUDIO EQUIPMENT
1
2
-
In all cases, it is very important to
follow the manufacturer’s instruc-
tions carefully.
-
The specifications of the brack-
ets and wires (available from our
network) vary depending on the
If your vehicle is not fitted with an audio
Radio location 1
equipment level of your vehicle
system, it is pre-equipped with:
Unclip and remove storage compart-
and the type of radio.
- a location for the radio 1;
ment 1.
Consult an approved Dealer to
find out the correct part number.
– door loudspeakers 2.
To install any equipment, please con-
sult an authorised dealer.
-
No work may be carried out on
the vehicle’s electrical or radio
circuits, except by approved
Dealers since an incorrectly
connected system may result in
damage to the electrical equip-
ment and/or the components
connected to it.
5.39
ACCESSORIES
Electrical and electronic accessories
Before installing this type of accessory (particularly for transmitters/receivers: frequency bandwidth, power level, po-
sition of the aerial, etc.), make sure it is compatible with your vehicle. You can get advice from an authorised dealer.
Connect accessories with a maximum power of 120 Watts only. Fire hazard. When several accessory sockets are
used at the same time, the total power of the connected accessories must not exceed 180 watts.
No work may be carried out on the vehicle’s electrical or radio circuits, except by authorised dealers: an incorrectly connected
system may result in damage being caused to the electrical equipment and/or the components connected to it.
If the vehicle is fitted with any aftermarket electrical equipment, make sure that the installation is correctly protected by a fuse.
Establish the rating and position of this fuse.
Using the diagnostic socket
The use of electronic accessories on the diagnostic socket may cause serious disturbance to the vehicle’s electronic systems.
For your safety we recommend that you use only electronic accessories approved by the manufacturer, consult an Approved
Dealer. Serious accident risk.
Use of transmitting/receiving devices (telephones, CB equipment etc.).
Telephones and CB equipment with integrated aerials may cause interference to the electronic systems originally fitted to the
vehicle: it is advisable only to use equipment with an external aerial. Furthermore, we remind you of the need to conform
to the legislation in force concerning the use of such equipment.
Fitting aftermarket accessories
If you wish to install accessories on the vehicle: please contact an authorised dealer. Also, to ensure the correct operation of
your vehicle, and to avoid any risk to your safety, we recommend that you use only accessories specifically designed for your
vehicle, which are the only accessories for which the manufacturer will provide a warranty.
If you are using an anti-theft device, only attach it to the brake pedal.
Obstructions to the driver
On the driver’s side, only use mats suitable for the vehicle, attached with the pre-fitted components, and check the fitting regu-
larly. Do not lay one mat on top of another. There is a risk of wedging the pedals.
5.40
OPERATING FAULTS (1/8)
The following advice will enable you to carry out quick, temporary repairs. For safety reasons you should always contact
an approved dealer as soon as possible.
Using the remote control
POSSIBLE CAUSES
ACTION REQUIRED
The remote control does not lock or The remote control battery is flat.
Use the emergency key.
unlock the doors.
Use of appliances operating on the same
Stop using the devices or use the key.
frequency as the remote control (mobile
phone, etc.).
Vehicle located in a high electromagnetic
Replace the battery. You will still be able to
radiation zone.
lock, unlock, and start your vehicle ➥ 1.6
Discharged battery.
and ➥ 2.3.
The vehicle is started.
With the engine running, the key’s locking/
unlocking device is blocked. Turn off the
ignition.
Desynchronisation of the remote control.
Unlock the driver’s door using the key in
the door lock, then start the engine to syn-
chronise the remote control.
5.41
OPERATING FAULTS (2/8)
The following advice will enable you to carry out quick, temporary repairs. For safety reasons you should always contact
an approved dealer as soon as possible.
The starter is activated
POSSIBLE CAUSES
WHAT TO DO
The instrument panel indicator lights
Battery terminals disconnected,
Retighten them, reconnect them or clean
are weak or fail to light up and the
oxidised or incorrectly secured.
them if they are oxidised.
starter does not turn.
Battery discharged or worn.
Connect another battery to the faulty bat-
tery. ➥ 5.33 or replace the battery if neces-
sary.
Do not push the vehicle if the steering
column is locked.
The engine will not start.
Starting conditions are not fulfilled.
➥ 2.3
With the vehicle stationary, engine
Petrol version, this is not necessar-
The engine’s idle speed should decrease
cold, the engine’s idle speed is high.
ily a fault.
after about one minute. Otherwise, this
This may be caused by the in-
may be caused by another fault. Call an ap-
crease in the engine temperature.
proved Dealer.
The steering column remains locked.
Steering wheel locked.
To unlock: turn the key and the steering
wheel slightly ➥ 2.2.
Faulty electrical circuit.
Consult an approved dealer.
5.42
OPERATING FAULTS (3/8)
On the road
POSSIBLE CAUSES
WHAT TO DO
Vibrations.
Tyres not inflated to correct pres-
Check the tyre pressures; if this is not the cause, have
sures, incorrectly balanced or dam-
their condition checked by an approved dealer.
aged.
Coolant boiling in the coolant
Mechanical fault: damaged cylin-
Stop the engine.
reservoir.
der head gasket.
Contact an approved dealer.
Smoke under the bonnet.
Short circuit or cooling system
Stop, switch off the ignition, move away from the vehi-
leak.
cle and contact an approved dealer.
The oil pressure warning light
comes on:
while cornering or braking;
The level is too low.
Top up the engine oil ➥ 4.6.
is slow to go out or re-
Loss of oil pressure.
Stop the vehicle and contact an approved dealer.
mains lit up under accel-
eration.
5.43
OPERATING FAULTS (4/8)
On the road
POSSIBLE CAUSES
WHAT TO DO
Abnormal white smoke from the ex-
In the diesel version, this is not
➥ 2.10.
haust.
necessarily a fault. Smoke may be
caused by particle filter regeneration.
In the case of the petrol version, this
Reduce the engine speed and avoid
is not necessarily a fault. Depending
sudden acceleration to gradually make the
on the climate conditions (cold,
smoke disappear.
moisture etc.), the smoke may occur
Otherwise, this may be caused by another
during strong vehicle acceleration.
fault. Consult an approved dealer.
Smoke under the bonnet.
Short-circuit or cooling system leak.
Stop, switch off the ignition, stand away from
the vehicle and contact an approved dealer.
Vibrations.
Tyres not inflated to the correct pres-
Check the tyre pressures; if this is not the
sure, incorrectly balanced or dam-
cause, have their condition checked by an
aged.
approved dealer.
Steering becomes heavy.
Assistance overheating.
Drive carefully at reduced speed, be aware
of the level of force in the steering wheel
No power-assisted steering oil.
needed to turn the wheels. Consult an ap-
Fault in the assistance system.
proved dealer.
5.44
OPERATING FAULTS (5/8)
On the road
POSSIBLE CAUSES
WHAT TO DO
Whistling.
Roof aerial poorly positioned.
Position the aerial.
The engine is overheating. The cool-
Engine cooling fan not working.
Stop the vehicle, switch off the engine and
contact an approved dealer.
ant temperature indicator light Ô
comes on in red.
Coolant leaks.
Stop the vehicle, switch off the engine and
check the coolant reservoir: it should con-
tain fluid. If there is no coolant, consult an
approved dealer as soon as possible.
The oil change warning light remains
Warning not reset after oil change.
Reset the alert after an oil change ➥ 1.67.
lit after an oil change.
Coolant boiling in the coolant reser-
Mechanical fault: cylinder head
Stop the engine.
voir.
gasket
Call an approved Dealer.
damaged.
Radiator: if there is a significant lack of coolant, remember that it must never be topped up using cold coolant when the
engine is very hot. After any procedure on the vehicle which has involved even partial draining of the cooling system,
it must be refilled with a new mixture prepared in the correct proportions. Reminder: only products approved by our
Technical Department may be used for this purpose.
5.45















Content      ..     10      11      12      13     ..
