PUNCTURE, EMERGENCY SPARE WHEEL (3/4)
9
10
11
1
A
B
7
8
7
6
Emergency spare wheel 7
To access emergency spare wheel 7
- from the outside of the vehicle, pull
- Open the boot lid;
the wheel in order to access the
It is located under the floor at the rear
– remove the blanking cover 6;
handle 11;
of the vehicle. In the event of a punc-
– only use the wheel brace 1 (using
- turn the handle 11 (movement B)
ture if your vehicle is fitted with a towbar
a different tool could damage the
in order to free the cable from the
and/or if the luggage compartment
mechanism) to unroll the retaining
part 9;
is loaded, to remove the emergency
cable. Unscrew the nut in a clock-
- lift the part 9 from the wheel 7;
spare wheel from its winch you must lift
wise direction (movement A), and
- remove the part 9 via the slot 10;
the vehicle using a jack at the jacking
the wheel will lower to the ground;
- stand the wheel up, pass the cable
point nearest the wheel.
and the component 8 through the
wheel rim and release the wheel.
Do not touch the exhaust.
Risk of burns.
5.4
PUNCTURE, EMERGENCY SPARE WHEEL (4/4)
9
10
C
11
1
D
7
8
7
12
To refit the wheel 7
From the luggage compartment, tighten
As the punctured wheel
To carry out this operation, the cable
the nut fully in an anti-clockwise direc-
is wider than the emer-
must be unwound.
tion (movement C) in order to wind up
gency spare wheel, when
- Stand the wheel up with the valve 12
the retaining cable, ensuring that the
you place the punctured
towards you.
wheel remains horizontal and the cable
wheel in the emergency spare
- Thread the cable and the compo-
taut.
wheel bay, the vehicle’s ground
nent 8 through the wheel rim.
Final tightening must be carried out with
clearance is reduced. To pre-
- Position wheel valve 12 towards the
the spanner 1 in the horizontal position.
vent damage, proceed carefully
ground.
Refit the 6 blanking cover.
when driving over raised sections
- Insert the cable in the slot 10 up to
of road and when dismounting
the centre of the part 9.
pavements When this is fitted to
- Insert the part 9 into the wheel 7.
the vehicle, which must only be
- Turn the handle 11 (movement D) to
a temporary measure, the driv-
lock the cable.
ing speed must not exceed the
speed indicated on the label on
the wheel.
5.5
TYRE PRESSURE KIT (1/3)
Do not attempt to use the
The kit is only approved for
B
inflation kit if the tyre has
inflating the tyres of the ve-
A
been damaged as a result
hicle originally equipped
of driving with a puncture.
with the kit.
You should therefore carefully check
It must never be used to inflate
the condition of the tyre sidewalls
the tyres of another vehicle, or any
before any operation.
other inflatable object (rubber ring,
rubber boat, etc.).
Driving with underinflated, flat or
punctured tyres can be dangerous
Avoid spillage on skin when han-
and may make the tyre impossible
dling the repair product bottle. If
to repair.
droplets do leak out, rinse them off
with plenty of water.
This repair is temporary
Keep the repair kit away from chil-
A tyre which has been punctured
dren.
should always be inspected (and re-
paired, where possible) as soon as
Do not dispose of the empty bottle
The kit repairs tyres with
possible by a specialist.
in the countryside. Return it to your
tread A damaged by ob-
approved dealer or to a recycling or-
jects smaller than 4 mm. It
When replacing a tyre repaired with
ganisation.
cannot repair all types of
this kit, you must consult a special-
puncture, such as cuts of more than
ist. When driving, vibration may be
The bottle has a limited service
4 mm, or cuts in tyre sidewall B etc.
felt due to the presence of the repair
life which is indicated on its label.
product injected into the tyre.
Check the expiry date.
Ensure also that the wheel rim is in
good condition.
Contact an approved dealer to re-
place the inflation tube and repair
Do not pull out the foreign body
product bottle.
causing the puncture if it is still in
the tyre.
5.6
TYRE PRESSURE KIT (2/3)
With the engine running and the
If a minimum pressure of 1.8 bar is
parking brake applied,
not reached after 15 minutes, repair
Disconnect any accessories previ-
is not possible; do not drive the ve-
ously connected to the vehicle’s ac-
hicle but contact an approved dealer.
1
cessories sockets;
-
refer to the information on the in-
flation kit compressor located in
the luggage compartment of the ve-
hicle and follow the instructions;
-
inflate the tyre to the recommended
pressure ➥ 4.14 ;
2
-
after a maximum of 15 minutes, stop
Before using this kit, park
inflating and read the pressure (on
the vehicle at a sufficient
pressure gauge 2).
distance from traffic, switch
Note: while the bottle is emptying
on the hazard warning
(approximately
30 seconds), the
lights, apply the handbrake, ask all
Depending on the vehicle, in the event
passengers to leave the vehicle and
pressure gauge 2 will briefly indicate
of a puncture, use the kit located in the
keep them away from traffic.
a pressure of 6 bar, then the pres-
boot or underneath the luggage com-
sure drops;
partment carpet.
-
Adjust the pressure: to increase it,
Vehicle fitted with a tyre pressure
continue inflation with the kit. To
loss warning system
reduce it, press the button 1.
In the event of under-inflation (punc-
If the vehicle is parked on
tures, under-inflation etc.), the
the hard shoulder, you must
warning light appears on the instrument
warn other road users of
panel. ➥ 2.18.
your vehicle’s presence
with a warning triangle or with other
devices as per the legislation apply-
ing to the country you are in.
5.7
TYRE PRESSURE KIT (3/3)
- Start immediately and drive at a
speed between 12 to 37 mph (20 to
3
60 km/h) in order to distribute the
product evenly in the tyre; after driv-
Please be aware that a
ing a distance of 2 miles (3 km), stop
poorly tightened or miss-
and check the pressure.
ing valve cap can make the
- If the pressure is higher than 1.3 bar
tyres less airtight and may
but lower than the recommended
lead to pressure loss.
pressure (refer to the label affixed to
Always use valve caps identical to
the edge of the driver’s door), adjust
those fitted originally and tighten
it. Otherwise, contact an approved
them fully.
dealer: the tyre cannot be repaired.
Precautions when using the
kit
Once the tyre is correctly inflated,
The kit should not be operated for more
remove the kit: unclip the inflation
than 15 consecutive minutes.
adapter slowly from the container 3 to
The container must be replaced after
Following repair with the kit,
prevent any product spatter and store
the first use even if liquid remains
do not travel further than
the container in plastic packaging to
inside.
120 miles (200 km). In addi-
prevent product leaks.
tion, reduce your speed and
- Affix the driving recommendation
under no circumstances exceed
label (located under the container) to
48 mph (80 km/h). The sticker,
the dashboard where the driver can
which you must affix in a prominent
see it.
position on the dashboard, reminds
- Put the kit away.
you of this.
Nothing should be placed
- At the end of this initial inflation op-
Depending on the country or local
around the driver’s feet
eration, air will still escape from the
legislation, a tyre repaired with the
as such objects may slide
tyre. You must drive a short distance
inflation kit may need to be replaced.
under the pedals during
in order to seal the hole.
sudden braking manoeuvres and
obstruct their use.
5.8
TOOLS
Wheelbrace 4
2
5
1
This locks and unlocks the wheel bolts
and the access to emergency spare
1
wheel.
4
2
3
Tow eye 3
➥ 5.37
4
3
Accessing the tools
Hubcap tool 2
The presence of the tools depends on
This tool is used to remove the wheel
the vehicle.
trims. Located behind the jack.
The tools are located in the luggage
compartment.
Jack 1
To use the jack, unscrew nut 5. When
replacing the jack, fold it down correctly
Do not leave the tools unsecured inside the vehicle as they may come
(being sure to put the handle back in
loose under braking. After use, make sure the tools are correctly posi-
position) and replace it in its housing.
tioned in their mountings: risk of injury.
Tighten the nut 5 to secure the jack.
If bolts are supplied with the emergency spare wheel, it is imperative that
they are used and that they are used for the emergency spare wheel only: refer
to the label affixed to the emergency spare wheel.
The jack is designed for wheel changing purposes only. Under no circumstances
should it be used for carrying out repairs underneath the vehicle or to gain access
to the underside of the vehicle.
5.9
WHEEL TRIMS
3
4
D
C
B
1
A
1
2
Wheel trim with concealed
Wheel trim 3
Central wheel trim with
wheel bolts
visible wheel bolts
Remove using hubcap tool 1 (located in
(Wheel trim 4)
Remove the wheel trim using hubcap
the tool kit) by engaging the hook in the
tool 1, (located in the tool kit) by en-
opening near the edge of the trim.
The bolts are directly accessible.
gaging the hook in the opening near
To refit, position the trim attachments
valve 2.
facing the wheel attachments and
To refit the wheel trim, align it with
press hard in the middle of the trim to
valve 2. Push the retaining hooks in fully,
clip it to the wheel.
starting on the side of valve A, followed
by B and C, finishing at Dopposite the
valve.
5.10
CHANGING A WHEEL (1/2)
Vehicles equipped with a jack
Place the jack 4 horizontally; the jack
head must be lined up with the sill 1
and wheelbrace
closest to the wheel concerned, as
If necessary, remove the hubcap.
shown by arrow 2.
2
Use the wheelbrace 3 to slacken off
Crank up the jack 4 by hand at first to
1
the wheel bolts. Fit it so that you press
align the base plate (which should be
downwards rather than pulling up-
inclined further inwards than the jack
wards.
head).
3
Continue to crank the jack so that the
baseplate is correctly positioned
(it
should be underneath the vehicle and
aligned with the jack head).
Turn the wheelbrace until the wheel lifts
4
off the ground.
Switch on the hazard warn-
ing lights.
Keep the vehicle away from
traffic and on a level surface
where it will not slip.
If the vehicle is parked on
the hard shoulder, you must
Apply the parking brake and engage
warn other road users of
a gear (first or reverse).
your vehicle’s presence
Ask all passengers to leave the ve-
with a warning triangle or with other
To prevent any risk of injury
hicle and keep them away from traf-
devices as per the legislation apply-
or damage to the vehicle,
fic.
ing to the country you are in.
only crank the jack until the
wheel you are replacing is
a maximum of 3 centimetres off the
ground.
5.11
CHANGING A WHEEL (2/2)
Undo the bolts and take off the wheel.
Vehicle fitted with a tyre pressure
loss warning system
Fit the emergency spare wheel on the
central hub and turn it to locate the
In the event of under-inflation (punc-
mounting holes in the wheel and the
tures, under-inflation etc.), the
hub.
warning light appears on the instrument
Tighten the bolts, checking that the
panel. ➥ 2.18.
wheel is correctly positioned on its hub.
Lower the jack.
With the wheel on the ground, tighten
the bolts fully and have the tightness of
the bolts checked and the emergency
spare wheel pressure checked as soon
as possible.
Do not leave the tools un-
secured inside the vehicle
as they may come loose
under braking. After use,
make sure the tools are correctly
positioned in their mountings: risk
of injury.
If bolts are supplied with the emer-
gency spare wheel, it is imperative
that they are used and that they
are used for the emergency spare
wheel only: refer to the label affixed
to the emergency spare wheel.
If you have a puncture, re-
The jack is designed for wheel
place the wheel as soon
Anti-theft bolt
changing purposes only. Under no
as possible. A tyre which
circumstances should it be used for
If you use anti-theft bolts, please
has been punctured should
carrying out repairs underneath the
refer to the instructions given on
always be inspected (and repaired,
vehicle or to gain access to the un-
the interior of the wheel trim to po-
where possible) by a specialist.
derside of the vehicle.
sition the bolts (wheel trim may not
be able to fit).
5.12
TYRES (1/3)
Tyre and wheel safety
When the tyre tread has been worn to
1
the level of the wear indicators, they
The tyres are the only contact between
become visible 2: it is then necessary
the vehicle and the road, so it is essen-
to replace your tyres because the tread
tial to keep them in good condition.
rubber is 1.6 mm deep at most, re-
You must make sure that your tyres
sulting in poor road-holding on wet
conform to local road traffic regulations.
roads.
An overloaded vehicle, long journeys
by motorway, particularly in very hot
weather, or continual driving on poorly
2
surfaced minor roads will lead to more
rapid tyre wear and affect safety.
For your safety, please re-
spect the speed limit.
When they need to be re-
placed, only tyres of the
same make, size, type and profile
Maintaining the tyres
should be used on a single axle.
The tyres must be in good condition
They must either have a load ca-
and the tread form must have sufficient
pacity and speed rating at least
depth; tyres approved by our Technical
equal to those of the original
Department have wear warning strips 1
tyres, or be recommended by an
which are indicators moulded into
authorised dealer.
the tread at several points.
Failure to heed these instructions
Incidents which occur when
could endanger your safety and
driving, such as striking the
affect your vehicle’s roadworthi-
kerb, may damage the tyres
ness.
and wheel rims, and could
Risk of loss of control of the ve-
also lead to misalignment of the
hicle.
front or rear axle geometry.
In this case, have the condition of
these checked by an approved
dealer.
5.13
TYRES (2/3)
Tyre pressures
Pressures should be checked when the
Vehicle fitted with a tyre pressure
tyres are cold; ignore higher pressures
loss warning system
Adhere to the tyre pressures (including
which may be reached in hot weather
the emergency spare wheel). The tyre
In the event of under-inflation (punc-
or following a fast journey.
pressures should be checked at least
tures, under-inflation, etc.), the
once a month and additionally before
If tyre pressures cannot be checked
warning light appears on the instrument
any long journey (refer to the label af-
when the tyres are cold, assume an in-
panel. ➥ 2.18.
fixed to the edge of the driver’s door).
crease of 0.2 to 0.3 bar.
Never deflate a hot tyre.
Incorrect tyre pressures
lead to abnormal tyre wear
and unusually hot running.
These are factors which
may seriously affect safety and lead
to:
- poor road holding,
- risk of bursting or tread separa-
tion.
Please be aware that a
The pressure depends on the load
poorly tightened or miss-
and the speed of use. Adjust the
ing valve cap can make the
pressure according to the condi-
tyres less airtight and lead
tions of use (refer to the label affixed
to pressure loss.
to the edge of the driver’s door).
Always use valve caps identical to
those fitted originally and tighten
them fully.
5.14
TYRES (3/3)
Changing wheels around
Use in winter
“Snow”or “Winter” tyres
This practice is not recommended.
We would recommend that these be
Chains
fitted to all four wheels to ensure that
For safety reasons, fitting snow
your vehicle retains maximum adhe-
Emergency spare wheel
chains to the rear axle is strictly for-
sion.
➥ 5.2, ➥ 5.11.
bidden.
Warning: These tyres sometimes have
Chains must not be fitted to tyres
a specific direction of rotation and a
which are larger than those originally
maximum speed index which may be
Fitting new tyres
fitted to the vehicle.
lower than the maximum speed of your
vehicle.
Studded tyres
Chains may only be fitted
This type of equipment may only be
to tyres of the same size
used for a limited period and as laid
as those originally fitted to
down by local legislation.
your vehicle.
It is necessary to observe the speed
For safety reasons, this op-
Only certain chains can be fitted to
specified by current legislation.
eration must be carried out
tyres. Consult an approved dealer.
These tyres must, at a minimum, be
by a specialist.
fitted to the two front wheels.
Special note for versions fitted
Fitting different tyres may
with 16” wheels: snow chains
change your vehicle as follows:
may not be fitted.
- it may mean that your vehicle no
If you wish to fit snow chains, you
longer conforms to current regu-
must use special equipment.
lations;
Consult your approved dealer.
- It may change the way it handles
when cornering;
- It may cause the steering to be
In all cases, we would recommend
heavy;
that you contact an approved dealer
- it may affect the use of snow
who will be able to advise you on
chains.
the choice of equipment which is
most suitable for your vehicle.
5.15
HEADLIGHTS: changing bulbs (1/2)
Direction indicators
Turn the bulb holder 2 a quarter of a
1
turn and take out the bulb.
Type of bulb: PY21W.
B
A
3
2
To comply with current legislation, or
Dipped beam headlights
Main beam headlights
as a precaution, you can obtain an
emergency kit from your approved
Remove cover A.
Remove cover B.
dealer containing a set of spare
Tilt bulb holder 3 to release it and then
Tilt bulb holder 1 to release it and then
bulbs and fuses.
replace the bulb.
replace the bulb.
Type of bulb: H7.
Type of bulb: H7.
Do not touch the bulb glass. Hold it
After replacing the bulb, please ensure
by its base.
Please note when work-
that the lights are adjusted by a profes-
It is essential to use anti-U.V. 55W
ing close to the engine that
sional.
bulbs so as not to damage the plastic
it may be hot. The engine
on the headlights. Mark the bulb’s po-
cooling fan may also start
sition before removal to ensure correct
positioning when replacing.
at any moment. The
label
When the bulb has been changed,
in the engine compartment reminds
make sure you refit the cover correctly.
you of this.
The bulbs are under pres-
sure and can break when
Risk of injury.
replaced.
Risk of injury.
5.16
HEADLIGHTS: changing bulbs (2/2)
4
Before carrying out any
action in the engine com-
partment, you must switch
off the ignition. ➥ 2.3.
Daytime running light, front
LED side light 4
Please see an authorised dealer.
Any operation on (or mod-
ification to) the electrical
system must be performed
by an approved dealer
since an incorrect connection might
damage the electrical equipment
(harness, components and in par-
ticular the alternator). In addition,
your Dealer has all the parts re-
quired for fitting these units.
5.17
FOG LIGHTS: changing bulbs
Any operation on (or mod-
1
2
ification to) the electrical
system must be performed
by an approved Dealer
since an incorrect connection might
damage the electrical equipment
(harness, components and in par-
ticular the alternator). In addition,
your Dealer has all the parts re-
quired for fitting these units.
Front fog lights 1
Refitting
- Access the bulb holder by releasing
To refit, proceed in the reverse order,
flap 2;
taking care not to damage the wiring.
- turn the bulb holder a quarter turn;
Once the bulb has been replaced,
- remove the bulb.
check that it is properly secured.
Type of bulb: H16.
However, we would advise you to
Please note when work-
have these bulbs replaced by an
ing close to the engine that
Approved Dealer.
it may be hot. In addition,
the engine cooling fan may
come on at any moment. The y
warning light in the engine compart-
ment reminds you of this.
The bulbs are under pres-
To comply with local legislation, or
sure and can break when
Risk of injury.
as a precaution, you can obtain an
replaced.
emergency kit containing a set of
Risk of injury.
spare bulbs and fuses from an ap-
proved Dealer.
5.18
BACK AND SIDE LIGHTS: changing bulbs (1/3)
3
2
4
5
2
1
6
3
7
2
Direction indicator lights,
Release the light assembly from out-
4 Brake light
side the vehicle by pulling towards the
Bulb type 4 : P21W.
brake and side lights
rear.
5 Indicator light
Undo bolt 1 to remove the light.
Remove the bulb holder 3 by releasing
Bulb type 5: PY21W.
clips 2.
6 Reversing light
Bulb type 6: P21W.
Refitting
7 Fog light
To refit, proceed in the reverse order,
Bulb type 6: P21W.
taking care not to damage the wiring,
and fasten clips 2 on the bulb holder 3.
5.19
BACK AND SIDE LIGHTS: changing bulbs (2/3)
10
9
8
LED 8 side lights
High-level brake light
Bulb type 10 : P21W.
Consult an approved dealer.
Remove the nut 9 and release the
brake light from its housing.
Refitting
To refit, proceed in the reverse order,
taking care not to damage the wiring.
The bulbs are under pres-
sure and may break when
replaced.
Risk of injury.
5.20
BACK AND SIDE LIGHTS: changing bulbs (3/3)
13
14
11
12
Number plate light
Indicator lights 13
Undo screw 11.
Unclip indicator light 13 (using a flat-
blade screwdriver or similar).
Remove the light cover 12 to access
the bulb.
Turn bulb holder 14 a quarter of a turn
and take out the bulb.
Bulb type: W5W.
Bulb type: W5W.
The bulbs are under pres-
sure and can break when
replaced.
Risk of injury.
5.21
INTERIOR LIGHTS: changing bulbs (1/5)
3
1
5
A
3
2
4
Front ceiling light 1
Refitting
- Unclip the lens 2 (using a tool such
- Clip the lens 2 on to the bulb holder 3;
as a flat screwdriver), positioned
- clip in the interior lights 1 until the unit
at A;
clicks;
- unclip and release the bulb
- ensure that the interior lights are
holder 3 using the tabs 4;
properly positioned and locked into
- remove the bulb concerned.
place.
Type of bulb 5: W5W.
1
The bulbs are under pres-
sure and can break when
replaced.
Risk of injury.
5.22
INTERIOR LIGHTING: changing bulbs (2/5)
6
B
B
8
7
B
8
B
9
10
Front map reading lights 6
Refitting
(depending on the vehicle)
- Clip the lens 7 on to the bulb holder 8;
- Unclip the lens 7 (using a tool such
- clip in the reading spots block 6 until
as a flat screwdriver), positioned
the unit clicks;
at B;
- make sure that the reading spots
- unclip and release the bulb
block is correctly positioned and
holder 8 using the tabs 9;
locked into place.
- remove the bulb concerned.
Type of bulb 10: W5W.
6
5.23
INTERIOR LIGHTING: changing bulbs (3/5)
13
11
13
C
14
12
15
Rear reading spot 11
Refitting
(depending on the vehicle)
- Clip the lens
12 on to the bulb
- Unclip the lens 12 (using a tool such
holder 13;
as a flat screwdriver), positioned
- clip in the reading spots block 11 until
at C;
the unit clicks;
- unclip and release the bulb
- make sure that the reading spots
holder 13 using the tabs 14;
block is correctly positioned and
- remove the bulb concerned.
locked into place.
Type of bulb 15: W5W.
11
The bulbs are under pres-
sure and can break when
replaced.
Risk of injury.
5.24















Content      ..     9      10      11      12     ..
