EXTERIOR LIGHTING AND SIGNALS (2/4)
To switch off the dipped
Main beam headlights
á
beam headlights:
With the engine running and
1
2
3
4
the dipped beam headlights lit, push
- turn the ring 2 to position š
stalk 1. This indicator light on the instru-
or
ment panel comes on.
– depending on the vehicle, to position
To return to the dipped headlight posi-
0;
tion, pull the stalk 1 towards you again.
Warning light k
goes out on the in-
Lights-on reminder buzzer
strument panel.
If the lights are on after the engine is
Switching off the lights
switched off, a warning beep sounds
The lights will go out automatically
when the driver’s door is opened to
when the engine is switched off, the
warn you that the lights are still on (to
driver’s door is opened or the vehicle
avoid draining the battery).
is locked. In this case, when you start
Dipped beam
the engine the lights will be switched
k
headlights
back on according to the position of the
ring 2, taking into account the exterior
Manual operation
light level, without moving the stalk 1.
Turn the ring 2 until the symbol is oppo-
site mark 3. This indicator light on the
instrument panel comes on.
Automatic operation
(depending on vehicle)
Turn ring 2 until the AUTO symbol is op-
posite mark 3: with the engine running,
the dipped beam headlights switch on
or off automatically depending on the
brightness of the light outside, without
any action on stalk 1.
1.84
EXTERIOR LIGHTING AND SIGNALS (3/4)
Rear fog light
Switching off the lights
f
Turn centre ring 4 on the stalk
Turn centre ring 4 again until mark 3
1
3
4
until the symbol faces mark 3, then re-
is opposite the symbol for the fog light
lease it.
that you want to switch off. The corre-
sponding indicator light will go out on
Depending on the vehicle, the stalk re-
the instrument panel;
turns to the initial position or stays in
position.
The front and rear fog lights switch off
when the exterior lights are switched
Operation of the fog lights depends on
off.
the exterior lighting selected, and an in-
dicator light will light up on the instru-
ment panel.
To avoid inconveniencing other road
users, remember to switch off the rear
fog light when it is no longer needed.
Front fog lights
g
Turn centre ring 4 on stalk 1
until the symbol faces mark 3, then re-
lease it.
Operation of the fog lights depends on
the exterior lighting position selected,
and an indicator light will light up on the
When driving in fog or snow, or
instrument panel.
when transporting objects which are
higher than the roof, the headlights
do not come on automatically.
Switching on the fog lights remains
the responsibility of the driver: the
indicator lights on the instrument
panel inform you whether the fog
lights are lit (indicator light on) or not
(indicator light not on).
1.85
EXTERIOR LIGHTING AND SIGNALS (4/4)
To increase this duration, you may pull
the stalk up to four times (total time re-
1
2
stricted to two minutes).
The message “Follow-me home_ _ _”
along with the times the lights will be on
for is displayed on the instrument panel
to confirm this action. You can then lock
your vehicle.
To switch off the lights before they go
out automatically, turn ring 2 to any po-
sition, then return it to position AUTO.
“See-me-home lighting”
function
(depending on the vehicle)
This function allows you to briefly switch
on the dipped beam headlights (to pro-
vide light when opening a gate, etc.).
With the engine lights switched off,
the 2 ring in AUTO, pull the lever 1 to-
wards you: the side lights and dipped
beam headlights will switch on for ap-
proximately 30 seconds along with the
š
and k
warning lights on the
instrument panel.
1.86
HEADLIGHT BEAM ADJUSTMENT
Examples of positions for adjusting
control A according to the load
Driver alone or with front passenger
0
A
Driver with one front passenger and
1
one rear passenger
Driver with one front passenger and
2
Control A is used to adjust the height
two rear passengers
of the headlight beams according to the
load.
Turn control A anticlockwise to lower
Driver with one front passenger and
3
the beams and clockwise to raise them.
two or three rear passengers
Driver with one front passenger,
3
three rear passengers and luggage
The table below gives some examples. In all cases, adjust control A according to the
vehicle load so that the road can be seen and other drivers are not dazzled.
If driving on the left in a left-hand
drive vehicle (or vice versa), drivers
must have the lights adjusted by an
authorised dealer for the duration of
the trip.
1.87
WINDSCREEN WASH, WIPE (1/5)
2
1
A
1
B
C
D
E
Vehicle fitted with intermittent
Special note
windscreen wipers
When driving the vehicle, the wiping
speed slows down whenever the ve-
A single sweep
hicle stops. For example, fast wiping
A short push will trigger one sweep
speed will slow to normal wiping speed.
of the wipers.
As soon as the vehicle moves off,
B stop
wiping will return to the speed originally
C intermittent wiping
selected.
The wipers will pause for sev-
If stalk 1 is operated, it overrides and
eral seconds between sweeps.
cancels the automatic function.
Depending on the vehicle, you can
change the time interval between
sweeps by turning the ring 2.
D slow continuous wiping
E fast continuous wiping
1.88
WINDSCREEN WASH, WIPE (2/5)
When activating automatic wiping or
when increasing sensitivity, one sweep
of the blades is performed.
1
2
F
Note:
A
1
-
the rain sensor is only intended as a
B
driving aid. In the event of reduced
visibility, the driver should manually
C
activate the wipers. In foggy weather
or during snowfalls, wiping is not au-
D
tomatically triggered and remains
G
E
under the driver’s control;
-
in the event of temperatures below
zero, automatic wiping is not acti-
vated when the vehicle is started. It
is automatically activated as soon as
Vehicle fitted with front
C
automatic wiper function
the vehicle exceeds a certain speed
When this position is selected, the
windscreen wiper rain sensor
(approximately 5 mph (8 km/h));
system detects water on the wind-
The rain sensor is located on the winds-
screen and triggers the wipers at a
-
do not activate automatic wiping in
creen, in front of the interior rear-view
suitable wiping speed. It is possi-
dry weather;
mirror.
ble to change the triggering thresh-
-
fully de-ice the windscreen before
old and the time sweeps by turning
A single sweep
activating automatic wiping.
ring 2:
A short push will trigger one sweep
- F : minimum sensitivity
of the wipers.
- G : maximum sensitivity
B stop
The higher the sensitivity, the quicker
the wipers will react and the faster
the wipe.
1.89
WINDSCREEN WASH, WIPE (3/5)
Operating faults
Special note
In the event of a malfunction of the au-
When driving the vehicle, the wiping
tomatic wiping, the wiper is set to inter-
speed slows down whenever the vehi-
mittent wiping. Contact an authorised
cle stops. For example, fast wiping
dealer.
A
speed will slow to normal wiping speed.
1
As soon as the vehicle moves off,
The operation of the rain sensor can be
B
wiping will return to the speed originally
disturbed in the event of:
selected.
- damaged wiper blades; a screen
C
If stalk 1 is operated, it overrides and
of water or traces left by a blade in
D
cancels the automatic function.
the sensor’s detection zone may
increase the response time of the
E
Precautions
automatic wiper, or increase the
wiping frequency;
- In the event of ice, check whether the
- a windscreen with any chip or
blades are stuck to the windscreen
crack level with the sensor, or a
before operating the wiping mecha-
windscreen covered in dust, dirt,
nism. If you activate the wipers while
D
slow continuous wiping
insects, ice, the use of washing
the blades are stuck down with ice,
wax and water-repellent chemi-
you may risk damaging both the
E
fast continuous wiping
cals; the automatic wiping will be
blade and the wiper motor.
less sensitive, or even unrespon-
- Do not activate the wipers on a dry
sive.
screen. This will lead to premature
wear or damage to the blades.
1.90
WINDSCREEN WASH, WIPE (4/5)
Specific front wiper position
(service position)
This position enables the blades to be
lifted to remove them from the winds-
A
creen.
1
It may be useful to:
B
- to clean the blades;
C
- to release the blades from the winds-
creen in winter;
D
- replace the blades ➥ 5.35.
E
With the ignition off, set the stalk 1 to
position E (fast wiping speed function).
The blades stop slightly away from the
bonnet.
To return the blades to their lowered po-
sition, with the ignition off, ensure that
the wipers have folded down onto the
windscreen, then set the stalk 1 to posi-
tion B (off).
In the event of obstacles on the
Before switching on the ignition,
windscreen (dirt, snow, ice etc.),
place the wipers on the windscreen.
clean the windscreen (including the
Otherwise, there may a risk of damage
central area located behind the inte-
to the bonnet or the wipers when they
rior rear view mirror) before starting
are switched on.
the wipers (risk of motor overheat-
Before any action involving
ing).
the windscreen
(washing
the vehicle, de-icing, clean-
If an object is preventing a blade
ing the windscreen, etc.)
from moving, it may stop functio-
return stalk 1 to position B (stop).
ning. Remove the obstacle and
reactivate the wiper using the wiper
Risk of injury and/or damage.
stalk.
1.91
WINDSCREEN WASH, WIPE (5/5)
Note:
In temperatures below zero, the washer
liquid risks freezing to the windscreen,
thereby reducing visibility. Heat the
windscreen using the demister control
1
before cleaning.
Efficiency of a wiper blade
Check the condition of the wiper
blades. How long they last depends
on you:
- it must remain clean: clean the
blade and the screen regularly
with soapy water;
- do not use it when the screen is
dry;
Windscreen washer
- free it from the screen when it has
With the ignition on, pull stalk 1 then
not been used for a long time.
release.
In all cases, replace it as soon as
A longer pull will trigger, in addition to
it begins to lose efficiency: approxi-
the windscreen washer, two sweeps
mately once a year. ➥ 5.35.
of the wipers followed, a few seconds
later, by a third.
Precaution for using the
wipers
- In freezing or snowy weather
conditions, clear the screen
When working in the engine
before starting the wipers (risk of
compartment, ensure that
motor overheating);
the windscreen wiper stalk
- ensure that no objects are ob-
is in position B (park).
structing the travel of the blade.
Risk of injury.
1.92
REAR SCREEN WASHER, WIPER (1/2)
To stop the operation, pivot ring 3 again.
Note:
2
3
When washing using a roller type car
1
wash, return the ring 3 on the stalk 1
to the stop position to deactivate auto-
matic wiping.
Follow usage recommendations.
Efficiency of a wiper blade
Check the condition of the wiper
blades. How long they last depends
on you:
- it must remain clean: clean the
blade and the screen regularly
with soapy water;
- do not use it when the screen is
dry;
Rear windscreen wiper
- free it from the screen when it has
Y
With the ignition on, turn ring 3
not been used for a long time.
on stalk 1 to align the symbol with
In all cases, replace it as soon as
mark 2.
Do not use the wiper arm to open or
it begins to lose efficiency: approxi-
- stop;
close the tailgate.
mately once a year. ➥ 5.35.
- intermittent wiping.
The wipers will pause for several
Precaution for using the
seconds between sweeps.
wipers
Before any action involving
- In freezing or snowy weather
the rear screen (washing
conditions, clear the screen
the vehicle, de-icing, clean-
before starting the wipers (risk of
ing, etc.) return stalk 1 to
motor overheating);
the stop position.
- ensure that no objects are ob-
structing the travel of the blade.
Risk of injury and/or damage.
1.93
REAR SCREEN WASHER, WIPER (2/2)
In the event of obstacles present on the
rear window (dirt, snow, etc.), the wiper
will try to sweep away all the obstacles.
1
If an obstacle prevents the blade from
moving, it can be stopped. Remove the
obstacle, wait for around 30 seconds
and reactivate the wiper using the wiper
stalk.
Precautions
-
In the event of ice, check that the
blades are not stuck to the wind-
screen before operating the wipers.
If you activate the wiper while the
blade is blocked by ice, you risk dam-
aging both the blade and the wiping
motor.
Rear screen wash/wipe
p
-
Do not operate the wipers on a dry
With the ignition on, push and
screen. This will lead to the prema-
hold stalk 1, then release.
ture wear or damage to the blades.
Holding the stalk for longer will trigger
(in addition to the windscreen washer)
two sweeps of the wipers followed,
a few seconds later, by a third (drip
wiping function).
When the stalk is released, it returns to
the rear wipe position.
1.94
FUEL TANK (1/4)
For details on filling the fuel tank, refer
to the information on “Filling with fuel”.
To close it, press the cover B with your
A
hand, as far as it will go.
To fill up with fuel, the engine
Depending on the vehicle, the hook A
must be stopped (and not
B
prevents the sliding side door from
only on standby in the case
opening fully.
of vehicles equipped with
1
the STOP and START function): you
must switch off the ignition ➥ 2.3.
Fire hazard.
C
2
Petrol and diesel versions
Usable capacity of the fuel tank:
50 litres approximately.
Fuel filler cap: this is a
specific type.
To open the fuel flap B, place your
finger in the recess C.
If you have to replace it,
make sure it is identical
On some vehicles, the cap 1 can be un-
to the original cap. Contact an ap-
locked with the ignition key. If not, un-
proved Dealer.
screw the fuel filler cap, it is connected
to the vehicle by a strip of plastic.
Never place the cap near a source
of heat or flame.
Use the cap holder 2 on the flap B
during filling to hold the cap 1 in place.
Do not wash the filler area with a
high-pressure washer.
After filling, check that the cap and
cover are closed.
1.95
FUEL TANK (2/4)
Fuel grade
Use a high-grade fuel that complies
with the legislation in force in each
country. It must comply with the spec-
ifications given on the label D on the
inside of the flap. ➥ 6.7.
Petrol versions
D
It is essential to use unleaded petrol.
The octane rating (RON) must conform
to the information given on the label D
on the inside of the flap ➥ 6.7.
Diesel versions
It is essential to use diesel that con-
Do not mix even small
forms to the information given on the
amounts of petrol
(un-
label D on the inside of the flap ➥ 6.7.
leaded or E85) with diesel.
Do not use ethanol-based
fuel if your vehicle is not compatible
with this fuel.
Do not add reagent to the fuel -
otherwise you risk damaging the
engine.
If you wish to add an additive to the
fuel, use a product approved by our
Technical Department.
Consult an approved dealer.
Fuel types that conform to European
standards with which the engines of
vehicles sold in Europe are compat-
ible: refer to the table ➥ 6.7.
1.96
FUEL TANK (3/4)
Filling with fuel
Petrol versions
Special case
Using leaded petrol will damage the
With the ignition off, insert the nozzle to
When the vehicle has been stopped for
antipollution system and may lead to a
open the valve and insert it fully before
around three months, you must add
loss of warranty.
turning it on to fill the fuel tank (risk of
fuel to prevent damage to the fuel
splashing).
To ensure that the fuel tank is not filled
pump.
with leaded petrol, the fuel tank filler
Keep the nozzle in this position
To do this, with the ignition off, top-up
neck contains a restrictor fitted with a
throughout the entire filling operation.
at least 1.10 gallons (5 litres) then start
foolproof system which only allows
When the pump cuts out automatically
the engine to operate the pump and
the nozzle for unleaded petrol to be
at the end of the filling procedure, a
renew the fuel in the circuit.
used (at the pump).
maximum of two further filling attempts
If it is not possible to add at least 1.10
may be made, as there must be suffi-
gallons (5 litres) of fuel due to the fuel
cient space in the fuel tank to allow for
level in the tank, drive the vehicle until
expansion.
the tank has capacity.
Make sure that no water enters the fuel
tank during filling. The valve and its sur-
round must remain clean.
Persistent fuel odour
If you notice a persistent
fuel odour you should:
-
stop the vehicle as soon as traf-
fic conditions allow and switch off
the ignition;
-
switch on the hazard warning
lights and ask your passengers to
leave the vehicle and stay clear
of the traffic;
-
contact an approved Dealer.
1.97
FUEL TANK (4/4)
Running out of fuel on Diesel
versions
Set the ignition key to “On” position C
➥ 2.2 and wait a few minutes before
starting in order to enable the fuel cir-
cuit to be primed.
If the engine does not start, repeat the
procedure.
If the engine does not start after several
attempts, please contact an authorised
dealer.
Please note when work-
No modifications what-
ing close to the engine that
soever are permitted on
it may be hot. The engine
any part of the fuel supply
cooling fan may also start
system
(electronic units,
wiring, fuel circuit, injectors, pro-
at any moment. The
label
tective covers, etc.) as this may be
in the engine compartment reminds
dangerous (unless undertaken by
you of this.
qualified Network personnel).
Risk of injury.
1.98
REAGENT TANK (1/4)
Always comply with the legislation in
place in the country where you are lo-
cated. Not abiding by the regulations in
To fill up with reagent, the engine
force may expose the vehicle owner to
must be stopped
(not just on
prosecution.
1
A
standby in the case of vehicles with
the STOP and START function). You
Operating principle
must switch off the ignition ➥ 2.3.
The reagent is intended for diesel en-
gines fitted with the SCR (selective cat-
alytic reduction) system.
Using a reagent reduces the quantity of
2
If the “xxxKM failure Top up
nitrogen oxides in exhaust gases.
AdBlue” message appears,
Reagent consumption in real time de-
fill the reagent tank and
pends on vehicle usage conditions, the
refer to the filling instruc-
equipment fitted, and driving style.
tions.
Filling
Risk of immobilisation of the
Reagent quality
Capacity of the tank: 17 litres approx-
vehicle.
Use only reagents which conform
imately.
to standard ISO 22241 and in accord-
With the ignition switched off, open the
ance with the mark on the tank filler
cover A, then unscrew the cap 1.
cap.
Cap holder 2 is provided on the fuel
filler flap for holding the cap when the
Filler cap: this is specific.
tank is being filled.
If you have to replace it,
Note: ammonium hydroxide vapour
make sure it is identical to
may escape from the cap opening
the original cap. Contact
when the tank temperature is high.
an approved Dealer. Do not wash
the filler area with a high pressure
washer.
The reagent must not come into contact with eyes or skin. If it does, wash
the affected area with plenty of cold water. If necessary, consult a doctor.
1.99
REAGENT TANK (2/4)
Filling (continued)
If the reagent overflows, or contami-
nates any paintwork, clean the affected
The tank can be filled at the pump. With
area quickly with plenty of cold water
the ignition off, insert the nozzle and
and a soft cloth.
insert it fully before turning it on to fill
the fuel tank (risk of splashing).
Note: If the reagent crystallises, use a
After filling the reagent tank, check
soft sponge.
that the cap and cover are closed,
No more than two filling operations may
start the engine and WAIT 10 sec-
be made after the feed has switched off
In extreme cold weather conditions
onds with the vehicle stationary,
automatically for the first time because
In frosty weather conditions, the rea-
engine running before setting off
there must be room for expansion in the
gent tank should be refilled when the
again.
tank.
If this operation is not carried out,
indicator and the message “Top
In other filling cases, it is essential to
the filling of the tank will not be
Up AdBlue before 1200 km” appear on
read the information shown on the re-
taken into account automatically
the instrument panel.
agent container (e.g. the can or bottle).
until after several dozens of minutes
Special cases
of driving.
The message “--- TOP UP AdBlue”
Precautions for use
The reagent fluid freezes below about
and/or the warning lights will con-
-10°C.
When filling:
tinue to appear until the filling has
In these conditions, do not attempt fill-
been taken into account by the
- handle the reagent with care. They
ing when the fluid is frozen. In the event
system.
can damage clothes, shoes, body-
of needing to top up or fill the tank with
work components etc. ;
reagent (
on), park the vehicle
- make sure that no water enters the
in a hotter location if possible so that
fuel tank.
the reagent becomes liquid again.
Otherwise, have a qualified profes-
sional top up or fill up with reagent fluid.
No work whatsoever is
permitted on any part of
the system. To prevent
damage, only qualified per-
sonnel from our network may work
on the system.
1.100
REAGENT TANK (3/4)
Maintenance/Range
The information displayed on the instrument panel may be accompanied by a beep.
Indicator lights
Message
What to do?
When the message is displayed when the ignition is switched on, you have less
“Top Up AdBlue
-
than 1,488 miles (2,400 km) range.
before 2400 km”
Fill or have an Approved Dealer fill or top up the reagent in the tank.
When the message is displayed when the ignition is switched on, you have be-
“TOP UP AdBlue
tween 744 miles (1,200 km) and 496 miles (800 km) range.
comes on.
before 1200 km”
Fill or have an Approved Dealer fill or top up the reagent in the tank.
The message is displayed when the ignition is switched on and is repeated:
- approximately every 62 miles (100 km), you have between about 496 miles
(800 km) and 124 miles (200 km) range;
“xxxKM failure Top
- approximately every 31 miles (50 km), you have less than 124 miles
comes on.
up AdBlue”
(200 km) range.
In any event, fill or have an Approved Dealer fill the reagent tank as soon as
possible.
«
0KM FAILURE
The engine will not start.
flashes.
TOP UP ADBLUE »
To restart, you must fill the reagent tank yourself.
1.101
REAGENT TANK (4/4)
System faults
The information displayed on the instrument panel may be accompanied by a beep.
Indicator lights
Message
Readings
“CHECK ANTI- POLLUTION SYSTEM”
Indicates a fault in the system. Contact your approved
and
come
“AdBlue quality to check”
dealer as soon as possible.
on.
“AdBlue injection to check”
Indicates a system fault and that in less than
496 miles (800 km) it will become impossible to
restart the vehicle.
These warnings are repeated:
- every 62 miles (100 km) until there are between
“xxx MILES (xxx KM) failure antipollu-
and
come
500 miles (800 km) and 124 miles (200 km) re-
tion”
on.
maining until the vehicle cannot be restarted;
- every 31 miles (50 km) when there is less than
124 miles (200 km) left before the vehicle cannot
be restarted.
Contact your approved dealer as soon as possible.
Indicates that after the ignition is switched off the vehi-
and
come
“0KM FAILURE TOP UP ADBLUE”
cle will not restart. Call an approved Dealer.
on.
1.102
Section 2: Driving
(Advice on use relating to fuel economy and the environment)
Running in
2.2
Ignition switch
2.2
Starting, stopping the engine
2.3
Stop and Start function
2.5
Special feature of petrol versions, particle filter
2.8
Special features of diesel versions, particle filter
2.10
Driving advice, Eco-driving
2.12
Maintenance and antipollution advice
2.16
Environment
2.17
Tyre pressure loss warning
2.18
Gear lever, handbrake
2.21
Rear camera
2.22
Driver correction devices and aids
2.25
Speed limiter
2.30
Cruise control
2.33
Parking distance control
2.37
Reversing camera
2.40
Blind spot warning
2.42
Overspeed function
2.46
Emergency call
2.47
2.1
RUNNING IN, IGNITION SWITCH
Petrol version
“Ignition” position C
For the first 600 miles (1,000 km), do
The ignition is switched on:
not exceed 80 mph (130 km/h) in the
- petrol version: the engine may be
highest gear, or 3,000 to 3,500 rpm.
started.
You may only expect top performance
- diesel version: the engine is pre-
from your vehicle after approximately
heating.
1,800 miles (3,000 km).
Service intervals: refer to the
C
“Start” position D
Maintenance Service Booklet for the
D
vehicle.
If the engine fails to start at the first
B
attempt, the key must be turned back
before the starter can be activated
Diesel version
1
again.
A
For the first 1,000 miles (1,500 km),
Release the key as soon as the engine
do not exceed 80 mph (130 km/h) in
Off position A (steering lock
starts.
the highest gear, or 2,500 rpm. After
completing this mileage you may drive
applied)
Note: on diesel versions, several sec-
faster, although you may only expect
onds may pass between turning the
To lock: remove the key 1 and turn the
top performance after approximately
key and the engine starting to allow for
steering wheel until the steering column
3,600 miles (6,000 km).
engine preheating.
locks.
During the running in period, do not ac-
To unlock: turn the key and the steering
celerate hard while the engine is still
wheel slightly.
cold and do not let the engine over-rev.
Service intervals: refer to the
“Accessories” position B
Maintenance Document for your vehi-
cle.
When the ignition is switched off, any
accessories (radio, etc.) will continue to
function.
2.2















Content      ..     3      4      5      6     ..
