DETECTION OF ROAD SIGNS (1/4)
Note: make sure the windscreen is not
For vehicles equipped with a navigation
obscured (dirt, mud, snow, condensa-
system and if the vehicle is travelling in
1
tion etc.).
a country where the speed units differ
from those of the vehicle, the system
For vehicles which are equipped with it,
displays the speed limit sign in the unit
the system also uses information from
of the country, alongside the speed limit
the navigation system.
converted to the unit used by the vehi-
Once the speed limiter is activated, you
cle’s instrument panel.
can adjust the speed limiter indication
For countries where the speed limit is
displayed by the system.
reduced during rainy weather on some
If the limit speed is exceeded, the dis-
types of roads, on vehicles equipped
play panel is modified to warn the driver.
with a navigation system, the system
can modify the limited speed after a few
seconds of wiping the windscreen.
Special situations
The system detects speed limit signs
The system does not take into account
on the side of the road and displays the
exceptional speed limit measures, such
speed limit on the instrument panel.
as peak pollution days.
It mainly uses information taken from
the camera 1, attached to the wind-
screen behind the rear view mirror.
2.88
DETECTION OF ROAD SIGNS (2/4)
- press the 4 or 5 control repeatedly
2
to reach the “Settings” menu and
press 6 OK;
- press the 4 or 5 control repeatedly to
reach the “DRIVING ASSIST” menu
and press 6 OK;
- press the 4 or 5 control repeatedly
to reach the “Speed alert” menu and
press 6 OK;
- press the 6 OK switch to activate or
3
4
deactivate the function:
=
function activated
6
5
<
function deactivated
Activating/deactivating the
With the function activated, depend-
ing on local regulations, you can acti-
system
vate the “Risk area display” option. The
Vehicles fitted with a multimedia
system will notify you of the distance
screen 2
separating you from this zone, and
while you are travelling in the zone.
To activate or deactivate the function,
refer to the multimedia instructions.
Vehicles not fitted with a multimedia
Select “ON” or “OFF”.
screen
- With the vehicle stopped, press the
switch 3 as many times as required
to reach the “Vehicle” tab;
2.89
DETECTION OF ROAD SIGNS (3/4)
If the speed limit is exceeded, the circle
7
8
around the panel flashes (7 warning
light) along with a sound signal to warn
the driver.
9
10
Operation
Varying the limit speed
If the speed limit notification differs from
Warning lights
the detected speed value, press and
The function displays the following
hold the following switches:
warning lights:
- 9 (RES/+) to increase the notification
7 Speed limit road signs.
speed to the detected speed;
8 Additional road signs (start or end
- 10 (SET/-) to reduce the notification
of “No overtaking” zone, slip road
speed to the detected speed.
speed limit, speed in case of a cara-
van, speed limit with length of appli-
cation, etc.).
2.90
DETECTION OF ROAD SIGNS (4/4)
Operating faults
The system cannot detect the speed
limit if:
- the windscreen is not clean;
- the camera is blinded by the sun;
- there is insufficient visibility (night,
fog etc.);
- the signs are not legible (snow, etc.)
or are hidden (by another vehicle or
by trees);
- the information taken from the navi-
gation system is not up to date.
This function is an additional driving aid. This function is not under any
circumstances intended to replace the due care and attention of the
driver, who should at all times be in control of the vehicle.
The driver should always adapt their speed to the traffic conditions, re-
gardless of the system indications.
The system detects speed limit signs and does not detect other signs (e.g. entry/
exit to/from urban areas, etc.).
The system may not detect all speed limit signs or may interpret them incorrectly.
The driver should not ignore signs that are not detected by the system and should,
as a priority, comply with the traffic signage and the highway code.
In the event of poor visibility (fog, snow, frost, etc.), it is possible that the system
may not indicate the correct speed to the driver.
The driver should always adapt their speed to the traffic conditions, regardless of
the system indications.
2.91
SPEED LIMITER (1/4)
Controls
1 Speed limiter On/Off switch.
2 Cruise control On/Off switch.
3 Speed limiter activation and speed
reduction (SET/-).
4 Speed limiter activation and speed
increase or recall of memorised limit
5
speed (RES/+).
1
4
5 Speed limiter function standby (with
limited speed memory) (O).
3
2
The speed limiter function helps you
stay within the driving speed limit that
you choose, known as the limit speed.
You can link the speed limiter to
the “Road sign detection” function.
➥ 2.88.
2.92
SPEED LIMITER (2/4)
7
7
1
4
3
Driving
Switching on
To store the current speed, press the 4
switch (RES/+) or the 3 switch (SET/- ):
When a limit speed has been set but
Press switch 1. The 7 warning light ap-
the limit speed replaces the dashes
not yet reached, driving is similar to
pears in grey. The “Speed limiter ON”
and, depending on the vehicle, the 7
driving a vehicle without the speed lim-
message appears on the instrument
warning light appears in white.
iter function.
panel accompanied by dashes to indi-
The minimum stored speed is 20 mph
cate that the speed limiter function is in
Once you have reached the stored
(30 km/h).
operation, waiting to store a limit speed.
speed, no effort on the accelera-
tor pedal will allow you to exceed
the programmed speed except in an
emergency (refer to information on
“Exceeding the limit speed”).
2.93
SPEED LIMITER (3/4)
Exceeding the limit speed
Limited speed cannot be maintained
It is possible to exceed the limit speed
When driving down a steep gradient,
at any moment. To do this, press firmly
the system may not maintain the limit
and fully the accelerator pedal (beyond
speed: the limit speed flashes in red
the kickdown point).
on the instrument panel and an audi-
While the speed is being exceeded, the
ble signal sounds at regular intervals to
speed limiter flashes red on the instru-
inform you of this situation.
ment panel. Then, release the accelera-
tor pedal: the speed limiter function will
4
return as soon as you reach a speed
lower than the memorised speed.
3
Varying the limit speed
The limit speed may be changed by
pressing repeatedly or holding down:
- switch 4 (RES/+) to increase speed;
- switch 3 (SET/-) to reduce speed.
If the speed limiter is not
available (after several at-
tempts to activate), contact
an approved dealer.
2.94
SPEED LIMITER (4/4)
7
7
5
1
4
3
2
Putting the function on
Switching off the function
standby
The speed limiter function is inter-
The speed limiter function is suspended
rupted:
when you press switch 5 (O). The limit
- when you press the 1 switch. In this
speed is stored and displayed in grey
case, the speed is no longer stored;
on the instrument panel.
- when you press the 2 switch. In this
case the cruise control is selected
Recalling the limit speed
and there is no stored speed.
If a speed has been stored, it can be re-
The warning light 7 disappears from
called by pressing the 4 switch.
the instrument panel to confirm that the
When the speed limiter is set to
function is no longer active.
standby, pressing the
3 switch
re-activates the function without
taking into account the memorised
speed: the speed at which the vehi-
cle is moving is taken into account.
2.95
CRUISE CONTROL (1/5)
Controls
1
Cruise control On/Off switch.
2
Switch to activate and decrease
cruising speed (SET/-).
3
Switch to activate and increase
cruising speed or to recall the mem-
orised cruising speed (RES/+).
4
4
Switch the function to standby (with
3
5
cruising speed saved) (O).
This function is an addi-
5
Speed limiter On/Off switch.
tional driving aid. The func-
tion does not take the place
2
1
of the driver.
Therefore, it can under no circum-
The cruise control function helps you to
stances replace the driver’s respon-
maintain your driving speed at a speed
sibility to respect speed limits and to
that you choose, called the cruising
be vigilant (the driver must always
speed.
be ready to brake).
This cruising speed may be set at any
Cruise control must not be used in
speed above 19 mph (30 km/h).
heavy traffic, on undulating or slip-
pery roads (black ice, aquaplan-
ing, gravel) and during bad weather
(fog, rain, side winds etc.).
There is a risk of accidents.
2.96
CRUISE CONTROL (2/5)
6
6
3
2
1
Switching on
Activating cruise control
Driving
Press switch 1.
While the vehicle is moving a steady
Once a cruising speed is registered
speed above approximately 19 mph
and the cruise control function is active,
The 6 warning light appears in grey.
(30 km/h), press the 2 (SET/-) switch
you may lift your foot off the accelera-
The “Cruise control ON” message ap-
or the 3 (RES/+) switch: the function
tor pedal.
pears on the instrument panel accom-
is activated and the current speed is
panied by dashes to indicate that the
taken into account.
cruise control function is in operation
The cruising speed replaces the
and waiting to memorise a cruising
dashes. Cruise control is confirmed
speed.
when the memorised speed and warn-
ing light appear in green 6.
If you try to activate the function below
19 mph (30 km/h), the message “Invalid
Please note that you must
Speed” will be displayed and the func-
keep your feet close to the
tion will remain inactive.
pedals in order to react in
an emergency.
2.97
CRUISE CONTROL (3/5)
Exceeding the cruising speed
The cruising speed may be exceeded
at any time by depressing the accelera-
tor pedal. While it is being exceeded,
the cruising speed flashes in red on the
instrument panel.
Then, release the accelerator pedal:
after a few seconds, the vehicle will
automatically return to its set cruising
3
speed.
Cruising speed cannot be
maintained
2
When driving down a steep gradient,
the system may be unable to main-
Adjusting the cruising speed
tain the cruising speed: the memorised
speed will flash in red on the instrument
The cruising speed may be changed by
panel and an audible signal sounds at
pressing the following repeatedly:
regular intervals to inform you of this
- the 2 switch (SET/-) to reduce the
situation.
speed;
- the 3 switch (RES/+) to increase the
speed.
Note: press and hold one of the
switches to modify speed by succes-
sive increments.
If the cruise control is no
longer available (after sev-
eral attempts to activate it),
contact an approved dealer.
2.98
CRUISE CONTROL (4/5)
6
6
4
3
2
Putting the function on
Returning to the cruising speed
NB: if the speed previously stored is
much higher than the current speed,
standby
If a speed is stored, it can be recalled,
the vehicle will accelerate more rapidly
once you are sure that the road condi-
The function is set to standby if you:
to reach this threshold.
tions are suitable (traffic, road surface,
- 4 switch (O);
weather conditions, etc.). Press the
When the cruise control is set to
- the brake pedal;
switch 3 (RES/+) if the vehicle speed is
standby, pressing switch 2 (SET/-) re-
above 19 mph (30 km/h).
activates the cruise control function
- the clutch pedal or shifting to neutral
without taking into account the stored
if the vehicle has an automatic gear-
When the speed is stored, cruise con-
speed: it is the speed at which the vehi-
box;
trol activation is confirmed by the dis-
cle is moving that is taken into account.
play in green of the cruising speed and,
- depending on the vehicle, the clutch
depending on the vehicle, the 6 warn-
pedal for a prolonged period or upon
ing light is displayed.
prolonged neutral position.
The cruising speed is stored and dis-
played in grey on the instrument panel.
2.99
CRUISE CONTROL (5/5)
6
6
5
1
Switching off the function
The warning light 6 disappears from
the instrument panel to confirm that the
The cruise control function is inter-
function is no longer active.
rupted:
- when you press the 1 switch. In this
case, the speed is no longer stored;
- when you press the 5 switch. In this
case the speed limiter is selected
and there is no stored speed.
Putting the cruise control
on standby or switching it
off does not cause a rapid
reduction in speed: you
must brake by depressing the brake
pedal.
2.100
ADAPTIVE CRUISE CONTROL (1/13)
Based on information from a radar
According to conditions on the road
This function is an addi-
or camera, the adaptive cruise con-
(traffic, weather etc.), the adaptive
tional driving aid. The func-
trol function
(or Stop and Go adap-
cruise control function can be activated:
tion does not take the place
tive cruise control function on vehicles
- 0 mph (0 km/h) to 105 mph (170 km)
of the driver.
equipped with an automatic gearbox)
for vehicles fitted with an automatic
enables you to maintain the speed se-
gearbox;
Therefore, it can under no circum-
lected (known as cruising speed) while
- 19 mph (30 km/h) to
105 mph
stances replace the driver’s respon-
keeping a following distance with the
(170 km) for vehicles fitted with a
sibility to respect speed limits and
vehicle in front in the same lane.
manual gearbox.
safe distances and to be vigilant
(the driver must always be ready to
On vehicles fitted with an automatic
The function is indicated by the
brake).
gearbox, if the vehicle in front stops,
symbol.
the Stop and Go adaptive cruise control
The driver must always be in con-
Note:
function may apply the vehicle brakes
trol of the vehicle. The driver must
- the driver must observe the maxi-
to a full-stop before allowing the vehicle
always adapt their speed according
mum speed limit and safe distances
to move-on.
to the surroundings and traffic con-
in the country where they are driving;
ditions. The adaptive cruise control
The system controls acceleration and
- the adaptive cruise control can brake
must only be used on a motorway
deceleration of your vehicle using the
the vehicle up to a third of the brak-
(or multi-lane road separated by a
engine and braking system.
ing capacity. Depending on the situ-
barrier). The cruise control must not
ation, the driver may need to brake
The system’s maximum range is ap-
be used in heavy traffic, on wind-
harder.
proximately 150 m. This may vary ac-
ing or slippery roads (black ice, aq-
cording to the road conditions (ground
uaplaning, gravel) or during bad
relief, weather conditions, etc.).
weather (fog, rain, side winds etc.).
There is a risk of accidents.
The adaptive cruise control does
not trigger an emergency stop and
its braking capability is limited.
2.101
ADAPTIVE CRUISE CONTROL (2/13)
1
8
11
9
3
4
10
7
2
6
5
Location of the camera 1
Controls
6
Cruising speed activation, storage
and decrease switch (SET/-).
Make sure the windscreen is not ob-
3 Safe distance settings
scured (by dirt, mud, snow, condensa-
7
Switch to activate and increase cruis-
4 Switch the function to standby (with
tion etc.).
ing speed or to recall the memorised
cruising speed saved) (0).
cruising speed (RES/+).
5 Adaptive cruise control main stop/
Location of the radar 2
start switch
Ensure that the radar area is not ob-
structed
(dirt, mud, snow, a badly
fitted/attached front number plate), im-
pacted, modified (including paintwork)
or hidden by any accessory fitted on the
The radar and camera
front of the vehicle (on the grille or logo
zones must be kept clean
etc.).
and free of any tampering in
order to ensure the proper
operation of the system.
2.102
ADAPTIVE CRUISE CONTROL (3/13)
Switching on
The cruising speed 11 replaces the
8
dashes and cruise control is confirmed
Press switch 5.
by the appearance of the cruising
Warning light
appears in grey, and
speed in green and warning light
11
the message “Adaptive Cruise Ctl ON”
If you try to activate the function when
9
appears on the instrument panel, ac-
the vehicle speed is over 105 mph
10
companied by dashes to indicate that
(170 km) or below 19 mph (30 km/h) for
the cruise control function is activated
vehicles fitted with a manual gearbox,
and waiting to store a cruising speed.
the message “Invalid Speed” is dis-
played and the function is not activated.
This function cannot be activated when:
Once a cruising speed is memorised
- the parking brake is applied;
and the cruise control function is active,
- the Park Assist function is already
you may lift your foot off the accelera-
activated ➥ 2.123.
tor pedal.
The message “Adaptive Cruise Ctl una-
Special feature on vehicles with
vailable” is displayed on the instrument
an automatic gearbox: if the vehicle
Displays
panel.
speed is below approximately 19 mph
8
Stop and Go adaptive cruise con-
(30 km/h), the cruising speed will auto-
trol warning light.
matically be set to 19 mph (30 km/h).
Activating cruise control
The vehicle will accelerate until it
9
Vehicle in front.
When the vehicle is stationary (vehicles
reaches the stored cruising speed.
10
Stored safe distance
equipped with an automatic gearbox) or
when the vehicle is moving at a steady
11
Stored cruising speed.
speed (all vehicles), press the 6 (SET/-)
or 7 (RES/+) switch to activate the func-
tion and store the current speed. The
minimum cruising speed is 19 mph (30
km/h).
Important: you should keep
your feet near the pedals at
all times to prepare for any
event.
2.103
ADAPTIVE CRUISE CONTROL (4/13)
Safe distance control
activation
As soon as cruise control is activated,
the default safe distance 10 is displayed
in green on the instrument panel. The
default safe distance corresponds to
approximately two seconds (see follow-
A
ing pages).
B
3
If the system detects a vehicle in your
C
lane, an outline of a vehicle 9 appears
above the distance gauge 10 on the in-
7
D
strument panel.
6
Your vehicle adapts its speed to that
of the vehicle in front and applies the
brakes if necessary (the brake lights
Setting the cruising speed
Adjusting the following
come on) in order to maintain the dis-
tance displayed on the instrument
You can vary the speed by repeatedly
distance
panel.
pressing (for a small variation) or press-
You can vary the safe distance from the
ing and holding (for a larger variation)
vehicle in front at any time by pressing
Note: the size of the 9 outline varies ac-
switch 6 or 7:
switch 3 repeatedly.
cording to the distance separating you
from the vehicle in front. The larger the
- use the “SET/-” switch 6 to reduce
The horizontal distance gauge on the
outline, the closer the vehicle in front.
the speed;
instrument panel indicates the various
- use the “RES/+” switch 7 to increase
available safe distances:
the speed.
- distance gauge A: long distance
(corresponding to approximately
2.4 seconds);
2.104
ADAPTIVE CRUISE CONTROL (5/13)
Adjusting the safe distance
(cont.)
- distance gauge B: intermediate dis-
11
tance 2 (corresponding to approxi-
mately 2 seconds);
- distance gauge C: intermediate dis-
tance 1 (corresponding to approxi-
11
mately 1.6 seconds);
- distance gauge D: short distance
(corresponding to approximately
1.2 seconds).
The selected distance gauge appears
in green on the instrument panel. The
other gauges remain in grey.
Exceeding the cruising speed
Then, release the accelerator pedal:
Note: the distance must be set accord-
the cruise control and safe distance
ing to the traffic level, local regulation
The cruising speed may be exceeded
control will automatically resume the
and weather conditions.
at any time by applying the accelerator
speed and distance instructions that
pedal.
you had previously selected.
If it is exceeded, the cruising speed 11
appears in red.
Overtaking manoeuvre
The distance gauge flashes if the dis-
If you wish to overtake the vehicle in
tance between your vehicle and the
front, activating the indicator will tem-
vehicle in front is less than the safe
porarily cancel the safe distance con-
distance selected: the Safe Distance
trol and enable an acceleration speed
Control function is no longer active.
sufficient to complete overtaking.
The safe distance is adjusted by de-
fault on the distance gauge B.
2.105
ADAPTIVE CRUISE CONTROL (6/13)
Stopping and starting on
Putting the function on
vehicles fitted with an
standby
automatic gearbox
You can set the function to standby
If the vehicle in front slows down, the
when:
system adapts its speed, if necessary
- you press switch 4 (0);
to a complete stop (e.g. in heavy traf-
- you apply the brake pedal while the
fic). The vehicle stops a few metres
vehicle is moving.
from the vehicle in front. The Stop and
The function is deactivated by the
Start function can put the engine on
system if:
standby ➥ 2.10.
- you set the automatic gearbox to P
4
When the vehicle in front sets off again:
or N;
7
- if the stop does not exceed about
– you engage the reverse gear;
three seconds, the vehicle sets off
- you unbuckle the driver’s seatbelt;
automatically without any action by
- you open one of the opening ele-
the driver;
ments;
- if the stop exceeds about three sec-
- you press the engine start/stop
In all circumstances, the standby is con-
onds, you must apply the accelera-
button;
firmed when the warning lights appear
tor pedal or press button 7 (RES/+) in
- the slope is too steep;
in grey and the message “Adaptive
order for the vehicle to set off again.
- the vehicle speed is above 112 mph
Cruise Ctl Disconnected” appears on
The message “Press RES/+ or ac-
(180 km/h);
the instrument panel.
celerate” appears on the instrument
- certain driving aids and correction
panel to confirm.
devices are triggered (active emer-
If the stop exceeds about three min-
gency braking, ABS, ESC);
utes, the electronic parking brake is
- when you press the clutch pedal for a
automatically applied and the Stop
prolonged period or upon prolonged
Putting the adaptive cruise
and Go adaptive cruise control is de-
neutral position on vehicles equipped
control in standby or switch-
activated. The
warning light disap-
with a manual gearbox.
ing it off does not cause a
pears to confirm that the function is de-
rapid reduction in speed:
activated.
you must brake by applying the
brake pedal if necessary.
2.106
ADAPTIVE CRUISE CONTROL (7/13)
Exit from standby
Depending on the situation, the system
sounds a beep associated with:
Based on the stored cruising speed
- the orange alert E if the situation re-
If a speed is stored, it can be recalled,
quires the driver’s attention;
E
once you are sure that the road con-
or
ditions are suitable (traffic, road sur-
face, weather conditions, etc.). Press
- the red alert F accompanied by the
switch 7 (RES/+) in the range of con-
message “Brake”, if the situation re-
firmed speeds.
quires the driver’s immediate atten-
When the stored speed is recalled, acti-
tion.
vation of the cruise control is confirmed
In all situations, react accordingly
by the illumination of the cruising speed
F
and perform the appropriate ma-
in green.
noeuvres.
Note: if the stored speed is higher than
the current speed, the vehicle will ac-
celerate to reach that speed.
“Take control of the vehicle”
Based on the current speed
warnings
When the cruise control is set to
In some situations (e.g. coming upon
standby, pressing switch 6 (SET/-) re-
a much slower vehicle, vehicle in
activates the cruise control function
front changing lanes quickly etc.), the
without taking into account the stored
system may not have time to react.
speed: it is the speed at which the vehi-
cle is moving that is taken into account.
2.107
ADAPTIVE CRUISE CONTROL (8/13)
If the radar detection area is obstructed
Operating faults
or the radar signal is disrupted, the
If an adaptive cruise control function
message “Front radar no visibility” is
operating fault is detected, the mes-
displayed on the instrument panel and
sage “Adaptive Cruise Ctl to check” ap-
the adaptive cruise control is inter-
pears on the instrument panel and the
rupted. The green warning light
adaptive cruise control function is de-
disappears to confirm that the function
activated.
has been automatically deactivated.
Ensure that the radar area is not ob-
If an operating fault is detected on one
structed
(dirt, mud, snow, a badly
or more components of the system, the
fitted/attached front number plate), im-
adaptive cruise control function is inter-
8
pacted, modified (including paintwork)
rupted.
6
or hidden by any accessory fitted on the
The
warning light appears on
7
front of the vehicle (on the grille or logo
the instrument panel along with, de-
etc.).
pending on the malfunction, one of the
Conditions in certain geographical
following messages:
Switching off the function
areas may hinder the function, for ex-
- “Front camera to check”;
The adaptive cruise control function
ample:
is deactivated when you press the 6
- arid zones, tunnels, long bridges or
- “Front radar to check”;
switch.
lightly used roads without road lines,
- “Camera/Radar to check”;
without signs or trees nearby;
The warning light
disappears from
- “Check vehicle”.
the instrument panel to confirm that the
- a military or airport zone.
Consult an approved dealer.
function is no longer active.
You must leave such areas in order for
the function to work.
Temporary unavailability
In all cases, if the message is not
erased after the engine is restarted,
The radar is able to detect vehicles
please contact an authorised dealer.
in front of your vehicle. The system
cannot operate correctly if the radar de-
tection area is obscured or if its signal
is disrupted.
2.108















Content      ..     9      10      11      12     ..
