ELECTRIC SUNROOF (3/3)
Precautions during use
-
Vehicle with loaded roof bars.
As a general rule, if there is a load
on the roof, use of the sunroof is not
recommended.
B
Before using the sunroof, check the
A
C
objects and/or accessories
(bike
0
D
racks, roof boxes, etc.) attached to
the roof bars: they should be prop-
Driver’s responsibility
erly arranged and secured and
Never leave an animal,
4
should not interfere with the opera-
3
child or non-autonomous
tion of the sunroof.
adult alone in your vehicle,
Contact an approved dealer for de-
even for a short time.
tails of possible conversions;
The reason for this is that the child
Operating faults
-
check that the sunroof is properly
may endanger himself or others by
closed before leaving your vehicle;
starting the engine, activating equip-
If the sunroof will not close, move the
ment such as the window winders
marked position 3 to position 0 then
-
clean the seal every three months
for example, or locking the doors.
press button 4 until the sunroof is com-
using products recommended by our
pletely closed: consult an approved
Technical Department;
If something gets trapped, reverse
dealer.
the direction of travel as soon as
-
do not open the sunroof immedi-
possible by turning button 4 fully to
ately after it has rained or immedi-
the right (position D).
ately after washing the vehicle.
Risk of serious injury.
Important: during this operation, the
sunroof anti-pinch function is de-
activated. Contact your approved
Dealer as soon as possible;
3.24
SUN VISOR
2
1
3
Front sun visor
Lower sun visor 1.
Courtesy mirrors
(depending on the vehicle)
Lift the cover 2. The light 3 switches on
automatically.
When driving, ensure the
courtesy mirror cover is
closed.
Risk of injury.
3.25
INTERIOR LIGHTING (1/3)
1
2
2
3
3
A
B
C
Courtesy light A
Reading lights B or C
Press switch 1 for:
Press the 2 switch for the driver, 3
switch for the front passenger, for per-
- permanent lighting;
manent lighting.
- lighting controlled by the unlocking of
Note: on vehicles fitted with a multime-
the vehicle or by opening one of the
dia screen, you can use the multime-
doors. This switches off after a time
dia screen to deactivate/activate the
delay, once the doors concerned
reading lights which switch on when
have been closed correctly;
the doors or luggage compartment are
– lighting switches off immediately.
opened. ➥ 1.83.
3.26
INTERIOR LIGHTING (2/3)
D
E
4
5
6
7
Courtesy light D
Map reading lights E
Press switch 4 for:
Press switch 5 6 or 7 for constant light-
ing
- permanent lighting;
Note: on vehicles fitted with a multime-
- lighting controlled by the unlocking of
dia screen, you can use the multime-
the vehicle or by opening one of the
dia screen to deactivate/activate the
doors. This switches off after a time
reading lights which switch on when
delay, once the doors concerned
the doors or luggage compartment are
have been closed correctly;
opened. ➥ 1.83.
- lighting switches off immediately.
3.27
INTERIOR LIGHTING (3/3)
9
8
8
Glove box light
Luggage compartment light
Depending on the vehicle, the 8 light
Light 9 comes on when the luggage
switches on when the cover is opened.
compartment is opened.
Unlocking and opening the doors or
tailgate switches on the timed cour-
tesy lights and lights.
3.28
PASSENGER COMPARTMENT STORAGE, FITTINGS (1/4)
2
3
1
Front door storage pockets 1
Sun blind storage
Centre console storage
compartment 2
compartment/induction
They can hold a 1.5-litre bottle.
charging zone 3
This can be used for storing motorway
tickets, cards, etc.
For more information on the induction
charging zone, please refer to the mul-
timedia instructions.
Nothing should be placed
Ensure that no hard, heavy
on the floor area in front of
or pointed objects are
the driver as such objects
placed in the “open” storage
may slide under the pedal
compartments in such a
during braking manoeuvres, thus
way that they may fall onto passen-
obstructing its use.
gers during sudden turning, braking
or in the event of an accident.
3.29
PASSENGER COMPARTMENT STORAGE, FITTINGS (2/4)
4
7
8
6
5
Centre console storage
Passenger storage
Passenger storage drawer
compartment 4/ induction
compartment
To open, press the button 7 to unlock
charging zone 5
the drawer and pull the handle 8.
Pull handle 6 to open it.
For more information on the induction
The glove box can hold A4-sized docu-
charging zone, please refer to the mul-
ments, a bottle etc.
timedia instructions.
Ensure that no hard, heavy
or pointed objects are
placed in the “open” storage
compartments in such a
way that they may fall onto passen-
gers during sudden turning, braking
or in the event of an accident.
3.30
PASSENGER COMPARTMENT STORAGE, FITTINGS (3/4)
10
11
9
12
Centre armrest storage
Cup holders 12
compartment 11
Depending on the vehicle, the cup
Lift the cover 9 of the sliding armrest by
holder may be equipped with retaining
pressing the 10 button.
hooks to keep the cup in place.
This can be used to store a mobile ash-
tray, drink cans, etc.
When turning corners,
accelerating or braking,
ensure that the recepta-
cle being held by the cup
holder is not dislodged.
There is a risk of injury if hot
liquid escapes.
3.31
PASSENGER COMPARTMENT STORAGE, FITTINGS (4/4)
15
14
13
Rear door storage
Rear seat storage pockets 14
Grab handle 15
compartment 13
This offers support and can be held
They can hold a 0.5-litre bottle.
when the vehicle is moving.
Do not use it for getting into or out of
the vehicle.
Ensure that no hard, heavy
or pointed objects are
placed in the “open” storage
compartments in such a
way that they may fall onto passen-
gers during sudden turning, braking
or in the event of an accident.
3.32
ACCESSORIES SOCKET
1
1
Accessories socket 1
You can use the 1 socket. It is provided
for connecting accessories approved
by our Technical Department.
Connect accessories with
a maximum power of
120 watts (12 V) only.
When several accessory
sockets are used at the same time,
the total power of the connected
accessories must not exceed
180 watts.
Fire hazard.
3.33
REAR HEAD RESTS
2
1
Position for use
To refit the headrest
When the headrest is set at the
lowest position, this is for storage
Raise the headrest as far as possible to
Fit the rods into their housing and push
only. It should not be in this position
use it in the high position. Check that it
down the headrest until it locks to set
when a seat is occupied.
is correctly locked.
it to raised position. Check that the
bonnet is correctly locked.
To remove the headrest
Folding positions 2 for the
Raise the headrest as far as it will go,
then press button 1 and remove the
headrest
headrest.
Press the button 1 and lower the head-
The headrest is a safety
rest completely.
component; check that it is
fitted and in the correct po-
sition. The top of the head-
rest should be as close as possible
to the top of the head.
3.34
REAR BENCH SEAT: functions (1/2)
Pull the vane 1 and lower the seat-
1
A
back B.
Note: for safety reasons, the seat-
back B is equipped with a retaining
system. You may experience resist-
B
ance when handling.
To replace the seatback, proceed in
the reverse order to removal.
Raise the seatback again until it
reaches the locking joint of the seat-
back. Be careful not to jam the safety
strap between the backrest and the
parcel shelf.
Check the operation of the seat belt.
To fold down the seatback
Ensure that the front seats are far
enough forward.
Before folding down a seatback:
- lower the headrest fully;
When refitting the seat-
- place the seat belt in the belt guide A
back, make sure it is cor-
and buckle the seat belt. This pre-
rectly locked in place.
vents the seat belt from locking when
If seat covers are fitted,
the seatback is lifted up again.
make sure these do not prevent the
seatback latch from locking in.
Make sure that the seat belts are
positioned correctly.
Reposition the headrests.
Before moving the seatback, put
the seat belt in belt guide A to avoid
damaging it.
3.35
REAR BENCH SEAT: functions (2/2)
3
2
To move forwards or
backwards
To unlock the seat:
- from the rear seats, lift the lever 2 ;
- from the luggage compartment, op-
For safety reasons, carry
erate the handle 3.
out any adjustments when
the vehicle is not being
Move the seat forwards or back to the
driven.
required position.
Release lever 2 or handle 3 and make
sure that the seat is locked correctly in
When moving the rear
position.
seats, ensure that nothing
obstructs the anchorage
points (passenger’s arm or
leg, a pet, gravel, cloth, toys, etc.).
3.36
BOOT
2
3
1
To open
Opening the doors manually
from the inside
Press the 1 button to open the luggage
compartment lid a few centimetres.
If it is impossible to unlock the tailgate,
Lift the luggage compartment lid.
it can be done manually from inside:
- access the luggage compartment by
tilting the rear bench seatback(s),
To close
- insert a pencil or similar object in
Lower the tailgate using the handles 2
recess 3 and slide the unit as shown
inside the tailgate to help you.
The attaching of any carry-
in the illustration;
ing device (bike rack, lug-
- push the tailgate to open it.
gage box etc.) resting on
the luggage compartment
lid is prohibited. To install a carrying
device on your vehicle, contact an
Approved Dealer.
3.37
REAR PARCEL SHELF
1
A
2
2
Removal
- Unhook the two straps 1 of the door
of the boot;
- lift the shelf
2 to unclip it (move-
ment A);
- pull the shelf towards you.
To refit, proceed in the reverse order to
removal.
Do not place any heavy or
hard object on the parcel
shelf. These may pose a
risk to the vehicle occu-
pants if the driver has to brake sud-
denly or if the vehicle is involved in
an accident.
3.38
BOOT ARRANGEMENTS
1
2
1
2
3
1
Mobile floor 1
Intermediate position
Storage position
In the blocked position, it allows you to
This allows for more space to store
Flat position
access the tools stored under the boot
things in the boot.
Enables you to flatten the floor by fold-
carpet.
- Remove the mobile floor 1;
ing down the back of the rear bench
- Remove the mobile floor 1;
seat and to compartmentalise the boot
- place it in the luggage compartment
into two distinct spaces.
- position it in the luggage compart-
under the runner 2.
ment, using the 2 runners provided.
The mobile floor is positioned on the
Bag hooks 3
runner 2.
Maximum weight per hook: 5 kg.
Maximum weight for the mobile
floor: 100 kg evenly distributed.
3.39
TRANSPORTING OBJECTS IN THE LUGGAGE COMPARTMENT
Always position the objects transported
so that the largest surface is against:
- the rear bench seatback, for normal
loading (example A);
A
1
1
– the front seatbacks with the rear seat-
backs folded down, as is the case for
B
maximum loads (example B).
Always position the heavi-
If you have to place objects on the folded
est items directly on the
seatback, it is necessary that you lower
floor. Use the lashing
the headrests before folding the seat-
points 1 on the boot floor, if
back so that it can be folded as flat as
these are fitted to the vehicle. The
possible against the seat.
luggage should be loaded in such a
Note: in the absence of an emergency
way that no items will be thrown for-
spare wheel or tyre inflation kit, do not
ward and strike the occupants if the
load the bottom of the luggage compart-
driver has to brake suddenly. Fasten
ment.
the rear seat belts, even if the seats
are not occupied.
3.40
TRANSPORTING OBJECTS towbar
A
Permissible nose weight, maxi- -
mum permissible towing weight
Maximum dimension A: 837 mm.
braked and unbraked: ➥ 6.9.
Choice and fitting of towing
equipment
Maximum weight of towing equip-
ment:
- 10 kg on a vehicle with towing
pre-equipment;
Any towing device must not ob-
- 28 kg on a vehicle without towing
struct any lighting component or
pre-equipment.
the number plate when not in use.
For fitting and conditions of use,
Towing devices (ball, hook, etc.)
refer to the equipment’s fitting in-
which can be removed without tools
structions.
and retractable objects must be re-
moved or repositioned when they
Please keep these instructions with
are not in use. In all cases, you must
the rest of the vehicle documenta-
comply with the regulations of the
tion.
particular country you are in.
3.41
ROOF BARS, SPOILER (1/2)
1
3
2
For information on the range of
equipment adapted to your vehi-
cle, we advise you to consult an ap-
proved Dealer.
Refer to the fitting instructions for in-
formation on how to fit roof bars and
Accessing the mounting
Vehicles not fitted with longitudinal
conditions of use.
roof bars
points
Please keep these instructions with
Open the doors to access the fixing
the rest of the vehicle documenta-
Vehicles fitted with longitudinal roof
points 3.
tion.
bars
Maximum permissible load on
The attachment inserts 2 are located on
roof rack ➥ 6.9.
the longitudinal roof bars 1.
If original roof bars, ap-
proved by our Technical
Department, are supplied
with screws, only use these
screws for attaching the roof bars to
the vehicle.
3.42
ROOF BARS, SPOILER (2/2)
Precautions during use
Handling the tailgate
A
Before handling the tailgate, check the
objects and/or accessories (bike rack,
roof box, etc.) fitted to the roof bars:
these must be correctly positioned and
secured, so as not to hinder the opera-
tion of the tailgate.
Spoiler A
It is prohibited to attach any
carrying equipment
(bike
rack, luggage box etc.)
resting against the spoiler
or tailgate. To install a carrying
device on your vehicle, contact an
Approved Dealer.
3.43
Section 4: Maintenance
Bonnet
4.2
Engine oil level: general information
4.4
Engine oil level: topping up, filling
4.5
Oil change
4.6
Levels
4.8
engine coolant
4.8
brake fluid
4.9
windscreen washer reservoir
4.10
Filters
4.10
Tyre pressure
4.11
Battery
4.13
Bodywork maintenance
4.16
Interior trim maintenance
4.19
4.1
BONNET (1/2)
6
5
4
1
3
2
To open the bonnet, open a door and
Unlocking the bonnet catch
Opening the bonnet
pull the 1 handle, located on the left-
To unlock, push tab 2 at the same time
Lift the bonnet and release stay 5 from
hand side of the dashboard.
as opening the bonnet.
its holder 6 using the handle 4. For
your own safety, it is very important
to fix the stay into the retainer 3 in the
bonnet.
Before carrying out any
action in the engine com-
Please note when work-
partment, you must switch
ing close to the engine that
off the ignition. ➥ 2.4.
it may be hot. The engine
cooling fan may also start
When working in the engine
at any moment. The
label
compartment, ensure that
in the engine compartment reminds
the windscreen wiper stalk
you of this.
Do not press down on the
is in the park position.
bonnet: there is a risk that
Risk of injury.
Risk of injury.
the bonnet may accidentally
close.
4.2















Content      ..     12      13      14      15     ..
