MULTI-SENSE
The MULTI-SENSE system enables a
Mode Eco
1
choice between three driving modes
Eco mode focuses on energy saving.
that can be used to control, depending
The steering is smooth, engine and
on the vehicle: driving, ambient lighting,
gearbox management enable fuel con-
comfort and engine sound:
sumption to be reduced ➥ 2.30.
- the Eco and Sport modes are pre-
configured and can be partially cus-
Sport mode
tomised (ambient lighting, etc.);
This mode enables an increased re-
- the My Sense mode is customisable.
sponsiveness from the engine and the
The drive modes affect the:
2
gearbox. The steering is firmer.
- power-assisted steering;
- Electronic Stability Program;
- the response of the engine and gear-
My Sense mode
box.
Using standard default vehicle settings,
this mode can be used to manually con-
They also affect the:
figure driving, ambient lighting, comfort
- the lighting in the passenger com-
and engine sound (depending on the
Accessing the menu
partment and of the instrument
vehicle).
You can access MULTI-SENSE, de-
panel;
pending on the vehicle:
- the information on the instrument
- from the multimedia screen 1;
panel and multimedia screen;
- using the 2 switch.
- depending on the vehicle, the engine
sound.
Please refer to the multimedia instruc-
tions for further information.
After the engine is switched off, the
vehicle will always restart in My
Sense mode.
In any mode, you can change the colour of the ambient lighting as well as the
Engine settings are specific to each
format of the information displayed on the instrument panel and multimedia
of the driving modes and cannot be
screen.
customised.
You can also reset to the default settings.
3.2
AIR VENTS, air outlets (1/2)
3
2
1
2
3
4
1
3
5
6
7
5
8
1
Side air vents
5 Footwell heater outlets for front
2 Demister outlets for side windows
passengers
3 Windscreen demisting vents
6
Control panel
4
Centre air vents
7 Footwell heater outlets for rear
passengers (depending on the
vehicle)
8
Rear console air vents
3.3
AIR VENTS, air outlets (2/2)
9
9
1
9
8
4
7
Central 4, side 1 and rear air
Rear seats
vents 8
(depending on vehicle)
Passenger footwell heater outlets 8.
Air flow
To close: move the cursor 9 towards the
outside of the vehicle beyond the resist-
ance point.
To open: move the cursor 9 towards the
inside of the vehicle.
Direction
Do not add anything to the
Move the cursor 9 to the desired posi-
vehicle’s ventilation circuit
tion.
(for example, to remove
bad odours).
Do not attach any objects to the air
vents (e.g. telephone mounting).
There is a risk of damage or of
fire.
Risk of damage.
3.4
MANUAL AIR CONDITIONING, HEATING SYSTEM (1/6)
Distribution of air in the
A
2
3
4
5
passenger compartment
1
6
There are five air distribution options.
Turn control 1 to choose the distribution
option.
The air flow is directed to the
W
windscreen and the front side
window demisting vents.
The air flow is distributed be-
tween front side window de-
misting vents, the windscreen demist-
ing vents and the footwells.
The air flow is directed mainly
towards the footwells.
The A controls
The air flow is directed to-
(depending on vehicle)
wards the dashboard air vents,
1 Distribution of air in the passenger compartment.
the front footwells and, depending on
the vehicle, the second row footwells.
2 De-icing/demisting of the rear screen and, depending on the vehicle, the rear view
mirrors.
The air flow is mainly directed
J
to the dashboard air vents.
3 Adjusting the ventilation fan speed.
4 Air recirculation.
5 Adjusting the air temperature.
6 Air conditioning.
3.5
MANUAL AIR CONDITIONING, HEATING SYSTEM (2/6)
Switching air conditioning on
B
7
6
3
1
or off
5
Activation is not possible if the 3 control
is set to “0" (control A) or "OFF" (con-
trol B).
Press the 6 button to deactivate the air
conditioning. The button’s warning light
will go out.
The air conditioning system is used
for:
- lowering the temperature inside the
passenger compartment;
2
4
- eliminating condensation more
Controls B
quickly.
(depending on the vehicle)
1 Distribution of air in the passenger compartment.
2 De-icing/demisting of the rear screen and, depending on the vehicle, the rear view
mirrors.
3 Adjusting the ventilation fan speed.
4 Air recirculation.
5 Adjusting the air temperature.
6 Air conditioning control.
7 “Clear View” function.
3.6
MANUAL AIR CONDITIONING, HEATING SYSTEM (3/6)
Air recirculation (isolation of
Stopping the system
Switching air conditioning on
the passenger compartment)
Turn the 3 control to “OFF" or "0" to
or off
switch off the system or press the 4
Air recirculation is for:
In automatic mode, the system switches
button. To start it, turn the 3 control to
the air conditioning system on or off,
- isolating the vehicle from the exter-
adjust the fan speed.
depending on the climate conditions.
nal atmosphere (driving in polluted
areas, etc.);
Activation is not possible if the 3 control
Clear View function
is set to “0" (control A) or "OFF" (con-
- to cool the passenger compartment
Press the 7 button: the integrated indi-
trol B).
temperature more quickly when air
conditioning is activated.
cator light comes on.
Press the 6 button to deactivate the air
conditioning. The button’s warning light
This function is managed automatically
This function quickly demists and de-
will go out.
but you can also activate it manually. In
ices the windscreen, the rear screen,
this case, the operation is confirmed by
the front side windows, and the door
The air conditioning system is used
the button’s warning light 4.
mirrors (depending on the vehicle). The
for:
air conditioning and rear screen de-ic-
Manual use
ing functions must be activated.
- lowering the temperature inside the
passenger compartment;
Press button 4, the button’s warning
Press button 2 to stop the heated rear
light comes on.
screen operating, and the integrated in-
- eliminating condensation more
dicator goes out.
quickly.
Prolonged use of this position may lead
to odours, caused by non-renewal of
To exit this function, press button 7
air, and the formation of condensation
or 5.
on the windows. To avoid this, air recir-
culation is disabled automatically after
a certain time.
Fuel consumption increases when
Using the demisting/de-icing func-
the air conditioning is being used
tion will disable the air recirculation.
(switch it off when it is not required).
3.7
MANUAL AIR CONDITIONING, HEATING SYSTEM (4/6)
1
3
5
Switching the air
recirculation on
Press button 4: the button’s warning
light comes on. Under these conditions,
air is taken from the passenger com-
partment and is recirculated, with no air
being taken from outside the vehicle.
If the air conditioning is not acti-
Air recirculation is for:
vated (“A/C" warning light on the 6
button goes off), prolonged use of
- isolating the vehicle from the exter-
recirculated air may cause mist to
nal atmosphere (driving in polluted
form on the side windows and wind-
areas, etc.);
screen as well as other problems
- to cool the passenger compartment
due to the presence of non-recircu-
temperature more quickly when air
lated air in the passenger compart-
conditioning is activated.
ment. To avoid this, air recirculation
is disabled automatically after a cer-
tain time.
3.8
MANUAL AIR CONDITIONING, HEATING SYSTEM (5/6)
Adjusting the air temperature
2
3
4
5
Turn control 5 to obtain the desired
temperature. The further towards the
red the slide is, the higher the tempera-
ture will be.
1
When the air conditioning system is
used for long periods, it may begin to
feel cold. To increase the temperature,
turn control 5 to the right.
Adjusting the ventilation
speed
Move the 3 control to adjust the amount
of air blown. If you want to shut off the
flow of air, set the 3 control to “0" (con-
trol A) or "OFF" (controlB).
The system is deactivated: the ventila-
tion speed is zero (vehicle stationary).
You can, however, still feel a slight flow
of air when the vehicle is moving.
Using W
position on the 1 con-
trol will disable the air recirculation
function in order to prevent misting
of the windscreen.
3.9
MANUAL AIR CONDITIONING, HEATING SYSTEM (6/6)
2
3
4
5
1
Rear screen de-icing/
Rapid demisting
demisting
Turn controls 1, 3 and 5 to:
With the engine running, press
- demisting W
;
button 2. The operating tell-tale comes
on.
- the fan speed in position 3 or 4;
This function permits rapid demisting/
- maximum temperature.
de-icing of the rear screen and de-icing
Press the 4 button to deactivate the air
of the door mirrors (on equipped vehi-
recirculation (warning light off).
cles).
To exit this function, press button 2
again. Warning light goes out.
Demisting automatically stops.
3.10
AUTOMATIC CLIMATE CONTROL (1/4)
Adjusting the ventilation
1
2
3
4
5
6
speed.
In automatic mode, the system uses
the most suitable amount of air to reach
and maintain the desired comfort level.
You can still adjust the ventilation
speed by turning control 1 to increase
or reduce the ventilation speed.
Adjusting the air temperature
Turn control 3 to obtain the desired
temperature.
8
7
Turning the control to the
right
in-
creases the temperature.
The controls
Automatic mode
(depending on the vehicle)
The automatic climate control system
1
Adjusting the ventilation fan speed.
guarantees comfort in the passen-
ger compartment and good visibility
2
“Clear View” function.
(except in the event of extreme condi-
3
Adjusting the air temperature.
tions), while optimising consumption.
4
Automatic mode.
The system controls the ventilation
speed, air distribution, air recirculation,
5
Air conditioning control.
and starting and stopping the air condi-
6
Distribution of air in the passenger
tioning and air temperature.
compartment.
AUTO: allows the selected comfort
7
Air recirculation.
level to be best attained, depending on
the exterior conditions. Press button 4.
8
De-icing/demisting of the rear screen
and, depending on the vehicle, the
rear view mirrors.
Any action on a button other than
button AUTO triggers deactivation
of automatic mode.
3.11
AUTOMATIC CLIMATE CONTROL (2/4)
Clear View function
2
4
6
Press the 2 button: the integrated indi-
cator light comes on.
This function quickly demists and de-
ices the windscreen, the rear screen,
the front side windows, and the door
mirrors (depending on the vehicle). The
air conditioning and rear screen de-ic-
ing functions must be activated.
Press button 8 to stop the heated rear
screen operating, and the integrated in-
dicator goes out.
To exit this function, press button 2
8
or 4.
Adjusting the distribution
The air flow is directed towards
the dashboard air vents, the
of air in the passenger
front footwells and, depending on the
compartment
vehicle, the second row footwells.
Turn control 6. The integrated warning
The air flow is mainly directed
light in the button comes on.
to the dashboard air vents.
All the air is then directed to
W
the windscreen and front side
owards the footwells.
window demisting vents.
The air flow is distributed be-
tween front side window de-
misting vents, the windscreen demist-
ing vents and the footwells.
3.12
AUTOMATIC CLIMATE CONTROL (3/4)
5
8
Rear screen de-icing/
Switching air conditioning on
demisting
or off
Press the 8 button: the integrated in-
In automatic mode, the system switches
dicator light comes on. This function
the air conditioning system on or off,
enables rapid demisting or de-icing of
depending on the climate conditions.
the rear screen and de-icing of the rear
Press the 5 button to deactivate the air
view mirrors (on equipped vehicles).
conditioning. The integrated indicator
To exit this function, press button 8
light goes off.
again. Demisting automatically stops.
3.13
AUTOMATIC CLIMATE CONTROL (4/4)
Stopping the system
1
4
Turn the control 1 to “OFF” to stop the
system. To start it, turn the control 1
again, then adjust the fan speed or
press the button 4.
7
Air recirculation (isolation of
Manual use
the passenger compartment)
Press the 7 button: the integrated indi-
cator light comes on.
This function is managed automatically
but you can also activate it manually. In
Prolonged use of this position may lead
this case, the operation is confirmed by
to odours, caused by non-renewal of
a warning light on the button 7.
air, and the formation of condensation
on the windows.
To avoid this, air recirculation is disa-
bled automatically after a certain time.
Fuel consumption increases when
Using the demisting/de-icing func-
the air conditioning is being used
tion will disable the air recirculation.
(switch it off when it is not required).
3.14
AIR CONDITIONING: information and operating instructions (1/2)
Advice on use
Fuel consumption
Operating faults
In some situations (air conditioning off,
You will normally notice an increase in
As a general rule, contact your ap-
air recirculation activated, ventilation
fuel consumption (especially in town)
proved dealer in the event of an oper-
speed at zero or low etc.), you may
when the air conditioning is operating.
ating fault.
notice that condensation starts to form
For vehicles fitted with air conditioning
- Reduction in de-icing, demisting
on the windows and windscreen.
with no automatic mode, switch off the
or air conditioning performance.
If there is condensation, use the “Clear
system when it is not required.
This may be caused by the passen-
View” function to remove it, then use
ger compartment filter cartridge be-
Advice for reducing consumption
the air conditioning in automatic mode
coming clogged.
and helping to preserve the environ-
to stop it forming again.
ment
- No cold air is being produced.
Check that the controls are set cor-
Drive with the air vents open and the
rectly and that the fuses are sound.
windows closed. If the vehicle has been
Otherwise, switch off the system.
parked in the sun, open the doors for a
few moments to let the hot air escape
before starting the engine.
Presence of water under the
vehicle
Maintenance
After prolonged use of the air condi-
Refer to the Maintenance Document
tioning system, it is normal for water
for your vehicle for the inspection fre-
to be present under the vehicle. This is
quency.
caused by condensation.
Do not add anything to the
vehicle’s ventilation circuit
Do not open the refriger-
(for example, to remove
Use the air conditioning system reg-
ant fluid circuit. The fluid
bad odours).
ularly, even in cold weather, running
may damage eyes or skin.
There is a risk of damage or of
it at least once a month for approxi-
fire.
mately 5 minutes.
3.15
AIR CONDITIONING: information and operating instructions (2/2)
Type of refrigerant fluid
Ñ
A
A
A
Type of oil in the air condi-
tioning circuit
Inflammable product
Consult the driver’s hand-
book
Maintenance
Quantity of refrigerant
x.xxx kg
fluid present in the ve-
The refrigerant fluid circuit (of which
hicle.
some components are hermetically
sealed) may contain fluorinated green-
Global
Warming
house gases.
GWP xxxxx
Potential
(CO2 equi-
Depending on the vehicle, you will find
valent).
Do not open the refriger-
the following information on label A af-
ant circuit. The fluid may
fixed inside the engine compartment.
damage eyes or skin.
CO2 eq
Quantity in weight and
The presence and location of the infor-
x.xx t
in CO2 equivalent.
mation on label A depends on the ve-
hicle.
Before carrying out any
action in the engine com-
partment, you must switch
off the ignition.
➥ 2.4 or
➥ 2.6.
3.16
MULTIMEDIA EQUIPMENT (1/3)
A
B
1
C
1
5
4
4
4
2
2
3
3
3
Multimedia system A, B or
Multimedia sockets 2
The sockets USB can also be used to
recharge accessories with a maximum
radio C
You can use the USB sockets to access
power rating of 12 Watts (5 Volts) per
The location and operation of equip-
the multimedia content of your acces-
socket, which have been approved by
ment may vary according to the vehicle.
sories and to update the system.
our Technical Department.
1 Multimedia screen;
The various sources can be selected
The JACK socket enables the radio to
2 Multimedia sockets;
using the multimedia screen or the
be used with an auxiliary cable.
3 Steering column controls;
radio and the steering column controls.
4 Steering wheel controls;
5 Radio.
Connect accessories with a
maximum power of 12 watts
only.
Please refer to the multimedia in-
Fire hazard.
structions for further information.
3.17
MULTIMEDIA EQUIPMENT (2/3)
8
4
6
7
Steering column controls 4
Microphone 8
You can use the hands-free telephone 6
and voice recognition 7 controls on ve-
hicles fitted with these.
3.18
MULTIMEDIA EQUIPMENT (3/3)
9
9
Wireless charger 9
(depending on the vehicle)
➥ 3.29
Using the telephone
We remind you of the need
to conform to the legislation
in force concerning the use
of such equipment.
3.19
ELECTRIC WINDOWS (1/2)
These systems operate with the igni-
tion on or off, until one of the front doors
is opened (limited to about 3 minutes).
1
5
6
Driver’s responsibility
2
Never leave your vehicle
with the card or key inside,
4
3
with a child, adult who is not
self-sufficient or a pet in the vehicle,
even for a short while.
They may pose a risk to themselves
One-touch electric windows
or to others by starting the engine
Avoid resting any objects against
Briefly press or pull a window switch
or activating equipment (such as the
a half-open window: there is a risk
as far as it will go: the window will be
gear lever or electric windows).
that the electric window could be
raised or lowered fully. Pressing the
If any part of the body becomes
switch again stops the window moving.
damaged.
trapped, reverse the direction of the
Note: the rear windows do not open
window immediately by pressing the
fully
relevant switch.
From the driver’s seat, use switch:
Passenger safety
1
for the driver’s side;
Risk of serious injury.
The driver can prevent the
2
for the front passenger side;
front and rear passenger
3
and 5 for the rear passengers.
electric windows from op-
From the passenger seats, use
erating (and the driver’s window)
switch 6.
by pressing switch 4. A confirmation
message is displayed on the instru-
ment panel.
3.20
ELECTRIC WINDOWS (2/2)
One-touch electric windows
Remote control window
Operating faults
(continued)
closing
In case of a fault when closing a
Note: if the window detects resistance
When the doors are locked from the
window, the system reverts to normal
when closing (e.g. tree branch etc.), it
outside, if you double-press the lock-
mode: pull the switch concerned up as
stops and then lowers again by a few
ing button on the driver’s door in
often as necessary to fully close the
centimetres.
hands-free mode, on the card or, de-
window (the window will close gradu-
pending on the vehicle, on the key,
ally), hold the switch (still on the clos-
all of the windows (and sunroof de-
ing side) for one second then lower and
Impossible to operate the
raise the window fully to reinitialise the
pending on the vehicle) equipped with
one-touch electric window
a one-touch electric window will close
system.
automatically.
The one-touch electric window is
If necessary, contact an approved
It is recommended that the user only
equipped with heat protection: if you
Dealer.
operates the system when the vehi-
press the switch for the window more
cle can be seen clearly and no one is
than 16 consecutive times it goes into
inside.
protection mode (locking the window).
You can:
- use the electric window switch briefly
and with intervals of approximately
30 seconds;
- with the engine running, the window
will be unlocked after approximately
20 minutes of inaction on the electric
window switch.
When closing the windows, ensure that no part of the body (arm, hand,
etc.) is protruding from the vehicle.
Risk of serious injury.
3.21
ELECTRIC SUNROOF (1/3)
1
Driver’s responsibility
Never leave an animal,
child or non-autonomous
adult alone in your vehicle,
even for a short time.
B
A
C
2
The reason for this is that the child
D
may endanger himself or others by
0
starting the engine, activating equip-
ment such as the window winders
4
for example, or locking the doors.
3
If something gets trapped, reverse
the direction of travel as soon as
possible by turning button 4 fully to
the right (position D).
To slide the curtain 1
To slide the sunroof
Risk of serious injury.
- To open: push the handle 2 rear-
- To tilt: move the marked position 3
wards to move the blind to the de-
to position A;
sired position;
- to open: move the marked posi-
- to close: pull the handle 2 forwards
tion 3 to position B, C or Ddepending
to move the blind to the desired posi-
on the type of opening required;
tion.
- to close: move the marked posi-
tion 3 to position 0.
If the vehicle is equipped
with this function, this action
will activate deadlocking.
➥ 1.5 or ➥ 1.9.
Check that there is no-one still
inside the vehicle
3.22
ELECTRIC SUNROOF (2/3)
Closing the sunroof by
remote control
If you press the locking button on the
card twice in quick succession, the
windows and sunroof will close auto-
matically.
It is recommended that the user only
A B C
operates the system when the vehi-
0
D
cle can be seen clearly and no one is
inside.
4
3
Special features
Your vehicle is fitted with an anti-pinch
facility: when the sunroof encounters
resistance whilst closing
(branch of
a tree, etc.), it stops and then moves
back a few centimetres.
After closing the sunroof by remote
control, pressing button 4 allows the
sunroof to return to its previous posi-
tion.
If the vehicle is equipped
When closing the sunroof,
with this function, this action
The sunroof will not open when the
ensure that no part of the
will activate deadlocking.
temperature is below -20°C. However,
body (arm, hand, etc.) is
➥ 1.5 or ➥ 1.9.
it will still close.
protruding from the vehicle.
Check that there is no-one still
Risk of serious injury.
inside the vehicle
3.23















Content      ..     11      12      13      14     ..
