ACTIVE EMERGENCY BRAKING (1/8)
Depending on the reactivity of the
1
driver, the system can assist with brak-
ing in order to limit damage or prevent
a collision.
Note: ensure that the windscreen and
front bumper are not obstructed (by
dirt, mud, snow, condensation, number
plate, etc.).
Location of the camera 1
Make sure the windscreen is not ob-
scured (by dirt, mud, snow, condensa-
This system can apply maximum
tion etc.).
braking to the vehicle until it is
2
completely stationary if necessary.
For safety reasons, always wear
The system uses information from the
Location of the radar 2
your seat belt when travelling in
radar 2 and the camera 1 to determine
Ensure that the radar area is not ob-
your vehicle and make sure that it
the distance from your vehicle:
structed (by dirt, mud, snow, a badly
is loaded so that no items can be
- from the vehicle ahead in the same
fitted front number plate), impacted,
thrown forward and hit the occu-
lane;
modified (including painting) or hidden
pants.
by any accessory fitted on the front of
or
the vehicle (on the grille or logo etc.).
- surrounding pedestrians and cy-
clists.
This function is an addi-
The system informs the driver if there
tional driving aid. This func-
is a risk of head-on collision to enable
tion is not under any circum-
appropriate emergency manoeuvres
stances intended to replace
(pressing the brake pedal and/or turn-
the due care and attention of the
ing the steering wheel).
driver, who should at all times be
in control of the vehicle.
2.82
ACTIVE EMERGENCY BRAKING (2/8)
Operation
Special features of warnings
Depending on the speed, the warning
Detection of vehicles
and braking may be activated simulta-
When driving at a speed between ap-
neously.
proximately 4 mph (7 km/h) and 105
mph (170 km/h), if there is a risk of
3
Special features of stationary
collision with the vehicle in front, the
vehicles
system:
Stationary vehicles are detected when
- warns you of a collision risk:
your vehicle is being driven at a speed
When the vehicle speed is between
between approximately 4 mph (7 km/h)
approximately 4 mph (7 km/h) and
and 50 mph (80 km/h). The system is
106 mph (170 km/h), the message
not active and does not emit a warning
“Brake” is displayed in red on the in-
for stationary vehicles when you exceed
strument panel 3 accompanied by a
approximately 50 mph (80 km/h).
beep.
If the driver depresses the brake
If active emergency braking has caused
pedal and the system still detects a
the vehicle to stop, the vehicle is kept
risk of collision, the brake force is in-
stationary for a short time. Beyond this
creased.
time limit, the vehicle must be held sta-
- may trigger braking:
tionary by the driver keeping their foot
when the vehicle speed is below ap-
on the brake pedal.
proximately 75 mph (120 km/h), if the
Note: if the driver uses the vehicle con-
driver does not respond to the warn-
trols (steering wheel, pedals, etc.) the
ing and a collision is imminent.
system may delay certain operations or
not activate.
In the event of emergency manoeu-
vre, you can stop braking at any
moment by:
- tapping the accelerator pedal;
or
- turning the steering wheel as a
collision avoidance manoeuvre.
2.83
ACTIVE EMERGENCY BRAKING (3/8)
Detection of pedestrians and
Special features of warnings
cyclists
Depending on the speed, the warning
(depending on the vehicle)
and braking may be activated simulta-
When driving at a speed between ap-
neously.
proximately 4 mph (7 km/h) and 50
mph (80 km/h), if there is a risk of col-
3
lision with a cyclist or a pedestrian, the
system:
- warns you of a risk of collision: the
red
warning light or, depend-
ing on the vehicle, 3 and the "Brake"
message are displayed on the instru-
ment panel accompanied by a beep.
If the driver presses the brake pedal
and the system still detects a risk of
If active emergency braking has caused
collision, the braking force may be in-
the vehicle to stop, the vehicle is kept
creased if it is not sufficient to pre-
stationary for a short time. Beyond this
vent the collision.
time limit, the vehicle must be held sta-
tionary by the driver keeping their foot
- may trigger braking:
on the brake pedal.
if the driver fails to react following the
alert and collision becomes immi-
Note: if the driver uses the vehicle con-
nent.
trols (steering wheel, pedals, etc.) the
system may delay certain operations or
not activate.
In the event of emergency manoeu-
vre, you can stop braking at any
moment by:
- tapping the accelerator pedal;
or
- turning the steering wheel as a
collision avoidance manoeuvre.
2.84
ACTIVE EMERGENCY BRAKING (4/8)
- press the 6 or 7 control repeatedly to
4
reach the “Active braking” menu and
press the 8 OK switch.
Press the switch 8 OK again to activate
or deactivate the function:
=
function activated
<
function deactivated
Upon deactivation of the system, the
5
6
warning light illuminates or, de-
pending on the vehicle, the
warning light illuminates on the instru-
8
7
ment panel.
Activating or deactivating the
For vehicles not fitted with a
multimedia screen
system
- With the vehicle stopped, press the
For vehicles fitted with a multimedia
switch 5 as many times as required
screen 4
to reach the “Vehicle” tab;
To activate or deactivate the function,
- press the 6 or 7 control repeatedly to
refer to the multimedia instructions.
reach the “Settings” menu. Press the
switch 8 OK;
Select “ON” or “OFF”.
- press the 6 or 7 control repeatedly to
reach the “DRIVING ASSIST” menu.
Press the switch 8 OK;
This system is reactivated each time
the ignition is switched on.
2.85
ACTIVE EMERGENCY BRAKING (5/8)
Temporarily not available
Operating faults
If the system detects a temporary fault
and
or, depending on the
the
warning light illuminates, or
vehicle,
and
illuminates
depending on the vehicle, the
on the instrument panel: this indicates
warning light illuminates on the instru-
that the system has detected an oper-
ment panel.
ating fault. Consult an approved dealer.
The possible causes are:
- the system is temporarily blinded
(glare from the sun, dipped beam
headlights, bad weather conditions
etc.). The system will be operational
again when visibility conditions are
better;
- the system is temporarily interrupted
(e.g. the windscreen or the front or
rear bumper is obscured by dirt,
mud, snow, condensation, etc.). In
this case, park the vehicle and switch
off the engine. Clean the windscreen
and front bumper. When you next
start the engine, the warning light
and the message go out.
If this is not the case, this may arise from
another cause; contact an Approved
Dealer.
2.86
ACTIVE EMERGENCY BRAKING (6/8)
Active emergency braking
This function is an additional driving aid. This function is not under any circumstances intended to replace the due care
and attention of the driver, who should at all times be in control of the vehicle. The triggering of this function may be
delayed or prevented when the system detects clear signs of control of the vehicle by the driver (action on the steer-
ing wheel, pedals etc.).
The system cannot be activated:
- when the gearbox lever is in neutral or the clutch pedal has been depressed during approximately ten seconds;
- when the parking brake is activated;
- when the Electronic Stability Program (ESC) has started.
System servicing/repairs
- In the event of an impact, the radar and/or camera alignment may be changed and its operation may consequently be af-
fected. Deactivate the function and consult an authorised dealer.
- Any work in the area where the radar and/or camera is located (repairs, replacements, windscreen modifications, etc.) must
be carried out by a qualified professional.
Only an authorised dealer is qualified to service the system.
2.87
ACTIVE EMERGENCY BRAKING (7/8)
System disturbance
Some conditions can disturb or damage the operation of the system, such as:
- a complex environment (metal bridge, tunnel etc.);
- poor weather conditions (snow, hail, black ice etc.);
- poor visibility (night, fog etc.);
- poor contrast between the object (vehicle, pedestrian etc.) and the surrounding area (e.g. pedestrian dressed in white lo-
cated in a snowy area etc.) ;
- being dazzled (glaring sun, lights of vehicles travelling in the opposite direction etc.);
- windscreen obscured (by dirt, ice, snow, condensation etc.);
- ...
In these conditions, the system may not react, may warn the driver or may brake inadvertently.
Limitation of the system operation
- Each time the vehicle is started, the system carries out a calibration according to the vehicle surroundings and may be inac-
tive for a length of time between approximately two and five minutes;
- A vehicle travelling in the opposite direction will not trigger any alert or affect operation of the system;
- The radar and camera zones must be kept clean and free of any tampering in order to ensure the proper operation of the
system;
- the system may not respond to small vehicles such as motorbikes as effectively as to other vehicles;
- the system may not operate properly when the road surface is slippery (rain, snow, black ice, etc.);
- to ensure correct operation, the system needs to distinguish the complete outline of the pedestrian. So the system cannot
detect:
- pedestrians in the darkness or in poor lighting conditions;
- partially visible pedestrians:
- pedestrians less than approximately 80 cm tall;
- pedestrians carrying large objects;
- ...
In these conditions, the system may not react, may warn the driver or may brake inadvertently.
2.88
ACTIVE EMERGENCY BRAKING (8/8)
Deactivating the function
You must disable the function if:
- the brake lights are not functioning;
- the area of the camera has been damaged (e.g. on the inside or outside of the windscreen);
- the front of the vehicle was damaged (impact, scratch on the radar, etc.);
- the vehicle is being towed (breakdowns);
- the windscreen is cracked or distorted (do not carry out windscreen repairs in this area; have it changed by an approved
dealer);
- you are not driving on a paved road.
In the event of the system behaving abnormally, deactivate it and consult an authorised dealer.
Halting the function
You can halt the active braking function at any time by tapping the accelerator pedal or by turning the steering wheel in a col-
lision avoidance manoeuvre.
2.89
DETECTION OF ROAD SIGNS (1/4)
Note: make sure the windscreen is not
For vehicles equipped with a navigation
1
obscured (dirt, mud, snow, condensa-
system and if the vehicle is travelling in
tion etc.).
a country where the speed units differ
from those of the vehicle, the system
For vehicles which are equipped with it,
displays the speed limit sign in the unit
the system also uses information from
of the country, alongside the speed limit
the navigation system.
converted to the unit used by the vehi-
Once the speed limiter is activated, you
cle’s instrument panel.
can adjust the speed limiter indication
For countries where the speed limit is
displayed by the system.
reduced during rainy weather on some
If the limit speed is exceeded, the dis-
types of roads, on vehicles equipped
play panel is modified to warn the driver.
with a navigation system, the system
can modify the limited speed after a few
seconds of wiping the windscreen.
Special situations
The system detects speed limit signs
The system does not take into account
on the side of the road and displays the
exceptional speed limit measures, such
speed limit on the instrument panel.
as peak pollution days.
It mainly uses information taken from
the camera 1, attached to the wind-
screen behind the rear view mirror.
2.90
DETECTION OF ROAD SIGNS (2/4)
Vehicles not fitted with a multimedia
2
screen
- With the vehicle stopped, press the
switch 3 as many times as required
to reach the “Vehicle” tab;
- press the 4 or 5 control repeatedly to
reach the “Settings” menu. Press the
switch 6 OK;
- press the 4 or 5 control repeatedly to
reach the “DRIVING ASSIST” menu.
3
4
Press the switch 6 OK;
- press the 4 or 5 control repeatedly
to reach the “Speed alert” menu and
press the 6 OK switch;
6
5
- press the 6 OK switch to activate or
deactivate the function:
Activating/deactivating the
With the function activated, depend-
ing on local regulations, you can acti-
system
=
function activated
vate the “Risk area display” option. The
Vehicles fitted with a multimedia
system will notify you of the distance
<
function deactivated
screen 2
separating you from this zone, and
while you are travelling in the zone.
To activate or deactivate the function,
refer to the multimedia instructions.
Select “ON” or “OFF”.
2.91
DETECTION OF ROAD SIGNS (3/4)
If the speed limit is exceeded, the circle
7
8
around the panel flashes (7 warning
light) along with a sound signal to warn
the driver.
9
10
Operation
Varying the limit speed
If the speed limit notification differs from
Warning lights
the detected speed value, press and
The function displays the following
hold the following switches:
warning lights:
- 9 (RES/+) to increase the notification
7 Speed limit road signs
speed to the detected speed;
8 Additional road signs (start or end
- 10 (SET/-) to reduce the notification
of “No overtaking” zone, slip road
speed to the detected speed.
speed limit, speed in case of a cara-
van, speed limit with length of appli-
cation, etc.)
2.92
DETECTION OF ROAD SIGNS (4/4)
Operating faults
The system cannot detect the speed
limit if:
- the windscreen is not clean;
- the camera is blinded by the sun;
- there is insufficient visibility (night,
fog etc.) ;
- the signs are not legible (snow, etc.)
or are hidden (by another vehicle or
by trees);
- the information taken from the navi-
gation system is not up to date.
This function is an additional driving aid. This function is not under any
circumstances intended to replace the due care and attention of the
driver, who should at all times be in control of the vehicle.
The driver should always adapt their speed to the traffic conditions, re-
gardless of the system indications.
The system detects maximum speed limit signs and does not detect other signs
(e.g. entry/exit to/from urban areas).
The system may not detect all speed limit signs or may interpret them incorrectly.
The driver should not ignore signs that are not detected by the system and should,
as a priority, comply with the traffic signage and the highway code.
In the event of poor visibility (fog, snow, frost, etc.), it is possible that the system
may not indicate the correct speed to the driver.
The driver should always adapt their speed to the traffic conditions, regardless of
the system indications.
2.93
SPEED LIMITER (1/4)
Controls
1 Speed limiter On/Off switch.
2 Cruise control On/Off switch.
3 Switch to activate and decrease the
limit speed (SET/-).
4 Switch to activate and increase the
limit speed or to set the stored limit
5
speed (RES/+).
4
1
5 Speed limiter function standby (with
limited speed memory) (0).
3
2
The speed limiter function helps you
stay within the driving speed limit that
you choose, known as the limit speed.
You can link the speed limiter to
the “Road sign detection” function.
➥ 2.90.
2.94
SPEED LIMITER (2/4)
7
7
4
1
3
Driving
Switching on
To store the current speed, press the 4
switch (RES/+) or the 3 switch (SET/- ):
When a limit speed has been set but
Press switch 1. The 7 warning light ap-
the limit speed replaces the dashes
not yet reached, driving is similar to
pears in grey. The “Speed limiter ON”
and, depending on the vehicle, the 7
driving a vehicle without the speed lim-
message appears on the instrument
warning light appears in white.
iter function.
panel accompanied by dashes to indi-
The minimum stored speed is 19 mph
cate that the speed limiter function is in
Once you have reached the stored
(30 km/h).
operation, waiting to store a limit speed.
speed, no effort on the accelera-
tor pedal will allow you to exceed
the programmed speed except in an
emergency (refer to information on
“Exceeding the limit speed”).
2.95
SPEED LIMITER (3/4)
Exceeding the limit speed
Limited speed cannot be maintained
It is possible to exceed the limit speed
When driving down a steep gradient,
at any time. To do this: press the accel-
the system may not maintain the limit
erator pedal firmly and fully (beyond
speed: the limit speed flashes in red
the resistance point).
on the instrument panel and an audi-
While the speed is being exceeded, the
ble signal sounds at regular intervals to
speed limiter flashes red on the instru-
inform you of this situation.
ment panel. Then, release the accelera-
tor pedal: the speed limiter function will
4
return as soon as you reach a speed
lower than the memorised speed.
3
Varying the limit speed
The limit speed may be changed by
pressing repeatedly or holding down:
- switch 4 (RES/+) to increase speed;
- switch 3 (SET/-) to reduce speed.
If the speed limiter is not
available (after several at-
tempts to activate), contact
an approved dealer.
2.96
SPEED LIMITER (4/4)
7
7
5
4
1
3
2
Putting the function on
Switching off the function
standby
The speed limiter function is inter-
The speed limiter function is suspended
rupted:
when you press switch 5 (0). The limit
- when you press the 1 switch. In this
speed is stored and displayed in grey
case, the speed is no longer stored;
on the instrument panel.
- when you press the 2 switch. In this
case the cruise control is selected
Recalling the limit speed
and there is no stored speed.
If a speed has been stored, it can be re-
The warning light 7 disappears from
called by pressing the 4 switch.
the instrument panel to confirm that the
When the speed limiter is set to
function is no longer active.
standby, pressing the
3 switch
re-activates the function without
taking into account the memorised
speed: the speed at which the vehi-
cle is moving is taken into account.
2.97
CRUISE CONTROL (1/5)
Controls
1
Cruise control On/Off switch.
2
Switch to activate and decrease
cruising speed (SET/-).
3
Switch to activate and increase
cruising speed or to recall the mem-
orised cruising speed (RES/+).
4
4
Switch the function to standby (with
3
5
cruising speed saved) (0).
This function is an addi-
5
Speed limiter On/Off switch.
tional driving aid. The func-
tion does not take the place
2
1
of the driver.
Therefore, it can under no circum-
The cruise control function helps you to
stances replace the driver’s respon-
maintain your driving speed at a speed
sibility to respect speed limits and to
that you choose, called the cruising
be vigilant (the driver must always
speed.
be ready to brake).
This cruising speed may be set at any
Cruise control must not be used in
speed above 19 mph (30 km/h).
heavy traffic, on undulating or slip-
pery roads (black ice, aquaplan-
ing, gravel) and during bad weather
(fog, rain, side winds etc.).
There is a risk of accidents.
2.98
CRUISE CONTROL (2/5)
7
7
3
2
1
Switching on
Activating cruise control
Driving
Press switch 1.
While the vehicle is moving a steady
Once a cruising speed is registered
speed above approximately 19 mph
and the cruise control function is active,
The 7 warning light appears in grey.
(30 km/h), press the 2 (SET/-) switch
you may lift your foot off the accelera-
The “Cruise control ON” message ap-
or the 3 (RES/+) switch: the function
tor pedal.
pears on the instrument panel accom-
is activated and the current speed is
panied by dashes to indicate that the
taken into account.
cruise control function is in operation
The cruising speed replaces the
and waiting to memorise a cruising
dashes. Cruise control is confirmed
speed.
when the memorised speed and warn-
ing light appear in green 7.
If you try to activate the function below
19 mph (30 km/h), the message “Invalid
Please note that you must
Speed” will be displayed and the func-
keep your feet close to the
tion will remain inactive.
pedals in order to react in
an emergency.
2.99
CRUISE CONTROL (3/5)
Exceeding the cruising speed
The cruising speed may be exceeded
at any time by depressing the accelera-
tor pedal.
While it is being exceeded, the cruising
speed flashes in red on the instrument
panel. Then, release the accelerator
pedal: after a few seconds, the vehicle
will automatically return to its set cruis-
3
ing speed.
Cruising speed cannot be
maintained
2
When driving down a steep gradient,
the system may be unable to main-
Adjusting the cruising speed
tain the cruising speed: the memorised
speed will flash in red on the instrument
The cruising speed may be changed by
panel and an audible signal sounds at
pressing the following repeatedly:
regular intervals to inform you of this
- the 2 switch (SET/-) to reduce the
situation.
speed;
- the 3 switch (RES/+) to increase the
speed.
Note: press and hold one of the
switches to modify speed by succes-
sive increments.
If the cruise control is no
longer available (after sev-
eral attempts to activate
it), contact an Approved
Dealer.
2.100
CRUISE CONTROL (4/5)
7
7
4
3
2
Putting the function on
Returning to the cruising speed
NB: if the speed previously stored is
much higher than the current speed,
standby
If a speed is stored, it can be recalled,
the vehicle will accelerate more rapidly
once you are sure that the road condi-
The function is set to standby if you:
to reach this threshold.
tions are suitable (traffic, road surface,
- 4 switch (0);
weather conditions, etc.). Press the
When the cruise control is set to
- the brake pedal;
switch 3 (RES/+) if the vehicle speed is
standby, pressing switch 2 (SET/-) re-
above 19 mph (30 km/h).
activates the cruise control function
- the clutch pedal or shifting to neutral
without taking into account the stored
if the vehicle has an automatic gear-
When the speed is stored, cruise con-
speed: it is the speed at which the vehi-
box;
trol activation is confirmed by the dis-
cle is moving that is taken into account.
play in green of the cruising speed and,
- depending on the vehicle, the clutch
depending on the vehicle, the 7 warn-
pedal for a prolonged period or upon
ing light is displayed.
prolonged neutral position.
The cruising speed is stored and dis-
played in grey on the instrument panel.
2.101
CRUISE CONTROL (5/5)
7
7
5
1
Switching off the function
The warning light 7 disappears from
the instrument panel to confirm that the
The cruise control function is inter-
function is no longer active.
rupted:
- when you press the 1 switch. In this
case, the speed is no longer stored;
- when you press the 5 switch. In this
case the speed limiter is selected
and there is no stored speed.
Putting the cruise control
on standby or switching it
off does not cause a rapid
reduction in speed: you
must brake by depressing the brake
pedal.
2.102
ADAPTIVE CRUISE CONTROL STOP AND GO (1/13)
Based on information from a radar or
Note:
This function is an addi-
camera, the Stop and Go adaptive
- the driver must observe the maxi-
tional driving aid. The func-
cruise control function gives you the
mum speed limit and safe distances
tion does not take the place
option of maintaining a selected speed,
in the country where they are driving;
of the driver.
known as the cruising speed, while
keeping a safe distance from the vehi-
- the adaptive cruise control can brake
Therefore, it can under no circum-
cle in front in the same lane.
the vehicle up to a third of the brak-
stances replace the driver’s respon-
ing capacity. Depending on the situ-
sibility to respect speed limits and
If the vehicle in front stops, the Stop
ation, the driver may need to brake
safe distances and to be vigilant
and Go adaptive cruise control may
harder.
(the driver must always be ready to
brake your vehicle to a complete stop
brake).
before setting off again.
The driver must always be in con-
The system controls acceleration and
trol of the vehicle. The driver must
deceleration of your vehicle using the
always adapt their speed according
engine and braking system.
to the surroundings and traffic con-
The system’s maximum range is ap-
ditions. The Stop and Go adaptive
proximately 150 m. This may vary ac-
cruise control must only be used on
cording to the road conditions (ground
a motorway (or multi-lane road with
relief, weather conditions etc.).
a central barrier). The cruise control
must not be used in heavy traffic, on
The Stop and Go adaptive cruise con-
winding or slippery roads (black ice,
trol function can be activated from 0 to
aquaplaning, gravel) or during bad
105 mph (0 to 170 km/h) according to
weather (fog, rain, side winds etc.).
conditions on the road (traffic, weather
There is a risk of accidents.
etc.).
It is represented by the symbol
The Stop and Go adaptive cruise
control does not trigger an emer-
gency stop and its braking capabil-
ity is limited.
2.103















Content      ..     8      9      10      11     ..
