Renault Alaskan (2018 year). Manual in english - page 3





WARNING
Never let children ride unrestrained or extend
their hands or face out of the window. Do not
attempt to hold them in your lap or arms.
Some examples of dangerous riding positions
are shown in the illustrations.
Children may be severely injured or killed
when the air bags inflate if they are not prop-
erly restrained.
SSS0099Z
Never install a rear-facing child restraint sys-
SSS0059AZ
tem in the front seat. An inflating supplemen-
tal front-impact air bag could seriously injure
or kill your child. (See “Child restraints” earlier
in this section.)
SSS0100Z
SSS0140Z
1-32
Safety — seats, seat belts and supplemental restraint system
The seat belts and the supplemental side-im-
Pre-tensioner seat belt system
pact air bags and supplemental curtain side-
(where fitted)
impact air bags are most effective when you
The pre-tensioner seat belt system may activate
are sitting well back and upright in the seat.
with the supplemental air bag system in certain
The supplemental side-impact air bags and
types of collisions. Working with the front seat belt
supplemental curtain side-impact air bags in-
retractors and anchors, it helps tighten the seat belt
flate with great force. If you and your passen-
the instant the vehicle becomes involved in certain
gers are unrestrained, leaning forward, sitting
types of collisions, helping to restrain front seat oc-
sideways, or out of position in any way, you
cupants. (See “Seat belts” earlier in this section.)
and your passengers are at greater risk of in-
jury or death in an accident.
Air bag warning labels
SSS0159Z
Do not allow anyone to place their hands, legs
or face near the supplemental side-impact air
bags and supplemental curtain side-impact
air bags located on the sides of the seatback
of the front seats or near the side roof rails. Do
not allow anyone sitting in the front seats or
rear outboard seats to extend their hands out
of the windows or lean against the doors.
Some examples of dangerous riding positions
are shown in the illustrations.
NPA1155
When sitting in the rear seats, do not hold onto
the seatback of the front seats. If the supple-
SSS0162Z
mental side-impact air bags and supplemen-
SRS air bag warning label: The warning label is
tal curtain side-impact air bags inflate, you
located on the surface of the front passenger
may be seriously injured. Be especially careful
sun visor.
WARNING
with children, who should always be properly
SRS front passenger air bag warning label: The
The supplemental
side-impact
air bags
restrained.
warning label is located on the outer side of
(where fitted) and supplemental curtain side-
Do not use seat covers on the front seatbacks.
the instrument panel (passenger side).
impact air bags (where fitted) ordinarily will
They may interfere with the supplemental
not inflate in the event of a front impact, rear
SRS side air bag warning label: The warning
side-impact air bag inflations.
impact, rollover, or lower severity side colli-
label is located on the side of the passenger
Do not attach the key with heavy objects, hard
side centre pillar. Tags are also sewn into the
sion. Always wear the seat belts to help reduce
objects or objects with sharp edges. This may
front seat covers.
the risk or severity of injury in accidents.
cause injury if the supplemental knee air bag
inflates.
Safety — seats, seat belts and supplemental restraint system
1-33
SRS front-impact passenger air bag:
SRS air bag warning light
Under these conditions, the air bag and/or pre-ten-
sioner seat belt system may not operate properly.
The warning label is located on the sun visor.
They must be checked and repaired. Contact an ap-
“NEVER use a rearward facing child restraint on a
proved dealer or qualified workshop immediately.
seat protected by an ACTIVE AIR BAG in front of it,
DEATH or SERIOUS INJURY to the CHILD can oc-
cur.”
The BACK SEAT is the SAFEST place for children
aged 12 and under. Always use seat belts and child
restraints. For maximum safety protection in all
types of crashes, you must always wear your
safety belt. Do not sit or lean unnecessarily close
SPA1097Z
to the air bag. Do not place any objects over the
air bag or between the air bag and yourself. If the
air bag warning light stays on or is flashing when
The supplemental air bag warning light, displaying
the ignition is placed in the ON position, go to an
in the instrument panel, monitors the circuits
approved dealer or qualified workshop. Air bags
for the air bag systems, pre-tensioner seat belt sys-
can only be removed or disposed of by an ap-
tem (where fitted) and all related wiring.
proved dealer or qualified workshop.
When the ignition switch is in the “ON” position, the
Be sure to read the “AIR BAG LABEL” description at
SRS air bag warning light illuminates for about 7
the end of this manual.
seconds and then turns off. This indicates that the
SRS air bag systems are operational.
In vehicles equipped with a front-impact passenger
air bag system, use a rear-facing child restraint sys-
Have the air bag systems and/or pre-tensioner seat
tem only on the rear seats.
belt systems serviced at the nearest approved
When installing a child restraint system in your ve-
dealer or qualified workshop if any of the following
hicle, always follow the child restraint system manu-
conditions occur:
facturer’s instructions for installation. For additional
The SRS air bag warning light remains on after
information, see “Child restraints” earlier in this sec-
approximately 7 seconds.
tion.
The SRS air bag warning light flashes intermit-
tently.
The SRS air bag warning light does not illumi-
nate at all.
1-34
Safety — seats, seat belts and supplemental restraint system
WARNING
Do not place any objects on the steering wheel
pad, on the instrument panel, under the steer-
ing column and near the front door finishers
and the front seats. Do not place any objects
between any occupants and the steering
wheel pad, on the instrument panel, and near
the front door finishers and the front seats.
Such objects may become dangerous projec-
tiles and cause injury if a supplemental air bag
inflates.
Immediately after inflation, several supple-
mental air bag system components will be hot.
Do not touch them: you may severely burn
yourself.
No unauthorised changes should be made to
any components or wiring of the supplemen-
tal air bag systems. This is to prevent acciden-
tal inflation of the supplemental air bags or
damage to the supplemental air bag systems.
Do not make unauthorised changes to your
vehicle’s electrical system, suspension sys-
tem, front end structure, and side panels. This
NPA1527
could affect proper operation of the supple-
mental air bag systems.
SUPPLEMENTAL AIR BAG SYSTEMS
5.
Supplemental curtain side-impact air bag
Tampering with the supplemental air bag sys-
modules (where fitted)
1.
Crush zone sensor
tems may result in serious personal injury.
6.
Air bag Control Unit (ACU)
Tampering includes changes to the steering
2.
Supplemental driver's knee air bag module
wheel and the instrument panel by placing
(where fitted)
7.
Satellite sensors (where fitted)
materials over the steering wheel pad and
3.
Supplemental front air bag modules
8.
Seat belt pre-tensioner retractors (where fit-
above, around or on the instrument panel or
ted)
4.
Supplemental curtain side-impact air bag
by installing additional trim materials around
inflators (where fitted)
9.
Supplemental side-impact air bag modules
the supplemental air bag systems.
(where fitted)
Safety — seats, seat belts and supplemental restraint system
1-35
Work on and around the supplemental air bag
frontal collisions. Vehicle damage (or lack of it) is not
systems should be done by an approved
always an indication of proper supplemental front-
dealer or qualified workshop. The SRS wiring
impact air bag system operation.
should not be modified or disconnected. Un-
authorised electrical test equipment and
WARNING
probing devices should not be used on the
Never install a rear-facing child restraint system
supplemental air bag systems.
on the front passenger seat without first deacti-
The SRS wiring harness connectors are yellow
vating the passenger air bag with the front pas-
for easy identification.
senger air bag switch (where fitted), see “Front
passenger air bag switch (where fitted)” later in
Never install a rear-facing child restraint sys-
tem on the front passenger seat without first
this section. In a frontal collision, supplemental
JVR0264XZ
deactivating the passenger air bag with the
front-impact air bags inflate with great force. An
front passenger air bag switch. In a frontal col-
inflating supplemental front-impact air bag could
WARNING
lision, supplemental front-impact air bags in-
seriously injure or kill your child.
flate with great force. An inflating supplemen-
Since your vehicle is equipped with a front
Front passenger air bag status light
tal front-impact air bag could seriously injure
passenger air bag, it is not permitted to install
(where fitted):
or kill your child.
a rearward facing child restraint on the front
passenger seat unless the front passenger air
When the air bags inflate, a fairly loud noise may be
bag has been deactivated first.
heard, followed by the release of smoke. This smoke
is not harmful and does not indicate a fire. Care
Do not fit a rearward facing child seat on the
should be taken not to inhale it, as it may cause irri-
front passenger seat if the air bag activation/
tation and choking. Those with a history of a breath-
deactivation system (where fitted) is malfunc-
ing condition should get fresh air promptly.
tioning. Your vehicle must immediately be
taken to an approved dealer or qualified work-
Supplemental front-impact air bag
shop in such a situation.
system
The front passenger air bag status lights
and
The driver’s supplemental front-impact air bag is
NPA1531
are located on the instrument panel between
located at the centre of the steering wheel. The pas-
the centre vents.
senger’s supplemental front-impact air bag is lo-
When the ignition switch is placed in the ON posi-
cated at the instrument panel above the glove box.
tion, the front passenger air bag status ON and OFF
The supplemental front-impact air bag system is
lights illuminate and then turn off or remain on de-
designed to inflate in higher severity frontal colli-
pending on the front passenger air bag status.
sions, although it may inflate if the forces in another
type of collision are similar to those of a higher se-
verity frontal impact. It may not inflate in certain
1-36
Safety — seats, seat belts and supplemental restraint system
When the ignition switch is placed in the ON po-
4. Place the ignition switch in the ON position. The
sition and the front passenger air bag is active,
front passenger air bag status ON light
will
both the front passenger air bag status OFF light
illuminate, and after a period of time, will then
, and the Supplemental Restraint System
turn off.
(SRS) air bag warning light
in the combina-
Supplemental driver's knee air bag
tion meter will turn off after about 7 seconds.
system (where fitted)
The front passenger air bag status ON light
The supplemental driver's knee air bag is located
will illuminate and then turn off after a
under the steering column.
period of time when the front passenger air bag
switch is in the ON position.
The supplemental driver's knee air bag system is
NPA1296
designed to inflate in higher severity frontal colli-
When the ignition switch is placed in the ON po-
sions, although it may inflate if the forces in another
sition and the front passenger air bag is inactive,
type of collision are similar to those of a higher se-
both the front passenger air bag status ON light
A Air bag switch (where fitted)
verity impact. It may not inflate in certain collisions.
, and the Supplemental Restraint System
B Left Hand Drive models
(SRS) air bag warning light
in the combina-
Vehicle damage (or lack of it) is not always an indi-
tion meter will turn off after about 7 seconds.
C Right Hand Drive models
cation of proper supplemental driver's knee air bag
To turn off the front passenger air bag:
system operation.
The front passenger air bag status OFF light
will illuminate and remain on as long as the
1. Place the ignition switch in the OFF position.
Supplemental side-impact air bag
front passenger air bag switch is in the OFF po-
2. Open the glove box and insert the key into the
system (where fitted)
sition.
front passenger air bag switch. For Remote Con-
If the front passenger air bag status light operates
trol Key equipped models, see “Keys” in the “3. Pre-
in a way other than described above, the front pas-
driving checks and adjustments” section for me-
senger air bag may not function properly. Have the
chanical key usage.
system checked, and if necessary repaired, by an
3. Push and turn the key to the <OFF> position.
approved dealer or qualified workshop promptly.
4. Place the ignition switch in the ON position. The
Front passenger air bag switch (where fitted):
front passenger air bag status OFF light
will
The front passenger air bag can be turned off with
illuminate and remain on.
the front passenger air bag switch
A located inside
To turn on the front passenger air bag:
the glove box.
1. Place the ignition switch in the OFF position.
SSS1092Z
2. Open the glove box and insert the key into the
front passenger air bag switch.
The supplemental side-impact air bag is located at
the outside of the front seats’ seatbacks.
3. Push and turn the key to the <ON> position.
Safety — seats, seat belts and supplemental restraint system
1-37
The supplemental side-impact air bag system is de-
No unauthorised changes should be made to
REPAIR AND REPLACEMENT
signed to inflate in higher severity side collisions,
any components or wiring of the pre-
PROCEDURE
although it may inflate if the forces in another type
tensioner seat belt system. This is to prevent
of collision are similar to those of a higher severity
accidental activation of the pre-tensioner seat
WARNING
side impact. It may not inflate in certain side colli-
belt or damage to the pre-tensioner seat belt
sions. Vehicle damage (or lack of it) is not always an
system.
Once the supplemental front-impact air bags
indication of proper supplemental side-impact air
have been inflated, the air bag modules will
Work around or on the pre-tensioner seat belt
bag system operation.
not function and must be replaced. The air bag
system should be done by an approved dealer
modules must be replaced by an approved
Supplemental curtain side-impact air
or qualified workshop. The SRS wiring should
dealer or qualified workshop. The inflated air
not be modified or disconnected. Unautho-
bag system (where fitted)
bag modules cannot be repaired.
rised electrical test equipment and probing
The supplemental curtain side-impact air bag is lo-
devices should not be used on the pre-ten-
The air bag systems should be inspected by
cated at the roof rails.
sioner seat belt system.
an approved dealer or qualified workshop if
The supplemental curtain side-impact air bag sys-
there is any damage to the vehicle.
If you need to dispose of the pre-tensioner
tem is designed to inflate in higher severity side col-
seat belt system, or scrap the vehicle, contact
If you need to dispose of the SRS or scrap the
lisions, although it may inflate if the forces in an-
an approved dealer or qualified workshop.
vehicle, contact an approved dealer or quali-
other type of collision are similar to those of a higher
Correct pre-tensioner disposal procedures are
fied workshop. Correct disposal procedures
severity side impact. It may not inflate in certain side
set forth in the appropriate maintenance ser-
are set forth in the appropriate maintenance
collisions. Vehicle damage (or lack of it) is not al-
vice manual. Incorrect disposal procedures
service manual. Incorrect disposal procedures
ways an indication of proper supplemental curtain
could cause personal injury.
could cause personal injury.
side-impact air bag system operation.
The pre-tensioner is encased with the front seat
The supplemental front-impact air bags and pre-
PRE-TENSIONER SEAT BELT SYSTEM
belt’s retractor and anchor. These seat belts are
tensioner seat belts (where fitted) are designed to
(where fitted)
used the same as conventional seat belts.
activate on a one-time-only basis. As a reminder,
unless the SRS air bag warning light is damaged,
When the pre-tensioner seat belt activates, a fairly
the SRS air bag warning light remains illuminated
WARNING
loud noise may be heard, followed by the release of
after inflation has occurred. The repair and replace-
smoke. This smoke is not harmful and does not in-
The pre-tensioner seat belt cannot be reused
ment of the SRS should be done only by an ap-
dicate a fire. Care should be taken not to inhale it, as
after activation. It must be replaced together
proved dealer or qualified workshop.
it may cause irritation and choking. Those with a
with the retractor and buckle as a unit.
history of a breathing condition should get fresh air
When maintenance work is required on the vehicle,
If the vehicle becomes involved in a collision
promptly.
information about the air bags, pre-tensioner seat
but the pre-tensioner is not activated, be sure
belts and related parts should be pointed out to the
to have the pre-tensioner system checked
person performing the maintenance. The ignition
and, if necessary, replaced by an approved
switch should always be in the “LOCK” position
dealer or qualified workshop.
when working under the bonnet or inside the ve-
hicle.
1-38
Safety — seats, seat belts and supplemental restraint system
2 Instruments and controls
Meters and gauges
2-2
Defogger switch (where fitted)
2-29
Speedometer and Fuel gauge
2-2
Headlight cleaner (where fitted)
2-30
Tachometer and Engine coolant temperature
Headlight cleaner switch (where fitted)
2-30
gauge
2-3
Horn
2-31
Instrument brightness control
2-4
Windows
2-31
Warning lights, indicator lights and audible
Manual windows (where fitted)
2-31
reminders
2-5
Power windows (where fitted)
2-31
Checking lights
2-6
Power outlets
2-33
Warning lights
2-6
Storage
2-34
Indicator lights
2-10
Glove box
2-34
Audible reminders
2-12
Console box
2-35
Vehicle information display
2-12
Sunglasses holder
2-34
How to use the Vehicle Information Display
2-13
Console side pockets
2-35
Settings
2-13
Cup holders (where fitted)
2-35
Trip computer
2-17
Roof rails (where fitted)
2-35
Indicators for operation
2-21
Card holder (where fitted)
2-36
Oil control system (where fitted)
2-24
Sun visors
2-36
Clock and outside air temperature (where
Sunroof (where fitted)
2-37
fitted)
2-25
Automatic sunroof
2-37
Headlight and turn signal switch
2-26
Interior lights
2-38
Headlight switch
2-26
Interior light switch (where fitted)
2-38
Headlight aiming control (where fitted)
2-27
Console light (where fitted)
2-38
Battery saver system (where fitted)
2-27
Map lights
2-38
Turn signal switch
2-27
Map light control switch (where fitted)
2-38
Fog light switch (where fitted)
2-28
Room light (where fitted)
2-39
Front fog lights (where fitted)
2-28
Rear personal light (where fitted)
2-39
Rear fog light (where fitted)
2-28
Vanity mirror lights (where fitted)
2-39
Wiper and washer switch
2-29
Battery saver system
2-40
Windscreen wiper and washer switch
2-29
METERS AND GAUGES
NOTE
Fuel gauge
Odometer
For an overview see “Meters and gauges” in the
“0. Illustrated table of contents” section and see
“Instrument panel” in the “0. Illustrated table of
contents” section.
The needle indicators may move slightly after the
ignition switch is placed in the OFF position. This
is not a malfunction.
SPEEDOMETER AND FUEL GAUGE
Speedometer
JVI0602XZ
JVI1041XZ
The fuel gauge indicates the approximate fuel level
in the tank when the ignition switch is in the ON
position.
The gauge may move slightly during braking, turn-
ing, accelerating, or going up and down hills due to
movement of fuel in the tank.
The low fuel warning appears on the vehicle infor-
mation display when the fuel level in the tank is get-
NIC2704
ting low. Refuel as soon as it is convenient, prefer-
ably before the gauge reads the empty (0) position.
NIC3094
The speedometer indicates the vehicle speed.
The arrow,
, indicates that the fuel filler lid is
Left Hand Drive (LHD) model
located on the left side of the vehicle.
Distance to empty (dte — km or mile):
CAUTION
The distance to empty (dte)
provides you with an
Refuel before the gauge reads the empty (0) posi-
estimation of the distance that can be driven be-
tion.
fore refuelling. The dte is constantly being calcu-
There is a small reserve of fuel in the tank when the
lated, based on the amount of fuel in the fuel tank
fuel gauge reads the empty (0) position.
and the actual fuel consumption.
The display is updated every 30 seconds.
2-2
Instruments and controls
The dte mode includes a low range warning fea-
Odometer (models without colour
TACHOMETER AND ENGINE
ture. If the fuel level is low, the warning is displayed
display)
COOLANT TEMPERATURE GAUGE
on the screen.
Odometer/twin trip odometer:
When the fuel level drops even lower, the dte display
The odometer/twin trip odometer is displayed
will change to “———”.
when the ignition switch is in the ON position.
If the amount of fuel added is small, the distance
The odometer displays the total distance the ve-
to empty shown just before the ignition switch
hicle has been driven.
is placed in the “OFF” position may continue to
be displayed.
The twin trip odometer displays the distance of
individual trips.
When driving uphill or rounding curves, the fuel
in the tank shifts, which may momentarily
Changing trip odometer display:
change the display.
Push the trip odometer reset switch to change
NIC2705
the display as follows:
Odometer/Twin trip odometer:
The odometer/twin trip odometer is displayed in
TRIP A ! TRIP B ! Trip computer mode ! TRIP A
The tachometer indicates the engine speed in revo-
the vehicle information display when the ignition
For trip computer information, see “Trip computer”
lutions per minute (rpm). Do not rev the engine into
switch is in the ON position.
later in this section.
the red zone j.
The odometer displays the total distance the ve-
Resetting trip odometer:
The red zone varies with models.
hicle has been driven.
While TRIP A or TRIP B is displayed push and hold
The twin trip odometer displays the distance of
the trip odometer reset switch for approximately
Engine coolant temperature gauge
individual trips.
1 second to reset the trip odometer to zero.
The engine coolant temperature gauge indicates
Changing twin trip odometer display:
For further information, see “Trip computer” later in
the engine coolant temperature.
Push the <TRIP RESET> switch (located on the
this section.
The engine coolant temperature is normal when the
instrument panel) to change the display as follows:
gauge needle points within the zone shown in
the illustration.
TRIP A ! TRIP B ! ODOMETER ! TRIP A
The engine coolant temperature will vary with the
Resetting twin trip odometer:
outside air temperature and driving conditions.
Push and hold the <TRIP RESET> switch for more
than 1 second to reset the trip odometer to zero.
Instruments and controls
2-3
INSTRUMENT BRIGHTNESS
Push the + side of the switch to brighten the meter
panel lights. The bar moves to the + side.
CONTROL
Push the - side of the switch to dim the lights. The
Instrument brightness control button
bar moves to the − side.
(models with colour display)
When the brightness level reaches the maximum or
minimum, a beep will sound.
The vehicle information display returns to the nor-
mal display when the instrument brightness con-
trol switch is not operated for more than 5 seconds.
NIC3095
Left Hand Drive (LHD) model
JVI0661MZ
The instrument brightness control switch can be
operated when the ignition switch is in the ON posi-
tion. When the switch is operated, the vehicle infor-
mation display switches to the brightness adjust-
ment mode.
2-4
Instruments and controls
WARNING LIGHTS, INDICATOR LIGHTS AND AUDIBLE REMINDERS
Anti-lock Braking System (ABS) warn-
Four-Wheel Drive (4WD) warning light
ing light*
(4WD model)
Front passenger air bag status light
Active Emergency Braking system
Low fuel warning light
warning light*
Automatic Transmission (AT) check
Low washer fluid warning light*
Glow plug indicator light*
warning light (AT model)
Automatic Transmission (AT) oil
Malfunction warning light (red)*
High beam indicator light
temperature warning light (AT model)
Automatic Transmission (AT) park
Hill descent control system on indicator
Master warning light*
warning light (AT model)
light*
Brake warning light
Seat belt warning light*
Malfunction Indicator Light (MIL)
Supplemental Restraint System (SRS)
Charge warning light
Rear fog light indicator light*
air bag warning light*
Diesel Particulate Filter (DPF) warning
Water-in-fuel-filter warning light*
Security indicator light*
light*
Door open warning light
Differential lock indicator light*
Small light indicator light*
Electronic Stability Programme (ESP)
Dipped beam indicator light
Trailer direction indicator light*
warning light*
Electronic Stability Programme (ESP)
Turn signal indicator/hazard warning
Engine oil pressure warning light
off indicator light*
lights
Engine temperature warning light (red
Front fog light indicator light*
*: where fitted
or blue)*
Instruments and controls
2-5
CHECKING LIGHTS
If an ABS malfunction occurs, the anti-lock function
Automatic Transmission (AT)
is turned off. The brake system then operates nor-
check warning light (AT model)
With all doors closed, apply the parking brake, fas-
mally, but without anti-lock assistance. (See “Anti-
ten the seat belts and place the ignition switch in
When the ignition switch is in the ON position, the
lock Braking System (ABS)” in the “5. Starting and
the ON position without starting the engine. The
Automatic Transmission (AT) check warning light il-
driving” section.)
following lights (where fitted) will come on:
,
luminates and then turns off. This indicates that the
,
,
,
While the differential lock
(where fitted) is
AT is operational.
engaged, the ABS warning light illuminates. This
The following lights (where fitted) will come on
If the AT check warning light illuminates while the
indicates that the anti-lock function is not fully
briefly and then go off:
,
,
,
,
engine is running, or while driving, it may indicate
operating. (See “Rear differential locking system
that the AT is not functioning properly and may
,
,
,
,
,
,
,
(red
(where fitted)” in the “5. Starting and driving” section
need servicing. Have the system checked, and if
and blue)
for the rear differential lock function.)
necessary repaired, by an approved dealer or quali-
If any light does not come on, or operates in a way
Active Emergency Braking
fied workshop promptly.
other than described it may indicate a burned-out
system warning light
bulb and/or a system malfunction. Have the system
Automatic Transmission (AT) oil
(where fitted)
checked, and if necessary repaired, by an approved
temperature warning light (AT
dealer or qualified workshop promptly.
This light illuminates when the Active Emergency
model)
Braking system is set to OFF on the lower display.
Models with colour display:
This light illuminates when the Automatic Transmis-
Some indicators and warnings are also displayed
If the light illuminates when the Active Emergency
sion (AT) oil temperature is too high. If the light illu-
on the vehicle information display between the
Braking system is ON, it may indicate that the sys-
minates while driving, reduce the vehicle speed as
speedometer and tachometer. (See “Indicators for
tem is unavailable. See “Active Emergency Braking
soon as safely possible until the light turns off.
system (where fitted)” in the “5. Starting and driving”
operation” later in this section.)
CAUTION
section for more details.
WARNING LIGHTS
Continued vehicle operation when the AT oil tem-
Disabling the ESP system with the Electronic Stabil-
perature warning light is on may damage the AT.
Anti-lock Braking System (ABS)
ity Programme (ESP) OFF switch causes the Active
Emergency Braking system to become unavailable.
Automatic Transmission (AT)
warning light (where fitted)
This is not a malfunction.
park warning light (AT model)
When the ignition switch is in the ON position, the
Anti-lock Braking System (ABS) warning light illumi-
For models without colour display:
This light indicates that the Automatic Transmis-
nates and then turns off. This indicates the ABS is
The warning light blinks when the Active
sion (AT) parking function is not engaged. If the
operational.
Emergency Braking system is operating.
transfer control is not secured in any driving posi-
tion while the AT shift lever is in the P (Park) position,
If the ABS warning light illuminates while the engine
the transmission will disengage and the wheels will
is running, or while driving, it may indicate the ABS
not lock.
is not functioning properly. Have the system
checked by an approved dealer or qualified work-
shop promptly.
2-6
Instruments and controls
For 4WD model: If the ATP warning light illumi-
The brake warning light indicates the parking brake
light illuminate, it may indicate the ABS is not func-
nates with the shift lever in the P (Park) position,
system operation, a low brake fluid level of the brake
tioning properly. Have the brake system checked,
shift the Four-Wheel Drive (4WD) mode switch to
system and an Anti-lock Braking System (ABS) mal-
and if necessary repaired, by an approved dealer or
the 2WD, 4H or 4LO position again with the shift
function.
qualified workshop promptly. (See “Brake system” in
lever in the N (Neutral) position. (See “4WD mode
the “5. Starting and driving” section.)
Parking brake warning indicator:
switch operation” in the “5. Starting and driving” sec-
When the ignition switch is placed in the ON posi-
Charge warning light
tion.)
tion, the brake warning light illuminates. When the
engine is started and the parking brake is released,
When the ignition switch is in the ON position, the
WARNING
the brake warning light turns off.
charge warning light illuminates. After starting the
If the 4WD mode indicator (see “Four-Wheel Drive
engine, the charge warning light turns off. This indi-
If the parking brake is not fully released, the brake
(4WD) warning light (4WD model)” later in this sec-
cates that the charging system is operational.
warning light remains on. Be sure that the brake
tion) is OFF or the ATP warning light is ON, this
warning light has turned off before driving. (See
If the charge warning light illuminates while the en-
indicates that the automatic transmission P
“Parking brake” in the “3. Pre-driving checks and
gine is running, or while driving, it may indicate that
(Park) position will not function and could result
adjustments” section.)
the charging system is not functioning properly and
in the vehicle moving unexpectedly, causing seri-
may need servicing.
ous personal injury or property damage. Always
Low brake fluid warning indicator:
When the charge warning light illuminates while
set the parking brake.
If the brake warning light illuminates while the en-
driving, stop the vehicle safely as soon as possible.
gine is running, or while driving, and the parking
Brake warning light
Stop the engine and check the alternator belt. If the
brake is released, it may indicate the brake fluid level
alternator belt is loose, broken or missing, contact
is low.
an approved dealer or qualified workshop promptly.
WARNING
When the brake warning light illuminates while driv-
(See
“Drive belt” in the
“8. Maintenance and
ing, stop the vehicle safely as soon as possible. Stop
If the brake fluid level is below the minimum
do-it-yourself” section.)
mark on the brake fluid reservoir, do not drive
the engine and check the brake fluid level. If the
If the alternator belt appears to be functioning cor-
the vehicle until the brake system has been
brake fluid level is at the minimum mark, add brake
rectly but the charge warning light remains illumi-
checked by an approved dealer or qualified
fluid as necessary. (See “Brake fluid” in the “8. Main-
nated, have the charging system checked by an ap-
workshop.
tenance and do-it-yourself” section.)
proved dealer or qualified workshop promptly.
If the brake fluid level is sufficient, have the brake
Even if you judge it to be safe, have your ve-
CAUTION
hicle towed because driving it could be dan-
system checked by an approved dealer or qualified
workshop promptly.
Do not continue driving if the alternator belt is
gerous.
loose, broken or missing.
Depressing the brake pedal without the en-
Anti-lock Braking System (ABS) warning
indicator (where fitted):
gine running and/or with a low brake fluid
level could increase the stopping distance and
When the parking brake is released and the brake
require greater pedal travel distance and ef-
fluid level is sufficient, if both the brake warning light
fort.
and the Anti-lock Braking System (ABS) warning
Instruments and controls
2-7
Diesel Particulate Filter (DPF)
When the warning light blinks while driving, the driv-
“Checking engine oil level” in the “8. Mainte-
warning light (where fitted)
ing condition is slippery and the vehicle’s traction
nance and do-it-yourself” section.)
limit is about to be exceeded.
When the DPF warning light illuminates, it indicates
Engine temperature warning
that particulate matter is accumulated to the speci-
If the ESP warning light illuminates while the engine
light (red/blue) (where fitted)
fied amount of the limit in the filter and the filter
is running or while driving, it may indicate that the
ESP system is not functioning properly and may
High temperature indicator light (red):
needs to regenerate. For filter regeneration details,
see “Diesel Particulate Filter (DPF) (where fitted)” in
need servicing. Have the system checked, and if
The red warning light comes on when the engine
the “5. Starting and driving” section.
necessary repaired, by an approved dealer or quali-
overheats.
fied workshop promptly. If a malfunction occurs, the
CAUTION
ESP function is turned off, but the vehicle is still driv-
WARNING
If you continue driving with the DPF warning light
able. (See “Electronic Stability Programme (ESP) sys-
If the high temperature warning light illuminates
on without performing the filter regeneration,
tem (where fitted)” in the “5. Starting and driving”
while the engine is running, it may indicate the
this will lead to particulate matter overload in the
section.)
engine temperature is extremely high. Stop the
filter.
Engine oil pressure warning
vehicle safely as soon as possible. If the vehicle is
If this occurs, then the Malfunction Indicator Light
light
overheated, continuing vehicle operation may se-
(MIL) will turn on. The performance of the engine
riously damage the engine.
might be limited to protect the DPF system. See
When the ignition switch is in the ON position, the
an approved dealer or qualified workshop to per-
engine oil pressure warning light illuminates. After
If the engine coolant temperature warning
starting the engine, the engine oil pressure warning
light (red) comes on while driving, stop the ve-
form the service regeneration.
light turns off. This indicates that the oil pressure
hicle as soon as possible and contact an ap-
Door open warning light
sensors in the engine are operational.
proved dealer or qualified workshop.
If the engine oil pressure warning light illuminates
When towing a trailer or driving uphill, reduce
When the ignition switch is in the ON position, the
or blinks while the engine is running, it may indicate
the vehicle speed as soon as safely possible to
door open warning light illuminates if any of the
that the engine oil pressure is low.
decrease the engine coolant temperature.
doors are open or not closed securely.
Stop the vehicle safely as soon as possible. Stop the
If the engine overheats, continued operation
Electronic Stability Programme
of the vehicle may seriously damage the en-
engine immediately and call an approved dealer or
(ESP) warning light
gine. See “If your vehicle overheats” in the “6. In
qualified workshop.
(where fitted)
case of emergency” section for immediate re-
CAUTION
quired action.
When the ignition switch is in the ON position, the
Running the engine with the engine oil pres-
Electronic Stability Programme (ESP) warning light
Low temperature indicator light (blue):
sure warning light illuminated could cause se-
illuminates and then turns off.
rious damage to the engine.
When the ignition switch is placed in the ON posi-
The warning light blinks when the ESP system is
tion, the engine temperature warning light (blue)
The engine oil pressure warning light is not
operating.
comes on. After a few seconds, it should go out and
designed to indicate a low oil level. The oil level
remain off while the engine is running.
should be checked using the dipstick. (See
2-8
Instruments and controls
Four-Wheel Drive (4WD)
Low fuel warning light
CAUTION
warning light (4WD model)
Continuing vehicle operation without proper ser-
The low fuel warning light illuminates when the fuel
vicing of the engine control system could lead to
When the ignition switch is in the ON position, the
level in the tank is getting low. Refuel as soon as it is
poor driveability, reduced fuel economy, and
Four-Wheel Drive (4WD) warning light illuminates.
convenient, preferably before the fuel gauge
damage to the engine control system, which may
After starting the engine, the 4WD warning light
reaches the empty (0) position.
affect the vehicle’s warranty coverage.
turns off.
There will be a small reserve of fuel remaining in
If the 4WD system malfunctions or the revolution or
Master warning light
the tank when the fuel gauge reaches the empty
radius of the front and the rear wheel differs, the
(where fitted)
(0) position.
warning light will either remain illuminated or blink.
When the ignition switch is in the ON position, the
(See “Four-Wheel Drive (4WD) (where fitted)” in the
Low washer fluid warning light
master warning light illuminates if any of the fol-
“5. Starting and driving” section.)
(where fitted)
lowing are displayed on the vehicle information dis-
CAUTION
The low washer fluid warning light illuminates when
play.
If the 4WD warning light illuminates or blinks
the washer fluid in the reservoir is at a low level. Add
No Key Detected warning (where fitted)
while driving, reduce the vehicle speed and
washer fluid as necessary. (See “Window washer
Shift to Park warning (Automatic Transmission
have your vehicle checked by an approved
fluid” in the “8. Maintenance and do-it-yourself” sec-
(AT) models)
dealer or qualified workshop as soon as pos-
tion.)
sible.
Key ID Incorrect warning (where fitted)
Malfunction warning light (red)
Release Parking Brake warning
If the Four-Wheel Drive (4WD) warning light
(where fitted)
turns on when driving on dry hard surface
Low fuel warning
When the ignition switch is placed in the ON posi-
roads:
tion, the malfunction warning light illuminates in
Door open warning
- in the 4H position, shift the 4WD mode
red. This means that the system is operational. Af-
Low Washer warning (where fitted)
switch to 2WD.
ter starting the engine, the warning light turns off.
Key System Error warning (where fitted)
- in the 4LO position, stop the vehicle and
For the orange Malfunction Indicator Light (MIL), see
Low Oil Pressure warning (where fitted)
shift the transmission lever to the N (Neu-
“Malfunction Indicator Light (MIL)” later in this sec-
tral) position with the brake pedal
tion for details.
AdBlue® warning (where fitted)
depressed and shift the 4WD mode switch
If the malfunction warning light (red) illuminates
4WD Error (where fitted)
to 2WD.
continuously while the engine is running, it may in-
Shipping Mode On Push Storage Fuse warning
If the warning light is still on after the above opera-
dicate an engine control system malfunction. Have
(where fitted)
tions, have your vehicle checked by an approved
your vehicle inspected by an approved dealer or
Headlight System Error warning (where fitted)
dealer or qualified workshop as soon as possible.
qualified workshop. You do not need to have your
vehicle towed to the dealer.
Automatic Transmission (AT) Error warning (Au-
tomatic Transmission (AT) models)
Parking Sensor Error (where fitted)
Instruments and controls
2-9
See “Vehicle information display” later in this sec-
(SRS) (where fitted)” in the “1. Safety — seats, seat
When the ESP OFF switch is pushed to the OFF posi-
tion.
belts and supplemental restraint system” section.)
tion, the ESP system is turned off.
Seat belt warning light
Water-in-fuel-filter warning
When the rear differential lock is engaged with the
differential lock mode switch or the <4LO> position
(where fitted)
light (where fitted)
is selected with the Four-Wheel Drive (4WD) mode
Front seat belts:
If the water-in-fuel-filter warning light illuminates
switch, the ESP system is disabled and the ESP off
while the engine is running, contact an approved
When the ignition switch is in the ON position, the
indicator light illuminates. (See “Electronic Stability
dealer or qualified workshop as soon as possible.
seat belt warning light illuminates. The light will con-
Programme (ESP) system (where fitted)” in the
tinue to illuminate until the driver's seat belt is fas-
CAUTION
“5. Starting and driving” section and “Rear differen-
tened.
tial locking system (where fitted)” in the “5. Starting
Continuing vehicle operation without properly
and driving” section.)
Supplemental Restraint System
draining could cause serious damage to the en-
(SRS) air bag warning light
gine.
Front fog light indicator light
(where fitted)
(where fitted)
INDICATOR LIGHTS
When the ignition switch is in the ON position, the
The front fog light indicator light illuminates when
Differential lock indicator light
Supplemental Restraint System (SRS) air bag warn-
the front fog lights are on. (See “Fog light switch
(where fitted)
ing light illuminates for about 7 seconds and then
(where fitted)” later in this section.)
turns off. This indicates the SRS air bag system is
When the differential lock mode switch is in the ON
/
Front passenger air
operational.
position, the differential lock indicator light will blink
bag status light
and then stay on after the differential gear is com-
If any of the following conditions occur, the SRS air
pletely locked.
The front passenger air bag status light (
) lo-
bag system and/or pre-tensioner seat belt (where
cated on the instrument panel will illuminate when
fitted) need servicing. Have the system checked, and
See “Rear differential locking system (where fitted)”
the front passenger air bag is turned off with the
if necessary repaired, by an approved dealer or
in the “5. Starting and driving” section.
front passenger air bag switch. When the front pas-
qualified workshop promptly.
Dipped beam indicator light
senger air bag is turned on, the front passenger air
The SRS air bag warning light remains illumi-
(where fitted)
bag status light (
) will illuminate.
nated after about 7 seconds.
The dipped beam indicator light illuminates when
For more details, see “Front passenger air bag sta-
The SRS air bag warning light flashes intermit-
the headlight low beam is on. (See “Headlight and
tus light (where fitted)” in the “1. Safety — seats, seat
tently.
turn signal switch” later in this section.)
belts and supplemental restraint system” section.
The SRS air bag warning light does not come on
Electronic Stability Programme
Glow plug indicator light
at all.
(ESP) off indicator light
(where fitted)
Unless checked and repaired, the SRS air bag sys-
The Electronic Stability Programme (ESP) off indica-
When the ignition switch is in the ON position, the
tem and/or pre-tensioner seat belt may not func-
tor light illuminates when the ESP OFF switch is
glow plug indicator light illuminates and turns off
tion properly. (See “Supplemental Restraint System
pushed to the OFF position.
after the glow plugs have warmed up.
2-10
Instruments and controls
If the glow plugs have already warmed up, the glow
economy, and damage to the engine control
Security indicator light
plug indicator flashes briefly and then turns off.
system, which may affect the vehicle’s war-
(where fitted)
ranty coverage.
High beam indicator light
The security indicator light blinks when the ignition
Incorrect setting of the engine control system
switch is in the ACC, OFF or LOCK position. This
The high beam indicator light illuminates when the
may lead to non-compliance of local and na-
function indicates that the security system
headlight high beam is on. The indicator turns off
tional emission laws and regulations.
equipped on the vehicle is operational.
when the low beam is selected. (See “Headlight and
When the ignition switch is in the ON position, the
If the security system is malfunctioning, this light
turn signal switch” later in this section.)
Malfunction Indicator Light (MIL) illuminates. After
will remain on while the ignition switch is in the ON
starting the engine, the MIL turns off. This indicates
position. (See “Security system (where fitted)” in the
Hill descent control system on
that the engine control system is operational.
“3. Pre-driving checks and adjustments” section for
indicator light (where fitted)
If the Malfunction Indicator Light illuminates or
additional information.)
When the ignition switch is in the ON position the
blinks while the engine is running, it may indicate
hill descent control system on indicator light illumi-
Small light indicator light
that the engine control system is not functioning
nates briefly and then turns off. This indicates that
(where fitted)
properly and may need servicing. Have the system
the hill descent control system is operational.
checked, and if necessary repaired, by an approved
The light illuminates when the headlight switch is
The light illuminates when the hill descent control
dealer or qualified workshop promptly.
turned to the
position.
system is activated.
Precautions:
Trailer direction indicator light
If the hill descent control switch is on and the indi-
To reduce or avoid possible damage to the engine
(where fitted)
cator light blinks, the system is not engaged.
control system when the MIL blinks:
The light will illuminate whenever an additional
If the indicator light does not illuminate or blink
Avoid driving at speeds above 70 km/h (43 MPH).
electrical load is detected by the direction indicator
when the hill descent control switch is on, the sys-
system.
tem may not be functioning properly. Have the sys-
Avoid sudden acceleration or deceleration.
For additional information, see “Trailer towing” in the
tem checked by an approved dealer or qualified
Avoid going up steep uphill grades.
“5. Starting and driving” section.
workshop.
Avoid carrying or towing unnecessary loads.
For additional information, see “Hill descent control
Turn signal/hazard warning
Rear fog light indicator light
system (where fitted)” in the “5. Starting and driving”
lights
section.
(where fitted)
The turn signal/hazard warning lights blink when
The rear fog light indicator light illuminates when
Malfunction Indicator Light
the turn signal switch lever or hazard warning
the rear fog light is on. (See “Fog light switch (where
(MIL)
flasher switch is on. (See “Turn signal switch” later in
fitted)” later in this section.)
this section or “Hazard warning flasher switch” in
CAUTION
the “6. In case of emergency” section.)
Continuing vehicle operation without proper
servicing of the engine control system could
lead to poor driveability, reduced fuel
Instruments and controls
2-11
VEHICLE INFORMATION DISPLAY
AUDIBLE REMINDERS
Light reminder chime
The light reminder chime will sound if the driver’s
Brake pad wear warning
side door is opened and the headlight switch is in
The disc brake pads have audible wear warnings.
either the
or
position, and the ignition
When a brake pad requires replacement, it will make
switch is in the ACC, OFF or LOCK position.
a high pitched scraping sound when the vehicle is
Be sure to turn the headlight switch to the <OFF> or
in motion. This scraping sound will first occur only
<AUTO> (where fitted) position when you leave the
when the brake pedal is depressed. After more wear
vehicle.
of the brake pad, the sound will always be heard
even if the brake pedal is not depressed. Have the
Parking brake reminder chime
brakes checked as soon as possible if the wear
JVI0899XZ
The parking brake reminder chime will sound if the
warning sound is heard.
vehicle is driven at more than 7 km/h (4 MPH) with
Have the system checked, and if necessary repaired,
the parking brake applied. Stop the vehicle and re-
The vehicle information display is located be-
by an approved dealer or qualified workshop
lease the parking brake.
tween the tachometer and the speedometer, and it
promptly. (See “Brakes” in the “8. Maintenance and
displays the warnings and information. The follow-
do-it-yourself” section.)
Seat belt warning chime (where fitted)
ing items are also displayed:
When the vehicle speed exceeds 15 km/h (10 MPH),
Key reminder chime
Automatic Transmission (AT) (where fitted)
the chime will sound unless the driver's and/or the
The chime will sound if any of the following opera-
— “Driving with Automatic Transmission (AT)” in
front passenger's seat belts are securely fastened.
tions are detected:
the “5. Starting and driving” section
The chime will continue to sound for about 95 sec-
onds until the seat belt is fastened.
Four-Wheel Drive (4WD) (where fitted)
Models with Remote Control Key system:
— “Four-Wheel Drive (4WD) (where fitted)” in the
The chime will sound if the driver side door is
“5. Starting and driving” section
opened while the ignition switch is placed in the
ACC position.
Clock
— “[Clock]” later in this section
Models without Remote Control Key system:
Trip computer
The chime sounds if the driver's side door is opened
— “Trip computer” later in this section
while the key is left in the ignition switch and the
ignition switch is in the ACC, OFF or LOCK position.
Cruise control (where fitted)
Remove the key and take it with you when leaving
— “Cruise control (where fitted)” in the “5. Start-
the vehicle.
ing and driving” section
Remote Control Key system (where fitted)
— “Remote Control Key system (where fitted)” in
the “3. Pre-driving checks and adjustments” sec-
tion
2-12
Instruments and controls
Oil control system (where fitted)
m Back button
A
[Driver Assistance]
— “Oil control system (where fitted)” later in this
Use the or switches and the <ENTER> button
section
Press the BACK button to return to the previous dis-
to change the status, or turn on or off any of the
play screen or menu level, or to cancel the selection
HOW TO USE THE VEHICLE
systems displayed in the [Driver Assistance] menu.
if it is not completed.
The following menu options are available:
INFORMATION DISPLAY
Display scrolling switch j
[Driving Aids] (where fitted):
Push to scroll up or to scroll down through the
The [Driving Aids] option has a sub-menu, from
items in the vehicle information display. Press
which you can choose whether to turn ON or OFF
<ENTER>
B to select an item in the display, then
the following item:
push or to scroll through the associated menu
[Emergency Brake]
options.
Select this item to enable/disable the Active
SETTINGS
Emergency Braking system. For additional infor-
The settings mode allows you to change the infor-
mation see, “Active Emergency Braking system
mation displayed in the vehicle information display:
(where fitted)” in the “5. Starting and driving” sec-
tion.
NIC3083
[Driver Assistance]
Type A
[Parking Aids] (where fitted):
[Clock]
The [Parking Aids] option has a sub-menu, from
[Display Settings]
which you can choose the following:
[Vehicle Settings]
[Sensor]
[Maintenance]
Select this item to enable/disable the parking
[Alert]
sensor (sonar).
[Units]
[Volume]
[Language]
Select this sub-menu to change the parking sen-
sor (sonar) buzzer volume to one of the follow-
[Factory Reset]
ing:
NOTE
NIC3124
-
[High]
Type B
The Settings menu cannot be operated while
Loudest available volume.
driving.
The vehicle information display can be changed us-
-
[Med.]
ing the <ENTER> and BACK buttons located on the
Medium volume. (Standard)
left side of the steering wheel.
-
[Low]
Lowest available volume.
Instruments and controls
2-13
[Range]
[Set Clock] (where fitted)
[ECO Drive Report] (where fitted):
Select this sub-menu to change the parking sen-
Select this sub-menu to adjust the time on the
There are 2 items in the [ECO Drive Report] menu.
sor (sonar) detection range to one of the follow-
clock.
[Display]
ing:
[12Hr/24Hr] (where fitted)
Select this item to enable/disable the ECO Drive
-
[Far]
Select this sub-menu to choose the clock for-
Report in the vehicle information display.
The parking sensor system will give earlier
mat between 12-hour and 24-hour.
[View History]
notice of objects further away.
[Display Settings]
Select this sub-menu to show the fuel economy
-
[Mid.]
history, current economy, and the best fuel
The parking sensor system is set to the stan-
The following sub-menus are available under the
economy. See, “ECO drive report” in the “5. Start-
dard distance.
[Display Settings] menu.
ing and driving” section.
-
[Near]
[Contents Selection]
-
[Back] will return you to the [ECO Drive Re-
The parking sensor system will only give no-
[Body Colour]
port] menu.
tice of objects close by.
[ECO Drive Report] (where fitted)
-
[Reset] will reset the fuel economy history to
[Clock]
[Welcome Effect]
zero.
The following sub-menus are available in the clock
[Contents Selection]:
[Welcome Effect]:
menu, depending on the level of equipment of each
Select this sub-menu to enable/disable the items
Select this sub-menu to enable/disable the items
vehicle.
that are displayed.
described below to ON or OFF.
[Set the Clock in NAVI] (where fitted)
[Home]
[Dial and Pointer]
The clock needs to be adjusted in the navigation
[Average Speed]
The indicator needles sweep in the meters when
system and will automatically be synchronised.
the engine is started.
See the separately provided Touchscreen Navi-
[Trip]
[Display Effect]
[Fuel Economy]
The welcome screen display appears when the
[Set the Clock in Audio] (where fitted)
[Navigation] (where fitted)
ignition is placed in the ON position.
The clock needs to be adjusted in the audio sys-
[Audio]
tem and will automatically be synchronised.
[Vehicle Settings]
[Driving Aids] (where fitted)
See “Setting the clock” in the “4. Display screen,
The following sub-menus are available under the
[Body Colour]:
heater and air conditioner, and audio system”
[Vehicle Settings] menu.
In this sub-menu you can change the colour of the
section, or “How to use <SETUP> button” in the
[Lighting]
vehicle displayed in the vehicle information display.
“4. Display screen, heater and air conditioner, and
[Turn Indicator]
audio system” section.
[Unlocking]
[Wipers]
2-14
Instruments and controls

















Content      ..     1      2      3      4      ..
