Renault Trafic (2018 year). Instruction

1.2

KEY, RADIO FREQUENCY REMOTE CONTROLS: general information

(1/2)

Radio frequency remote

control A or B

1 Ignition-starter key, door key.

2 Locking the doors and tailgate.

3 Unlocks all doors and boot or, de-

pending on the vehicle, the driver’s

door only. Refer to the information on

“Key, radio frequency remote con-

trol: use” in Section 1.

4 Locks/unlocks the boot and, depend-

ing on the vehicle, the side sliding

door.

The key must not be used for any

function other than those described

in the handbook (removing the cap

from a bottle, etc.).

Advice
Avoid leaving the remote control in

hot, cold or humid areas.

Driver’s responsibility

when parking or stopping

the vehicle
Never leave an animal,

child or adult who is not self-suffi-

cient alone in your vehicle, even for

a short time.
They may pose a risk to themselves

or to others by starting the engine,

activating equipment such as the

electric windows or locking the

doors, for example.
Also, in hot and/or sunny weather,

please remember that the tempera-

ture inside the passenger compart-

ment increases very quickly.
RISK OF DEATH OR SERIOUS

INJURY.

1.3

Radio frequency remote

control operating range

This varies according to the environ-

ment: take care not to lock or unlock

the doors by inadvertently pressing the

buttons on the remote control.
Note: on certain vehicles, if a door is

not opened within approximately 2 min-

utes of the door being unlocked by

remote control, the doors will lock again

automatically.

Interference

Interference by factors in the immediate

vicinity (external installations or the use

of equipment operating on the same

frequency as the remote control) may

affect the operation of the remote con-

trol.

KEY, RADIO FREQUENCY REMOTE CONTROLS: general information

(2/2)

For replacement, or if you

require an additional remote

control.

You must only contact an approved

Dealer.

– To replace a remote control, the

vehicle and all its keys must be

taken to an authorised dealer

as the vehicle and remote con-

trol are required to initialise the

system.

– Depending on the vehicle, you

have the option of using up to

four remote controls.

Remote control unit failure
Make sure that the correct battery

type is being used, and that the

battery is in good condition and in-

serted correctly. These batteries

have a service life of approximately

two years.

To learn how to change the battery,

please refer to the information on

the “Key, radio frequency remote

control: Batteries” in Section 5.

1.4

KEYS, RADIO FREQUENCY REMOTE CONTROL: use

(1/2)

Unlocking the doors and

tailgate

For vehicles not fitted with

unlocking of the driver’s door only
Pressing and holding button 2 unlocks

all the opening elements.

For vehicles fitted with unlocking of

the driver’s door only
A single press on button 2 unlocks

the driver’s door only. A second press

within approximately 20 seconds after

the first press unlocks all the doors.

Driver’s responsibility

when parking or stopping

the vehicle
Never leave an animal,

child or adult who is not self-suffi-

cient alone in your vehicle, even for

a short time.
They may pose a risk to themselves

or to others by starting the engine,

activating equipment such as the

electric windows or locking the

doors, for example.
Also, in hot and/or sunny weather,

please remember that the tempera-

ture inside the passenger compart-

ment increases very quickly.
RISK OF DEATH OR SERIOUS

INJURY.

The key must not be used for any

function other than those described

in the handbook (removing the cap

from a bottle, etc.).

Note: if a door is not opened within ap-

proximately 2 minutes of the door being

unlocked by the remote control, the

doors will lock again automatically.

A short press on button 3 unlocks the

rear doors and, depending on the vehi-

cle, the sliding side doors.
The hazard warning lights and indica-

tor lights flash once to indicate that the

doors have unlocked.

1.5

KEYS, RADIO FREQUENCY REMOTE CONTROL: use

(2/2)

Locking the doors and

luggage compartment

Pressing button 1 unlocks all the open-

ing elements.
A short press on button 3 unlocks the

rear doors and, depending on the vehi-

cle, the sliding side doors.
The hazard warning lights and indica-

tor lights flash twice to indicate that the

doors have locked.

If a door is open or incorrectly closed,

the vehicle locks and then unlocks

quickly and the side indicator lights and

hazard warning lights do not flash.

1.6

DEADLOCKING

Never use deadlocking if

someone is still inside the

vehicle.

Deadlocking the doors

If fitted to the vehicle, this allows the

doors to be locked and prevents them

from being opened with the interior

handles (for example, by breaking the

window and then trying to open the

doors from the inside).

To activate deadlocking
Press button 1 twice in quick succes-

sion.
The hazard warning lights and indica-

tor lights flash five times to indicate that

the doors have locked.
Special note: deadlocking is not pos-

sible if the hazard warning lights or the

side lights are lit.

1.7

The RENAULT card is used

for:

– locking and unlocking the doors

(refer to the following pages);

– switch on the vehicle lighting re-

motely (refer to the following pages);

– starting the engine; refer to the in-

formation on “Starting the engine” in

Section 2.

Battery life

Make sure that the correct battery type

is being used, and that the battery is in

good condition and inserted correctly.

Its service life is approximately two

years: replace it when the message

“KEYCARD BATTERY LOW” appears

on the instrument panel (refer to the in-

formation on the “RENAULT card: bat-

tery" in section 5).

1 Unlocking the doors and tailgate.

2 Locking all doors and tailgate.

3 Switch on the courtesy lighting re-

motely.

4 Locking/unlocking the boot and the

sliding side doors.

5 Integrated key.

RENAULT CARD: general information

(1/2)

Driver’s responsibility

when parking or stopping

the vehicle
Never leave an animal,

child or adult who is not self-suffi-

cient alone in your vehicle, even for

a short time.

They may pose a risk to themselves

or to others by starting the engine,

activating equipment such as the

electric windows or locking the

doors, for example.

Also, in hot and/or sunny weather,

please remember that the tempera-

ture inside the passenger compart-

ment increases very quickly.

RISK OF DEATH OR SERIOUS

INJURY.

When the battery is flat, you can

still lock/unlock and start your ve-

hicle. Refer to the information on

“Locking/unlocking the doors” in

Section 1 and “Starting the engine”

in Section 2.

RENAULT card operating

range

This varies according to the surround-

ings: when handling the RENAULT

card, it is important to make sure that

you do not lock or unlock the doors by

inadvertently pressing the buttons.

1.8

Access to key 5
Press button 6 and pull on key 5 then

release the button.

Using the key
Please refer to the information on

“Locking and unlocking the opening el-

ements”.
Once you have accessed the vehicle

using the integrated key, replace it

in its housing in the RENAULT card,

then insert the RENAULT card into

the card reader to start the vehicle.

Integrated key 5

The integrated key is used to lock or

unlock the front left-hand door and, de-

pending on the vehicle, the rear door

when the RENAULT card does not

work:
– when the RENAULT card battery is

drained, flat battery, etc.

– use of devices using the same fre-

quency as the card;

– vehicle located in a high electromag-

netic radiation zone.

RENAULT CARD: general information

(2/2)

Replacement: need for an

additional RENAULT Card
If you lose your RENAULT card or

require another, you can obtain one

from an authorised dealer.
If a RENAULT card is replaced, it

will be necessary to take the vehi-

cle and all of its RENAULT cards to

an approved Dealer to initialise the

system.
You may use up to four RENAULT

cards per vehicle.

Advice
Avoid leaving the card in hot, cold or

humid areas.
Do not keep the RENAULT card in

a place where it could be bent or

damaged accidentally, such as in a

back pocket of a garment.

1.9

Do not store the RENAULT card

anywhere it may come into con-

tact with other electronic equipment

(computer, phone, etc.) as this could

hinder its operation.

“HANDS-FREE” RENAULT CARD: usage

(1/4)

Driver’s responsibility

when parking or stopping

the vehicle
Never leave an animal,

child or adult who is not self-suffi-

cient alone in your vehicle, even for

a short time.
They may pose a risk to themselves

or to others by starting the engine,

activating equipment such as the

electric windows or locking the

doors, for example.
Also, in hot and/or sunny weather,

please remember that the tempera-

ture inside the passenger compart-

ment increases very quickly.
RISK OF DEATH OR SERIOUS

INJURY.

Locking/unlocking the

vehicle

There are two ways to unlock/lock the

vehicle: be within the access zone or

using the card RENAULT.

It allows locking/unlocking without input

on the card RENAULT when within the

access zone 1.

1.10

Special features relating to vehicle

locking
– When locking, if a door is open or in-

correctly closed, the vehicle will lock

and unlock in quick succession with-

out the hazard warning lights flash-

ing;

– after locking by pressing button 2,

you have to wait approximately

3 seconds to be able to unlock the

vehicle again.

“HANDS-FREE” RENAULT CARD: usage

(2/4)

Be within the access zone
Depending on the vehicle, press

button 2 on the handle of one of the

front doors, the tailgate or the rear

hinged door.
The hazard warning lights flashing tells

you about the vehicle status:

– two flashes indicate that the vehicle

is locked.

– one flash indicates that the vehicle

is unlocked.

1.11

After locking/unlocking the vehicle

using the buttons on the RENAULT

card, "hands-free" locking and un-

locking is deactivated.
To reactivate the “hands-free” mode:

restart the vehicle.

Unlocking with the card RENAULT
Press the button 3.

The hazard warning lights flash once

to indicate that the doors have been un-

locked.

Locking using the RENAULT card
With the doors closed, press button 4:

the vehicle will lock.
The hazard warning lights flash twice

to indicate that the doors have locked.
NB: The maximum distance at which

the vehicle locks depends on the sur-

roundings.

“HANDS-FREE” RENAULT CARD: usage

(3/4)

Special note:

The vehicle will not lock if:

– a door is open or not properly closed;

– the card is not in the zone 1.

Driver’s responsibility

when parking or stopping

the vehicle
Never leave an animal,

child or adult who is not self-suffi-

cient alone in your vehicle, even for

a short time.
They may pose a risk to themselves

or to others by starting the engine,

activating equipment such as the

electric windows or locking the

doors, for example.
Also, in hot and/or sunny weather,

please remember that the tempera-

ture inside the passenger compart-

ment increases very quickly.
RISK OF DEATH OR SERIOUS

INJURY.

1.12

Distance lighting function

The interior lights come on for approxi-

mately 30 seconds when button 6 is

pressed. This can be used, for exam-

ple, to identify the vehicle from a dis-

tance when parked in a car park.

NB: Pressing button 6 again switches

off the lighting.

“HANDS-FREE” RENAULT CARD: usage

(4/4)

Rear opening elements

locking/unlocking

Press button 7 to lock/unlock the rear

hinged doors or the tailgate and, de-

pending on the vehicle, the side doors.
The hazard warning lights flashing noti-

fies you of the status of the rear open-

ing elements:

– two flashes indicate that the rear

opening elements are locked;

– one flash indicates that the rear

opening elements are unlocked.

With the engine running, if, after

opening and closing a door, the card is

no longer in the zone 5, the message

“KEYCARD NOT DETECTED” (to-

gether with a beep when the speed ex-

ceeds a limit) warns you that the card

is no longer in the vehicle. This avoids

you driving away after having dropped

off a passenger who has the card, for

example.
The warning disappears when the card

is detected again.

After locking/unlocking the vehicle

using the buttons on the RENAULT

card, "hands-free" locking and un-

locking is deactivated.
To reactivate the “hands-free” mode:

restart the vehicle.

1.13

Never use deadlocking if

someone is still inside the

vehicle.

If the vehicle is equipped with a dead-

locking function, this allows you to lock

the opening elements and to prevent

the doors from being unlocked using

the interior handles (for example, by

breaking the window and then trying to

open the door from the inside).

RENAULT CARD: deadlocking

To deactivate deadlocking

Unlock the vehicle using button 1 on

the RENAULT card.
The hazard warning lights flash once to

indicate that the doors have been un-

locked.

After activating the deadlocking

function using button 2, “hands-

free” locking and unlocking are de-

activated.
To reactivate the “hands-free” mode:

restart the vehicle.

To activate deadlocking

– Press the button 2 twice in quick suc-

cession;

or
– With the vehicle unlocked, you can

also press the button 3 on the driver

or passenger side door twice in quick

succession (or, depending on the

vehicle, on the tailgate or the rear

door).

In both cases, locking is indicated by

the hazard warning lights flashing five

times.

1.14

FRONT DOORS

(1/2)

Opening the doors from the

outside

Vehicles with a remote control

Unlock the vehicle using the remote

control and pull handle 1.
Vehicles with RENAULT card

With the card on your person, press

button 2 to unlock the vehicle and pull

handle 1.

Closing from the outside

Push the door. Lock it using the remote

control or, for vehicles fitted with the

RENAULT card, by pressing button 2.

Opening from the inside

Pull handle 4 and push the door.

Closing from the inside

Pull the door exclusively using handle 3.

As a safety precaution,

the doors should only be

opened or closed when the

vehicle is stationary.

Driver’s responsibility

when parking or stopping

the vehicle

Never leave an animal,

child or adult who is not self-suffi-

cient alone on your vehicle, even for

a short time.

They may pose a risk to themselves

or to others by starting the engine,

activating equipment such as the

electric windows or locking the

doors.

Also, in hot and/or sunny weather,

please remember that the tempera-

ture inside the passenger compart-

ment increases very quickly.

RISK OF DEATH OR SERIOUS

INJURY.

1.15

FRONT DOORS

(2/2)

Lights-on reminder buzzer

If you have switched off the ignition

and left the lights switched on, a re-

minder buzzer will sound when a door

is opened.

Card reminder buzzer

(depending on the vehicle)
On opening the driver’s door, if the

card is still in the reader, the message

“PLEASE REMOVE KEYCARD” is dis-

played on the instrument panel accom-

panied by a warning beep.

Key reminder alarm

(depending on the vehicle)
If you have left the key in the ignition,

an alarm will sound when the driver’s

door is opened.

Door/tailgate open buzzer

If a door is open or not properly closed,

as soon as the vehicle reaches a speed

of approximately 12 mph (20 km/h), the

message “Door open” will appear on

the instrument panel, accompanied by

a warning light.

Special note

Depending on the vehicle, accessories

(e.g. radio) stop working either when

the engine is switched off or when the

driver’s door is opened or when the

doors are locked.

1.16

SLIDING SIDE DOOR

(1/2)

Opening the doors from the

outside

With the vehicle unlocked, pull handle 1

towards you and slide the door towards

the rear.

Opening from the inside

Pull lever 2 towards the rear and open

the sliding door until it locks into posi-

tion.

Closing from the outside

Pull handle 1 and slide the door to-

wards the front of the vehicle until it

closes completely.

Closing from the inside

Pull lever 2 towards the front and close

the door until it latches.

Manual locking from inside
Lower button 3. The sliding door is

locked.

As a safety precaution,

the doors should only be

opened or closed when the

vehicle is stationary.

Vehicles with a remote

control

The sliding side door is locked and un-

locked by pressing the remote control

button.

Vehicles with RENAULT card

The sliding side door is locked and un-

locked:

– by pressing the RENAULT card but-

tons;

– in hands-free mode by locking/unloc-

king the front doors or the tailgate.

1.17

Recommendations concer-

ning the sliding side door.
Care must be taken when

opening or closing the sli-

ding door, as is the case for any of

the opening elements on the vehi-

cle:
– Check that the door will not come

into contact with any person, part

of the body, animal or object.

– Only use the handles on the

inside and outside of the door to

operate it.

– Take care when opening and clo-

sing the door.

– Take particular care when the

vehicle is parked on a slope:

open or close the door fully until

it latches into its locking position.

– Before moving off, always ensure

that the sliding door is properly

closed.

Child safety

To make it impossible for the rear doors

to be opened from the inside, move

screw 4 and close the door.
Check from the inside that all the doors

are locked.
The door can only be opened from the

outside of the vehicle.

SLIDING SIDE DOOR

(2/2)

Driver’s responsibility

when parking or stopping

the vehicle

Never leave an animal,

child or adult who is not self-suffi-

cient alone on your vehicle, even for

a short time.

They may pose a risk to themselves

or to others by starting the engine,

activating equipment such as the

electric windows or locking the

doors.

Also, in hot and/or sunny weather,

please remember that the tempera-

ture inside the passenger compart-

ment increases very quickly.

RISK OF DEATH OR SERIOUS

INJURY.

Renault Trafic (2018 year). Instruction - part 1
