Renault Scenic (2018 year). Instruction - part 16

3.32

Central storage

compartment 12

Lift up the armrest 11.

PASSENGER COMPARTMENT STORAGE SPACE AND FITTINGS

(3/8)

Central armrest 11

Storage drawer under

driver’s seat 10

This drawer can hold a road atlas, the

vehicle documentation etc.

Nothing should be placed

on the floor area in front of

the driver as such objects

may slide under the pedal

during braking manoeuvres, thus

obstructing its use.

3.33

PASSENGER COMPARTMENT STORAGE SPACE AND FITTINGS

(4/8)

Centre console 13

To move the centre console forward

or backward (movement B), press the

button 14 and slide the console. Once

in position, release the button and

check that it is correctly locked.

In cases of intensive use, a protective

system will prevent it from operating for

a few minutes.
In any case, the load must not

exceed 6 kg.

3.34

PASSENGER COMPARTMENT STORAGE SPACE AND FITTINGS

(5/8)

Storage compartment 15

Cup holders 16

This can be used for storing a mobile

ashtray, cup holder, etc.

Front and rear underfloor

storage 17

These compartments can hold road

maps, manuals, cloths, etc.

Nothing should be placed

on the floor area in front of

the driver as such objects

may slide under the pedal

during braking manoeuvres, thus

obstructing its use.

3.35

Cup holders 19

Rear armrest with cup holder

Lower armrest 18.

When turning corners,

accelerating or braking,

ensure that the recepta-

cle being held by the cup

holder is not dislodged.
There is a risk of burning if hot

liquid escapes.

PASSENGER COMPARTMENT STORAGE SPACE AND FITTINGS

(6/8)

3.36

PASSENGER COMPARTMENT STORAGE SPACE AND FITTINGS

(7/8)

Ensure that no hard, heavy

or pointed objects are

placed in the “open” stor-

age compartments in such

a way that they may fall onto pas-

sengers during sudden turning or

braking.

Storage drawer 21 under the

centre console

Rear door storage

compartment 20

Nothing should be placed

on the floor area in front of

the driver as such objects

may slide under the pedal

during braking manoeuvres, thus

obstructing its use.

Front seat storage pockets 22

3.37

PASSENGER COMPARTMENT STORAGE SPACE AND FITTINGS

(8/8)

Rear parcel shelf 23

Retaining straps 24

They can be used, for example, to

retain a multimedia tablet etc.

Grab handle 26

This offers support and can be held

when the vehicle is being driven.
Do not use it for getting into or out of

the vehicle.

Clothes hooks 27

For a multimedia tablet
Attach the upper section of the parcel

shelf using the straps 24 and place the

lower section in one of the housings 25.

3.38

ASHTRAY, CIGAR LIGHTER, ACCESSORIES SOCKET

Cigarette lighter 1

With the ignition on, push in cigar

lighter 1. It will spring back with a click

when it is ready. Pull it out to use. After

use, replace it without pushing it all the

way in.

Ashtray location 2

Accessories sockets

You can use the one of the sockets 1

or 3. They are provided for connecting

accessories approved by our Technical

Department.

Connect accessories with

a maximum power of

120 watts (12 V) only.

When several accessory

sockets are used at the same time,

the total power of the connected

accessories must not exceed

180 watts.

Fire hazard.

If your vehicle is not fitted with a

cigar lighter and an ashtray, these

can be obtained from an authorised

dealer.

3.39

To adjust the angle of the

headrest

Depending on the vehicle, move sec-

tion A towards or away from you to the

required position.

To adjust side supports

Depending on the vehicle, sections B

can be adjusted independently to the

desired position.

Storage position 2 for the

headrest

Press tab 1 and lower the headrest

completely.

REAR HEADRESTS

Position for use

Lift the headrest fully until it locks.

To remove the headrest

Lower the seatback slightly, press the

tab 1 and remove the headrest.

To refit the headrest

Insert the headrest rods into the

sleeves, and lower the headrest until it

locks.

The headrest is a safety

component; check that it is

fitted and in the correct po-

sition. The top of the head-

rest should be as close as possible

to the top of the head.

When the headrest is set at the

lowest position, this is for storage

only. It should not be in this position

when a seat is occupied.

3.40

To move the seats forwards

or backwards

Lift lever 1 to unlock the seat. Once in

the desired position, release the lever

and check that the seat is correctly

locked.

To tilt the seatback

Move the seat forwards if necessary.

Lift handle 2 and tilt the seatback to the

desired position.

Release the handle 2 and ensure that

the seatback is fully locked into posi-

tion.

REAR SEATS

(1/6)

When moving the rear

seats, ensure that nothing

obstructs the anchorage

points (passenger’s arm or

leg, a pet, gravel, cloth, toys, etc.).

To fold down the seatback

(flat-floor position)

Lower the headrest 3 and lift the

handle 2 to fold down the seat. Make

sure the seat is correctly locked in po-

sition.
Note: before folding down the seat-

back, check that no device is plugged

into the sockets 4.

For safety reasons, carry

out any adjustments when

the vehicle is not being

driven.

To raise the seatback

Be sure to position the seat belt cor-

rectly, hold the seatback, lift and ensure

that it is correctly locked.

3.41

REAR SEATS

(2/6)

To unfold a seat in the third

row

– Access the third row seats;
– place seat belt in hook 6 to avoid

damaging it;

– Pull the strap 7 to lift the seatback.

Check that the bonnet is correctly

locked.

To access the third row rear

seats

– Lift the handle 5;

– Hold the seatback and lower it at the

front until it locks;

– sit in the third row rear seat;

– hold the second row seatback and

fold it down;

– Make sure the seat is correctly

locked in position.

When moving the rear

seats:
– check that no one is near

to any of the moving parts;

– check that there is sufficient

space around the seat;

– check that nothing is obstructing

the section of the boot reserved

for storing the seat;

For safety reasons, carry out any

adjustments when the vehicle is sta-

tionary.

Before moving a second row seat forwards, ensure that the seat is not in the flat-

floor position.

When refitting the seat-

back, make sure it is cor-

rectly locked in place.

If seat covers are fitted,

make sure these do not prevent the

seatback latch from locking in.

Make sure that the seat belts are

positioned correctly.

Reposition the headrests.

3.42

REAR SEATS

(3/6)

To fold down a third row seat

manually

– From the luggage compartment,

lower the headrest;

– pull strap 10. Depending on the vehi-

cle, it is located above or below the

false floor 11.

To get out of the third row

rear seats

– Lift the lever 8;
– guide the seat forwards until it locks.

Note: If the lever 8 does not work, pull

the emergency exit strap 9.

Using the emergency exit

strap 9 causes the second

row rear seats to move

backwards. During the op-

eration, ensure that nothing is ob-

structing the movement of the seat

(body parts, pets, toys etc.).

For safety reasons, carry out any

adjustments when the vehicle is sta-

tionary.

Risk of injury.

3.43

REAR SEATS

(4/6)

To automatically fold down

the seats (flat position)

The rear seats are electrically unlocked

to fold down in order to create a flat

floor.
There are two ways to manoeuvre the

seats:

– from the boot using control 12;

– on the multifunction screen 13.

Disabling the function

– With the engine running, a buckled

seat belt prevents the movement of

the relevant seat.

– Once the vehicle is moving the two

controls are deactivated.

To raise the seats manually

Raise each seat as described on the

previous pages.

Conditions of use
With the vehicle at a standstill and the

rear seat belts unlocked:
– from control 12, with the boot lid

open;

– from the multifunction screen 13,

with the engine running.

Note: Before performing any unlock-

ing operations to fold down the seats,

the trays on the back of the front seats

must be folded away.

When moving the rear

seats:
– check that no one is near

to any of the moving parts;

– check that there is sufficient

space around the seat;

– check that nothing is obstructing

the section of the boot reserved

for storing the seat;

For safety reasons, carry out any

adjustments when the vehicle is sta-

tionary.

3.44

REAR SEATS

(5/6)

From the multifunction screen 13
With the vehicle at a standstill, select

menu “Vehicle”, “Seats” then “One-

touch folding”.
Press on the seat you wish to fold away,

or on all seats, then confirm.

Encountering an obstacle
While being moved, if a seat encoun-

ters an obstacle, the movement stops

of its own accord. You will then have

to manually fold back the seat after re-

moving the obstacle.

Operating fault
If all user conditions have been ful-

filled and the folding action still fails to

operate, please contact an authorised

dealer.

When moving the rear

seats, ensure that nothing

obstructs the anchorage

points (passenger’s arm or

leg, a pet, gravel, cloth, toys, etc.).

Using control 12
Depending on the vehicle, folding

switches:
A the rear left seatback in the second

row.

B the rear centre and right-hand seat-

backs in the second row.

C the rear right seatback in the third

row.

D the rear left seatback in the third row.
E all seats.

For safety reasons, carry

out any adjustments when

the vehicle is not being

driven.

3.45

Use restriction

It is not permitted to drive with a second

row rear seatback or seat folded down

when there is a passenger occupying a

third row rear seat.

REAR SEATS

(6/6)

Special feature

For vehicles fitted with the “Hybrid

Assist" system: if it is present, take

care not to obstruct the vent 14 (refer

to the information on the “Hybrid Assist

System" in Section 2).

3.46

TAILGATE

Manual controls

To open
Press button 1 and lift the tailgate.

To close
Lower the boot lid using the handle

inside the boot 2 to assist you.

Opening the doors manually

from the inside

If it is impossible to unlock the tailgate,

it can be done manually from inside:
– access the luggage compartment by

folding forward the seatback(s) of

the rear bench seat;

– insert a pencil or similar object in

recess 3 and slide the unit as shown

in the illustration;

– push the tailgate to open it.

The attaching of any carry-

ing device (bike rack, lug-

gage box, etc.) resting on

the luggage compartment

lid is prohibited. To install a carrying

device on your vehicle, contact an

Approved Dealer.

3.47

Removal

– Unhook the two cords 1.
– Lift the parcel shelf 2 upwards, then

pull it towards you.

To refit it, proceed in reverse order to

removal.

REAR PARCEL SHELF

Do not place any heavy or

solid objects on the parcel

shelf.

These may pose a risk to

the vehicle occupants if the driver

has to brake suddenly or if the vehi-

cle is involved in an accident.

Content .. 14 15 16 17 ..
