Renault Scenic (2018 year). Instruction - part 15

3.16

Press button 10 – the integrated indica-

tor light comes on.
Press button 6 to stop the heated rear

screen operating, and the integrated in-

dicator goes out.
To adjust the ventilation speed: press

buttons 12 or 18 or slide your finger in

zone 19.

Clear View function

This function quickly demists and de-

ices the windscreen, the rear screen,

the front side windows, and the door

mirrors (depending on the vehicle). It

imposes automatic operation of the

air conditioning and rear screen de-ic-

ing and, depending on the vehicle, the

windscreen electric de-icer.

To exit this function, press either:
– again button 10;
– one of the buttons 14, 15 or 16.

14 15

AUTOMATIC CLIMATE CONTROL: Controls B and C

(3/5)

3.17

Switching air conditioning on

or off

In automatic mode, the system switches

the air conditioning system on or off,

depending on the climate conditions.
Press button 17 to:
– activate the air conditioning (a warn-

ing light in zone 1 comes on);

– deactivate the air conditioning (the

warning light in zone 1 goes out).

Rear screen de-icing/

demisting

Press button 6 – the integrated indica-

tor light comes on. This function en-

ables rapid demisting or de-icing of the

rear screen and de-icing of the door

mirrors (on equipped vehicles).
To exit this function, press button 6

again. Demisting automatically stops.

It is preferable to use one of the automatic programmes AUTO, SOFT or

FAST.
In automatic mode (indicator light on button 14, 15 or 16 lit), all air conditioning

functions are controlled by the system.
You can still change the selection made by the system. In this case, the indicator

light for button 14, 15 or 16 goes out.
To return to automatic mode, press one of programmes AUTO 15, SOFT 14 or

FAST 16.

Stopping the system

To switch the system off, press

button 12 repeatedly until the message

OFF appears in zone 1.

AUTOMATIC CLIMATE CONTROL: Controls B and C

(4/5)

3.18

Automatic usage
Press button 8 (a warning light comes

on in zone 1).

Manual use
Press button 9 to force air recirculation.
Prolonged use of this position may lead

to odours, caused by non-renewal of

air, and the formation of condensation

on the windows.
We advise you to return to automatic

mode as soon as air recirculation is no

longer needed, by pressing button 8 or

button 9 again.
To exit this function, press button 8 or

button 9 again.

Adjusting the distribution

of air in the passenger

compartment

Press buttons 7 to select the desired

distribution (a warning light is displayed

in zone 1):

The air flow is mainly directed

to the demisting vents for the

windscreen and the side windows.

The air flow is mainly directed

to the dashboard air vents.

The air flow is directed mainly

towards the footwells.

The demisting/de-icing will still take

priority over the air recirculation.

Air recirculation

This function is managed automatically

but you can also activate it manually.

Note:
– during recirculation, air is taken from

the passenger compartment and

is recycled, with no air being taken

from outside the vehicle;

– air recirculation allows the exter-

nal atmosphere to be cut off (when

driving in polluted areas, etc.) and

to cool the passenger compartment

temperature more quickly.

AUTOMATIC CLIMATE CONTROL: Controls B and C

(5/5)

3.19

Operating faults

As a general rule, contact your ap-

proved dealer in the event of an oper-

ating fault.
– Reduction in de-icing, demisting

or air conditioning performance.

This may be caused by the passen-

ger compartment filter cartridge be-

coming clogged.

– No cold air is being produced.

Check that the controls are set cor-

rectly and that the fuses are sound.

Otherwise, switch off the system.

Presence of water under the

vehicle

After prolonged use of the air condi-

tioning system, it is normal for water

to be present under the vehicle. This is

caused by condensation.

AIR CONDITIONING: information and operating instructions (1/2)

Do not add anything to the

vehicle’s ventilation circuit

(for example, to remove

bad odours).

There is a risk of damage or of

fire.

Do not open the refriger-

ant fluid circuit. The fluid

may damage eyes or skin.

Fuel consumption

You will normally notice an increase in

fuel consumption (especially in town)

when the air conditioning is operating.

For vehicles fitted with air conditioning

with no automatic mode, switch off the

system when it is not required.

Advice for reducing consumption

and helping to preserve the

environment

Drive with the air vents open and the

windows closed. If the vehicle has been

parked in the sun, open the doors for a

few moments to let the hot air escape

before starting the engine.

Maintenance

Refer to the Maintenance Document

for your vehicle for the inspection fre-

quency.

Advice on use

In some situations (air conditioning off,

air recirculation activated, ventilation

speed at zero or low etc.), you may

notice that condensation starts to form

on the windows and windscreen.
If there is condensation, use the “Clear

View” function to remove it, then use

the air conditioning in automatic mode

to stop it forming again.

Use the air conditioning system reg-

ularly, even in cold weather, running

it at least once a month for approxi-

mately 5 minutes.

Vehicles equipped with

mode ECO
Once activated, ECO mode may

reduce air conditioning perform-

ance. Please refer to the informa-

tion on “Driving advice, Eco-driving”

in Section 2.

3.20

AIR CONDITIONING: information and operating instructions (2/2)

The refrigerant circuit may contain

fluorinated greenhouse gases.
Depending on the vehicle, you will find

the following information on label A af-

fixed inside the engine compartment.
The presence and location of the infor-

mation on label A depends on the ve-

hicle.

Do not open the refriger-

ant circuit. The fluid may

damage eyes or skin.

Before performing any

action in the engine com-

partment, the ignition must

be switched off (please see

the information on “Starting, stop-

ping the engine” in Section 2).

Type of refrigerant fluid



Type of oil in the air condi-

tioning circuit



Inflammable product



Consult the driver’s hand-

book



Maintenance

Quantity of refrigerant

fluid present in the ve-

hicle.

x.xxx kg

G l o b a l Wa r m i n g

Potential (CO2 equi-

valent).

GWP xxxxx

Quantity in weight and

in CO2 equivalent.

CO2 eq

x.xx t

3.21

OUTSIDE AIR QUALITY AND DEODORISATION FUNCTION

With the air conditioning switched

on, from the screen A, select Menu,

Vehicle, Take care.

Outside air quality

The air quality is given using a graph on

the multifunction screen.
Three colours indicate the air quality

level (from the cleanest to the most

polluted):
1 (blue)
2 (light grey)
3 (grey)

Deodorisation function

This reduces unpleasant odours in the

passenger compartment.

Deodorization cycle
– ON: helps to reduce the unpleasant

odour more quickly in the passenger

compartment,

– OFF: stop the function.
Note:
The function is on a timer. It stops auto-

matically after a few minutes.

Take care

Deodorization cycle

Please refer to the multimedia in-

structions for further information.

3.22

MULTIMEDIA EQUIPMENT

(1/2)

Using the telephone
We remind you of the need

to conform to the legislation

in force concerning the use

of such equipment.

Hands-free telephone

integrated control

For equipped vehicles, use the steering

wheel controls 3.

Multimedia systems

The location and operation of equip-

ment may vary according to the vehicle.
1 Multimedia touchscreen display;

2 Steering column controls;

3 Steering wheel controls;

4 or 5 microphone.

Refer to the equipment instructions

for information on how to operate

this equipment.

3.23

Multimedia sockets 6

You can use sockets USB or the SD

card reader to access the multime-

dia content of your accessories and

the system update (please refer to the

equipment instructions).
The various sources can be selected

from the multifunction screen and from

the steering column controls.

MULTIMEDIA EQUIPMENT

(2/2)

Multimedia sockets 7

Sockets USB can only recharge acces-

sories with a maximum power rating

of 12 Watts (voltage: 5V) per socket,

which have been approved by our

Technical Department.
The JACK socket enables the radio to

be used with an auxiliary cable.

The sockets USB can also recharge ac-

cessories with a maximum power rating

of 12 Watts (voltage: 5V) per socket,

which have been approved by our

Technical Department.
The JACK socket enables the radio to

be used with an auxiliary cable.

Connect accessories with a

maximum power of 12 watts

only.
Fire hazard.

3.24

ELECTRIC WINDOWS

(1/2)

These systems operate:
– with the engine running;
– with the ignition off until one of the

front doors is opened (limited to ap-

proximately 12 minutes).

– before starting, with the front doors

closed, after pressing the start

button.

Press the window switch down or pull it

up to lower or raise the window to the

desired height: the rear windows do not

open fully.

Safety of rear occupants

The driver can prevent operation of the rear electric windows by pressing

switch 4. A confirmation message is displayed on the instrument panel.

Driver’s responsibility

Never leave your vehicle with the RENAULT card or key inside, and never leave

a child, adult who is not self-sufficient or a pet, even for a short while. They may

pose a risk to themselves or to others by starting the engine or activating equip-

ment (such as the gear lever or electric windows). If any part of the body becomes

trapped, reverse the direction of the window immediately by pressing the relevant

switch.
Risk of serious injury.

Avoid resting any objects against

a half-open window: there is a risk

that the electric window could be

damaged.

From the driver’s seat, use switch:

1 for the driver’s side;

2 for the front passenger side;

3 and 5 for the rear passenger win-

dows.

From the passenger seats, use

switch 6.

3.25

Operating faults

In case of a fault when closing a

window, the system reverts to normal

mode: pull the switch concerned up

as often as necessary to fully close

the window, then hold the switch (still

on the closure side) for approximately

one second, then lower and raise the

window fully to reinitialise the system.
If necessary, contact an approved

Dealer.

ELECTRIC WINDOWS

(2/2)

Remote control window

closing

(vehicles with 4 one-touch electric win-

dows).
When you lock the doors from the out-

side, press the locking button on the

RENAULTcard twice in quick suc-

cession, or on the driver's door in

hands-free mode, and all the windows

will close automatically (and, depend-

ing on the vehicle, the sunroof).
It is recommended that the user only

operates the system when the vehi-

cle can be seen clearly and no one is

inside.

One-touch mode
This mode works in addition to the ope-

ration of the electric windows described

previously.
Briefly press or pull the window switch

fully: the window is fully lowered or

raised. Pressing the switch again stops

the window moving.
Note: if the window detects resistance

when closing (e.g. tree branch, etc.), it

stops and then lowers again by a few

centimetres.

When closing the windows,

ensure that no part of the

body (arm, hand, etc.) is

protruding from the vehicle.

Risk of serious injury.

3.26

FIXED GLASS ROOF

To slide the curtain 1

With the ignition on:
– full opening: move the mark 3 on

the button 2 towards position B. The

marks in between correspond to the

intermediate positions of the sun-

blind.

– to close: move mark 3 on button 2

to position 0.

Driver’s responsibility
Never leave your vehicle

with the RENAULT card or

key inside, and never leave

a child, adult who is not self-suffi-

cient or a pet, even for a short while.
They may pose a risk to themselves

or to others by starting the engine,

activating equipment such as the

electric windows or by locking the

doors.
If something gets trapped, reverse

the direction of travel as soon as

possible by turning button 2 fully to

the right (position B).
Risk of serious injury.

Special features
If the fixed sunroof blind detects resist-

ance when closing (arm etc.), it stops

and then moves back several centime-

tres.

Operating fault

If the blind will not close, turn switch 2

to position A or B to open the blind,

then turn switch 2 to position 0 until the

blind is fully closed.

If the blockage persists, contact an ap-

proved dealer.

3.27

When the doors or boot are un-

locked and opened, the reading and

footwell lights come on temporarily.

INTERIOR LIGHTING

(1/2)

Map reading lights

Press switch 1 to get:

– permanent lighting;

– immediate switching off.
Note: for vehicles fitted with a multi-

function screen, you can use the mul-

tifunction screen to deactivate/acti-

vate the courtesy lights which come on

when the doors or luggage compart-

ment are opened. To do this, please

refer to “Vehicle settings customisation

menu” in Section 1.

Footwell lights

The lights 2 come on when the doors

are opened.

3.28

Boot lights

Light 5 comes on when the luggage

compartment is opened.

INTERIOR LIGHTING

(2/2)

Glove box light 4

Light 4 comes on when the cover is

opened.

Centre console storage

compartment light

The light 3 comes on when the storage

compartment is opened.

3.29

SUN VISOR, BLINDS

Front sun visor

Lower the sun visor 1 on the wind-

screen or unclip it and lower it over the

side window.

Vanity mirror

Slide cover 2, depending on the vehi-

cle, and the mirror is lit.

Lateral sun visor

Pull the sun visor upwards using the

tab 3 until the hooks 4 engage in their

housings (make sure the hooks are

properly locked in position).

3.30

Passenger storage drawer 3

To open, move your fingers into area 4 -

it will open by itself. If on a steep slope,

assist the drawer opening by pulling the

handle 5. It can hold A4 documents. It

is ventilated and refrigerated.

Dashboard storage

compartment 2

Door pockets 1

It can hold a bottle.

PASSENGER COMPARTMENT STORAGE SPACE AND FITTINGS

(1/8)

Nothing should be placed

on the floor area in front of

the driver as such objects

may slide under the pedal

during braking manoeuvres, thus

obstructing its use.

Ensure that no hard, heavy

or pointed objects are

placed in the “open” sto-

rage compartments in such

a way that they may fall onto pas-

sengers during sudden turning or

braking.

Maximum load allowed in the pas-

senger storage compartment: 6 kg,

evenly distributed.

When driving, ensure

that the storage drawer is

closed. Risk of injury.

3.31

PASSENGER COMPARTMENT STORAGE SPACE AND FITTINGS

(2/8)

Cup holders 7

When turning corners,

accelerating or braking,

ensure that the recepta-

cle being held by the cup

holder is not dislodged.
There is a risk of burning if hot

liquid escapes.

Passenger storage

compartment

Pull handle 6 to open it.
The glove box can hold A4-size docu-

ments, a large bottle of water, etc.
The storage compartment is ventilated

and refrigerated.

Central storage

compartment 8

Slide the curtain 9 to open the storage

compartment.

Content .. 13 14 15 16 ..
