10
10 - 66
ENGINE AND LOWER ENGINE UNITS
OIL PUMP DISMOUNTING – REMOUNTING
D
ISMO UNTING
Disconnect the battery.
Drain the oil off the engine.
Dismount :engine shield,crossbar between the longitudinal girders,elastic bushing nuts on the
anti rolling shaft and the oil pump.
Unscrew the attachement screws and take out the oil pump.
Clean the contact surfaces of the gaskets or those with sealant material ( engine bloc and oil
sump).
R
EMOUNTING
Mount the new oil pump with a new gasket.
Τighten the attachment screws.
Remount:
- the oil sump;
- the bearing attachement nuts to stabilizer rod;
- the crossbar between the longitudinal girders;
- the engine shield.
Perform the oil filling of the engine.
OIL PUMP
