Peugeot Bipper (2015 year). Instruction

TECHNOLOGY

on BOARD

Bluetooth hands-free system

Bipper_en_Chap05_technologie_ed02-2014

PRESENTATION

Adjustment of the volume of
the functions: hands-free, audio
and text message player, voice
announcements.

Pause/resume the file being played
(portable player).

uSB connection port. Remove the plastic cover to
connect your portable player.

Display of the menus and directories of the files
being played (uSB storage device).

- Scroll the menu options.

- Select the files to be played

(portable player).

- Scroll the list of text messages.

- Activate voice recognition.
- Interrupt the voice message in order to

issue a new voice command.

- Deactivate voice recognition.
- Interrupt the voice message.

- exit from the main menu.
- exit from a sub-menu and return to the

previous menu option.

- exit without storing.
- Deactivate/reactivate the microphone

during a telephone conversation.

- Set the volume of the incoming call ring

to zero.

- Confirm the current menu option.
- transfer he telephone conversation

from the hands-free system to the
mobile telephone and vice versa.

- Select the audio source.
- Select the text displayed.

-  Activate the main menu.
-  Confirm the current menu option.
-  Accept the incoming call.
-  Switch one telephone conversation to

another.

-  Select a visual message.
-  Reject an incoming telephone call.
-  end the current telephone call.

Description of the steering mounted controls

- Repeat the last voice message.

Bluetooth hands-free system

Bipper_en_Chap05_technologie_ed02-2014

PRESENTATION

Description of voice commands

By pressing this button and saying "Help", you have access to the list of voice commands available at any time or by saying "Help"
after a system message.

the main voice commands for navigating in the menu are the following:

You can access the main menu of the system via the voice command by pressing this button.

* If the system is activated.

** Not available on iPod

lASt CAllS

HeNRY BRIDgeS

CHRIStOPHeR ANDReW
123456789

PHONeBOOK

HeNRY BRIDgeS

CHRIStOPHeR ANDReW
123456789

MeSS. ReADeR

ReAD lASt
IN BOX

VIS+ACOuSt

Delete All

VIS. SIgNAl

SIgNAl tYPe

ReADeR OFF

MeDIA PlAYeR

uSB OPtION*

PlAY ANYtHINg

Set uSB

FOlDeRS**
ARtIStS
geNReS
AlBuMS
PlAYlIStS

tRACK PlAY
SHuFFle
tRACK lOOP

SettINgS

uSeR DAtA

COPY PHONeBOOK

PAIRINg

Delete uSeRS

ADVANCeD OPtIONS

Delete PHONeBOOK

eXIt

Delete All
ADD CONtACtS

TECHNOLOGY

on BOARD

Bluetooth hands-free system

Bipper_en_Chap05_technologie_ed02-2014

When prompted by the telephone, enter the
PIN displayed in the instrument panel.
If the pairing has been successful, the
system announces "Connecting".
the name of the telephone identified
appears in the instrument panel screen,
pairing is confirmed.

"Settings"\wait for a
response\"Pairing".

PIN

Pairing a mobile telephone

Pairing consists of setting your vehicle's
Bluetooth

system to recognise your mobile

telephone.
For this you must activate the Bluetooth

function of your telephone and set its
visibility.

MOBILE TELEPHONE WITH HANDS-FREE FUNCTION

With the ignition on, activate the
main menu.

Select SettINgS.

Confirm.

Select PAIRINg.

Confirm.

this number, which permits
recognition of your mobile
telephone, is generated
randomly by the system.

It is communicated by the instrument panel
screen and is repeated verbally by the
system.
this PIN is independent of your SIM card
and your mobile's access code.
Once your handset has been paired, there is
no need to keep a record of this number.
If you change your mobile telephone, you
must repeat the pairing procedure as you
will be given a new PIN.

look for the option which displays
the Bluetooth

system detected

by your telephone.

When the system has been
identified, a message appears in
your telephone (My car, …).

Pressing MAIN or eSC during the pairing
phase may cancel the procedure.

If the pairing fails, an error message will
appear; in this case, repeat the procedure.

Bluetooth hands-free system

Bipper_en_Chap05_technologie_ed02-2014

Downloading your phonebook

There are 2 options:
1 - Following the pairing procedure, the

system suggests downloading your
telephone's phonebook.

Calling a contact recorded in the
phonebook

Your telephone's phonebook must first be
downloaded into the system.

"Call [Name of the person]"\
wait until the information relating
to the person (name, tel. n°, ...)
appears\
"Yes" to make the call or "No"
to cancel.

Pressing confirms your agreement.

"Yes" starts the download.

Pressing declines this download.

"No" declines.

2 - You can download the phonebook later

via the menu:

Activate the main menu.

Select SettINgS then uSeR
DAtA then PHONeBOOK.

"Settings"\"user
data"\"Download phonebook".

Activate the main menu.

Select PHONeBOOK.

Confirm.

Select the group with which
the person to be contacted is
associated.

Confirm.

Select the name.

Confirm to make the call, if the
person has only one number.

If the person has more than one number:

Select the number.

Confirm to make the call.

Specify "Home" or "Work",
or "NeXt" or "PReVIOuS".
Press OK to make the call.

TECHNOLOGY

on BOARD

Bluetooth hands-free system

Bipper_en_Chap05_technologie_ed02-2014

Making a call by dialling a number

Ending a call

Incoming call

"Dial/Dial a number"\
Say the number character by
character (+, #, *), digit by
digit (0 to 9).

the system displays and
verbally repeats the number
recognised.

"Call" if the number is correct.
or
"Cancel" to cancel dialling of the
number.
"Start over" to delete and start
dialling another number.
"Repeat" to hear the number again.

If the person is recorded in
the phonebook, his name is
displayed.

Press to accept the call.

Press and hold to decline the
call.

Press to ignore the call, however,
the call is stored in the log of
incoming calls.

During a call, if a second incoming call
is received.

By means of the voice commands only

Press and hold.

Press to switch the conversation
and place the other person on
hold.

100

Bluetooth hands-free system

Bipper_en_Chap05_technologie_ed02-2014

Transferring an active call

There are 2 options:
1 - From the mobile telephone to the hands-

free system

With the ignition on, the recognition
connection between the mobile telephone
and the vehicle's audio equipment is done
automatically.
Confirm this recognition using the keypad on
the mobile telephone.
the call can then be transferred.

Placing a call on hold

Call list

this enables you to call the number of one
of the last 10 calls received, of one of the
last 10 people called or of one of the last
5 missed calls.

2 - From the hands-free system to the

mobile telephone

Press to deactivate the
microphone and place your
contact on hold.

Press again to resume the
conversation.

Activate the main menu.

Select CAll lISt.

Confirm.

Select the number to be called.

Confirm.

"Callback" for the last person who
called you, or
"Redial" for the last person you
called.
"Yes" or "No" to confirm/cancel.
the "Redial" button can also be
used.
the system will again ask "Redial or

callback?".
"Callback" to call back the last
person who called you.
"Redial" to redial the last person you
called.

Press, the system's controls are
still active.

101

TECHNOLOGY

on BOARD

Bluetooth hands-free system

Bipper_en_Chap05_technologie_ed02-2014

VOICE COMMANDS

the key words which can be recognised by the system are organised into three levels (levels 1, 2 and 3).
When you say a level 1 command, the system makes the level 2 commands available; when you say a level 2 command, the
system makes the level 3 commands available.

Settings/pairing

Level 1

Level 2

Level 3

Actions

Settings
Adjust
Configure

user data

Activation of the hands-free system SettINgS menu.

Activation of the uSeR DAtA menu.

Delete users

Deletion of the data recorded for all of the users.

Delete contacts/
Delete directory/
Delete numbers

Deletion of the phone book data.

Copy phone book/
Copy phonebook/
Copy numbers

transfer of the phone books from your mobile telephone to the
hands-free system (available according to the type of mobile
telephone).

Add Contacts

transfer of the names from your mobile telephone to the hands-free
system (available according to the type of mobile).

Delete all

Deletion of the pairing data and of the phone books/contacts of all
of the telephones paired, with restoration of the default settings of
the hands-free system.

Pairing/Pair/Pair the user

Activation of the pairing procedure for a new mobile telephone.

Advanced options

Activation of the ADVANCeD OPtIONS menu.

102

Bluetooth hands-free system

Bipper_en_Chap05_technologie_ed02-2014

VOICE COMMANDS

Mobile telephone with hands-free function

Level 1

Level 2

Level 3

Actions

Dial/Dial a number

One, two, ..., Plus,
Star, Hash

Call/Dial

entering the digits or symbols to dial the telephone number.

Delete/Correct

Deletion of the last group of digits entered.

Start over

Deletion of all of the groups of digits entered with the option of
entering a new number.

Repeat

Repeating the telephone number entered and recognised by the
hands-free system.

Cancel

Cancellation of dialling of the number.

Sending the call to the number entered verbally.

Call

[ Name ]

Yes/No

Call to the name of the person, stored in the system's phone book.

Mobile

Call to the name of the person with personalisation if there are
several numbers stored in the system.

Home

Work/Office

Redial

Call to the last person called.

Callback

Call to the last person who called.

103

TECHNOLOGY

on BOARD

Bluetooth hands-free system

Bipper_en_Chap05_technologie_ed02-2014

If your mobile telephone includes this
function, every time a text message is
received, the system produces an audible
signal and offers to read the text message
vocally.

to read the text received.

"Yes" starts the playback of the text
received.

Only on mobile telephones with this
function

to save a message and read it
later.

"No" to save the message and read
it later.

TEXT READER

Read an incoming text message

Read the last text received

Activate the main menu.

Select MeSS. ReADeR.

Confirm.

Select ReAD lASt.

Confirm.

"Read last" starts playback of
the last text message received.

List of text messages

the system can hold around 20 text
messages. If the list is full, reception of a
new text message causes the deletion of the
oldest text message.

to go to a specific text message:

Activate the main menu.

Select MeSS. ReADeR.

Confirm.

Select IN BOX.

Confirm.

104

Bluetooth hands-free system

Bipper_en_Chap05_technologie_ed02-2014

Select the desired text message.

"Message reader" then after the
audible signal "message received".

"Previous" or "Next" moves through
the list of text messages.
"Read" starts reading of the text
message selected.

Confirm to read the text message.

Managing text messages

"Read" starts reading of the message.
"erase" deletes the message.
"Call" allows you to contact the
sender of the message.

Deleting all text messages

Activate the main menu.

Select Delete All.

Confirm.

the system asks you to confirm your choice:

Confirm to delete.

to cancel.

"Message reader" then after the
audible signal "Delete all".

the system requests confirmation,
reply with: "Yes" to confirm or "No"
to cancel.

"Message reader" then after the
audible signal "Signal type".
the system lists the options, select

between: "Reader deactivated", "Audio
and visual info" or "Visual info only".

Information settings

Activate the main menu.

Choose the desired option.

During reading of the message:

Activate the main menu.

Select MeSS. ReADeR.

Confirm.

Select SIgNAl tYPe.

Confirm to select from the
3 choices available:

- Audio + visual: the system signals the

receipt of a message audibly and visibly
and offers to read it.

- Visual only: reception of a message is

signalled visibly in the instrument panel.

- Off: the text message reader is

deactivated.

105

TECHNOLOGY

on BOARD

Bluetooth hands-free system

Bipper_en_Chap05_technologie_ed02-2014

VOICE COMMANDS
Message reader

Level 1

Level 2

Level 3

Actions

Message reader
Messages

Messages received /
Received

Activation of the MeSS. ReADeR menu.

Activation of the list of text messages received.

Read/ read again

Reads the text message selected in the list.

CAll

Deletion of the phone book data.

Delete

transfer of the phone books from your mobile telephone to the
hands-free system (available according to the type of mobile).

Back / Next / NeXt

go to the next text message in the list

Back / PReVIOuS

go to the previous test message in the list.

Read last / read last message / read message

Read the last text message received.

Delete all / Delete messages / Delete

Delete all text messages in the list after confirmation.

106

Bluetooth hands-free system

Bipper_en_Chap05_technologie_ed02-2014

Level 1

Level 2

Level 3

Actions

Read messages /
Messages

type of info / Info

Activation of the MeSS. ReADeR menu.

Deactivation of the info settings function.

Deactivate reader /
Reader not active /
Reader off

Deactivates the reading of text messages.

Visual and audible
info / Visual and
audible / Visual plus
audible / Audible

Reception of a text message is signalled in the instrument panel
screen and by an audible signal.

Visual info only /
Only visual / Visual

Reception of a text message is signalled only in the instrument
panel screen.

107

TECHNOLOGY

on BOARD

Bluetooth hands-free system

Bipper_en_Chap05_technologie_ed02-2014

Audio tracks in .mp3, .wma, .wav format
and playlists with the extension .wpl are
recognised by the system.

Selecting tracks

PORTABLE AUDIO DEVICE PLAYER

Autoplay

USB port

Connect the device to the
uSB port directly or using an
appropriate cable (not provided).

Ignition on:
- activates the recognition connection and

automatically starts the playlist,

- or activates automatic play if the system

is programmed to autoplay.

Otherwise, select the track to be
played via the menu.

Activate the main menu.

Select SettINgS then MeDIA
PlAYeR then tRACK PlAY.

Confirm.

Select ReADeR or ReADeR
OFF.

Confirm.

Activate the main menu.

Select MeDIA PlAYeR.

Confirm.

Choose one of the selection
modes:
FOlDeRS, ARtIStS, geNReS,

AlBuMS, PlAYlIStS, SHuFFle
(random play of tracks in the
playlist).

"Media player", then "uSB
options" and finally choose
"Folders", "Artists", ...

the PLAY ALL function enables you
to listen to the entire content of a

selection mode (folders, artists, ...).

108

Bluetooth hands-free system

Bipper_en_Chap05_technologie_ed02-2014

Displaying the file information

Previous track

Confirm.

Pausing/resuming play

Next file

Changing the sound source

Select the file.

Start play.

this function is only available by voice
command.

Pressing:

- within 3 seconds following the start of

play enables you to play the previous
track.

- after 3 seconds enables you to listen to

the current track again.

"Previous".

Press to play the next file.

"Next".

"Stop" to interrupt playback. "Play"
to continue playback.

Press to select the audio source
(Radio, CD, Media player).

Pressing suspends or resumes
play.

"track info".

the voice function "Play" is only
available if playback has been
previously interrupted by the "Stop"
command.

109

TECHNOLOGY

on BOARD

Bluetooth hands-free system

Bipper_en_Chap05_technologie_ed02-2014

VOICE COMMANDS
Portable audio device

Level 1

Actions

Player/Multimedia player/Media player

Activation of the MeDIA PlAYeR menu.

Play/Play the track/Play the multimedia file

Activation of play.

Stop/Stop the track/Stop the multimedia file

Interruption of playing of the current file.

Next/Next track

go to the next menu or file.

Previous/Previous track/Back

go to the previous menu or file.

Shuffle on/Random play on

Activation of playing of the files in random order.

Shuffle off/Random play off

Deactivation of playing of the files in random order.

track repeat on/Repeat on/Repeat

Activation of playing of the files in a loop.

track repeat off/Repeat off

Deactivation of playing of the files in a loop.

Now playing/track information/What is playing/What is this?

Display of the information for the file currently being played.

uSB media settings/uSB settings

Activation of the MeDIA PlAYeR menu.

Activate automatic play

Activation of automatic play on connection of a portable device.

Deactivate automatic play

Deactivation of automatic play on connection of a portable device.

Shuffle/Any/Random

Activation of play of all tracks in random order

Bluetooth hands-free system

Bipper_en_Chap05_technologie_ed02-2014

Level 1

Level 2

Level 3

Actions

Player/Multimedia
player/Media player /
Player

Activation of the MeDIA PlAYeR menu.

Advanced uSB options/Other options

Activation of playback options.

Folder/explore
folders/Consult list of
folders

Activation of FOlDeRS menu.

Artists/list of artists

Activation of ARtIStS menu.

genres/list of
genres

Activation of geNReS menu.

Album/list of albums

Activation of AlBuMS menu.

Playlist/list of tracks

Activation of PlAYlIStS menu.

Peugeot Bipper (2015 year). Instruction - part 7
